Grundig G-BCAM-01 Manual de usuario

BABY WATCH

G-BCAM-01

AUS GUTEM GRUND

ENGLISH

Do not use any cleaning agent dur-

ing the cleaning process as these

may damage its body. Wipe the

camera with a clean and dry cloth.

Unplug the device before cleaning.

Use the power supply delivered

with the product only.

BABYWATCH

Monitoring camera ensures you to

keep an eye on your children.

For this, you need a local network

access and a GRUNDIG television

on which the "BABYWATCH" appli-

cation is installed.

Information about the

camera

3 Megapixel resolution.

Large pivot range and wide angle

of inclination.

Supports IEEE 802.3 Ethernet

Standard.

Notes:

When the camera is used with wire-

less network connection, audio/

video quality may be impaired.

When the television is switched

off or the BABYWATCH applica-

tion has not been started in any

mode yet, no sound or video

image can be received from the

camera.

Safety

This device should not replace

parental supervision of your chil-

dren. It is designed to assist you

as parents for supervision of your

children.

In order to avoid the risk of chok-

ing with power cable, the video

camera should be installed out of

reach of children.

This video camera is not a toy; do

not let the children play with it.

This device is for transmission of

image/sound signals within a

house or building. Any other use

is strictly prohibited.

Protect the camera against rain,

humidity (dripping or splashing)

and heat (temperature, direct sun-

light, etc.).

Use the camera only under aver-

age weather conditions. Do not

use the device under direct sun-

light for a long time.

Do not drop the camera.

Never supply power to the "DIR/

DO" sockets.

Do not dismantle the camera

body under any circumstances.

Warranty claims are excluded for

damage resulting from improper

usage.

SAFETY AND INFORMATION ______________

ENGLISH

OVERVIEW _______________________________________

A B C

HN M L K J I

ENGLISH

J DO ... DIR, no function.

K WPS/Reset, is the button to

record the camera to the router;

(If Router WPS supports, you

can make wireless connection

by pressing and holding the

button on the camera for 3 to 10

seconds while pressing the WPS

buttons on the router concur-

rently).

in order to reset the camera to its

factory defaults, press and hold

the button for more than 10 sec-

onds; all settings will be deleted.

L SD, no function.

M DC 12V, is a connection socket

for the power supply delivered

with the device.

N Audio Out, no function.

A Camera lens and its cover.

B Brightness sensor determines the

brightness of the location of the

camera.

C Infrared LEDs turn on if the

brightness at this location is not

sufficient (Night Vision mode).

D Adjustment Ring is used to cor-

rect the image clarity.

E Microphone.

F LAN Indicator

on: it means that the LAN con-

nection is activated;

flashes: it means that data

transfer is in progress;

off: it means that the LAN con-

nection is deactivated.

G Operation LED, turns on when

the camera is in operating.

H WLAN antenna input socket.

I Ethernet, it is a socket to con-

nect to the home network with a

LAN cable.

OVERVIEW _______________________________________

ENGLISH

1 Remove the safety screw in the

mounting bracket (A) and loosen

the connection fittings (B).

(A)

2 Insert the fixing (B) to the camera

base and tighten it with the sup-

plied screws (C).

(B)

(C)

3 Determine the installation place of

the camera and mark the places

where holes will be drilled on the

wall by using the mounting kit.

ASSEMBLY AND CONNECTION ___________

You can position your GRUNDIG

camera in a suitable place or mount

it onto the wall. Packaging of the

device contains an mounting brack-

et and fixing elements.

Wall mounting

Notes:

Base unit should be fixed and it

should draw the static load.

For the wall superstructures,

for example for the wooden or

hollow walls, use appropriate

plugs and screws. For sug-

gestions, please consult your

authorised dealer.

Installation place should be

near a power outlet.

If the camera is not to be fixed,

the bracket (B) and fixings are

not required. Please start from

step 6.

ENGLISH

8 Adjust the camera position onto

the mounting bracket and tighten

the safety screw (A).

(A)

9 Plug the DC 12V adaptor to the

wall socket.

– Operation LED lights up soon

and the camera tests the motors

automatically.

10 Connect the LAN cable to an

unused socket on the modem or

router.

Warning:

Do not connect the camera to

the LAN input of the television

set. Camera and television

should be connected to each

other over modem or router as

to be on the same network.

Notes:

Remove the lens cover.

Adjust the camera to the obser-

vation position by using the but-

tons on the remote control.

See Adjusting Sharpness sec-

tion on page 27 to adjust image

sharpness.

4 Drill the holes on the wall and

insert the given plugs into these

holes.

5 Fix the mounting bracket with the

4 supplied screws to the wall.

6 For the WLAN operation, screw

the WLAN antenna onto the de-

vice;

for LAN operation, connect the

LAN cable to the »Ethernet«

socket.

