Grundig GRKHD01 Manual de usuario

www.topvehicletech.com

The informaon provided in this document is subject to change without noce due to changes and/or

improvements to the product/s.

V1.0522

GRKHD01

SUZUKI SWIFT

2011-2017

INSTALLATION MANUAL

This dash image is a visual representaon for display purposes only.

www.topvehicletech.com

ABOUT THIS PRODUCT

The GRKSZ01 installaon kit allows for the retenon of the vehicle’s steering wheel controls and helps maintain

the original aesthec of the interior when installing a new car stereo. The GRKSZ01 gives you everything you

need for a complete install in one box. The components of this kit are compable for the Suzuki Swi (2011-

2017) with Panasonic factory stereos. The wiring harness and interface will retain the steering wheel controls

and phone buon funconality (if vehicle is equipped).

The interface supplied features an OEM specic connector.

CUSTOMER SUPPORT

Installaons should be carried out by, or under the guidance of an experienced installer. If you do encounter any

problems during the installaon of this product, then please contact our dedicated customer service team at:

Phone: 01420 470 605 E-Mail: help@topvehicletech.com

CONTENTS

• 1x Fascia plate (with accessories)

• 1x Instrucon manual

• 1x Steering wheel control harness and interface

• 1x Antenna adapter

• 1x Stereo patch lead

www.topvehicletech.com

FITTING GUIDE

STEREO REMOVAL

FASCIA PLATE SET-UP

1. Once you have taken the main head unit out of the dashboard, you will need to transfer the 4x retaining

clips onto the corresponding posts of the new fascia.

2. Take the brackets from within the kit and line them up to the rear of the new fascia and use the 6x

screws within the kit to aach them securely.

3. Take the new radio and slide this inbetween the brackets from behind the fascia panel. Line the holes up

correctly and aach them accordingly.

4. Take the rubber band and align this around the outside of the trim. When aligned correctly, this can

then be pushed onto the front of the fascia for a seamless looking t.

1. Use a panel removal tool to free up the top vent panel which will have 3x retaining clips either side.

Once free, either disconnect the hazard switch connector and remove, or simply put to one side.

2. With the vent’s out of the way, this will uncover 2x phillips screws at either side of the radio. Undo these

screws and carefully remove them out of the dashboard.

3. When the top screws are out of the way, use the panel removal tool again to dislodge the 4x retaining

clips that hold the main head unit in place. Once free, remove completely whilst disconnecng the wiring.

5. With the bracketry aligned correctly, and the “Stereo Installaon” process complete, you can then push

the head unit and fascia assembly into the dashboard to complete the installaon.

www.topvehicletech.com

FITTING GUIDE

4. Aach the addional wiring on the harness to the back of the stereo:

Pink - Speed Pulse

5. When all the above wires (and any addional accessories) have been connected, nally make the power

connecons between the stereo and the vehicles pre-exisng connector.

3. Aach the antenna adapter to the vehicles pre-exisng connecon and the back of new stereo.

1. Take the steering wheel control interface and aach the 14-way steering wheel harness connector to

the relevant side.

STEREO INSTALLATION

2. Make a cut within the orange and purple loops on the back of the patch lead connector. Then proceed

to aach ‘Key 1’ to the light blue ‘SWC Remote’ wire on the stereo. When done, connect the 12-way

connector to the steering wheel control interface.

www.topvehicletech.com

Please note: conguraon layout may dier dependent on vehicle model.

STEERING WHEEL CONTROL FUNCTIONALITY

MODE

VOL

-8

1. Volume +

2. Volume -

3. Track +

4. Track -

5. Mute

6. Source

7. Pick Up

8. Hang Up

1. Volume +

2. Volume -

3. Up Arrow

4. Down Arrow

5. Mute

6. Mode

7. Pick Up

8. Hang Up

Original Buon New Funcon

www.topvehicletech.com

WIRING DIAGRAM

ISO Connector

Connect to new stereo

OEM Speciﬁc Connector [20 Pin]

Connect to corresponding

connector from vehicle

Main Wiring Loom Connector [14 Pin]

Connect to Interface Box

Interface Box

Flying Wires

Pink - Speed Pulse

Stereo Connection (Patch)

Lead Connector [12 Pin]

Connect to Interface Box

Note: Must be connected

ﬁrst, before power

connection is made to the

interface

www.topvehicletech.com

NOTES

www.topvehicletech.com

If at any point you experience any problems and need any assistance before, during or aer the

installaon process, please contact us via :

Phone: 01420 470 605

E-Mail: help@topvehicletech.com

Mon - Fri 9am - 5.30pm GMT

TECHNICAL ASSISTANCE

If you would like to download a digital copy of this manual, or any other product, then please

visit the www.topvehicletech.com website.

This manual is considered correct at the me of prinng but is subject to change. For the latest

manuals & updates, refer to our website.

in any form or by any means, including photocopying, recording, copying or other electronic or

mechanical methods, without the prior wrien permission of the author.
