Haier HWF75AW3 Manual de usuario

HWF75AW3

NZ AU

Thank You NZ AU

Legend

Warning – Important Safety information

General information and tips

Environmental information

Disposal

Thank you for purchasing a Haier Product.

Keep this manual in a convenient place so you can always refer to it for the safe and proper

use of the appliance.

If you sell the appliance, give it away, or leave it behind when you move house, make sure

you also pass this manual so that the new owner can become familiar with the appliance

and safety warnings.

WARNING!

of it. Remove the door catch to prevent children and pets to get closed in the appliance.

Please read these instructions carefully before using this appliance. The instructions

contain important information which will help you get the best out of the appliance and

ensure safe and proper installation, use and maintenance.

Help protect the environment and human health. Put

the packaging in applicable containers to recycle it.

Help to recycle waste of electrical and electronic

appliances.Donot dispose appliances marked with this

symbol with the household waste. Return the product

to your local recycling facility or contact your municipal

NZ AU Content

1-Safety information........................................................................................................................... 4

2-Product description......................................................................................................................... 7

3-Control panel .................................................................................................................................... 8

5-Consumption..................................................................................................................................12

4-Programmes ..................................................................................................................................11

6-Daily use ...........................................................................................................................................19

7-Eco-friendly washing ....................................................................................................................18

8-Care and cleaning ..........................................................................................................................19

9-Troubleshooting .............................................................................................................................22

10-Installation.....................................................................................................................................25

11-Technical data...............................................................................................................................29

12-Customer service........................................................................................................................30

1-Safety information NZ AU

Bef -

ing safety hints!

WARNING!

Make sure there is no transport damage.

Make sure all transport bolts are removed.

Remove all packaging and keep out of children´s reach.

Handle the appliance always with at least two persons because it

is heavy.

Daily use

▶

Children shall not play with the appliance.

Do not let children or pets come close to the appliance when the

door is open.

Store washing agents out of reach of children.

prevent laundry from being entangled. If necessary, use an

bag or net.

Do not touch or use the appliance when barefoot or with wet or

damp hands or feet.

Do not cover or encase the appliance during operation or

to allow any moisture or dampness to evaporate.

Do not place heavy objects or sources of heat or damp on top of

the appliance.

Do not use or store detergent or dry cleaning agent in

close vicinity to the appliance.

Do not use any sprays in close vicinity to the appliance.

Do not wash any garments treated with solvents in the appliance

without having dried them previously in the air.

appropriate

afterwards

This appliance is not intended for use by persons (including child-

ren) with reduced physical,sensory or mental capabilities, or lack

of experience and knowledge, unless they have been given super-

vision or instruction concerning use of the appliance by a person

responsible for their safety.

Children should be supervised to ensure that they do not play with

the appliance.

NZ AU 1-Safety information

WARNING!

Daily use

▶Do not remove or insert the plug in the presence of ﬂammable

gas.

▶Do not hot wash foam rubber or sponge-like materials.

▶Do not wash any laundry which is polluted with ﬂour.

▶Do not open detergent drawer during any wash cycle.

▶Do not touch the door during the washing process, it gets hot.

▶Do not open the door if the water level is visibleover the porthole.

▶Do not force the door to open. The door is tted with a self-lock

device and will open shortly after the washing procedure is ended.

▶

undertaking any routine maintenance and disconnect the appli-

ance from the electrical supply to save electricity and for safety.

▶Hold the plug, not the cable, when unplugging the appliance.

Maintenance / cleaning

▶Make sure children are supervised if they carry out cleaning and

maintenance.

▶Disconnect the appliance from the electrical supply before

undertaking any routine maintenance.

▶Keep the lower part of the porthole clean and open door and

detergent drawer if appliance is not in use to prevent odours.

▶Do not use water spray or steam to clean the appliance.

▶

▶Do not try to repair the appliance by yourself. In case of repair

please contact our customer service.

Installation

▶The appliance should be placed in a well-ventilated place. Ensure

a location which allows opening the door fully.

▶Never install the appliance outdoors in a damp place, or in an area

which may be prone to water leaks such as under or near a sink

unit. In the event of a water leak cut power supply and allow the

machine to dry naturally.

Replace a damaged supply cord only by the manufacturer, its

ser

hazard.

