Refrigerator

User Manual

GR33KN4686DVW

58 7337 0000/ EN/ AB/ 30/05/2022 15:08

7282946301

EN / 2

Please read this manual first!

Dear Customer

Please read this manual before using the product.

Thank you for choosing this Grundig product. We would like you to achieve the optimal effi-

ciency from this high quality product which has been manufactured with state of the art tech-

nology. To do this, carefully read this manual and any other documentation provided before

using the product and keep it as a reference.

Heed all information and warnings in the user manual. This way, you will protect yourself and

your product against the dangers that may occur.

Keep the user manual. Include this manual with the unit if you hand it over to someone else.

The following symbols are used in the user manual:

Hazard that may result in death or injury.

Important information or useful tips on operation.

Read the user manual.

Combustible material, warning against fire hazard.

NOTICE A hazard that may cause material damage to the product or its surroundings

The model information as stored in the product data base

can be reached by entering following website and search-

ing for your model identifier (*) found on energy label.

https://eprel.ec.europa.eu/

EN / 3

1 Safety Instructions ........................ 4

1.1 Intention of Use ............................ 4

1.2 Safety of Children, Vulnerable Per-

sons and Pets ..............................

1.3 Electrical Safety ............................ 5

1.4 Handling Safety ............................ 6

1.5 Installation Safety.......................... 6

1.6 Operational Safety ........................ 8

1.7 Food Storage Safety..................... 10

1.8 Maintenance and Cleaning Safety. 10

2 Environmental Instructions .......... 11

2.1 Compliance with the WEEE Direct-

ive and Disposing of the Waste

Product ........................................

3 Your Refrigerator .......................... 12

4 Installation ..................................... 12

4.1 Right Place For Installation............ 12

4.2 Electrical Connection .................... 13

4.3 Attaching the Plastic Wedges ....... 13

4.4 Adjusting the Legs........................ 14

4.5 Hot Surface Warning .................... 14

5 Preparation .................................... 14

5.1 What to Do for Energy Saving....... 14

5.2 First Use ....................................... 15

5.3 Climate Class and Definitions........ 15

6 Operating the Product .................. 15

7 Use of Your Appliance .................. 16

7.1 Control Panel of the Product......... 16

7.2 Storing Food In The Cooler Com-

partment.......................................

7.3 Crisper Technologies.................... 19

7.4 Dairy Products Cold Storage Area 19

7.5 Door Open Alert ........................... 20

7.6 Replacing the Illumination Lamp ... 20

7.7 AeroFresh..................................... 20

7.8 Using the Water Dispenser ........... 20

8 Maintenance and Cleaning .......... 22

9 Troubleshooting ............................ 23

EN / 4

1 Safety Instructions

This section includes the safety

instructions necessary to pre-

vent the risk of personal injury or

material damage.

Our company shall not be held

responsible for damages that

may occur if these instructions

are not observed.

Installation and repair opera-

tions shall always be performed

by authorized service.

Use original spare parts and ac-

cessories only.

Original spare parts will be

provided for 10 years, following

the product purchasing date.

Do not repair or replace any

component of the product un-

less it is clearly specified in the

user manual.

Do not perform any modifica-

tions on the product.

1.1 Intention of Use

This product is not suitable for

commercial use and should not

be used other than for its inten-

ded use. This product is de-

signed to be used indoors, at

home and similar places.

For example;

• In the staff kitchens of the

stores, offices and other work-

ing environments,

• In farm houses,

• In the units of hotels, motels or

other resting facilities that are

used by the customers,

• In hostels, or similar environ-

ments,

• In catering services and similar

non-retail applications.

This product shall not be used

in open or enclosed external en-

vironments such as vessels,

balconies or terraces. Exposing

the product to rain, snow, sun-

light and wind may cause risk of

fire.

1.2 Safety of Children,

Vulnerable Persons

and Pets

• This product may be used by

children aged 8 years and

older and persons with under-

developed physical, sensory

or mental capabilities or lack

of experience and knowledge

if they are being supervised or

have been given instruction

EN / 5

concerning use of the appli-

ance in a safe way and the

hazards involved.

• Children between 3 and 8

years are allowed to put and

take out food into/from the

cooler product.

