Haier 29F9D Manual de usuario

Digital Curtain

218 Preset Channel

Multiple Picture and Sound Mode

On/Off Timer

Child Lock

Soft Channel change Function

Personalized Channel Timer Function

DVD Video Component Input Terminals

0090505164

V 1.0

COLOR TV RECEIVER

OWNER'S MANUAL

29F9D

Please read this manual carefully before operating

the unit, and keep it for future reference.

MAIN FEATURES

WARNING AND CAUTIONS

1. When you clean the TV set, please

pull out the power plug from AC outlet.

Or may result in electric shock, fire or

damage to the TV set. Don't clean the

cabinet and the screen with benzene,

petrol and other chemicals.

4. Do not place the TV set near rain

or moisture as it may cause an electric

shock, or the TV set to catch fire. The

TV set must only be

Used in dry indoor

location.

2. In order to prolong the using life of

the TV set, please place it at a well

ventilated location.

5. The back cover must only be

removed by a registered electrical

service person. Removing the back

cover may result in electric shock, fire

or damage to

the TV set.

3. Don't place the TV

set in direct sunlight

or near heat source.

6. If the TV set is not going to be

used for a long time, or there is a

severe thunder & lightening storm, it

is recommended that the TV set be

disconnected from the AC.

Explanation on the display tube

When the picture tube requires cleaning, please disconnect the power and use

a dry soft cotton cloth. Do not use any cleaner or abrasive cloth.

CONTENTS

Warning and cautions....................................................................................1

Basic feature..................................................................................................2

Technical specification...................................................................................2

Preparing for operations................................................................................3

Function buttons and external sockets..........................................................4

AV connections.............................................................................................5

Remote controller guide................................................................................6

Power supply.................................................................................................7

Tuning procedure..........................................................................................7

Picture and audio adjustment function ........................................................11

Time function...............................................................................................14

Setting function ...........................................................................................17

Game...........................................................................................................22

Trouble shooting guide................................................................................23

BASIC FEATURE

TECHNICAL SPECIFICATION

Stage curtain for open and close effect

218 programs stored

Multi-picture modes and sound modes selection

On/Off timer

Child lock

Soft exchange

Count

Appointment

DVD component input

Antenna connection

Connect an antenna to the antenna socket on

the TV set, we recommend using a Cable TV

system for better picture and audio quality.

1.If you use a coaxial cable(75 ),insert the

antenna plug (see figure C) into 75 socket

(see figure A).

2.If you use a twin-lead cable(300 ),please

shape the cable as figure D, and connect the

leads to antenna adapter and then insert the

antenna adapter into the 75 socket (see

figure B).

Power source wire connection

Insert the power plug into AC outlet.

Install and replace batteries of the

remote control unit:

1.Place the remote control unit with the face

down, then open the battery cover of the

unit.

2.Place the two"AA"size batteries, matching

the + and - signs on each battery to the +

and -signs of the battery compartment.

3.Close the cover of the battery compartment.

NOTE:

(1)Don't drop or wet or dismantle the unit.

(2)If you don't intend to use the unit for a

long period or the electricity of the

batteries is used up, remove the batteries

to prevent batteries acid from leaking

into the battery compartment.

(3)Replace the two old batteries at the

same time.

(4)Don't use charge battery (Ni-cd )and

don't mix battery type.

(5)Don't throw your batteries into a fire.

Dispose of your batteries in a required

place.

PREPARING FOR OPERATIONS

Figure A Figure B

Antenna cable

with a plug

Figure C Figure D

Antenna feeder

Antenna adapter

75-300¦¸

Coaxial cable(75 ) twin-lead cable(300 )

Antenna

1.CRT: 29"

2.COLOUR SYSTEM: PAL NTSC3.58/4.43(AV)

3.AUDIO SYSTEM: BG

4.POWER SUPPLY: ~220V 50Hz

5.POWER SUPPLY VOLTAGE RANGE: ~160V -250V 50/60Hz

5.POWER CONSUMPTION: 155W

6.ANTENNA INPUT IMPEDANCE : 75

7.VIDEO INPUT: 1.0Vp-p( 75 )

8.VIDEO OUTPUT: 1.0Vp-p( 75 )

9.AUDIO INPUT: 400Vrms(40k )

10.AUDIO OUTPUT: 400Vrms(600k )

11.SOUND OUTPUT POWER: 10W+10W

Supplied accessories:

Infrared remote control handset 1

Battery(AA) 2

Operating instruction 1

Design and specifications are subject to change without notice.