1-Safety information NZ AU

Intended use

This appliance is intended for washing machine-washable laundry

only. Anytime follow the instructions given on the label of each

garment label. It is designed exclusively for domestic use inside the

house. It is not intended for commercial or industrial use.

use may cause hazards and loss of all warranty and liability claims.

WARNING!

Installation

▶Install or use the appliance only where the temperature is above

5 °C.

▶Do not place the appliance directly on a carpet, or close to a wall

or furniture.

▶Do not install the appliance in direct sunlight or in the near of heat

sources(e.g. stoves, heaters).

▶Make sure that the electrical information on the rating plate

agrees with the power suppl y. If

does

not, contact an

electrician.

▶Do not use multi-plug adapters and extension cables.

▶Make sure only the delivered electric cable and hose set are used.

▶Make sure not to damage the electric cable and the plug. If

damaged have it replaced by an electrician.

▶Use a separate earthed socket for the power supply which is easy

accessible after installation. The appliance must be earthed.

▶

no leakage.

▶The new hose-sets supplied with the appliance are to be used

and that old hose-sets should not be reused.

The manual are suitable for 7.5kg washing machines.

The applicable water pressure of the washing machine is 0.03MPa

to 1MPa.

▶

NZ AU 2-Product description

2.1 Picture of appliance

Front (Fig. 2-1): Rear side (Fig. 2-2):

2.2 Accessories

Check the accessories and literature in accordance with this list (Fig.2-3):

Note:

2-3

1 Detergent /

Softener drawer

2 Work top

2 Programme selector

3 Panel

4 Washer door

5 Service ﬂap

6 Adjustable feet

2-1 2-2

Inlet hose-

assembly 5 Blanking

plugs

Drain hose

bracket User manual

Warranty

card

Noise reduc-

tion pads

136 7

13 4 5

1 Transportation bolts

3 Back cover

4 Back cover screws

5 Power cord

6 W

Drain hose

ater inlet valve

T1 T2

T3 S1

S3 S5

NZ AU

3-2 3.1 Programme selector

By turning the knob (Fig. 3-1) one of 15 programmes

can be selected.

3-3 3.2 Display

The display (Fig. 3-3) shows following information

Temp.: Touch to select washing temperature.

Spin Speed: T ouch to select diﬀerent speeds.

Soak: Touch to select soak function.

Eco:

Delay: Touch to select to delay the start time

of the cycle.

Error codes and service information.

Function buttons and “Start/Pausse” button.

Remaining completion time.

Touch to select energy saving mode.

3.3 Detergent drawer

Open dispenser drawer, the following components can

be seen (Fig. 3-4):

1: compartment for powder or liquid detergent.

MAX

3-4

3-1

Rinse & Spin

Refresh

Express 15

Towels

Wool

Spin Speed Soak Eco Delay

Temp.

Cotton

Synthetics

Delicate

Shirts

Bedding

Hygiene

Bulky

Durable

Spin

Drum Clean

2: compartment for laundry aid products such as

powder stain removers and soaking agents.

Note: Factory settings

there is no special requirement default settings are recommended.

NE AU

3: compartment for softener.

4: lock tab, press it down to pull out dispenser drawer.

The recommendation on the type of detergents is

suitable for the various washing temperatures, please

refer to the manual of detergent (see P11).

3.4 Function buttons

The function buttons (Fig. 3-5) enable additional options

in the selected programme before programme starts. The

related indicators are displayed.

By switching oﬀ the appliance or setting a new programme,

all options are disabled.

If a button has multiple options, the desired option can be

selected by pressing the button sequentially.

3-5

3.4.1 3.4.2 3.4.3 3.4.4 3.4.5

3-6

Touch this button (Fig. 3-6) to change the washing temperature

of the programme. If no value is selected (the display “--℃”)

the water will not be heated.

3.4.1 Function button “Temp.”

3.4.2 Function button “Spin Speed” 3-7

3-8

3.4.3 Function button “Soak”

Touch this button (Figure 3-8), select the depth soaking time,

panel displays , and some programs ”Soak“ are not optional.

Touch this button (Fig. 3-7) to change the spin speed of the

programme. If ” “ is selected,the laundry will not spin.

3.4.4 Function button “Eco”

3-9

Touch the button (Fig. 3-9) to use the Eco option to save water

and energy, panel displays , and some programs ”Eco“ are not

optional.