• Electrical products are danger-

ous for children and pets. Chil-

dren and pets must not play

with, climb on, or enter the

product.

• Cleaning and user mainten-

ance should not be performed

by children unless there is

someone overseeing them.

• Keep the packaging materials

away from children. Risk of in-

jury and suffocation.

Before disposing of old

products that shall not be used

any more:

1. Unplug the power cord from

the mains socket.

2. Cut the power cable and re-

move it from the appliance

together with the plug.

3. Do not remove the racks and

drawers from the product to

prevent children from getting

inside the appliance.

4. Remove the doors.

5. Store the product so that it

shall not be tipped over.

6. Do not allow children to play

with the scrapped product.

• Do not dispose of the product

by throwing it into fire. Risk of

explosion.

• If there is a lock available on

the product’s door, keep the

key out of children's reach.

1.3 Electrical Safety

• The product shall not be

plugged into the outlet during

installation, maintenance,

cleaning, repair, and transport-

ation operations.

• If the power the cable is dam-

aged, it shall be replaced by

authorized service only to

avoid any risk that may occur.

• Do not tuck the power cord

under the product or to the

rear of the product. Do not put

heavy items on the power

cord. The power cable should

not be bent, crushed, and

come into contact with any

heat source.

• Do not use an extension cord,

multi-plug or adaptor to oper-

ate your product.

• Portable multi-plugs or port-

able power supplies may over-

heat and cause fire. Thus, do

not have a multi-plug behind

or in the vicinity of the product.

EN / 6

• The plug shall be easily ac-

cessible. If this is not possible,

a mechanism that meets the

electrical legislation and that

disconnects all terminals from

the mains (fuse, switch, main

switch, etc.) shall be available

on the electrical installation.

• Do not touch the plug with wet

hands.

• When unplugging the appli-

ance, don’t hold the power

cord, but the plug.

• When placing the device,

make sure that the feed cable

is not being pinched or dam-

aged.

• Do not place multi portable

sockets or portable power

supplies behind the device.

1.4 Handling Safety

• This product is heavy, do not

handle it by yourself.

• Do not hold the product from

its door while handling the

product.

• Be careful not to damage the

cooling system and the pipes

while handling the product. Do

not operate the product if the

pipes are damaged, and con-

tact an authorized service.

1.5 Installation Safety

• Contact the Authorized Ser-

vice for the product's installa-

tion. To prepare the product

for use, see the information in

the user manual and make

sure the electric and water util-

ities are as required. If not, call

a qualified electrician and

plumber to arrange the utilities

as necessary. Failure to do so

may result in electric shock,

fire, problems with the

product, or injury.

• Check for any damage on the

product before installing it. Do

not have the product installed

if it is damaged.

• Place the product on a clean,

level and hard surface and bal-

ance it with the adjustable

legs. Otherwise, the refriger-

ator may tip over and cause

injuries.

• The product shall be installed

in a dry and ventilated environ-

ment. Do not keep carpets,

rugs or similar covers under

the product. This may cause

risk of fire as a result of inad-

equate ventilation!

EN / 7

• Do not block or cover ventila-

tion holes. Otherwise, power

consumption increases and

your product may be dam-

aged.

• The product must not be con-

nected to supply systems

such as solar power supply.

Otherwise, your product may

be damaged due to sudden

voltage changes!

• The more refrigerant a refriger-

ator contains, the bigger its in-

stallation room should be. In

very small rooms, a flammable

gas-air mixture may occur in

case of a gas leak in the cool-

ing system. At least 1 m³ of

volume is required for each 8

grams of refrigerant. The

amount of the refrigerant avail-

able in your product is spe-

cified in the Type Label.

• The installation place of the

product shall not be exposed

to direct sunlight and it shall

not be in the vicinity of a heat

source such as stoves, radiat-

ors, etc. If you cannot prevent

installation of the product in

the vicinity of a heat source,

use a suitable insulation plate

and make sure the minimum

distance to the heat source is

as specified below:

– At least 30 cm away from

heat sources such as

stoves, ovens, heating units

and heaters, etc.,

– And at least 5 cm away from

electrical ovens.

• Your product has the protec-

tion class of I.