(7)S-video input

(1)AV1 input socket

(4)DVD component input

(5)Audio/Video output socket

(6)Antenna socket

(1)Remote sensor: let the remote

controller aim here the set can

receive remote control signal.

(2)Power switch: press the button

to turn on the TV set . Press

the button again to turn off

the TV set.

(3)Power indicator: the indicator

lights in standby status ,the

indicator lights in sleep status.

The indicator glints when you

use remote controller.

(4)Menu button

(5)Program up/down button

(6)Volume up/down button

(7)TV/AV

4 5

1.Front Panel

FUNCTION BUTTONS AND EXTERNAL SOCKETS

2.Rear Panel and

Side Panel

(7) (4)

(1)

(6)

(2)

(5)

(3)

You can connect DVD VCD LD to the TV set to watch the high quality picture.

The connections are as follows:

EXTERNAL CONNECTION

Direction of signal

white left audio

red C /right audio

blue C

green

video

yellow

DVD(with DVD component)

VCR (without S-VIDEO terminalL)

To audio out

VCR (with S-VIDEO terminal)

Tos-videooutput

To audio output

To component out

To audio out

Tovideooutput

Note:

1.S-VIDEO terminal and VIDEO input terminal can not be used at the same

time.

2.AV input terminal and DVD component input terminal can not be used at

the same time.

3.AV3 input terminal and AV1 input terminal can not be used at the same

time.

(7)

(1)

(4) (5) (6)

(2)

(3)

(2)AV2 input socket

(3)AV3 input socket

VIDEO

AUDIO

POWER SUPPLY

Power supply (switch on/off to set main power supply).

1.Press power switch button to switch on AC power supply. The red power

indicator will light.

2. Press the power switch button on the remote controller to enter normal

receiving condition when the TV set is in standby condition.

There are Auto-search, Semi-Auto search and

Fine tuning method.

Auto-search

1.Press [MENU] button to let TUNING menu display

on the screen, then press [-CH+] buttons to select

AUTO MEMORY.

2. Press [VOL+] button to make the AUTO

MEMORY mode work, the TV set will begin to

search programs from program number 0.

After the search is finished, program number

0 will display on the screen.

Note: During auto-search, if you want to stop

searching, press [VOL-] button.

TUNING PROCEDURE

Remote controller functions

TV/AV exchanging button

Mute button

Numeric button

One/two/three digital buttons

Picture mode selection

Volume up/dwon button

Program play-forward button

Surround sound selection button

Volume mode selection

Display button

Game start or restart button

System preset button

Lock preset button

Scan button

DC standby button

Sleep timer

Game background selection button

Game exit button

6 7

Calendar display button

REMOTE CONTROLLER GUIDE

Program play-backward button

Intelligent button:

The numeric button 1 has intelligent function,

press it for 6s, then the TV set will search and store

the program automatically.

ASM VL 0

STOP

TUNING

SELECT ADJUST

POSITION 1

BAND UL

SKIP OFF

SEARCH DOWN

MFT UP

AUTO MEMORY

49.87 MHZ

TUNING PROCEDURE

Press [MENU] button to let TUNING menu

display on the screen,

3.Press [-VOL+] buttons to start searching.

1.Press [-CH+] buttons or numeric button (0~9) to

select the channel number you need.

(For example: channel 1).

Then press [-CH+]

buttons to select SEARCH item.

[CH-] button is to search the program from

low FC. [CH+] button is to search the program

from high FC. Repeat above procedure until

you find the channel you need.

4.When you intend to memory another channel in

another position, press [-CH+] buttons to select

POSITION, and use [-VOL+] buttons to select a

number you need, then press [-CH+] buttons to

select SEARCH, and repeat fourth procedure.

Skip

After pre-tuning the channel, you can skip the

channel you do not need in order to only select

the channel you want to watch.

1.Press [-CH+] buttons or numeric button(0~9) to

select the channel number skipped(for example:

channel 1).

2.Press [MENU] button to let TUNING menu

display on the screen, then press [-CH+]

buttons to select SKIP item.

3.Press [-VOL+] buttons to set SKIP ON mode.

4.Press [DISPLAY] button to shut off the menu.

The channel number will be skipped when

you use[-CH+] buttons to select channels.

But you can still use numeric button to select

the channel number skipped.

Note:

1.You can use the numeric button to select

the channel number that need recover.

2.Press [MENU] button to let the TUNING

menu appear on the screen, then press

[-CH+] buttons to select SKIP.

3.Press [-VOL+] buttons to set SKIP OFF

mode.

