Haier HW100-BP14959S6 Manual de usuario

User manual

Washing machine

HW100-BP14959S6

Thank You

Warning – Important Safety information

General information and tips

Environmental information

Disposal

Protect the environment and human health by recycle

the appliance’s packaging to the designated recycling

bin. Do not dispose appliance marked with this symbol

together with the household waste. Send the appliance

to the local recycling center or contact the municipal

office.

Thank you for purchasing a Haier Product.

Please read this manual thoroughly before operate the appliance. This manual contains

important information on the installation, use and maintenance of the appliance.

Keep this manual in a safe and convenient place for future reference.

Please ensure this manual is along with the appliance if you plan to transfer this applia-

nce to other. This is to allow the next user understand and familiar the features and fun-

ctions of the appliance and safely operate this appliance.

Disconnect the appliance from the mains supply. Cut off the mains cable and dispose

f it. Removethe door catch to prevent childrenand pets to get closed in the appliance.

Risk of injury or suffocation!

WARNING!

Content

1-Safety information................................................................................................ 4

2-Product description.............................................................................................. 7

3-Control panel........................................................................................................8

4-Programmes.......................................................................................................11

5-Daily use.............................................................................................................12

6-Eco-friendly washing..........................................................................................17

7-Care and cleaning..............................................................................................18

8-Troubleshooting..................................................................................................21

9-Installation..........................................................................................................24

10-Technical data................................................................................................. 28

1-Safety information

WARNING!

Check the appliance is free from any transport damage.

Remove all the transport bolts

Remove and dispose all packaging materials (plastic bags, polystyrene,

etc) and keep out of children’s reach.

Handle the appliance with at least two persons.

Daily use

Before first use

This appliance can be used by children aged from 8 years and above and

persons with reduced physical, sensory or mental capabilities or lack of e-

xperience and konwledge if they have been given supervision or instructi-

on concerning use of the appliance in a safe way and understand the haz-

ards involved.

Before switching on the appliance for the first time read the following safety

instructions!

Keep children under 3 years of age away from the appliance unless they

are constantly supervised.

Children shall not play with the appliance.

Pull up zips, fix loose threads and take care for small items to prevent lau-

ndry from being entangled. If necessary, use laundry bag or net.

Do not let children or pets come close to the appliance when the door is

open. Store washing agents out of reach of children.

Do not press or use the appliance when barefoot or with wet or damp han-

ds or feet.

Do not cover or encase the appliance during operation or afterwards to all-

ow moisture or dampness to evaporate.

Do not place heavy objects or sources of heat or damp on top of the appli-

ance.

Do not use or store flammable detergent or dry cleaning agent in close vic-

inity to the appliance.

Do not use any flammable sprays in close vicinity to appliance.

Do not wash any garments treated with solvents in the appliance without

having dried them previously in the air.

1-Safety information

WARNING!

Daily use

Do not remove or insert the plug in the presence of flammable gas.

Do not hot wash foam rubber or sponge-like materials.

Do not wash any laundry which is polluted with flour.

Do not open detergent drawer during any wash cycle.

Do not press the door during the washing precess, it gets hot.

Do not open the door if the water level is visibly over the port hole.

Do not force the door to open. The door is fitted with a self-lock device and

will open shortly after the washing procedure is ended.

Switch off the appliance after each wash programme and before under tak-

ing any routine maintenance and disconnect the appliance from the electri-

cal supply to save electricity and for safety.

Hold the plug, not the cable, when unplugging the appliance.

Maintenance/cleaning

Make sure children are supervised if they carry out cleaning and maintena-

nce.

Disconnect the appliance from the electrical supply before undertaking any

routine maintenance.

Keep the lower part of the porthole clean and open door and detergent dr-

awer if appliance is not in use to prevent odours.

Do not use water spray or steam to clean the appliance.

Replace a damaged supply cord only be the manufacturer, its service age-

nt or similarly qualified persons in order to avoid a hazard.

Do not try to repair the appliance by yourself. In case of repair please cont-

act our customer service.

Installation

The appliance should be placed in a well-ventilated place. Ensure a locati-

on which allows opening the door fully.

Never install the appliance outdoor, in a damp place, or in an area which

may be prone to water leaks such as under or near a sink unit, In the event

of a water leak, cut power supply and allow the machine to dry naturally.

