Table of Contents
GENERAL
”Service per mouse click “ ((flash-programming,Digi 100 chassis) .................................................................. e_01/01
AUDIO / HiFi
M 100 CD MK II................................................................................................................................................ e_01/01
CAR AUDIO
Navigation system GPS 3 ................................................................................................................................ e_01/01
DVD
DVD-Player GDV 100D, GDV 100D/002, GDV 110, GDV 200, Xenaro GDP 5100,
GDP 5102, GDP 5120, GDP 6150, Malaga SE 1230 ...................................................................................... e_01/01
SAT
Satellite headend station STC 1880 ................................................................................................................ e_01/01
TV
Colour TV sets wit the chassis Digi Basic 3 - CUC 1832, 1930 and 1931 ....................................................... e_01/01
Flash programming for the new Digi 100 generation ....................................................................................... e_02/01
Special functions (options) for the colour TV sets with the chassis Digi 100 ................................................... e_03/01
Chassis Digi 100 - Flash-Programmer FProg1 ................................................................................................ e_04/01
Chassis CUC 21… - Service Documents ........................................................................................................ e_04/01
Colour TV sets with the chassis CUC 2103 and CUC 2121 ............................................................................ e_05/01
Replacing the memory EEPROMs with the chassis CUC 2103, 2105, 2121, and 2130 ................................. e_07/01
Burned battery socket or battery connecting cable P 37-830/12 and P 37-840/12 SAT, and eqivalent units... e_08/01
Damage to the bottom corners and edges of the TV sets Lenaro MFW 84 - 6110 and MFW 92 - 6110 ......... e_09/01
TV sets with Digi 100 chassis .......................................................................................................................... o_01/01
TP 750/715 and equivalent units...................................................................................................................... o_02/01
ST 70-2103 SAT retrofitting not possible.......................................................................................................... o_03/01
General
Central
After-Sales Service
Service Information
MWLE_0201 (8002/8012_o. DK, F, N, S, SF, P / 8003_MT)
1/2
Serial No. 01/01
”Service per mouse click “ (flash-programming, Digi 100 chassis)
Dear business partner,
For an optimum stationary and mobile product support of our new CTV
models generation fitted with the DIGI 100 chassis, we are able to offer you
the Flash-Programmer F-Prog. 1“. This is a service interface enabling the
dialogue between the CTV terminal unit and a desktop or notebook PC.
With the help of a PC and the Flash-Programmer F-Prog. 1, software updating
can be carried out both in the workshop and on-site at the end user.
This kind of updating guarantees an immediate availability of the current
software. With this TV set type, order/delivery delays as well as the repair
through EPROM updating are a thing of the past. We are sure that this way
of software updating will make its entrance also with future products.
The F-Prog. 1 (material number 759880740000) will be offered at a price of
DM 29.90 (EUR 15.29) plus VAT.
Scope of delivery: Flash programmer (RS232 converter)
RS232 cable (25-to-9-pin)
Diskette (PC software and user manual)
We recommend you to make use of the order option via the Internet.
Of course you may still order the F-Prog. 1 also via the Hotline number
++49 911 93394828 or via email: [email protected].
As registered Grundig reseller you are authorized to access the Grundig
spare parts master record. Please let assign you via the below stated address
your individual password after indicating your customer number:
email: [email protected].
For ordering via the Internet, please follow the instructions below:
- Start the Microsoft Internet xplorer or Netscape Navigator.
- Enter the address: http://www.grundig.com
- Click to Info + Products.
- Position the mouse pointer to Service and click to Reseller Support.
- Click to spare parts: ordering and listings, service documents.
- Login by entering your customer number and password.
- Enter the product number (759880740000) then click to search now.
Note: on this display you will also find the link to downloading the
current device software (spare parts listings and service documents)
- Click to the appearing product number 759880740000.
- Click to put into cart.
- Click to shopping cart in the head bar.
- Click to offer.
- Click to send order.
In cooperation with one of our suppliers we have establisehd for you an offer for a Notebook which,
because of its configuration, is especially appropriate for the on-site updating at the customer.
Manufacturer/ type: Fujitsu-Siemens Liteline 325 A
Features: AMD K6-2 500MHz
64 MB RAM
5.0 GB Hard Drive
12.1" HPA Display 1024 x 768
24x CD-ROM
NiMH accu
56k modem
MS Windows 98 SE
MS Works Suite 2000
12 months bring-in guarantee
Price: DM 2,450.00 plus VAT
EUR 1,252.67 plus VAT
Please place your order directly to :
Grundig AG
Zentralkundendienst
Beuthener Straße 55
D-90471 Nürnberg
Kind regards
Yours
GRUNDIG Central After-Sales Service
Enclosure: Hotline and further contact addresses of the supplier of the PC.
Hotline und weitere Kontaktadressen
Bitte halten Sie vor Ihrem Kontakt mit der PC-Hotline oder mit unseren Servicepartnern immer die Identnr. Ihres Geräts griff-
bereit (siehe Beispiel Typenschild).
