Haier HW80-B14959U1 Manual de usuario

HW80-B14959U1

HW90-B14959U1

HW100-B14959U1

HW80-B14959S8U1

HW90-B14959S8U1

HW100-B14959S8U1

Thank You EN

Legend

Warning – Important Safety information

General information and tips

Environmental information

Disposal

Help protect the environment and human health. Put

the packaging in applicable containers to recycle it.

Help to recycle waste of electrical and electronic ap-

pliances. Do not dispose appliances marked with this

symbol with the household waste. Return the product

to your local recycling facility or contact your municipal

Thank you for purchasing a Haier Product.

Please read these instructions carefully before using this appliance. The instructions con-

tain important information which will help you get the best out of the appliance and ensure

safe and proper installation, use and maintenance.

Keep this manual in a convenient place so you can always refer to it for the safe and proper

use of the appliance.

If you sell the appliance, give it away, or leave it behind when you move house, make sure

you also pass this manual so that the new owner can become familiar with the appliance

and safety warnings.

WARNING!

of it. Remove the door catch to prevent children and pets to get closed in the appliance.

EN Content

1-Safety information........................................................................................................................... 4

2-Product description......................................................................................................................... 7

3-Control panel .................................................................................................................................... 8

4-Programmes...................................................................................................................................12

5-Consumption..................................................................................................................................13

6-Daily use...........................................................................................................................................14

7-hOn....................................................................................................................................................19

8-Eco-friendly washing ....................................................................................................................22

9-Care and cleaning ..........................................................................................................................23

10-Troubleshooting ..........................................................................................................................26

11-Installation.....................................................................................................................................29

12-Technical data...............................................................................................................................33

13-Customer service........................................................................................................................34

1-Safety information EN

Before switching on the appliance for the rst time read the follow-

ing safety hints!

WARNING!

Before rst use

▶Make sure there is no transport damage.

▶Make sure all transport bolts are removed.

▶Remove all packaging and keep out of children´s reach.

▶Handle the appliance always with at least two persons because it

is heavy.

Daily use

▶This appliance can be used by children aged from 8 years and

above and persons with reduced physical, sensory or mental ca-

pabilities or lack of experience and knowledge if they have been

given supervision or instruction concerning use of the appliance

in a safe way and understand the hazards involved.

▶Keep away children under 3 years of age from the appliance un-

less they are constantly supervised.

▶Children shall not play with the appliance.

▶Do not let children or pets come close to the appliance when the

door is open.

▶Store washing agents out of reach of children.

▶Pull up zips, x loose threads and take care for small items to pre-

vent laundry from being entangled. If necessary, use an appropri-

ate bag or net.

▶Do not touch or use the appliance when barefoot or with wet or

damp hands or feet.

▶Do not cover or encase the appliance during operation or after-

wards to allow any moisture or dampness to evaporate.

▶Do not place heavy objects or sources of heat or damp on top of

the appliance.

▶Do not use or store ﬂammable detergent or dry cleaning agent in

close vicinity to the appliance.

▶Do not use any ﬂammable sprays in close vicinity to the appliance.

▶Do not wash any garments treated with solvents in the appliance

without having dried them previously in the air.

EN 1-Safety information

WARNING!

Daily use

▶Do not remove or insert the plug in the presence of ﬂammable

gas.

▶Do not hot wash foam rubber or sponge-like materials.

▶Do not wash any laundry which is polluted with ﬂour.

▶Do not open detergent drawer during any wash cycle.

▶Do not touch the door during the washing process, it gets hot.

▶Do not open the door if the water level is visibly over the porthole.

▶Do not force the door to open. The door is tted with a self-lock

device and will open shortly after the washingprocedure is ended.

▶

undertaking any routine maintenance and disconnect the appli-

ance from the electrical supply to save electricity and for safety.

▶Hold the plug, not the cable, when unplugging the appliance.

Maintenance / cleaning

▶Make sure children are supervised if they carry out cleaning and

maintenance.

▶Disconnect the appliance from the electrical supply before un-

dertaking any routine maintenance.

▶Keep the lower part of the porthole clean and open door and de-

tergent drawer if appliance is not in use to prevent odours.

▶Do not use water spray or steam to clean the appliance.

▶Replace a damaged supply cord only by the manufacturer, its ser-

▶Do not try to repair the appliance by yourself. In case of repair

please contact our customer service.

