Haier HDW100WHT Manual de usuario

Parts Manual

Dishwasher

Model:

HDW100WHT

Dishwasher Model:HDW100WHT BOM:FA05U0E0900

Edition:20 08/09

No. Spare parts

number Spare parts description in

English Qty

1 0120801750 Complete top 1

2 012G2150035 Shelf fastening small 3

3 0120200964 Wheel for basket 8

4 0120105148A Door hook 1

5 012G1310020 Upper rear crosspiece 1

6 012G1020066 Painted right side 1

7 012G1020068 Painted left side panel 1

8 0120807213 Insulated tub assembly 1

9 0120300248 Tub gasket 1

10 0120200967 Basket rail stop 4

11 012G1020069 Mobile rail for basket 2

12 0120200966 Rail support assembly 4

13 0120200124 Upright small block 2

14 012G2130482 Right baseboard side 1

15 012G2130481 Left baseboard side 1

16 012G2130483 Baseboard 1

17 0120200065 Cover for front 2

18 012G1310027 Lower front crosspiece 1

19 012G1451091 Front foot support 2

20 H012G1451092 Adjustable foot (Rear) 2

21 012G1310023 Rear intermediate 1

22 012G2160204 Drain hose stop 1

23 0120101601 Lower rear crosspiece 1

24 0120105715 Tray 1

25 012G1610002 Adjustable foot (Front) 2

26 0120106652 Upper basket 1

27 0120200963 Wheel for basket 8

28 0120200965 Wheel support pin 16

29 0120201235 Tilter for upper basket 2

30 0120801727 Cutlery basket 1

31 0120106687 Fix lower basket 1

32 0120106568 Strengthen iron(Left) 1

33 0120106569 Strengthen iron(Right) 1

34 012G2160241 Outer duct 1

35 012G4050157 O-Ring gasket 2

36 0120202777 upper sprayer base 1

37 0120202779 Inner duct 1

38 0120202780 Inner duct sealing 1

39 0120300947 Diversion pipe sealing 1

40 0120201019 Upper sprayer 1

41 0120202056 Support for float 1

42 0120505219 Float for Aquastop 1

43 012G6050040 Micro switch 1

44 012G5060020 1-way solenoid valve 1

45 0120800683 Water charging hose 1

46 0120400440 Power supply cable 1

47 012G2160197 Air break nozzle 1

48 0120201008 Breather ring nut 1

49 012G6010009 Thermo limiter 1

50 012G1450902 Bush for fastening of 1

51 012G8040038 Elasticity retainer 1

52 0124000661 Drain pump 1

53 012G4050158 O-Ring gasket 1

54 012G1040020 Band 1

55 012G2130193 U-support for drain 1

56 012G2140061 Drain hose 1

57 012G6050043 Water-level pressure 1

58 012G2140067 Pressure switch tube 1

59 012G8050084 Band 2

60 0120202556A Insulated tub inlet 1

61 012G1040020 Band 2

62 0124000163 Thermo limiter 1

63 012G4050150 O-Ring gasket 9

64 012G8060036 Dentiform retainer 1

65 0120203065 Water gutter 1

66 012G4050151 Cup gasket 1

67 0120201292 Ring nut for cup 1

68 012G1040014 Micro filter 1

69 0120200949 Inner filter screen 1

70 012G1040012 Plane filter screen 1

71 0120201009 Extractable glass-filter 1

72 0120202778 Inner duct 1

73 012G4050152 Rubber coupling 2

74 012G1040028 Band 4

75 012G2160193 Lower sprayer base 1

76 012G4050153 O-Ring gasket 1

77 0120201006 Ring nut for lower 1

78 0120201004 Lower sprayer base 1

79 0120201005 Lower sprayer column 1

80 012G1020070 Lower sprayer 1

81 012G4050162 Heater jacket 2

83 012G1250028 Heater support block 1

84 012G6040016 Heating element 1

85 012G405058 Ring 1

86 0120202557A Insulated tub inlet nut 1

87 012G9370094 Motor pump assembly 1

88 0120301100 Connection pipe 1

89 012G4050159 Vibration-proof ring 1

83 012G9350006 Motor support bracket 1

90 012G2140092 PVC velum for 1

91 0120202675 Duct for upper sprayer 1

92 012G4050242 Duct coupling 1

93 0124000821 connection capacitance 1

94 0120202527A Dashboard 1

95 0120801189 knob 1

96 0120203187 Closing handle 1

97 012G2130488 Power button 1

98 012G6040017 Red spy lamp 1

99 0124000084 Power supply switch 1

100 0124000657 Program select switch 1

101 0120400361B Complete wiring group 1

102 0120806358 Switch mechanism 1

109 012G1120047 outer door 1

110 0120800589 Complete hinge 1

111 012G9380558 Right hinge 1

112 012G9380559 Left hinge articulation 1

113 0120104971 Door spring 2

114 012G4050171 Door spring Cover 2

115 0120600060 Elasticity retainer 4

116 012G8080007 Hinge pin 2

117 0120106595 Inner door assembly 1

118 0124000215 Detergent dispenser 1

119 0120202617 PCB board cover 2

120 0124000658A PCB board 1

121 0120202618 PCB board cover 1

122 0120202582 PVC Velmn for PCB 1

123 012G2140089 Antijamming filter 1