PC-Hotline
Bei Fragen oder Problemen hilft Ihnen gerne die PC-Hotline weiter.
Öffnungszeiten Montag bis Freitag von 9.00 – 18.00 und Samstag von 9.00 – 14.00.
Consumer-PC’s (SCENIC Xpert) + 49 (0) 180 / 3 77 70 04 (Tarif DM 0,18/min.)
Notebooks + 49 (0) 180 / 3 77 70 01 (Tarif DM 0,18/min.)
Business-PC’s + 49 (0) 180 / 3 77 70 00 (Tarif DM 0,18/min.)
Workstations + 49 (0) 180 / 3 77 70 03 (Tarif DM 0,18/min.)
Fax: + 49 (0) 821 / 8 04 37 50 (Tarif DM 0,18/min.)
Siemens IT Service Call Management Center
Call Center (Störannahme) Öffnungszeiten durchgehend + 49 (0) 180 / 5 40 40
Fax: + 49 (0) 180 / 5 33 67 79
weitere Kontaktadressen
Die Adressen der Servicepartner finden Sie in dem zu Ihrem Fujitsu Siemens Produkt mitgelieferten Serviceadressheft oder
im Internet, Webseite http://www.fsc-pc.de/Kontakt.asp
auf dem Abruffax Fax: + 49 (0) 821 / 8 04 27 01
in der PC Service Mailbox + 49 (0) 821 / 8 04 33 33 (analog)
+ 49 (0) 821 / 81 40 07 (ISDN)
+ 49 (0) 821 / 8 29 71 (ISDN)
Auch Ihr Vertriebspartner, bei dem Sie das Produkt gekauft haben, gibt Ihnen gerne Auskunft. Für weitere Fragen oder Be-
merkungen bezüglich unserer Garantie, wenden Sie sich bitte an Ihren Vertriebs- oder Servicepartner oder an:
Fujitsu Siemens Computers GmbH
Service Management
D - 86147 Augsburg
Hotline and further Contact Addresses
Please always keep handy the identification no. of the product concerned (see type plate example) before contacting our PC
Hotline or our service partners.
PC Hotline
In the case of questions or problems our PC Hotline personnel will be glad to assist you. Hours of business on Monday
through Friday from 9 to 18 hours and Saturdays from 9 to 14 hours.
Consumer PCs (SCENIC Xpert) +49 (0) 180 / 3 77 70 04 (tariff 0.18 DM/min.)
Notebooks +49 (0) 180 / 3 77 70 01 (tariff 0.18 DM/min.)
Business PCs (SCENIC Xpert) +49 (0) 180 / 3 77 70 00 (tariff 0.18 DM/min.)
Workstations +49 (0) 180 / 3 77 70 03 (tariff 0.18 DM/min.)
Fax: +49 (0) 180 / 3 77 70 04 (tariff 0.18 DM/min.)
Notebooks +49 (0) 821 / 8 04 37 50 (tariff 0.18 DM/min.)
Siemens IT Service Call Management Center
Call Center (failures reception) Round-the-clock hours of business +49 (0) 180 / 5 40 40
Fax: +49 (0) 180 / 5 33 67 79
Further Contact Addresses
The addresses of our service partners are to be found in the service address booklet supplied with your Fujitsu Siemens
product, or
in the Internet, Web page http://www.fsc-pc.de/Kontakt.asp
under the polling Fax No. +49 (0) 821 / 8 04 27 01
in the PC Service Mailbox +49 (0) 821 / 8 04 33 33 (analog)
+49 (0) 821 / 81 40 07 (ISDN)
+49 (0) 821 / 8 29 71 (ISDN)
Your reseller where you have purchased the product will also be glad to provide you with the necessary information. For
further information on our guarantee please contact your sales or service partner, or:
Fujitsu Siemens Computers GmbH
Service Management
D – 86147 Augsburg
8002/12, 8003/13, 8005/15
46161(8002/8012, 8005/8015)
Returns
analysis
Unit:
Service Information
AUDIO / HIFI
Serial no. 1/01
M 100 CD MK II
Possible complaint:
CD’s are at times not read, tracks are not found.
Remedy:
Replacement of the microprocessor CIC 1 carrying the designation
D78P048 AGF M 100 CD with a D78P048 AGF CD-05 MK-II.
Workshop:
In the event of a complaint, replace the microprocessor along with new
software.
Stockkeeping:
CIC 1, D78P048 AGF CD-05 MK-II, part no. 59798 419 0000
1/1
44241000 (9033)
Returns
analisys
Unit:
Service Information
CAR AUDIO
Serial no.
Navigation system GPS 3
Possible complaint:
The colours of the leads to socket 3 (voltage supply) of the cable tree supplied do
possibly not correspond with the information given in the mounting instructions.
Remedy:
Please consult the excerpt of the updated mounting instructions:
Workshop:
Please observe in the event of a complaint.
