Firmware Upgrade Procedure

This document will take you through each step of the program installation

for the hähnel MODUS 360RT ﬁrmware upgrade procedure.

• The Firmware installation and ﬁrmware upgrade can only be

done with a Windows PC

• You will need a USB to Micro USB data cable to transfer data

Note

(1.1) Download and save the zip ﬁle

for Speedlight MODUS 360RT to

a Windows PC (available from

the relevant product page on

www.hahnel.ie - ensure that you

choose the correct brand)

Brands

Can = Canon

Nik = Nikon

Son = Sony

Fuj = Fujiﬁlm

M43 = Panasonic

M43 = Olympus

(1.2) Connect the MODUS 360RT to your PC

as shown below – you must connect

the MODUS 360RT before you begin

the upgrade procedure

* The USB to Micro USB cable must be data-

transmission compatible

* The MODUS 360RT power switch must be in

the OFF position & the MODUS battery removed

(1.3) Use the Unzip program on your

computer to open the zip ﬁle which

you have downloaded. You will see

4 language versions of the upgrade

procedure and the upgrade ﬁle.

Conﬁrm that the upgrade ﬁle is the

correct version for your product.

(1.4) Your PC windows version may ask for

permission to start the installation.

Proceed and allow the program to

start the installation procedure.

Download update

Step 1

OFF

(2.1) The Welcome screen is the ﬁrst step of the

installation. Read it carefully and press Next to

proceed

(2.2) Read the licence agreement carefully and then

click on ‘I agree’ and press Next

(2.3) Enter your user Name and Company (optional)

and press Next

Installation

Step 2

Enter your name

(2.4) Allow the Program to install the MODUS 360RT

Firmware folder on your PC. Press Next.

(2.5) Allow the Program to install a Shortcut Folder

MODUS 360RT Firmware on your PC.

(2.6) Program is now ready to do the installation.

Press Next.

(2.7) You have successfully installed the Firmware

program. Press Finish.

(2.8) The USB Driver required to connect the

Speedlight to the PC will now be installed.

Press Next to proceed.

(2.9) Press Finish to complete the Driver installation.

(2.10) A Shortcut Icon MODUS 360RT Firmware will

now appear on your PC Desktop.

(3.1) Click the MODUS 360RT Firmware Icon on your

desktop.

Firmware Update

Step 3

You are now ready to start the Firmware update of

your MODUS 360RT.

(3.2) The Hahnel Firmware Update program will now

open. Check once again that you have installed

the correct brand that matches your MODUS

360RT Speedlight. The new ﬁrmware version

number is also shown.

(3.3) Press Start to begin the ﬁrmware update.

Do not disconnect the Speedlight during this

process.

Brand

type

Firmware

version

(3.4) You have successfully completed the new

ﬁrmware upgrade to you MODUS 360RT.

Click on Exit to end.

If any error messages appear on the

screen, please click the Help button for

more info.

Note

(3.5) You may now remove the MODUS 360RT

from the PC. To check that you have the new

ﬁrmware on the MODUS 360RT, carry out the

following steps:

• Insert charged HLX-MD2 battery

• Turn ON the MODUS 360RT

• Press and hold the TEST button on the

bottom left corner. Keep pressed while you

switch on the power button. The new ﬁrmware

number will be displayed on the LCD.

Press &

hold

Thank you for choosing Hahnel products.

For more information please visit our website www.hahnel.ie