TUNING PROCEDURE

SELECT ADJUST

POSITION 1

BAND UL

SKIP OFF

SEARCH DOWN

MFT UP

AUTO MEMORY

49.87 MHZ

SELECT ADJUST

POSITION 1

BAND UL

SKIP OFF

SEARCH DOWN

MFT UP

AUTO MEMORY

49.87 MHZ

SELECT ADJUST

POSITION 1

BAND UL

SKIP OFF

SEARCH DOWN

MFT UP

AUTO MEMORY

49.87 MHZ

SELECT ADJUST

POSITION 1

BAND UL

SKIP OFF

SEARCH DOWN

MFT UP

AUTO MEMORY

49.87 MHZ

SELECT ADJUST

POSITION 1

BAND UL

SKIP OFF

SEARCH DOWN

MFT UP

AUTO MEMORY

49.87 MHZ

SELECT ADJUST

POSITION 1

BAND UL

SKIP ON

SEARCH DOWN

MFT UP

AUTO MEMORY

49.87 MHZ

TUNING

Picture mode selection

You can select the picture mode you need

quickly in five preset modes and a user's

personal set.

Press [ P.STD] button to select the picture

quality you need. There are six picture modes

you can select in turn.

DYNAMIC, STANDARD, MILD, MEMORY,

PICTURE MUTE and COLOR MUTE.

Mode Picture quality

DYNAMIC Rich , Bright Movie

STANDARD Proper color

MILD Soft, Light

MEMORY The picture quality you set

PICTURE MUTE function ( no signal)

COLOR MUTE Black &White picture

Note: If the picture in PICTURE MUTE or COLOR MUTE

status, the TV set will recover to DYNAMIC

status when restart.

Adjust the picture status you need to Memory.

Item Press [VOL-]button

CONTRAST Weak Strong

BRIGHT Dark Bright

COLOR Light Dark

SHARP Soft Sharp

B.B Light green Light purple

Note: Tint is only appear in N signal, the method of adjustment is the same

as above.

Picture mute

Press [MENU] button to let PICTURE menu

display on the screen.

2.Press [-CH+] buttons to select the item you

want to adjust, then press [-VOL+] buttons to

adjust to your expect effect. The picture status

will be stored to the COLOR MUTE item.

Press [VOL+]button

PICTURE AND AUDIO ADJUSTMENT FUNCTION

TUNING PROCEDURE

Fine tuning

Because of some reasons, if auto searching effect of program

isn't good, please fine tune your TV set.

1.Press [-CH+] buttons or numeric button(0~9)

to select the channel number that need to fine

tune.( For example: channel1)

3.Press and hold [-VOL +] buttons until the effects

of the picture and audio are good.

2.Press [MENU] button to let main menu display on

the screen, then press [-CH+] buttons to select

MFT item.

[VOL -] button is to search program from low FC.

[VOL+] button is to search program from low FC.

DYNAMIC

MILD

MEMORY

COLOR MUTE

STANDARD

PICTURE MUTE

SELECT ADJUST

CONTRAST 100

BRIGHT 50

COLOR 50

SHARP 50

B.B ON

SELECT ADJUST

POSITION 1

BAND UL

SKIP OFF

SEARCH DOWN

MFT UP

AUTO MEMORY

49.87 MHZ

SELECT ADJUST

POSITION 1

BAND UL

SKIP OFF

SEARCH DOWN

MFT UP

AUTO MEMORY

49.87 MHZ

TUNING


S.C.C

There is soft exchange function in this TV set, when you set this function is

ON and exchange channels, the picture will fade in/fade out to protect

your eyes.

1.Press [MENU] button to let FUNCTION menu

display on the screen.

2.Press [-CH+] buttons to select S.C.C item, then

press [-VOL+] buttons to set the S.C.C ON/OFF.

COUNT

This TV set provides COUNT function, if you want to know count, you can

press MENU button to enter FUNCTION menu to see the time your use.

(Restart time from 0 after 100000 hours).

The time is the total time your watch(no time in standby status), the value

is not be adjusted through remote controller or the buttons of this TV set.

MUTE function

When you need pay attention to the surround sound or answer the telephone

or the guest to visit, using mute function will be

convenient.

1.Press [ ] button on the remote controller, the( )

will appear at the bottom of the screen, at this time

the sound will be shut off.

2.If you want to recover the sound, you can press the

[ ] button again or press the [-VOL+] buttons

directly.

PICTURE AND AUDIO ADJUSTMENT FUNCTION

Sound mode selection

You can select the sound mode you need from

three modes quickly.

Press [S.STD] button to select the sound quality

you need. There are THEATER, NEWS, MUSIC,

PERSONAL to select in turn.