Note:

LAN cable is supplied with the

device.

7 Plug the power cable to the

»DC 12V« socket.

ASSEMBLY AND CONNECTION ___________

ENGLISH

Connection of the camera

with a LAN connection

and signing in

Note:

Many home networks are Dy-

namic Networks. If you have

a dynamic network, you must

use a DSL modem that supports

DHCP. If the DHCP server of

the modem does not work, the

camera cannot receive an IP

address.

1 Switch on your television.

2 Select the »Quick Apps« menu

with »@«.

3 Select the »BabyWatch« applica-

tion with »

« or »

« and confirm

with »OK«.

– »Help« page will be displayed

soon which shows how the in-

stallation will be made.

Camera Start

∙Plug in the camera adaptor to start set-up.

∙ Power lamp in the front part of the camera will light up. Upper part of the camera will

move after a while..

∙ Attach one end of the LAN cable to the camera and the other to the modem or router to

which the TV is connected..

4 With the »<«, exit the »Help«

page.

– Settings page will be displayed.

NETWORK INSTALLATION __________________

Connect the camera to

the home network and

In order to ensure that the camera

view is displayed on your TV screen

over the "BABYWATCH" applica-

tion, your TV and Camera should be

connected to the same network.

You can connect your camera to the

home network with the cabled “LAN”

or wireless “WLAN” connection.

If you are using a cabled “LAN”

connection, please refer to the part

titled "Connection of the camera

with the LAN connection..." in this

section;

If you want to use a wireless

network “WLAN”, follow the instruc-

tions described in the section "Op-

eration on the Wireless Network"

"WLAN”.

Warning:

Malicious software may pen-

etrate through your personal

local network via Internet and

abuse your audio-visual files.

For such situations, secure your

personal local network. Ensur-

ing the security of the personal

local network is under the re-

sponsibility of the user.

ENGLISH

5 Select the »Search Camera« line

with »

« or »

« and confirm it

with »OK«.

– After a while, the found camera

icon and IP address will be

displayed.

Note:

If camera search fails;

For detailed search, press »«

(red);

if the detailed search fails too,

for Manual IP entry, press »«

(green).

6 Confirm the found camera with

»OK«.

– »Add Camera« menu will be

displayed.

7 In order to display the on-screen

keyboard, press »OK«.

Notes for data entry:

Data are entered with the pop-up

keyboard. Select the necessary

letters/numbers with »

«, »

«,

« or »

« and confirm with

»OK«.

To toggle between uppercase and

lowercase letters, select »Shift«

and confirm with »OK«.

Keyboard mode can be changed by

pressing »▯« (red).

7You can change the language of

the keyboard/key assignments

with »▯▯« (green).

NETWORK INSTALLATION __________________

Last character/number can be de-

leted with »▯▯▯▯« (blue).

All entries can be deleted with

»▯▯▯« (yellow).

If the entry of the current line is

completed, close the keyboard

with »<«.

8 Enter and save the name of the

camera according to your pref-

erence as explained in the notes

about data entry.

9 Select the »Password« line with

« and open the pop-up key-

board with »OK«.

Notes:

Camera password has been set

as »admin« as standard factory

default.

We recommend you to use a

password belonging to you, see

page 31 “Settings” section.

10 Enter and save »admin« pass-

word as explained in the notes

about data entry.

11 Select the push button »OK«

with »

« and confirm with

»OK«.

– “Live streaming” of the camera

is shown on the screen.

Note:

If the modem is switched off and

on, IP address of the camera

may change, then repeat the

steps from 5 to 11.

ENGLISH

6 Enter the camera settings with

»OK« and select the »Set Wire-

less Connection« line with the »

or »

« and confirm with »OK«.

– After a while, available wireless

networks will be displayed on

the screen.

7 Select the wireless network which

the TV is connected to by using

«, »

« »

« and »

« and con-

firm with »OK« button.

– Network name and entrance

menu with password will be dis-

played.

8 Select the »Password« line with

the »

« or »

« and press »OK«.

Enter by using the keyboard the

wireless network password and

close the keyboard with »

«.

9 Select »Yes« push button with »

and confirm with »OK«.

10 To return to the »Settings« menu,

press »<«.

11 Remove the Network cable.

LAN led on the camera will flash

quickly.

– Wireless network connection is

made now.

12 In order to view the “live stream-

ing” of the camera on the screen,

press »▯« (red).

NETWORK INSTALLATION __________________

Registration of the Cam-

era via the Wireless Net-

work “WLAN”

Notes:

In order to make the wireless

network “WLAN” settings, first

camera should be connected to

the router over the cabled local

area network.

Many home networks are Dy-

namic Networks. If you have

a dynamic network, you must

use a DSL modem that supports

DHCP. If the DHCP server of the

modem does not work, the cam-

era cannot receive an IP.