Stockkeeping:
none
1/1
1/01
ENGLISH
7
CONNECTIONS TO THE CABLE TREE ________________________________________
Socket
:: to ISO plug
of the vehicle (ISO socket)
1white SCV
2green/yellow Mute
3red /white
4clamp 15/30 ignition (clamp 15) red line
5blue Aerial
6orange Illumination
7clamp 15/30 (continuous plus, clamp 30) yellow line
8brown Earth
Connections 3and 5are transferred directly to plug
(for the car radio).
Plug 1: telephone connection (6-pin) GRUNDIG devices since WKC 5300 RDS
11
pink Telephone: AF output
12
black Telephone: earth
When using DAB and a navigation system (to be carried out by a qualified workshop):
Remove plug 1, pins 11 and 12, and insert them into the corresponding plug of the DAB system.
12
11
1 3 5 7
2468
All illustrations show the plug
layout from the rear.
43280100 (8002/8012, 8005/8015)
Returns
analysis
Unit:
Service Information
DVD
Serial no.
DVD-Player GDV 100D, GDV 100D/002, GDV 110, GDV 200,
Xenaro GDP 5100, GDP 5102, GDP 5120, GDP 6150, Malaga SE 1230
1/1
01/01
Controlling the DVD players with the TP 100C, TP 110C and TP 130C TV
remote controls
The basic functions of the above DVD players can be controlled with the TV
remote controls TP 100C, TP 110C and TP 130C.
The DVD players operate with two different remote control codes.
The GDV 100D, GDV 100D/002, GDV 110 and GDV 200 can be controlled
without changing the code.
For controlling the DVD players Xenaro GDP 5100, GDP 5102, GDP 5120,
GDP 6150 and Malaga SE 1230, the remote control code must be changed on
the TV remote controls.
For this, press and hold down the „MODE“ button on the TV remote controls
while pressing the numeric buttons 4, 5 and 6 simultaneously.
To reset the TV remote controls to the factory setting (control of the GDV 100D,
GDV 100D/002, GDV 110 and GDV 200), press and hold down the „MODE“
button on the TV remote controls while pressing the numeric buttons 1, 2 and 3
simultaneously.
When the operating voltage is decreased, the TP 100C, TP 110C and TP 130C
are also restored to the factory setting. For controlling the DVD players Xenaro
GDP 5100, GDP 5102, GDP 5120, GDP 6150 and Malaga SE 1230, the remote
control code must be set again when the battery is replaced.
Stockkeeping:
Telepilot TP 100C (gray) Part no. 296420614102
Telepilot TP 100C (black) Part no. 296420614600
Telepilot TP 110C Part no. 296420614202
Telepilot TP 130C Part no. 296420614400
SAT
Service Information
Returns
analysis
4119100000 (8002/8012, 8005/8015) 1/1
Serial no. 1/01
Satellite headend station STC 1880
Possible complaint:
Complete failure of the headend station. The fuse Si 60002 T1 AL, and partly
the fuse Si 60020 T2,5 AL, are broken.
Cause:
Short circuit in the power supply transistor T 60006 (IRF PC 50).
Remedy:
In addition to replacing the power supply transistor, replace the diode D60006
MUR 480 with a wire bridge. This measure reduces the drain voltage and with
that the danger of a damage by overvoltage.
Workshop:
In the event of a failure of the power supply transistor, carry out the change.
In addition, carry out this change as a preventive measure on all STC 1880
which are in the workshop, without regard of the existing failure.
Stockkeeping:
Transistor IRF PC 50 Part no. 830280505000
Fuse T1 AL Part no. 831561700400
Fuse T2,5 AL Part no. 831561700600
TV
Returns
analysis
Service Information
4116100000 (8002/8012, 8005/8015) 1/1
Serial no. 1/01
Colour TV sets wit the chassis Digi Basic 3 - CUC 1832, 1930 and 1931
e.g.: Sydney SE 720 Dolby, Xentia M 72-400 Dolby, Denver SE 8250/8 PIP/
Dolby
Possible complaint:
No picture, no sound.
Cause:
Failure of the power supply transistor T 60006 (IRF PC50 or 2SK2699).
Remedy:
In addition to replacing the power supply transistor change the SMD
capacitor CC 60014 from 3.3 nF to 10 nF. This results in a better softstart
function of the power supply.
Workshop:
In the event of a defective power supply transistor replace in addition the
capacitor.
Stockkeeping:
SMD capacitor 10 nF 0805 Part no. 867219817300
Transistor IRF PC 50/2SK2699 Part no. 830280505000
Otros manuales para DIGI 100
2
Tabla de contenidos
Otros manuales de Hardware de red de Grundig
Manuales populares de Hardware de red de otras marcas
Matrix Switch Corporation
Matrix Switch Corporation MSC-HD161DEL Manual de usuario
B&B Electronics
B&B Electronics ZXT9-IO-222R2 Manual de usuario
Yudor
Yudor YDS-16 Manual de usuario
D-Link
D-Link ShareCenter DNS-320L Manual de usuario
Samsung
Samsung ES1642dc Instrucciones de uso
Honeywell Home
Honeywell Home LTEM-PV Instrucciones de montaje