Volume set function

You can adjust the volume to your preset value

quickly(for example: BASS, TREBLE, BALANCE)

1.Press [MENU] button to let SOUND menu

display on the screen.

2.Press [-CH+] buttons to select BASS item,

then press [-VOL+] buttons to adjust to your

expect effect. You can adjust the parameters

of TREBLE,BALANCE by using the same way.

THEATERTHEATER

NEWSNEWS

MUSICMUSIC

PICTURE AND AUDIO ADJUSTMENT FUNCTION

PERSONALPERSONAL

SELECT ADJUST

BASS 66

TREBLE 68

BALANCE 00

SELECT ADJUST

BASS 66

TREBLE 68

BALANCE 00

SELECT ADJUST

BASS 66

TREBLE 68

BALANCE 00

LANG. ENGLISH

CURTAIN III

POS. EX.

S.C.C OFF

AUTO OFF OFF

COUNT 0:38

SELECT ADJUST

SOUND

FUNCTION

Off timer function

When you use OFF TIMER function, you can make the TV set switch to the

standby status in that the appointing timer is

coming.

1.Press

[MENU] button to let the TIMER menu

display on the screen.

2.Press [-CH+] buttons to select OFF TIMER item,

then press [-VOL+] buttons repeatedly to set

ON-TIMER to ONCE or EVERY or OFF.

3.Press [-CH+] buttons to select the next item,

at this time, you can set the off time by pressing

[-VOL+] buttons.

4.Press [-CH+] buttons to select CLOCK item,

then you can set the current time by pressing

[-VOL+] buttons.( on timer/off timer take this

clock as standard )

TIME FUNCTION

14 15

TIME FUNCTION

Sleep timer function

Using the sleep timer function, the TV set can switch to the standby status

automatically when the TV set restarts after an appointing certain time.

1.The sleep timer can be set 120 minutes longest, and it can

change every 10 minutes unit, there are 12 off timer

in all.

2.Press[ ] button, the bottom of the

screen will display the right figure cycle.

On timer function

Using ON TIMER function in the standby status, the TV set can connect

power supply and broadcast the appointing channel number automatically

when the appointing time is coming.

1.Press [MENU] button to let the TIMER menu appear

on the screen.

2.Press[-CH+] buttons to select ON TIMER item,

then press [-VOL+] buttons repeatedly to set

the ON TIMER to OFF or ONCE or EVERY .

3.Press[-CH+] buttons to select next item. At this

time, press [-VOL+] buttons to set ON TIMER

(the method is the same as OFF TIMER).

4.Press[-CH+] buttons to select POS 0 item, then

press [-VOL+] buttons to set ON/OFF TIMER

channel number(for example 5).

5.Press[-CH+] buttons to select CLOCK item, then

press [-VOL+] buttons to set the current time(the

method is the same as OFF TIMER, ON/OFF

TIMER takes this clock as standard).

SLEEP: OFFSLEEP: OFF

SLEEP: 120MINSLEEP: 120MIN

SLEEP: 110MINSLEEP: 110MIN

SLEEP: 20MINSLEEP: 20MIN

SLEEP: 10MINSLEEP: 10MIN

SELECT ADJUST

OFF TIMER ONCE

19:00

ON TIMER OFF

22:00

POS 0

CLOCK 1:40

APPOINTMENT

SELECT ADJUST

OFF TIMER ONCE

19:00

ON TIMER OFF

22:00

POS 0

CLOCK 1:40

APPOINTMENT

SELECT ADJUST

OFF TIMER ONCE

19:00

ON TIMER OFF

22:00

POS 0

CLOCK 1:40

APPOINTMENT

SELECT ADJUST

OFF TIMER ONCE

19:00

ON TIMER OFF

22:00

POS 0

CLOCK 1:40

APPOINTMENT

SELECT ADJUST

OFF TIMER ONCE

19:00

ON TIMER OFF

22:00

POS 0

CLOCK 1:40

APPOINTMENT

SELECT ADJUST

OFF TIMER ONCE

19:00

ON TIMER OFF

22:00

POS 0

CLOCK 1:40

APPOINTMENT

TIMER

16 17

TIME FUNCTION

Appointing program

1.Press [MENU] button to let the TIMER menu display

on the screen.

2. Press [-CH+] buttons to select CLOCK item,

then press [-VOL+] buttons to set the current

time( themethod is the same as OFF TIMER,

APPOINTMENT takes this clock as standard).

3.Press [-CH+] button to select the APPOINTMENT

item. Then press [ VOL+/-] buttons to enter

APPOINTMENT sub-menu.

