H&S S1125 Manual de usuario

S1125

SPREADER

Part#72936

HSMFG0318

Revision#01

StartingSer.#711909

PARTS BOOK

2608 S. HUME AVE. , MARSHFIELD, WI 54449

(715) 387-3414 FAX (715) 384-5463

www.hsmfgco.com

CONTENTS

Instructions for Ordering Parts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

Figure 1 - Main Frame and Component Parts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-5

Figure 2 - Optional Rear Pan. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

Parts Notes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

-1-

INSTRUCTIONS FOR ORDERING PARTS

PLEASERECORDNUMBERSFORYOURUNITFORQUICKREFERENCE

ABOUT IMPROVEMENTS

H&S ISCONTINUALLYSTRIVINGTOIMPROVEIT’SPRODUCTS

We must therefore, reserve the right to make improvements or changes whenever it becomes practical

to do so without incurring any obligation to make changes or additions to the equipment previously sold.

All service parts should be ordered through your authorized H&S dealer. They will be able to

giveyoufaster service if you will provide themwiththefollowing

1. Model & Serial number is located on the rightsideframebehindthe transport wheel.

2. Allreferencetoleftorrightapplytothemachineasviewed from the rear.

3. Partsshouldnotbeorderedfromillustrationonly.Pleaseorderbycompletepartnumber.

4. Ifyourdealerhastoorderparts-giveshippinginstructions:

VIAtruck-largepieces(pleasespecify local truck lines)

VIAUnitedParcel Service (include full address)

-2-

FIGURE 1

MAIN FRAME AND COMPONENT PARTS

-3-

FIGURE 1

MAIN FRAME AND COMPONENT PARTS

ITEM

PART #

25G18

25G19

25G20

25G17

25G6

X61

25G38

4C4

X28

25G51

L4C4

25G13

25G12

25G9

25G29

LI0R24

25G7

5N51

5N26

25G10

25G66

25G67

23N94

25G4

25G30

25G40

BFR273

BFR274

BFR275

25G42

CAT14

YNSL24010

CAT46

YWFL24010

YPCT05015

YBSD16018

RG21

78852

BFR280A

25G43

25G5

25G3

25G22

K101

25G31

DESCRIPTION

LH SPREADER SIDE

RH SPREADER SIDE

BEATER DRIVE SHIELD

RATCHET SHIELD

BEATER

#50 CONNECTOR LINK

#50CHAIN 147 PITCH

13T SPROCKET

SPACER

BEARING

COLLAR

HOLDING DOG W/ 90 DEGREE ZERK

DOG PLATE

BACK BRACKET

APRONSHAFT

APRON CHAIN SPROCKET

CAM

DRIVE DOG W/ 45 DEGREE ZERK

DOGPIN

RATCHETGEAR

CAM ROLLER

CAM ROLLER COMPLETE

SPACER

HUB

SPINDLE

HUB-ROAD WHEELS

SEAL

BEARING

RACE

STUD BOLT

STUDNUT

HEX NUT, SLOTTED, 3/4-16, PLAIN

HUBCAP

WASHER, FLAT, SAE 3/4, PLAIN

COTTER PIN, 5/32" X 1-1/4"

STUD BOLT

GREASE ZERK

HUB ASSEMBLY INCLUDES (BFR275)(YBSD16018)(RG21)

WHEEL

TIRE 6 X 12C

RIGHTHUB

UNDERAXLE

CHAINWASHER

SPROCKET

PIVOTBUSHING

NOTE: * MEANS NOT SHOWN

FIGURE 1

MAIN FRAME AND COMPONENT PARTS

-4-

FIGURE 1

MAIN FRAME AND COMPONENT PARTS

ITEM

DESCRIPTION

ENGAGEMENTARM

PULLEYMOUNT

SPACER

POLYPULLEY

FRONTPANEL

FLOOR

SPACER

FRONTSHAFT

CONTROL HANDLE

SHIFTER DOG

SPACER

RIGHT CONTROL BAR

RIGHTCHAINTIGHTENER

BOLT, HEX, FT, 3/8-16 X 9, G2, ZC

FRONT END

SHIELDANGLE

LANYARD,CLIPPIN CABLE

LEFTCHAIN TIGHTENER

FRONT POLYSHIELD

POLE

LEFT CONTROL BAR

COMPLETEAPRON CHAIN

APRON SLAT

CONNECTOR LINK

ATTACHMENTLINK RH

ATTACHMENTLINK LH

1/4" X 1" WOODRUFF KEY

SPRING-DOG FRONT

SPRING-ROPE RETURN

SPRING-DOG FRONT

SPRING

CABLE 47"

CABLE62"

RADIALBEARING ONLY

BEARING SPACER

FRONTAPRON CHAIN SPROCKET

CHAINGUIDE

SNAPRING

FRONT FLOOR PROTECTOR

REAR FLOOR PROTECTOR

MANUALHOLDER

NUT, PANEL CAGE, 3/8-16

CLAMP, 3/16 CABLE

THIMBLE

PART#

25G8

25G21

ST81

BFR292

25G16

25G36

K132

25G28

25G11

23N282

ST77

S70

25G14

25G24

YBHH12250

25G2

R26

S122

25G23

25G34

25G1

25G15

25G46

25G47

25G48

25G49

25G50

5B10

23N186

K103

23N284

12R3

25G41

25G44

25G45

12V52

25G-TU-13

L10R20

25G53

25G68

25G65

25G64

S522

YNPC12005

BFR220

ES14

NOTE: * MEANS NOT SHOWN

-5-

OPTIONAL REAR PAN

FIGURE 3

-6-

ITEM

PART #

25G59

25G61

25G56

25G60

25G57

25G58

R26

R27

25G62

YPCT06020

R31

YBTE08005

DESCRIPTION

PANANGLE

PAN RUBBER

PAN

LHPANPLATE

RHPAN PLATE

PANHANDLE

SPINGANGLE

PANHANDLE SPRING

TRIP ROPE

PAN SPACER

COTTER PIN, 3/16" X 2"

S HOOK

TURNED EYE BOLT, 1/4" X 1" FULLTHREAD

-7-

PARTS NOTES

H&S Manufacturing products are approved for the

FEMA SEAL OF QUALITY

P.O. BOX 768, MARSHFIELD, WI 54449

(715) 387-3414 FAX (715) 384-5463

www.hsmfgco.com