Installation

▶The appliance should be placed in a well-ventilated place. Ensure

a location which allows opening the door fully.

▶Never install the appliance outdoors in a damp place, or in an area

which may be prone to water leaks such as under or near a sink

unit. In the event of a water leak cut power supply and allow the

machine to dry naturally.

1-Safety information EN

Intended use

This appliance is intended for washing machine-washable laun-

dry only. Anytime follow the instructions given on the label of each

garment label. It is designed exclusively for domestic use inside the

house. It is not intended for commercial or industrial use.

Changes or modications to the device are not allowed. Unintended

use may cause hazards and loss of of all warranty and liability claims.

WARNING!

Installation

▶Install or use the appliance only where the temperature is above

5 °C.

▶Do not place the appliance directly on a carpet, or close to a wall

or furniture.

▶Do not install the appliance in direct sunlight or in the near of heat

sources(e.g. stoves, heaters).

▶Make sure that the electrical information on the rating plate

agrees with the power supply. If it does not, contact an electri-

cian.

▶Do not use multi-plug adapters and extension cables.

▶Make sure only the delivered electric cable and hose set are used.

▶Make sure not to damage the electric cable and the plug. If dam-

aged have it replaced by an electrician.

▶Use a separate earthed socket for the power supply which is easy

accessible after installation. The appliance must be earthed.

Only for UK: The appliance’s power cable is tted with 3-cord

(grounding) plug that ts a standard 3-cord (grounded) socket.

Never cut o or dismount the third pin (grounding). After the ap-

pliance is installed, the plug should be accessible.

▶Make sure the hose joints and connections are rm and there is

no leakage.

EN 2-Product description

2.1 Picture of appliance

Front (Fig. 2-1): Rear side (Fig. 2-2):

2.2 Accessories

Check the accessories and literature in accordance with this list (Fig.2-3):

Note:

2-3

2-1 2-2

Inlet hose-

assembly 5 Blanking

plugs Drain hose

bracket User manual

Warranty

card

Noisereduc-

tionpads

1 Transportation bolts (T1-T4)

2Backcover

3Backcover screws(9EA)

4Power cord

Water inlet valve

6Drain hose

123 4 5 6

1Detergent/Softener drawer

Control panel

Worktop

4Door

5Filter cover

6 Adjustable feet

Steam

冰蓝色灯珠

TM1624

6.94

13.

30.06

11.82

红色灯珠

6x3.5

盲孔深度2.5mm

Mix Synthetic

Allergy Care Wool Spin

Refresh

Eco40-60Remote

Quick 15’Smart

Cotton

Cotton 20°C

3-2

3-3

Mix Synthetic

Allergy Care Wool Spin

Refresh

Eco 40-60

Remote

Quick 15’Smart

Cotton

Cotton 20°C

Steam

冰蓝色灯珠

TM1624

6. 94

13. 74

30. 06

11. 82

红色灯珠

6x 3.5

盲孔深度2.5 mm

Mix Synthetic

Allergy Care Wool Spin

Refresh

Eco 40-60Remote

Quick 15’Smart

Cotton

Cotton 20°C

3-1

activated within 2 minutes before starting the program or at the end of the

program.

With WIFI connection, the waiting time duration is 24h.

EN 3-Control panel

Control panel is locked.

Steam.

Alarm.

Pre-wash.

Delay.

3.4 Function buttons

The function buttons (Fig. 3-5) enable additional op-

tions in the selected programme before programme

starts. The related indicators are displayed. o-

gramme, all options are disabled.

If a button has multiple options, the desired option can

be selected by pressing the button sequentially.

Note: Factory settings

there is no special requirement default settings are recommended.

3-5

Steam

3-4

Display symbols

Speed, Temperature, etc

3.4.1-Function button “Delay“

Touch this button(Fig . 3-6) to start the programme with a delay. End time

delay could be increased in steps of 30 minutes from 0,5-24h(End time will

longer than original programme time).For example display oﬀ 6:30 means

end of programme cycle will be in 6 hours and 30 minutes.Touch “Start/Pa

use” button to activate the time delay. It is not applicable to programme Spin,

Refresh,Remote.