4.Press [-VOL+] buttons to set the POS.

you need( for example:100).

5.Press [CH-] button to enter TIME item. Then

press [-VOL+] buttons to set the time. Pressing

[-VOL+] buttons, the time will change with 1

minute unit. Pressing and holding [-VOL+] buttons,

the time will change with 10 minutes unit.

6.Press [CH-] button and repeatedly the fourth and

fifth to set the next POS.l.

7.Press [DISPLAY] button to exit the [TIMER] menu.

When the time is coming, the TV set will

switch to the channel number you appointed

automatically.

The APPOINTMENT is only valid in ON

TIMER status, it is invalid in AC or DC standby

status.

APPOINTMENT

POS. TIME

000 OFF

SETTING FUNCTION

Language selection

1.Press [MENU] button to let the FUNCTION menu

display on the screen.

2. Press [-CH+] buttons to select LANG. Item,

then press [-VOL+] buttons to select language,

the character will display with the change of

language.

Screen projection function

When the background function is activated and the

TV set receive no signal, the screen will change

into the right figure.(game screen projection

picture).

1.Press [MENU] button to let the PICTURE menu

display on the screen.

2.Press [-CH+] button to select the B.B item,

then press [ VOL+/-] buttons to set the B.B

ON.

APPOINTMENT

POS. TIME

100 OFF

000 OFF

APPOINTMENT

POS. TIME

100 12:58

000 OFF

CONTRAST 100

BRIGHT 50

COLOR 50

SHARP 50

B.B ON

SELECT ADJUST

OFF TIMER ONCE

19:00

ON TIMER OFF

22:00

POS 0

CLOCK 1:40

APPOINTMENT

SELECT ADJUST

TIMER


FUNCTION

LANG. ENGLISH

CURTAIN III

POS. EX.

S.C.C OFF

AUTO OFF OFF

COUNT 0:38

Otros manuales para 29F9D

Tabla de contenidos

Otros manuales de TELEVISOR de Haier

Haier

Haier 34FV6H Manual de usuario

Haier

Haier 21F9G Manual de usuario

Haier

Haier HTX25S31, HTX29S31S, HTX34S31 Manual de usuario

Haier

Haier P42LV6-T1 Manual de usuario

Haier

Haier TDC1354AD Manual de usuario

Haier

Haier KGNFHD32HVAA Manual de usuario

Haier

Haier LC-2610D Manual de usuario

Haier

Haier NS-F20C Manual de usuario

Haier

Haier 29F9D Manual de usuario

Haier

Haier HTX20S32 Manual de usuario

Haier

Haier RGBTV-21TA Manual de usuario

Haier

Haier DX-LDVD22-10A Manual de usuario

Haier

Haier LE20F6500 Manual de usuario

Haier

Haier 21T8D-S Manual de usuario

Haier

Haier TV-8888-30 Manual de usuario

Haier

Haier HLH37ATBB - 37" LCD TV Manual de usuario

Haier

Haier 34T9B Manual de usuario

Haier

Haier L22T3 Manual de usuario

Haier

Haier DX-RCRT20-09 Manual de usuario

Haier

Haier HL42XZK42a Manual de usuario

Haier

Haier HLH26BBTV Manual de usuario

Haier

Haier LE32B7000 Manual de usuario

Haier

Haier HTAF21S Manual de usuario

Haier

Haier LC-3710D Manual de usuario

Manuales populares de TELEVISOR de otras marcas

Philips

Philips Colour Television Manual de usuario

Toshiba

Toshiba 27A10 Manual de usuario

Philips

Philips 42PF9630A/37 Manual de usuario

Hitachi

Hitachi 32FX48B Manual de usuario

DAEWOO ELECTRONICS

DAEWOO ELECTRONICS DTQ-14V1FC Manual de usuario

Changhong Electric

Changhong Electric uhd55b6000is Manual de usuario

Philips

Philips Matchline 21CE7551 Manual de usuario

Panasonic

Panasonic Genus TX-G10 Manual de usuario

Toshiba

Toshiba 19A20 Manual de usuario

Philips

Philips 25PT4523-16 Manual de usuario

Sony

Sony XBR-100Z9D Manual de usuario

Philips

Philips PR0930X3 Manual de usuario

Philips

Philips Brilliance 231P4QPY Manual de usuario

Samsung

Samsung 55S9 B Series Manual de usuario

Philips

Philips 32HF9385D Guía de solución de problemas

Sharp

Sharp LC-40FI5012E Manual de usuario

Loewe

Loewe Table Stand Reference 55 Manual de usuario

Philips

Philips 32PFH5300 Manual de usuario
