Grundig Sonoclock 691 DAB+ Manual de usuario

KITCHEN RADIO

Sonoclock 691 DAB+

-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------

ON/OFF DISPLAY

PRESETS

1 – 5

6 – 10

+ 5 SELECT/

INFO

+ VOL. –

SLEEP MENU MODE

SCAN

ALARM

-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------

DEUTSCH

6 AUFSTELLEN UND SICHERHEIT

7 AUF EINEN BLICK

8 STROMVERSORGUNG/AUFSTELLEN

9 EINSTELLUNGEN

12 BETRIEB

14 TIMER-BETRIEB

15 SONDERFUNKTIONEN

16 INFORMATIONEN

ENGLISH

17 SET-UP AND SAFETY

18 OVERVIEW

19 POWER SUPPLY/INSTALLATION

20 SETTINGS

23 OPERATION

24 TIMER MODE

26 SPECIAL FUNCTIONS

27 INFORMATION

FRANCAIS

28 INSTALLATION ET SÉCURITÉ

29 APERÇU

30 ALIMENTATION ÉLECTRIQUE/

INSTALLATION

31 RÉGLAGES

34 FONCTIONNEMENT

35 MODE MINUTERIE

37 FONCTIONS SPÉCIALES

38 INFORMATIONS

ITALIANO

39 INSTALLAZIONE E SICUREZZA

40 PANORAMICA

41 ALIMENTAZIONE/INSTALLAZIONE

42 IMPOSTAZIONI

45 FUNZIONAMENTO

46 MODALITÀ TIMER

48 FUNZIONI SPECIALI

49 INFORMAZIONI

PORTUGUÊS

50 INSTALAÇÃO E SEGURANÇA

51 VISÃO GERAL

52 ALIMENTAÇÃO ELÉCTRICA/

INSTALAÇÃO

53 DEFINIÇÕES

56 FUNCIONAMENTO

57 MODO TIMER (TEMPORIZADOR)

59 FUNÇÕES ESPECIAIS

60 INFORMAÇÕES

ESPAÑOL

61 SEGURIDAD E INSTALACIÓN

62 INFORMACIÓN GENERAL

63 ALIMENTACIÓN/INSTALACIÓN

64 CONFIGURACIÓN

67 FUNCIONAMIENTO

68 MODO TEMPORIZADOR

70 FUNCIONES ESPECIALES

71 INFORMACIÓN

NEDERLANDS

72 INSTALLATIE EN VEILIGHEID

73 OVERZICHT

74 STROOMTOEVOER/INSTALLATIE

75 INSTELLINGEN

78 WERKING

79 TIMERMODUS

81 SPECIALE FUNCTIES

82 INFORMATIE

POLSKI

83 USTAWIENIE I BEZPIECZEŃSTWO

84 OPIS OGÓLNY

85 ZASILANIE/INSTALACJA

86 USTAWIENIA

89 OBSŁUGA

90 TRYB TIMER (PROGRAMATOR CZASOWY)

92 FUNKCJE SPECJALNE

93 INFORMACJA

DANKS

94 OPSÆTNING OG SIKKERHED

95 OVERSIGT

96 STRØMFORSYNING/INSTALLATION

97 INDSTILLINGER

100 FUNKTION

101 TIMER

103 SPECIELLE FUNKTIONER

104 INFORMATION

SVENSKA

105 SÄKERHET OCH INSTALLATION

106 ÖVERSIKT

107 STRÖMFÖRSÖRJNING/INSTALLATION

108 INSTÄLLNINGAR

111 ANVÄNDNING

112 TIMERLÄGE

114 SPECIALFUNKTIONER

115 INFORMATION

SUOMI

116 TURVALLISUUS JA ASETUKSET

117 YLEISKATSAUS

118 VIRTALÄHDE/ASENNUS

119 ASETUKSET

122 TOIMINTA

123 AJASTINTILA

125 ERIKOISTOIMINNOT

126 TIETOJA

TÜRKÇE

127 KURULUM VE GÜVENLİK

128 GENEL BAKIŞ

129 GÜÇ KAYNAĞI/KURULUMU

130 AYARLAR

133 ÇALIŞTIRMA

134 ZAMANLAYICI MODU

136 ÖZEL FONKSİYONLAR

137 BİLGİLER

-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------

ENGLISH

This device is designed for the playback of

audio signals.

Any other use is expressly prohibited.

Make sure the device is protected from drip-

ping or splashing water.

Do not place any vessels such as vases on the

device. These may be knocked over and spill

fluid on the electrical components, thus present-

ing a safety risk.

Do not place any naked flames such as candles

on the device.

Ensure that the device is adequately ventilated

by placing it at least 10 cm from any other ob-

ject.

Do not cover the device with newspapers, table

cloths, curtains, etc.

Only use the device in a moderate climate.

If malfunctions occur due to static electricity

charges or fast transient (burst), reset the de-

vice. To do this, pull out the power plug and

connect it again after a few seconds.

