Content
Safety Notice …………………………………………………..3
Digital Scope Meter………………………………………
…
…5
CHAPTER 1: Getting Started…………………………………6
General Check……………………………………
…
....6
User’s Interface……………………………………...…6
Input Connections…………………………………
....
.11
Function Check…………………………………
…
….12
To compensate probes…………………………
…..
...13
To display a signal automatically…………………....15
Using the Scope Meter……………………………
...
.15
CHAPTER 2: Operating Scope……………………………..18
Set Vertical System……………………………
…….
..18
Set Horizontal System…………………………
…….
.29
Set Trigger System………………………………
…..
.33
Save / Recall Waveforms and Setups……………...37
Utility Function……………………………
…………
...41
Signal Measurement……………………………
…..
..49
Cursor Measurement…………………………
….......
51
CHAPTER 3: Multimeter………………………………….....53
CHAPTER 4: Troubleshooting………………………
……
...65
CHAPTER 5: Specications……………
………………
…...66
CHAPTER 6: APPENDIX..................................................69
1000MENUAL.indd 2 2009-04-06 �� 9:06:45
General Safety Notice
1. Safety Terms and Symbols
Terms in this manual:
These terms may appear in this manual:
WARNING: Warning statements identify conditions or practices that could result in injury
or loss of life.
CAUTION: Caution statements identify conditions or practices that could result in
damage to this product or other property.
Terms on the Product:
These terms may appear on the product:
DANGER: indicates an injury hazard may be immediately accessible.
WARNING: indicates an injury hazard may be not immediately accessible.
CAUTION: indicates that a potential damage to the instrument or other property
might occur.
Symbols on the Product:
These symbols may appear on the product:
2. General Safety Information
Carefully read the following safety information in order to avoid any personal injury
or damage on this product or any products connected with it. Review the following
safety precautions carefully before operate the device to avoid any personal injuries or
damages to the device and any products connected to it. To avoid potential hazards use
the device as specied by this user’s manual only.
■ To Avoid Fire or Personal Injury.
■ Use Proper Power Cord. Use only the power cord specied for this product and
certied for the country of use.
1000MENUAL.indd 3 2009-04-06 �� 9:06:45
■ Connect and Disconnect Properly. Do not connect or disconnect probes or test
leads while they are connected to a voltage source.
■ Connect and Disconnect Properly. Connect the probe output to the
measurement device before connecting the probe to the circuit under test. Disconnect
the probe input and the probe reference lead from the circuit under test before
disconnecting the probe from the measurement device.
■ Observe All Terminal Ratings. To avoid re or shock hazard, observe all ratings
and markings on the product. Consult the product manual for further ratings information
before making connections to the product.
■ Use Proper Probe. To avoid shock hazard, use a properly rated probe for your
measurement.
■ Avoid Circuit or Wire Exposure. Do not touch exposed connections and
components when power is on.
■ Do Not Operate With Suspected Failures. If suspected damage occurs with the
device, have it inspected by qualied service personnel before further operations.
■ Provide Proper Ventilation. Refer to the installation instructions for proper
ventilation of the device.
■ Do not operate in Wet/Damp Conditions.
■ Do not operate in an Explosive Atmosphere.
■ Keep Product Surfaces Clean and Dry.
1000MENUAL.indd 4 2009-04-06 �� 9:06:45
Digital Scope Meters
Protek1000 Series digital scope meters offer exceptional waveform viewing and
measurements in a compact, lightweight package. Protek1000 series is ideal for
production test, eld service, research, design, education and training involving
applications of analog circuit tests and troubleshooting.
Product features:
■ Dual Channel, Bandwidth:
60MHz (Protek1006)
200MHz (Protek1020)
500MHz (Protek1050)
600MHz (Protek1160)
600MHz (Protek1260)
■ Maximum real-time sampling rate:
150MSa/s (Protek1006)
250MSa/s (Protek1020)
500MSa/s (Protek1050)
1GSa/s (Protek1160)
2GSa/s (Protek1260)
■ Memory depth:
32K points (Single Channel), 16K points (Dual Channels)
■ Color TFT LCD, 320×240 pixels resolution.
■ USB storage and printing supports, rmware upgrade via USB interface.
■ Adjustable waveform intensity, more effective waveform viewing.
■ One-touch automatic setup, ease of use (AUTOSET).
■ 15 Waveforms, 15 setups, supports CSV and bitmap format.
■ 20 Automatic measurements.
■ Automatic cursor tracking measurements.
■ Waveform recorder, record and replay dynamic waveforms.
■ User selectable fast offset calibration.
■ Built-in FFT function, Frequency Counter.
■ Pass/Fail Function.
■ Add, Subtract, Multiply and Division Mathematic Functions.
■ Advanced trigger types include: Edge, Pulse width.
■ Multiple Language User Interface.
■ Pop-up menu makes it easy to read and easy to use.
■ Built-in Chinese and English help system.
■ Easy-to-use le system supports Chinese & English characters le
name input.
■ Selectable 20 MHz bandwidth limit;
■ External trigger;
1000MENUAL.indd 5 2009-04-06 �� 9:06:45
CHAPTER 1: Getting Start
This chapter covers the following topics:
■ General Check
■ Functional Check
■ The User Interface
■ Input Connections
■ To compensate probes
■ To display a signal automatically
■ Using the Scope Meter
General Check
When you have got a new Protek1000 series scope meter, it is suggested that you
should perform a general inspection on the instrument according to the following steps:
■ Check the shipping container for damage:
Keep the damaged shipping container or cushioning material until the contents of the
shipment have been checked for completeness and the instrument has been checked
mechanically and electrically.
■ Check the accessories:
Accessories supplied with the instrument are listed in “Accessories” in this guide. If the
contents are incomplete or damaged，please notify our distributor at your local area or
the overseas sales dept. of GSI.
■ Check the instrument:
In case there is any mechanical damage or defect, or the instrument does not operate
properly or fails performance tests, please notify our distributor at your local area or the
overseas sales dept. of GSI.
User’s Interface
The rst thing to do with a new scope meter is to know its front panel. This chapter
helps to be familiar with the layout of the keys and how to use them. Read this chapter
carefully before further operations.
Front Panel (Figure 1-1):
The buttons allow you to use some of the functions directly but also bring up the manual
keys on the screen, which enable the access to many measurement features associated
with advanced functions, mathematics, and reference or to run control features.
1000MENUAL.indd 6 2009-04-06 �� 9:06:45
Figure 1-1
Protek1000 Series H/H Scope Meter Front Panel
1000MENUAL.indd 7 2009-04-06 �� 9:06:46
