Haier HDW201WH Manual de usuario

61515

Parts Manual

Dishwasher

Model:

HDW201WH HA

Product Code:

61515

61515 - NOVEMBER 2009

Fisher & Paykel Appliances Ltd

78 Springs Road,

East Tamaki,

PO Box 58-732, Botany,

Manukau 2163,

New Zealand

Telephone: 09 273 0600

Facsimile: 09 273 0656

PRODUCT

Brand Haier

Voltage 220-240V, 50Hz

Model HDW201WH HA

Product Code 61515

61515

GUIDE TO USING THIS MANUAL

The model covered by this manual is listed on the front cover.

The information detailed in this manual is subject to change without notice. The latest version is indicated by

the reprint date and replaces any earlier editions.

The front cover picture shows the type of product and may not necessarily be an exact image of the model

covered by the manual.

Kit Parts

Kit components are shown in italics. Where a part number is shown against the descriptions for these kit

components, they are also available as separate items. In addition, some parts may be supplied with these

kits that are not available as separate items, and are therefore either not listed, or a part number is not

shown against the part description in this manual.

Parts List Key

italics Kit components or parts included are shown in italics. Refer to above notes: Kit Parts.

NI As a part reference, indicates the part is not illustrated on the diagram.

NOT USED As a part number, indicates the diagram part reference is not used in this manual.

CONTENTS

CABINET & BASKET AREA .............................................................................................................6

RETICULATION AREA.....................................................................................................................8

DOOR AREA...................................................................................................................................12

61515

CABINET & BASKET AREA

61515

CABINET & BASKET AREA

REF PART DESCRIPTION

1 H0120801875 COMPLETE TOP ASSEMBLY

2 H012G2150035 SHELF FASTENING SMALL BLOCK

3 H012G1310022 UPPER FRONT CROSSPIECE

4 H012G1020068 PAINTED RIGHT SIDE PANNEL

5 H0120805924 RIGHT UPRIGHT ASSEMBLY

6 H0120100074 UPPER BASKET

7 H0120201235 RACK FOR UPPER BASKET

8 H0120801727 CUTLERY BASKET

9 H0120103099 LOWER BASKET

10 H012G1310023 REAR INTERMEDIATE CROSSPIECES

11 H012G2160204 DRAIN HOSE STOP

12 H012G1310028 LOWER REAR CROSSPIECE

13 H012G2150046 TERMINAL BOX ASSEMBLY

14 H0120200964 WHEEL FOR LOWER BASKET

15 H0120200963 WHEEL FOR UPPER BASKET

16 H0120802145 THE STRUCTURE CAN BE ADJUST

17 H0120200967 BASKET RAIL STOP

18 H012G1020069 MOBILE RAIL FOR BASKET

19 H0120300248 TUB GASKET

20 H0120201260 KNIFE REST

21 H012G2130482 RIGHT BASEBOARD SIDE PLATE

22 H012G2130483 BASEBOARD

23 H0120105715 TRAY

24 H012G2130481 LEFT BASEBOARD SIDE PLATE

25 H012G1610002 ADJUSTABLE FOOT

26 H012G1451091 FRONT FOOT SUPPORT

27 H012G1310027 LOWER FRONT CROSSPIECE

28 H012G1020066 PAINTED LEFT SIDE PANNEL

29 H0120805453 LEFT UPRIGHT ASSEMBLY

30 H0120200065 COVER FOR FRONT CROSSPIECE

31 H0120200966 RAIL SUPPORT ASSEMBLY

32 H0120200124 UPRIGHT SMALL BLOCK

33 H012G2150037 HOOKING SMALL BLOCK

34 H012G4120003 SOUND INSULATION BACK COVER

35 H012G1310020 UPPER REAR CROSSPIECE

36 H012G2150036 HOOKING SMALL BLOCK

37 H0120802963 INSULATED TUB ASSEMBLY

38 H0120201261 INSERT CUTLERY BASKET

39 H0120201383 BRACKET BASKET

40 H0120103101 INSERT BASKET

41 H012G1451092 ADJUSTABLE FOOT

61515

RETICULATION AREA

61515

RETICULATION AREA

REF PART DESCRIPTION

42 H012G2160197 AIR OUTLET

43 H0120201008 BREATHER RING NUT

44 H012G4050157 O-RING

45 H012G4050253 PVC TUBE + 40% NITRILIC RUBBER

46 H012G4050157 O-RING

47 H012G2160200 CONNECTION FOR 3RD SPRAYER

48 H0120201003 3RD SPRAYER

49 H012G2160236 OUTER DUCT

50 H012G4050157 O-RING

51 H0120201007 BASKET GUIDE HOUSING

52 H012G2160194 RING NUT FOR OUTER DUCT FASTENIG

53 H0120801832 FEEDING DISPENSER ASSEMBLY

54 H0120201011 WATER DIVERSION PIPE

55 H0120201010 PIN FOR INNER DUCT HOOKING

56 H0120801726 UPPER SPRAYER ASSEMBLY

57 H012G6050040 MICRO SWITCH ELBI TYPE S3

58 H0120503119 FLOAT FOR ACQUASTOP

59 H0120202056 SUPPORT FOR FLOAT

60 H012G9381036A ACQUASTOP DEVICE

61 H012G1040029 TUBE CLAMP

62 H012G2140093 CONNECTOR

63 H012G1040029 TUBE CLAMP

64 H0120400028 POWER SUPPLY CABLE

65 H0120201008 BREATHER RING NUT

66 H012G4050157 O-RING

67 H012G2160197 AIR OUTLET

68 H012G2140061 DRAIN HOSE ASSEMBLY

69 H0120800379 THERMO LIMITER ASSEMBLY

70 H0120201009 EXTRACTABLE GLASS FILTER

71 H012G1040012 STAINLESS STEEL EXTRACTABLE FILTER

72 H0120200949 CYLINDRIC STAINLESS STEEL FILTER

73 H012G1040014 MICROFILTER (POLYESTHERE)

74 H0120201292 RING NUT FOR CUP FASTENING

75 H012G4050151 CUP GASKET

76 H012G2160191 COMPLETE CUP ASSEMBLY

77 H012G145199 TUBE CLAMP

78 H012G5040004 DRAIN PUMP

79 H012G4050158 O-RING

80 H012G6050043 1-LEVEL PRESSURE SWITCH

81 H012G2140067 PRESSURE SWITCH TUBE

82 H0120200239 SUPPORT FOR HEATER

83 H012G1040028 TUBE CLAMP

Continued next page…

61515

RETICULATION AREA