• Plug the product in a groun-

ded socket that conforms with

the Voltage, Current and Fre-

quency values specified in the

type label. The socket must

have a 10A – 16A fuse. Our

firm will not assume respons-

ibility for any damages due to

usage without earthing and

without power connection in

compliance with local and na-

tional regulations.

• The product’s power cable

must be unplugged during in-

stallation. Otherwise, risk of

electric shock and injury may

occur!

• Do not plug the product to

loose, broken, dirty, greasy

sockets or sockets that have

come out of their seats or

sockets with a risk of water

contact.

• Place the power cable and

hoses (if any) of the product so

that they shall not cause a risk

of tripping over.

EN / 8

• Penetration of humidity to live

parts or to the power cord

may cause short circuit. Thus,

do not use the product in hu-

mid environments or in areas

where water may splash (e.g.

garage, laundry room, etc.) If

the refrigerator is wet by wa-

ter, unplug it and contact an

authorized service.

• Do not ever connect your refri-

gerator to power saving

devices. These systems are

harmful for the product

1.6 Operational Safety

• Do not ever use chemical

solvents on the product.

These materials contain an ex-

plosion risk.

• In case of a failure of the

product, unplug it and do not

operate until it is repaired by

the authorized service. There

is a risk of electric shock!

• Do not place a source of flame

(e.g. candles, cigarettes, etc.)

on the product or in the vicinity

of it.

• Do not get on the product.

Risk of falling and injury!

• Do not cause damage to the

pipes of the cooling system

using sharp and piercing tools.

The refrigerant that sprays out

in case of puncturing the gas

pipes, pipe extensions or up-

per surface coatings may

cause irritation of skin and in-

jury to the eyes.

• Do not place and operate

electrical appliances inside the

refrigerator/freezer unless it is

advised by the manufacturer.

• Do not jam any parts of your

hands or your body to the

moving parts inside the

product. Be careful to prevent

jamming of your fingers

between the refrigerator and

its door. Be careful while

opening or closing the door if

there are children around.

• Do not put ice cream, ice

cubes or frozen food to your

mouth as soon as you take

them out of the freezer. Risk of

frostbite!

• Do not touch the inner walls,

metal parts of the freezer or

food kept inside the freezer

with wet hands. Risk of frost-

bite!

• Do not place soda cans or

cans and bottles that contain

fluids that may be frozen to

the freezer compartment.

EN / 9

Cans or bottles may explode.

Risk of injury and material

damage!

• Do not use or place materials

sensitive against temperature

such as flammable sprays,

flammable objects, dry ice or

other chemical agents in the

vicinity of the refrigerator. Risk

of fire and explosion!

• Do not store explosive materi-

als such as aerosol cans with

flammable materials inside the

product.

• Do not place cans containing

fluids over the product.

Splashing of water on an elec-

trical part may cause the risk

of an electric shock or a fire.

• This product is not intended

for storage and cooling of

medicines, blood plasma,

laboratory preparations or sim-

ilar materials and products

that are subject to the Medical

Products Directive.

• If the product is used against

its intended purpose, it may

cause damage to or deteriora-

tion of the products kept in-

side.

• If your refrigerator is equipped

with blue light, do not look at

this light with optical devices.

Do not stare directly at UV

LED light for a long time. Ultra-

violet rays may cause eye

strain.

• Do not fill the product with

more food than its capacity.

Injuries or damages may occur

if the contents of the refriger-

ator fall when the door is

opened. Similar problems may

also occur when an object is

placed over the product.

• Ensure that you have removed

any ice or water that may have

fallen to the floor to prevent in-

juries.

• Change the locations of the

racks/bottle racks on the door

of your refrigerator only when

the racks are empty. Danger

of injury!

• Do not place objects that may

fall/tip over on the product.

These objects may fall while

opening or closing the door

and cause injuries and/or ma-

terial damages.

• Do not hit or exert excessive

pressure on glass surfaces.

Broken glass may cause injur-

ies and/or material damages.

• The cooling system in your

product contains R600a refri-

gerant. The refrigerant type

used in the product is spe-

cified in the type label. This

EN / 10

gas is flammable. Therefore,

be careful not to damage the

cooling system and the pipes

while operating the product. In

case of damage to the pipes;

1. Do not touch the product or

the power cable.