3-6

Delay

3-Control panel EN

3.4.4 Function button “Speed“

Touch this button (Fig. 3-9) to change or deselect the spin of

the programme. If no value is illuminated the display" "the

laundry will not spin.

3.4.7 Function button “Start/Pause“

Touch this button (Fig. 3-12) gently to start or interrupt the

currently displayed programme.

3.4.5 Function button “Extra Rinse”

Touch this button (Fig. 3-10) to rinse the laundry more

intense

with fresh water. This is recommended for people

with sensitive

skin.

By touching the button several times z ero to three additional

cycles can be selected. They appear in the display

with P--0/

P--1/P--2/P--3.Diﬀerent programme optiones are diﬀrent.

3.4.2 Function button “ Steam“

Touch this button (Fig. 3-7) the steam program can be selected.

When this program is selected, the default temperature is the

max temperature of this program.You can select if you require

this function when programs"Smart,Mix,Synthetic, Cotton,Alle-

rgy Care“ are used. When you select the program "steam " the

icon light up to warn you ,the icon turns oﬀ when the program is

canceled .

When you select the program , you cannot change the temper-

ature . If you press the temperature button the program will be

canceled .Switch on the washing machine and select this program

If the washing machine is working you can not select this program .

Steam

Extra Rinse

Speed

3-9

3-10

3-11

3-7

3-8

3-12

Temp.

3.4.3 Function button “Temp.“

Touch this button (Fig. 3-8) to change the washing temperature

of the programme. If no value is illuminated(the display" ") the

water will not heated.

I-time

3.4.6 Function button ””

Not all programmes can select this function. See P12 for pro-

grams that can select this function.

diﬀerent washing time.

Note: Liquid detergent

If usingliquid detergent, it is not recommended to activate the end time delay.

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Arandela de Haier

Haier

Haier HW-C1270TVE-F - SERVICE Manual de usuario

Haier

Haier HWT60FVW2 Manual de usuario

Haier

Haier HW-C1260TVE-E Manual de usuario

Haier

Haier HW1210A Manual de usuario

Haier

Haier HWM55-33W Manual de usuario

Haier

Haier XQB42-62 Manual de usuario

Haier

Haier HW80-B14266A Manual de usuario

Haier

Haier HWM100-287S Manual de usuario

Haier

Haier HW-F1481 ME Manual de usuario

Haier

Haier HW100-BD14979U1 Manual de usuario

Haier

Haier XQJ100-96A Manual de usuario

Haier

Haier HW80-BP12929 Manual de usuario

Haier

Haier Mini magical child XQBM23-12 Manual de usuario

Haier

Haier HWM60-9288NZP Manual de usuario

Haier

Haier HW90-B14636N Manual de usuario

Haier

Haier JW-G50C Manual de usuario

Haier

Haier HW-C1050TVE Manual de usuario

Haier

Haier HWM55-23BS Manual de usuario

Haier

Haier XPB60-CS Manual de usuario

Haier

Haier HWM150-0623S Manual de usuario

Haier

Haier HBF600TE Manual de usuario

Haier

Haier HW80-B1486 Manual de usuario

Haier

Haier JW-K33B Manual de usuario

Haier

Haier HLP22P Guía de configuración

Manuales populares de Arandela de otras marcas

Tricity Bendix

Tricity Bendix AW 1000 W Guía del producto

Panasonic

Panasonic NA-F60L5WRB Manual de usuario

GE WSLP1500 Manual

Electrolux

Electrolux EWF1284EDW Manual de usuario

Bosch

Bosch WAN2829BSN Manual de usuario

LG TV2516DV3B Manual de usuario

LG TH2517DSAV Manual de usuario

VESTEL

VESTEL CMH-XL 7510 TE Manual de usuario

AEG

AEG 74335 Manual de operación

Johnson

Johnson JWF721A Manual de usuario

Beko

Beko WTE7604XLW0 Manual de usuario

Danby

Danby DTT100A1WDB Instrucciones de montaje

Amica

Amica WA 14 Ex Manual de usuario

Daewoo

Daewoo DWD-F1222 Manual de usuario

Bosch

Bosch WAS28461AU Manual de usuario

Miele

Miele PW 6080 Vario Manual de usuario

Finlux

Finlux FLX108CF220 Manual de usuario

Whirlpool

Whirlpool 3LBR5132AN0 Manual de usuario