1 Switch on your television.

2 Select the »Quick Apps« menu

with »@«.

3 Select the »BabyWatch« applica-

tion with »

« or »

« and confirm

with »OK«.

– “Live streaming” of the camera

is shown on the screen.

4 While "live streaming" is shown on

the screen, select the »Settings«

menu with the »▯« (red).

5 Select the »Camera Settings« line

with the »

« or »

« and confirm

with »OK«.

– The camera which is connect-

ed to the network via cabled

“LAN” is displayed on the

screen.

ENGLISH

OPERATION OF THE CAMERA _____________

Adjusting the Image sharp-

ness

1 Adjust the image sharpness by

using the adjustment ring on the

camera lens.

Selecting the viewing

mode

1 While "live streaming" is dis-

played on the screen, select the

»Application View Mode« menu

with »@«.

– Options:

Full Screen Mode– "live

streaming" is displayed

as "full screen";

Widget Mode – "live

streaming" is displayed

as a small image in the

valid television show.

Dimension and position

of this small image can

be selected;

Notification Mode –

streaming is displayed

only when a movement

is made or a sound is

transmitted.

My Applications – func-

tion ends and the device

returns to the »Quick

Apps« menu or »My Ap-

plications« page;

Close – function ends and

the device returns to the

current television show.

2 Select the desired mode with »

or »

« and confirm with »OK«.

Changing the camera

angle

Camera angle can be set to the Full

Screen Mode for the "Live stream-

ing".

1 Select the »Application View

Mode« with »@«.

2 Select the »Full Screen Mode«

with »

« or »

« and confirm with

»OK«.

3 Adjust the desired camera angle

with »

«, »

« or »

«.

Note:

The camera can be reset to the

starting position (90° horizon-

tal/vertical). To do this:

select the »Settings« menu with

»▯« (red), select the »Camera

settings« row with »

« or »

and confirm with »

«.

Press»

« again, select the

»Reset Position« row with »

or »

« and confirm with »

«.

Close the settings menu with

« and switch to the “live

streaming” with »▯« (red).

Otros manuales para G-BCAM-01

Tabla de contenidos

Otros manuales de Cámara IP de Grundig

Grundig

Grundig GCI-K1527V Manual de usuario

Grundig

Grundig Reason GCT-K2305B Manual de usuario

Grundig

Grundig GCI-M1566F Manual de usuario

Grundig

Grundig GCI-K1627D Manual de usuario

Grundig

Grundig GCI-K0779P Manual de usuario

Grundig

Grundig GCI-K1503B Manual de usuario

Grundig

Grundig GCI-C0735P Manual de usuario

Grundig

Grundig GCT-K2326D Manual de usuario

Grundig

Grundig GD-CI-BP2647P Manual de usuario

Grundig

Grundig GCH-K0305B Manual de usuario

Grundig

Grundig GCI-K1677D Manual de usuario

Grundig

Grundig GCA-B0323T Manual de usuario

Grundig

Grundig GCH-K1327T-1 Manual de usuario

Grundig

Grundig GCI-H0503B Manual de usuario

Grundig

Grundig GCI-K0622D Manual de usuario

Grundig

Grundig GCI-K1503B(S) Manual de usuario

Grundig

Grundig GCT-K0123T Manual de usuario

Grundig

Grundig GCI-F1576V Manual de usuario

Grundig

Grundig GCI-K1587V Manual de usuario

Grundig

Grundig GCI-K1527V-1 Manual de usuario

Grundig

Grundig GCI-K1577TH Manual de usuario

Manuales populares de Cámara IP de otras marcas

FLIR

FLIR Exx series Manual de usuario

Avigilon

Avigilon H4A-BO1-IR Manual de usuario

Digital Watchdog

Digital Watchdog DWCA-C128-64 Manual de usuario

ShareTech

ShareTech AV1 Manual de usuario

Ezviz

Ezviz C6C Manual de usuario

Melchioni

Melchioni UCAM 2015 Manual de usuario

Geutebruck

Geutebruck G-Cam/ESD-4630 Manual de usuario

Arecont Vision

Arecont Vision MegaBall AV3146DN-3310-D-LG Manual de usuario

Mitel

Mitel 6800i Series Manual de servicio

Vitek

Vitek VTC-IR403-212NP Manual de usuario

THOMSON

THOMSON DSC - 323W Manual de usuario

AVer

AVer FB2027 Manual de usuario

ENFORCER

ENFORCER EV-T5105-N2SQ Manual de usuario

Wansview

Wansview NC543 Manual de usuario

Eneo

Eneo MCB-64A0003M0A Manual de usuario

deView electronics

deView electronics CBDNI36F Manual de usuario

Swann

Swann SwannEye Manual de usuario

LevelOne

LevelOne IP CamSecure Manual de usuario