3-Control panel NZ AU

Speed

Touch this button (Fig. 3-10) to increase the delay

time in a regular pattern of 0:15, 0:30, 1:00, 2:00, 3:00...

(the maximum range is12h).

The delay time is the washing start time.

3-10

3.4.5 Function button “Delay”

3-11

3.5 ”Start/Pause” button

Touch the button (Fig. 3-11) gently to start or pause

the currently displayed programme.

3-12

3.6 Key lock

Press and hold “Temp.” and “Spin Speed” combination

keys for three seconds, the Key lock icon (Fig. 3-12)

lights up. All buttons on control panel excepting the

Power buttons are disabled. Repeat the operation to

release the lock.

The display shows (Fig.3-13) if a button is

pressed, if a button is pressed while the key lock

is activated.

3.7 Favourite

Choose a program and the desirable modiﬁers, before

starting the loop. Press “Spin Speed” and “Soak” (Fig. 3-14)

for 3 seconds simultaneously to save personalised o-

ptions for available programme, panel displays . For

restoring the default parameters for all programmes

please select Express 15 programme and then touch

button “Soak”,”Delay” for 3 seconds simultaneausly, the

display shows (Fig. 3-15).

3-13

3-14

3-15

3-16

3.8 Add clothes halfway

Press the "Soak" and "Eco" buttons at (Fig. 3-16) the same

time, the washing machine will stop running (if the water

level is high, it will automatically drain to a safe height and

the door lock will open).At this time, open the door to add

clothes, and press the "Start/Pause" button to continue

running.

Tabla de contenidos

Otros manuales de Arandela de Haier

Haier

Haier JW-G42A Manual de usuario

Haier

Haier HWD1000 - 1.7 cu. Ft. Washer/Dryer Combo Manual de usuario

Haier

Haier HWM62-0566 Manual de usuario

Haier

Haier JW-G50B Manual de usuario

Haier

Haier HW-B1460 Guía de inicio rápido

Haier

Haier XPB60-CS Manual de usuario

Haier

Haier GWT460BW Manual de usuario

Haier

Haier HL1400TXV Manual de usuario

Haier

Haier HW-D1270TVE ME Manual de usuario

Haier

Haier HWM160-B1678S Manual de usuario

Haier

Haier HWM50-0701 Manual de usuario

Haier

Haier HWM140-1826T Manual de usuario

Haier

Haier JW-W30C Manual de usuario

Haier

Haier HNY500TX Manual de usuario

Haier

Haier HWM60-111S Manual de usuario

Haier

Haier HW85-B1486NZP Manual de usuario

Haier

Haier WMS656 Manual de usuario

Haier

Haier HW80-B14979 Manual de usuario

Haier

Haier HWM80-9288DD Manual de usuario

Haier

Haier HW90-BP14636 Manual de usuario

Haier

Haier HN500TX Manual de usuario

Haier

Haier AWT-100LI Manual de usuario

Haier

Haier XQG60-HA800TX(M), XQG60-HA1000 Guía del usuario

Haier

Haier HW90-SB1230N Manual de usuario

Manuales populares de Arandela de otras marcas

Tricity Bendix

Tricity Bendix AW 1000 W Guía del producto

Panasonic

Panasonic NA-F60L5WRB Manual de usuario

GE WSLP1500 Manual

Electrolux

Electrolux EWF1284EDW Manual de usuario

Bosch

Bosch WAN2829BSN Manual de usuario

LG TV2516DV3B Manual de usuario

LG TH2517DSAV Manual de usuario

VESTEL

VESTEL CMH-XL 7510 TE Manual de usuario

AEG

AEG 74335 Manual de operación

Johnson

Johnson JWF721A Manual de usuario

Beko

Beko WTE7604XLW0 Manual de usuario

Danby

Danby DTT100A1WDB Instrucciones de montaje

Amica

Amica WA 14 Ex Manual de usuario

Daewoo

Daewoo DWD-F1222 Manual de usuario

Bosch

Bosch WAS28461AU Manual de usuario

Miele

Miele PW 6080 Vario Manual de usuario

Finlux

Finlux FLX108CF220 Manual de usuario

Whirlpool

Whirlpool 3LBR5132AN0 Manual de usuario