2. Keep the product away from

potential sources of fire that

may cause the product to

catch fire.

3. Ventilate the area where the

product is placed. Do not

use a fan.

4. Contact Authorized Service.

5. If the product is damaged

and you observe gas leak,

please stay away from the

gas. Gas may cause frostbite

if it contacts your skin.

1.7 Food Storage

Safety

Please pay attention to the fol-

lowing warnings to avoid food

spoilage:

• Leaving the doors open for a

long time may cause the tem-

perature inside the product to

rise.

• Regularly clean the accessible

drainage systems in contact

with food.

• Clean the water tanks that

have not been used for 48

hours and mains-fed water

systems that have not been

used for more than 5 days.

• Store raw meat and fish

products in appropriate com-

partments within the product.

Thus, it does not drip on or

come into contact with other

foods.

• Two-star freezer compart-

ments are used for storing

pre-filled foods, making and

storing ice and ice cream.

• One, two and three-star com-

partments are not appropriate

for freezing fresh food.

• If the cooling product has

been left empty for a long

time, turn off the product, de-

frost, clean, and dry the

product in order to protect the

housing of the product.

1.8 Maintenance and

Cleaning Safety

• Do not pull by the door handle

if you shall move the product

for cleaning purposes. Handle

may cause injuries if it is pulled

too hard.

Tabla de contenidos

Otros manuales de Refrigerador de Grundig

Grundig

Grundig GFNI 12410 Manual de usuario

Grundig

Grundig GKN 26860 XRHN Manual de instrucciones

Grundig

Grundig GKNM17822X Manual de usuario

Grundig

Grundig GKFI5050 Manual de usuario

Grundig

Grundig GPRND47731 Manual de usuario

Grundig

Grundig GSND 6282 S Manual de usuario

Grundig

Grundig GSBS14620XWF Manual de usuario

Grundig

Grundig GTMI 10120 Manual de usuario

Grundig

Grundig GKND 5600 Manual de usuario

Grundig

Grundig GKF15810DN Manual de usuario

Grundig

Grundig GKNE 268E40 FXN Manual de usuario

Grundig

Grundig GTNI 10320 Manual de usuario

Grundig

Grundig GKNE 4750 Manual de usuario

Grundig

Grundig GKNG 26840 Manual de usuario

Grundig

Grundig GKPN66840LXPW Manual de usuario

Grundig

Grundig GDN17920X Manual de usuario

Grundig

Grundig GKPN46820FX Manual de usuario

Grundig

Grundig GKNR16820 Manual de usuario

Grundig

Grundig GKN 26840 XN Manual de instrucciones

Grundig

Grundig GSMI24330N Manual de usuario

Grundig

Grundig GFT 12320 Manual de usuario

Grundig

Grundig GFNR 13820 XN Manual de usuario

Grundig

Grundig GKN27960FHXPN Manual de usuario

Grundig

Grundig GKNE26870FXPN Manual de usuario

Manuales populares de Refrigerador de otras marcas

Bonnet Neve

Bonnet Neve SKYVIEW PLUS Manual de usuario

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Manual de usuario

Sharp

Sharp SJ-BA31IEXW2-EU Manual de usuario

CORBERO

CORBERO CC2300MCW Manual de usuario

KitchenAid

KitchenAid 2205264 Manual de usuario

Stengel

Stengel KU 1101 A++ Manual de usuario

NEFF

NEFF KI181 Series Manual de usuario

Hoshizaki

Hoshizaki Reach-In Manual de usuario

Amana

Amana ASD2524VES00 Manual de usuario

BOMANN

BOMANN KGC 213 Manual de usuario

Danby

Danby DAR044A1SLDD Instrucciones de montaje

Samsung

Samsung RF323TE Manual de usuario

Beko

Beko CSA31022 Manual de usuario

IKEA

IKEA FROSTIG C 185 E Manual de usuario

Electrolux

Electrolux ER 6821 D Manual de usuario

True

True TS-28 Manual de usuario

Frigidaire

Frigidaire FSC23R5DW9 Manual de usuario

Beko

Beko LSP4579W Manual de usuario
