WASHER AND DRYER

Service Manual

Suited model:

HTD1268

MANUAL CODE˖

Washer And Dryer Model:HTD1268 SERIES

SM-HTD1268- 1

1.Contents----------------------------------------------------------------------------------------1

2.Product code illumination and series introduction-----------------------------------2

3.Features ---------------------------------------------------------------------------------------3

4.Specification ----------------------------------------------------------------------------------4

5.Safety caution --------------------------------------------------------------------------------6

6.Installation ------------------------------------------------------------------------------------9

7.Net dimension -------------------------------------------------------------------------------11

8.Names of the parts-------------------------------------------------------------------------12

9.Operational Functions----------------------------------------------------------------------13

10.Functions schedule-----------------------------------------------------------------------15

11.Error Display and Trouble shooting---------------------------------------------------16

12.Wiring circuit --------------------------------------------------------------------------------26

13.Back cover-----------------------------------------------------------------------------------27

MANUAL CODE˖

Washer And Dryer Model:HTD1268 SERIES

SM-HTD1268- 1

PRODUCT CODE ILLUMINATION AND SERIES INTRODUCTION

Model code rule description

Model identification˖

HTD12 68

A˖Serial code

B˖Max spin speed

C˖silver gray

MANUAL CODE˖

Washer And Dryer Model:HTD1268 SERIES

SM-HTD1268- 1

Multi-gear speed controller

According to different costumingˈyou can select corresponding spin speedˈ

from 0 to 1200 rpm.

Unique gasket design featuring no residual water hidden inside.

By the unique gasketˈwashing machine can left no residual water hidden between outer

drum and front board.

Delay time adjustive.

According to different costumingˈyou can select delay timeˈfrom1hto24h.

Apperceive drying degree of laundry automatically, just in time to save energy and

make you more comfortable.

Gradient 30 degree control panel, extra big VFD indication, washing process is clear

at a glance

Custom memory function, more time saving and convenient.

Washer And Dryer Model:LSE-1200 S SERIES

5.6002senihcamgnihsaw

HTD1268

Last update

1. Product identification

enihcamgnihsaWecnailppafonoitpircseD

Type of appliance(FS = standing, BI = built-in FS

HaierdnarbnworeilppuS

NAEedocrabreilppuS

Commercial Brand / Model

CBTNAEedocrablaicremmoC

2. Key-Features

AssalcycneiciffeygrenE

BssalcecnamrofrepgnihsaW

BssalcycneiciffenipS

°nsmargorP 11

gKyticapaC 6

Spin speed (max./optional) rpm

1200-400

Noise level sound pressure level dB(A) 65

Energy consumption per wash circle kWh 1.14

Water consumption per wash cycle L 54

Annual average energy consumption * kWh 190

Annual average water consumption* L 9600

Residualdampness (spin result) %54%

Spin speed selector switch (steps) rpm

Adjustable thermostat (water temp. adjus

°C

90 -

Drum capacity dry laundry /

kg / l 6 /46

Auto water level adjust (depending on volu

AWL

251nim).xam(emitgnihsaW

Washing temperatures (program-co

°C

30 -90

Certification's (CE / ISO 9001 / ISO 9002) CE / ISO 9001

).lhR(SG/VÜT)QMI/SG/VÜT/SG/EDV(slavorppA

*per average200 wash cycles (EN60456)ðT= COLD

3. Basics data

Unit dimension(H x W x D)

85 x 59,5 x 60

88gkthgiewteN

zH05/~V042-022zH/Vycneuqerf/egatloV

Inputpower / main fuse (intensity) W / A 2100/10

Work top / removable

Control M = electromechanical, E= electronic, F= fuzzy

Drum S= stainless steel / Z= zinc coated

Tub P= Polyprop./ S= stainless steel

Door:

aesthetic (R= round,Y= big eye, Q= square)

Diameter

cm 30

Outer door frame S= stainless steel/M= metal / P= plastic

Inner doorG= glass / P= plastic

3°nstnemtrapmoctnegreteD

Removable compartment for liquid detergent

Delay timer (from-to) h1-24

Self cleaning sudspump

Washer And Dryer Model:HTD1268 SERIES

Water inlet hose cold water / hot water

/-

Water drain hose / -support

/

Adjustable feet n° 4

4. Safety systems

Auto door lock ADL 

Motor overheating protection MOP 

No heating without water NHW 

Auto water cool-down (before drain 90°C b

AWC 

Water protection WRP 

Acqua Stop kit -

Child protection 

5. Programs

1) COTTON PREWASH (90°C/60°C/40°C

n° 1

2) COTTON (60°C/40°C/Ć)n° 1

3) SYNTHETIC (40°C/Ć)n° 1

4)WOOL n° 1

5)CASHMERE n° 1

6)HAND WASH n° 1

7)QUICK WASH n° 1

8)SPORT WASH n° 1

9)DUVET n° 1

10)Drain n° 1

11)Spin n° 1

Optional function keys (additional program settings)

