Hamilton Bahl AudioAce Manual de usuario
Never-Ending Learning Innovation
Portable Bluetooth®CD Player with
Cassette Recorder and FM Radio
80 Little Falls Road, Fairfield, NJ 07004 • 1-800-631-0868 • www.HamiltonBuhl.com
AudioAce™
AudioAce
™
AudioAce™
One color when
needed
Color Option 1
Color Option 2
AudioAce™
AudioAce™AudioAce
Instruction Manual
2
AudioAce™Portable Bluetooth®CD Player
Contents
Warnings and Precautions ...............................................................................3
Important Safety and Instructions ....................................................................5
Warnings ..........................................................................................................6
Technical Specications ...................................................................................7
In the Box .........................................................................................................7
Feature Controls ..............................................................................................8
Getting Started / Main Operation....................................................................10
DC Batteries / AC Power Operation ...............................................................10
Listening to Radio .......................................................................................... 11
Listening to CD ..............................................................................................12
Using Bluetooth®............................................................................................13
Using AUX-In..................................................................................................14
Listening to a Cassette ..................................................................................14
Warranty ........................................................................................................16
3
AudioAce™Portable Bluetooth®CD Player
Warnings and Precautions
Caution:
• TO PREVENT ELECTRIC SHOCK, FULLY INSERT THE PLUG INTO THE
OUTLET, ENSURING THE WIDE PRONG IS IN THE CORRECT SLOT.
• Use of any controls or adjustments or performance of procedures other
than those herein specified may result in hazardous radiation exposure.
• There is a danger of explosion if batteries are placed incorrectly.
Warning:
• To reduce the risk of fire or electric shock, do not expose this apparatus to
rain or moisture.
• Changes or modifications to this unit not expressly approved by the party
responsible for compliance could void the user’s authority to operate the
equipment.
• Do not place the unit on top of any soft, porous, or sensitive surfaces to
avoid damaging the surface. Use a protective barrier between the unit and
surface to protect the surface.
• Use of this unit near fluorescent lighting may cause interference.
• There is a danger of explosion if you attempt to charge standard alkaline
batteries in the unit. Only use rechargeable NiMH batteries.
• Shock Hazard - Do Not Open.
• Mains plug is used as disconnect device and it should remain readily
operable during intended use. In order to disconnect the apparatus from
the main completely, the mains plug should be disconnected form the
mains socket outlet completely.
• Do not mix old and new batteries. Do not mix alkaline, standard
(carbon-zinc), or rechargeable (Ni-Cad, Ni-Mh, etc.) batteries.
4
AudioAce™Portable Bluetooth®CD Player
CAUTION
RISK OF ELECTRICAL SHOCK
DO NOT OPEN
WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT
REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE.
THIS UNIT MUST BE SERVICED BY QUALIFIED SERVICE PERSONNEL.
The lighting flash with arrowhead symbol, within an equilateral triangle,
is intended to alert the user to the presence of uninsulated “dangerous
voltage” within the product’s enclosure that may be of sufficient magnitude
to constitute a risk of electric shock.
The exclamation point within an equilateral triangle is intended to alert the
user to the presence of important operating and maintenance (servicing)
instructions in the literature accompanying the appliance.
This product utilizes a Class 1 laser to read compact discs. The laser
Compact Disc Player is equipped with safety switches to avoid exposure
when the CD door is open and the safety interlocks are defeated.
Invisible laser radiation is present when the CD Player’s lid is open and
the system’s interlock has failed or been defeated. It is very important that
you avoid direct exposure to the laser beam at all times. Please do not
attempt to defeat or bypass the safety switches.
5
AudioAce™Portable Bluetooth®CD Player
Important Safety Instructions
1. Please read, follow and keep these instructions and comply with all
recommended cautions.
2. Do not use this unit near water.
3. Clean with a dry cloth only.
4. Do not block ventilation openings.
5. Do not place the unit near any heat sources such as radiators,
heat registers, stoves, or other apparatus (including amplifiers)
that produce heat.
6. Follow safety precautions and use a polarized or grounded-type plug.
A polarized plug has two blades with one prong wider than the other.
A grounded-type plug has two prongs and a third grounding prong.
The wide blade or the third prongs are provided for your safety.
If the provided plug does not fit your outlet, consult an electrician for
replacement of the obsolete outlet.