When deciding where to place the device,

please note that furniture surfaces are covered

by various types of varnish and plastic, most of

which contain chemical additives. These addi-

tives can corrode the device supports, leaving

residues on the furniture surfaces which can be

difficult or impossible to remove.

Do not use any cleaning agent, as this may

damage the casing. Clean the device with a

clean, dry cloth.

Never open the device casing. The manufac-

turer will not accept any liability for damage

resulting from improper handling.

SET-UP AND SAFETY

-----------------------------------------------------------------------------------------------

ENGLISH

OVERVIEW

---------------------------------------------------------------------------------------------------------------------------------

See the figure on page 3.

Controls on the front

ON/OFF Switches the device on and

off.

1 till 10 Preset buttons for storing

and selecting radio stations.

Display Shows various information

such as channel name, time,

alarm time, volume and the

menu.

+ 5 Activates the second level

(6 to 10) of preset buttons 1

to 5.

SLEEP Sets the sleep timer.

MENU Opens and closes the menu.

SELECT/INFO Confirms settings in the

menu.

MODE SCAN

ALARM

In standby mode: activates

and deactivates the alarm

function.

In operating mode: short

press selects the input

source DAB or FM radio;

when you press and hold

down, it starts auto tuning for

DAB and FM radio stations.

+ VOL. – Adjusts the volume;

selects menu options.

Controls on the back

AC ~ Power cable.

Pull out the power cable

when you want to discon-

nect the device from the

mains.

–

Wire antenna for DAB and

FM reception.

Controls on the bottom

USB USB socket for upgrading

the software of the device.

ENGLISH

Connecting to the mains supply

Note:

Check that the mains voltage on the type

plate (on the bottom of the device) corre-

sponds to your local mains supply. If this is

not the case, contact your specialist dealer.

1 Plug the power cable into the socket (230 V~,

50/60 Hz).

Caution:

The device is connected to the mains with the

power cable. Pull out the power cable when

you want to disconnect the device from the

mains.

Make sure the power plug is easily acces-

sible during operation and not hindered by

other objects.

POWER SUPPLY/INSTALLATION -------------------------------------------------

Setting up the device

The speaker of the device is located at the bottom

of the device. To optimise the sound, mount the

device holder on the bottom of the device.

1 Click the device holder in place in the recesses

on the bottom of the device.

VOL.

Mounting the device under the

cabinet

The fixing screws can be found in the side com-

partment of the packing.

1 Mark the locations for four mounting screws.

2 Screw the device holder under the cabinet with

four screws.

VOL.

3 Insert the device in the holder.

Note:

To remove the device, press the snap-catch

at the back and remove by pulling forwards.

ENGLISH

Tuning and storing radio stations

(DAB and FM) – first installation

When the device is connected to the mains for

the first time or after factory reset, the Auto Tun-

ing System will start to scan the whole DAB band-

width and store in the program list.

The device will then scan the FM waveband and

store the first 10 radio stations as presets 1 to 10.

The time is updated automatically.

1 Press »ON/OFF« to switch on the device.

– Display: »WELCOME« and then »SCAN«.

– The automatic station search starts, searches

and stores the radio stations.

– After the automatic scan, the device switches

to standby, the current time lights up.

Tuning and storing DAB radio

stations – after a removal

You can activate the Auto Tuning System again.

That is reasonable, if you will use the device in

another place or search new DAB radio stations.

1 Press »ON/OFF« to switch on the device.

– Display: the name of the radio station, e.g.

»B5 AKT«.

2 Start the automatic station search by pressing

and holding down »MODE SCAN ALARM«.

– Display: »SCAN«.

– The automatic station search starts, searches

and stores the radio stations in the program

list.

Note:

You can also activate the automatic scan for

DAB and FM radio stations from the menu.

Open the menu with »MENU«.

Select the option »SYSTEM« with »+ VOL. -«

and confirm by pressing »SELECT/INFO«.

Select the option »ATS« with »+ VOL. -« and

press »SELECT/INFO« to confirm (display:

»N«).

Select »Y« with »+ VOL. -« and start the

automatic station search by pressing

»SELECT/INFO«.

SETTINGS

---------------------------------------------------------------------------------------------------------------------------------------

Storing DAB radio stations to

presets

After the automatic station search, all radio sta-

tions will be stored in the program list. You can

store your favored radio stations on presets 1 to

10.

1 Open the menu with »MENU«.

2 Select the option »STATION« with »+ VOL. -«

and press »SELECT/INFO« to confirm.

3 Select DAB radio stations with »+ VOL. -« and

press »SELECT/INFO« to confirm

4 For storing the DAB radio station on a preset,

press and hold down the required preset but-

ton »1« to »5«, until »STORED« appears.

Note:

Press »+5« for a short time and then the re-

quired preset buttons »1« to »5« change for

presets 6 to 10.

Programming DAB radio stations

– manually

1 Open the menu with »MENU«.

2 Select the option »MANUAL« with »+ VOL. -«

and press »SELECT/INFO« to confirm.

– Display: e.g. »I74.9 SA« (frequency and

channel of a DAB radio station).

3 Select the desired frequency/channel with

»+ VOL.« or »VOL. -«.