Program button(with power switch) 

Start / pause 

Baby care 

Economic key/load 

Rinse hold / No Soak 

Delay timer 

speed 

temperature 

Packing dimensions & loadability -

Packing dimensions (H x W x D) cm

89×65×60

Gross weight kg 74

40' Container load pcs -

40' HC load capacity pcs 171

Logistic / recicling information RS

Packing weight kg 6

Packing materials / Recycling symbols REzY

Carton (w

gr 0

Polistyren (w

gr 1000

Polyetylene foil

gr 500

Other packing materials

gr -

Wood (w

kg -

Service -

6. User instruction (languages)

D/F/I/GB/E/P/NL

Max. failure rate (12 Months after sale

Washer And Dryer Model:HTD1268 SERIES



Precaution

The power cable must be replaced

by a qualifed engineer; if not, please

consult the Service Center.

5. Do not use inflammable detergents or

dry-cleaning agents. Do not use inflammable

spray containers in close vicinity to the

washing machine. In the event of gas leaks,

remove the washing machine plug and do not

connect.

6. The door of the washing machine will

become very hot during the water-heating

process. Avoid contact with the door during

the heating process. For safety, keep children

away from the washing machine.

7. Do not allow children

with the

ackin

materials after un

ackin

Washer And Dryer Model:HTD1268 SERIES

ƽ 8VH

8. The washing machine must not be installed

outside or in a very humid areaas drops of

water may form on electricalcomponents,

If drops of water have splashed on the

warming on the washing machine,leave it

dry before use.

10. Keep away from heat sources and di-

rect sunlight to prevent plastic and rubber

components from aging.

2. Keep the door slightly open when the

washing machine is not being used. Never

cover the machine with a plastic sheet.

1. Before starting the wash programme,

ensure that the washing machine is

correctly connected to the water supply. In

the event of water leakage, turn off the

water supply and reconnect, or call the

Service Center.

precaution

Washer And Dryer Model:HTD1268 SERIES

3.Do not place heavy objects or container

with water on the washing machine,so as to

prevent deformation of the flat surface and

plastic parts.

4. Do not wash articles containing

polystyrene or similar elastic materials.

5. Before washing, do up zippers and ensure

that buttons are securely fastened. Place

small items, such as socks,belts,etc. in a

small washing bag or a pillow-case . To

protect the washing machine, do not wash

garments containing wire parts.

7. The door is fitted with a self-lock device

and can not be opened until 2-3 minutes

after the end of the programme.You are not

recommended not to force the door open

before the programme end. Do not open the

door if the water level is above the lower

part of the door.

8. At the end of the wash cycle, turn off the

water supply to prevent water leakage, un-

plug the washing machine and thoroughly

clean the trim so as not to dirty the laundry

in the next wash cycle.

Precaution

6.Do not open the detergent drawing

during the wash cycle.

9.For appliances with type Y attachment,the

intructions shall contain the substance of the

following.

If the supply cord is damaged,it must be

replaced by the manufacturer,its service

agent or similarly qualifled persons in order

to avoid a hazard.

10.The installation instructions shall state

that the appliance is to be connected to the

water mains using new hose-sets and that

the old should not be used.

For washing machines with ventilation

openings in the base,that a carpet must not

obstruct the openings.

Washer And Dryer Model:HTD1268 SERIES

Remove all the packing materials (including the

EPS base)to prevent vibration during use, as

shown in the right picture.Upon opening of the

package, water drops may be seen on the plastic

bag and the porthole. This is normal phenomenon

resulting from water test in the factory.

Fig

Check attachments and materials with reference to the following

Dismantle the packing bolts as shown in Fig. 2.

The packing bolts are designed for clamping anti-vibration components

inside of the washing machine during the transportation process.

Before use:

1. Remove the back plate;

2. Remove the three packing bolts on the back plate and take out the

rubber hose;

3. Replace the back plate;

4. Fill the holes left by the packing bolts with plastic plugs.

(Attention: The packing bolts and rubber hose should be kept in a safe

place for later use)

Fig.3

Adjusting the washing machine

There are adjustable feet under the bottom of the washing machine. Before

use, the washing machine should be adjusted, as shown in Fig. 3, so that it

is level.

Fig.2

Model

Qty Name

Operation

manual

Operation

manual

Quality

certificate

Quality certificate

Water

hose

Water hose

Drainage

holder

Drainage holder

Plastic

plugs

Plastic plugs

Installation

12 11

Warrantly

card

Warrantly card

HTD1268

Washer And Dryer Model:HTD1268 SERIES