1-Safety information

Intended use

This appliance is intended for washing machine-washable laundry only. Any-

time follow the instructions given on the label of each garment label. It is not

intended for commercial or industrial use.

Changes or modifications to the device are not allowed. Unintended use may

cause hazards and loss of all warranty and liability claims.

WARNING!

Installation

Installor use the appliance only where the temperature is above 5 °C.

Do not place the appliance directly on a carpet, or close to a wall or furn-

iture.

Do not install the appliance in direct sunlight or in the near of heat sourc-

es (e.g. stoves, heaters).

Make sure the electrical information on the rating plate agrees with the

power supply. If it does not, contact an electrician.

Do not use multi-plug adapters and extension cables.

Make sure only the new electric cable and hose sets supplied with the a-

ppliance are to be used.

Make sure not to damage the electric cable and the plug. If damaged ha-

ve it replaced by an electrician.

Use an easy accessible and earthed socket for the power supply.

The appliance must be earthed.

Make sure the hose joints and connections are firm and there is no leak-

age.

2.1 Picture of appliance

Front (Fig. 2-1): Rear side (Fig. 2-2):

2.2 Accessories

Check the accessories and literature in accordance with this list (Fig. 2-3):

Note:

1 Detergent/Softener drawer

Control panel

Worktop

4 Door

5 Filter cover

6 Adjustable feet

1 Transportation bolts (T1-T4)

2 Backcover

Backcover screws（7 EA）

4 Power cord

5 Drain hose

2-1 2-2

2-3

2-Product description

Inlet Hose

Assembly

6 Blanking

Plugs+2 Screws Drain Hose

Bracket User Manual Bottom Plate

Due to technical changes and different models, the illustrations in the following chapt-

ers may differ from your model.

123 4 5 6

Warranty Card

Water inlet valve

3-Control panel

Note : Acoustic signal

Infollowing cases an acoustic signal sounds:

▶when pressing a button

▶at the end of programme

▶

▶when selecting the programme

in case of failures

The acoustic signal can be deselected if necessary; see DAILY USE.

Programme selector

3 Display

4 Detergent / Softener drawer

5 Function buttons

“Start/Pause” button

“Power” button

3.2 Programme selector

By turning the knob (Fig. 3-3), you may choose one

from 12 programmes and the corresponding progr-

3.3 Display

The display (Fig. 3-4) shows following information:

▶

▶Washing time

▶

End time delay

▶

Favorites

Locking the door

Child lock

Steam washing

▶

3.1 “Power” button

Touch this button (Fig. 3-2) gently to swicth on the

appliance, the display is shining, press it again for

about 2 seconds to swicth off. If no panel element

or programme is activated after a while machine

will shut down automatically.

3-1

3-2

3-3

3-4

4 2

amme LED icon will light up.

3-Control panel

3.5 Function buttons

Choose the extra function from the (Fig. 3-6) before the

3.5.1-Function button “Delay”

Note: Factory settings

To get best results in each programme, Haier has well defined specific default settings.

Default settings are recommended if there is no specific requirement.

3.4 Detergent drawer

Open the drawer, two compartments can be seen

The recommendation on the type of detergents is suit-

able for the various washing temperatures, please refer

to the manual of detergent.

This model does not have a disinfection washing prog-

ramme, and disinfectant can not be added to the disin-

fection washing inlet.

3.5.2-Function button “Temp.”

2 Compartment 2: Softener, Conditioning agent etc.

1 Compartment 1: Powder or Liquid detergent.

Press this button (Fig. 3-7) to start the programme with a delay.

End time delay could be increase in interval of 30 minutes from

0.5-24h. After you select the delay function, the total washing

time will longer than the default programme washing time. For

example, display off 6:30 means end of programme cycle will

be in 6 hours and 30 minutes. Press Start / Pause” button to

activate the time delay.

Press this button (Fig. 3-9) to change the washing temperature

of the programme. If the display showing “0”, the temperature

function will not be activated and the water will not be heated.

(Fig. 3-5):

3-6

3-5

3-8

3-7

washing cycle start. The related indicators are light up

once selected. You may choose more than one function

by pressing the buttons sequentially.