4 Press »SELECT/INFO« to confirm the frequen-

cy/channel.

– Display: the signal strength, the DAB radio

stations will be stored in the program list.

5 Press »MENU« to end the setting.

ENGLISH

SETTINGS

---------------------------------------------------------------------------------------------------------------------------------------

Programming FM radio stations –

manually

1 To select FM radio as input source, press

»MODE SCAN ALARM« for a short time.

– Display: »FM«, then the name or the frequen-

cy of the FM radio station.

2 Open the menu with »MENU«.

3 Select the option »TUNE« with »+ VOL. -« and

press »SELECT/INFO« to confirm.

4 Press and hold down »+ VOL.« or »VOL. -« to

search the desired radio station.

– The automatic station search starts, and stops

at the next station with a strong signal;

briefly pressing »+ VOL.« or »VOL. -« until

you have found the frequency you want.

– The frequency changes in steps of 50 kHz.

5 To store the FM radio station on a preset, press

and hold down the required preset buttons »1«

to »5«, until »STORED« appears.

Press »+5« and the required preset buttons »1«

to »5« change for presets 6 to 10.

Note:

The device normally scans for FM radio sta-

tions which are strong enough to get good

reception. To scan radio stations with weak

signal:

Open the menu with »MENU«, select the

option »SCAN« with »+ VOL. -« and press

»SELECT/INFO« to confirm.

Select the option »DX« with »+ VOL. -« and

press »SELECT/INFO« to confirm.

Repeat the setting from point 2.

Setting the clock format

(12 or 24 hours)

1 Press »ON/OFF« to switch on the device.

– Display: e.g. »B5 AKT«.

2 Open the menu with »MENU«.

3 Select the option »SYSTEM« with »+ VOL. -«

and press »SELECT/INFO« to confirm.

4 Select the option »TIME« with »+ VOL. -« and

press »SELECT/INFO« to confirm.

– Display: »SET TIME«.

5 Select the option »12/24 HR« with »+ VOL. -«

and press »SELECT/INFO« to confirm.

– Display: »24«.

6 Select the desired clock format (12 or 24

hours) with »+ VOL. -«.

7 Press »SELECT/INFO« to confirm the setting.

8 Press »MENU« to end the setting.

Tabla de contenidos

Otros manuales de Radio de Grundig

Grundig

Grundig DKR 2000 Manual de usuario

Grundig

Grundig TR 1200 Manual de usuario

Grundig

Grundig TR 1200 Manual de usuario

Grundig

Grundig GRUNDIG YB300 Manual de usuario

Grundig

Grundig GUADAB08IP Manual de usuario

Grundig

Grundig Ocean Boy 70 Manual de usuario

Grundig

Grundig WTR 3000 BT Manual de usuario

Grundig

Grundig FR200 Instrucciones de funcionamiento

Grundig

Grundig SATELLIT 750 Manual de usuario

Grundig

Grundig SATELLIT 750 Manual de usuario

Grundig

Grundig S450DLX Manual del propietario

Grundig

Grundig Sonoclock 55 SC 5305 Manual técnico

Grundig

Grundig World Receiver G-2000A Manual de usuario

Grundig

Grundig CLASSIC 960 Manual de usuario

Grundig

Grundig 01M-GDB1030-4620-02 Manual de usuario

Grundig

Grundig Sonoclock 50 Manual técnico

Grundig

Grundig Sonoclock 30 SC 3000 Manual técnico

Grundig

Grundig G2 REPORTER Manual de usuario

Grundig

Grundig YB500 Manual de usuario

Grundig

Grundig G6 AVIATOR Manual de usuario

Grundig

Grundig TR 2200 DAB Plus Manual de usuario

Grundig

Grundig 5450DLX Manual de usuario

Grundig

Grundig Sonoclock 51 Manual técnico

Grundig

Grundig Music 61 Manual de usuario

Manuales populares de Radio de otras marcas

EisSound

EisSound KBSound iSelect Manual de usuario

Midland

Midland 1001LWX Manual de usuario

Konig

Konig HAV-SR41 Manual de usuario

Roberts

Roberts exprssion Manual de usuario

VDigi

VDigi DD3.0 Manual de usuario

Radio Shack

Radio Shack 21-1863 Manual de usuario

Roberts

Roberts Stream 207 Manual de usuario

Sony

Sony Walkman SRF-M97 Manual de usuario

Stanley

Stanley FatMax FMC770 Manual de usuario

auna

auna DAB-Radio 10026947 Manual de usuario

SOUNDMASTER

SOUNDMASTER UR190 Manual de usuario

HYT

HYT TC-320 Manual de usuario

auna multimedia

auna multimedia Yellowstone 10026851 Manual de usuario

B-Tech

B-Tech GMRS-V2 Manual de usuario

Weierwei

Weierwei VEV-V8 Manual de usuario

SOUNDMASTER

SOUNDMASTER DAB750 Manual de usuario

Telefunken

Telefunken TF-1505 Manual de usuario

Makita

Makita LXRM03 Manual de usuario