7. Protect the power cord from being walked on or pinched, particularly
at plugs, or where they exit the unit.
8. Only use attachments and accessories specified by the manufacturer.
9. Unplug the unit during lightning storms or when unused for long periods
of time.
10.Refer all service needs to qualified service personnel. Servicing is
required if the unit has been damaged in any way, such as power
cord (or plug damage), if liquid has been spilled or objects have
fallen into the unit, if exposed to rain or moisture, or if dropped and
not working properly.
Note: When placing your unit on a lacquered or natural finish, protect your
furniture with a cloth or other protective material.
6
AudioAce™Portable Bluetooth®CD Player
FCC Warnings
NOTE: This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses,
and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will
not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
• Consult the dealer or an experienced radio / TV technician for help.
Additional Warnings
• The apparatus shall not be exposed to dripping or splashing and that no
objects filled with liquids, such as vases, shall be placed on apparatus.
• Main plug is used as disconnect device and it should remain readily
operable during intended use. In order to disconnect the apparatus from
the mains completely, the mains plug should be disconnected form the
mains socket outlet completely.
• Battery shall not be exposed to excessive heat such as sunshine,
fire or the like.
• Caution marking is located at the rear or back of the apparatus.
• The marking information is located at the rear or back of apparatus.
This symbol indicates that this product incorporates double insulation
between hazardous mains voltage and user accessible parts.
7
AudioAce™Portable Bluetooth®CD Player
Technical Specications
• Mode: MPC5050BT - MPC5050
• Bluetooth®2.1
• Adapter AC Input: AC100-240V~50/60Hz
• Adapter DC Output: DC 6V 1.2A
• Batteries Power: DC 12V (8x1.5V) “C” size UM-2/LR14 Batteries
• Output Power: 2 x 2 Watts
• Speaker: 76mm (3”) Cone Type
• AUX-In: 3.5mm Jack
• Headphone: 3.5mm x 6
• Dimensions: 13.39” L x 10.24” D x 5.31” H
• Weight: 5.07 lbs.
• Operation Temperature: +41°F - +95°F
• General Frequency: FM 88 - 108 MHz
• CD Optical Pick-Up Lens: 3 Bean Semiconductor Laser
In the Box
• AudioAce™
• Power Supply
• Instruction Manual
8
AudioAce™Portable Bluetooth®CD Player
Feature Controls
20
1919
4
3
2
1
12
10
9
8
7
11
13
14 15 16 17 18
6
5
21
22
23
9
AudioAce™Portable Bluetooth®CD Player
Feature Controls
1. AUX-In Jack (Line in)
2. Power Button
3. Tune+ or /Tune- Button
4. Play/Pause/Pair Button
5. Stop/M+ (Memory Up) Button
6. X-BASS Button
7. FM Antenna Rod
8. Carrying Handle
9. Repeat Button
10. MEM/PROG Button
11. Source Button
12. Volume Buttons
13. CD Open Button
14. Cassette Pause Button
15. Cassette Stop/Eject Button
16. Cassette F.FWD/REW Button
17. Cassette Play Button
18. Cassette Rec Button
19. Speakers
20. LCD Display
21. 6x Headphone Jacks
22. DC in (DC-6v)
23. Battery Compartment (“C” Battery x8)
10
AudioAce™Portable Bluetooth®CD Player
Getting Started / Main Operation
Power On the Unit:
Press the Power button to turn the unit on or off.
Adjusting the Volume:
Press the Volume buttons to increase or decrease the volume level.
Adjusting the Antenna Rod:
The antenna should be extended to ensure good reception. It may be
necessary to alter the position of the unit and/or antenna to achieve the
best signal.
Using Headphones:
This unit can support up to 6 headphones connected together. The
headphone sockets are located on the side of the unit. The headphones
must be compatible with a 3.5mm diameter plug.
X-BASS (Bass Boost):
Press the X-BASS button to turn on or off X-BASS function.
DC Batteries / AC Power Operation
Battery Operation:
Before installing batteries, ensure that the unit is disconnected from the
main AC power supply. Remove the battery compartment cover on the
bottom of the unit.
This unit utilizes (8) 1.5V C-size batteries (not included). Be careful to
insert the batteries according to the correct polarity +/-. Never mix old and
new batteries. Re-attach the cover. For battery operation, disconnect the
main AC power supply and remove the cable from the power socket.
Battery operation will be selected automatically.
Install Batteries
