Grundfos JPA Series Manual de funcionamiento

JPA, JPC, JPD, NS, PF, SB, SBA, MQ

Pumps and boosters

Safety instructions and other important information

GRUNDFOS INSTRUCTIONS

Table of contents

JPA, JPC, JPD, NS, PF, SB, SBA, MQ

English (GB)

Safety instructions and other important information . . . . . . . . . . . . . . . . . . . . . . 5

 (BG)

      . . . . . . . . . . . . . . . 10

eština (CZ)

Bezpenostní pokyny a další dležité informace . . . . . . . . . . . . . . . . . . . . . . . 16

Deutsch (DE)

Sicherheitshinweise und zusätzliche wichtige Informationen . . . . . . . . . . . . . . 21

Dansk (DK)

Sikkerhedsanvisninger og andre vigtige oplysninger . . . . . . . . . . . . . . . . . . . . 27

Eesti (EE)

Ohutusjuhised ja muu tähtis informatsioon . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

 (GR)

      . . . . . . . . . . . . . . . . . . 37

Hrvatski (HR)

Sigurnosne upute i druge važne informacije. . . . . . . . . . . . . . . . . . . . . . . . . . . 42

Magyar (HU)

Biztonsági utasítások és más fontos információk . . . . . . . . . . . . . . . . . . . . . . . 47

Lietuviškai (LT)

Saugumo instrukcija ir kita svarbi informacija . . . . . . . . . . . . . . . . . . . . . . . . . . 52

Latviešu (LV)

Drošbas nordes un cita svarga informcija. . . . . . . . . . . . . . . . . . . . . . . . . . 57

Polski (PL)

Zalecenia dotyczce bezpieczestwa i inne wane informacje . . . . . . . . . . . . 63

Român(RO)

Instruciuni de siguran i alte informaii importante . . . . . . . . . . . . . . . . . . . . 69

Srpski (RS)

Bezbednosna uputstva i druge važne informacije . . . . . . . . . . . . . . . . . . . . . . 74

 (RU)

       . . . . 79

Slovensko (SI)

Varnostna navodila in druge pomembne informacije . . . . . . . . . . . . . . . . . . . . 85

Slovenina (SK)

Bezpenostné pokyny a alšie dôležité informácie . . . . . . . . . . . . . . . . . . . . . 90

Türkçe (TR)

Güvenlik talimatlarıve dier önemli bilgiler. . . . . . . . . . . . . . . . . . . . . . . . . . . . 95

Table of contents

JPA, JPC, JPD, NS, PF, SB, SBA, MQ

 (UA)

       . . . . . . . . . . . . . . . 100

Bosanski (BS)

Sigurnosne upute i druge važne informacije. . . . . . . . . . . . . . . . . . . . . . . . . . 106

Bahasa Indonesia (ID)

Petunjuk keselamatan dan informasi penting lainnya. . . . . . . . . . . . . . . . . . . 111

 (KZ)

      . . . . . . . . . . . . . . . . 116

 (MK)

     . . . . . . . . . . . . . . . . . . 122

(AR)

    . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 131

ไทย (TH)

คําแนะนําเพื่ อความปลอดภัยและขอมูลสําคัญอื่ นๆ. . . . . . . . . . . . . . . . . . . . . . . 132

Português (BR)

Instruções de segurança e outras informações importantes . . . . . . . . . . . . . 137

Limited warranty / Garantia limitada / Garantie limitée (US). . . . . . . . . . . . . . 142

Declaration of conformity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 144

Operating manual EAC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 147

English (GB)

English (GB) Safety instructions and other important information

Original safety instructions

These safety instructions give a quick overview of

the safety precautions to be taken in connection with

any work on this product.

Observe these safety instructions during handling,

installation, operation, maintenance, service and

repair of this product.

These safety instructions is a supplementary

document, and all safety instructions will appear

again in the relevant sections of the installation and

operating instructions.

Keep these safety instructions at the installation site

for future reference.

Prior to installation, read

this document and the

online version of the

installation and

operating instructions.

Installation and

operation must comply

with local regulations

and accepted codes of

good practice.

This appliance can be

used by children aged

from 8 years and above

and persons with

reduced physical,

sensory or mental

capabilities or lack of

experience and

knowledge if they have

been given supervision

or instruction concerning

use of the appliance in a

safe way and

understand the hazards

involved.

Children shall not play

with the appliance.

Cleaning and user

maintenance shall not

be made by children

without supervision.

Make sure that the

system in which the

pump is incorporated is

designed for the

maximum pump

pressure.

This pump has been

evaluated for use with

water only.

English (GB)

Intended use

MQ, JPA, JPC JPD, NS, PF, SB and SBA pumps and

boosters are suitable for domestic water supply and

for pumping clean, thin, non-aggressive and

non-explosive liquids without solid particles or fibres.

Examples of liquids:

• potable water

• rainwater.

Installing the product

Observe local

regulations setting limits

for manual lifting or

handling.

CAUTION

Crushing of feet

Minor or moderate

personal injury

- Use safety shoes when

handling the pump.

DANGER

Electric shock

Death or serious

personal injury

- Switch off the power

supply before starting

any work on the

product. Make sure

that the power supply

cannot be accidentally

switched on.

DANGER

Electric shock

Death or serious

personal injury

- The protective earth of

the socket outlet must

be connected to the

protective earth of the

pump. The plug must

therefore have the

same PE connection

system as that of the

socket outlet. If not,

use a suitable adapter.

We recommend that you

fit the permanent

installation with a

residual-current circuit

breaker, RCCB, with a

tripping current less than

30 mA.

English (GB)

DANGER

Electric shock

Death or serious

personal injury

- If the pump is used for

cleaning or other

maintenance of

swimming pools,

garden ponds or

similar places, make

sure that the pump is

supplied through a

residual-current circuit

breaker, RCCB, with a

tripping current of 30

mA.

DANGER

Electric shock

Death or serious

personal injury

- Make sure that the

power supply is

switched off before you

make any connections

in the terminal box.

The pump must be

earthed.

DANGER

Electric shock

Death or serious

personal injury

- Connect pumps that

are delivered without

cable and/or plugs to

an external mains

switch with a minimum

contact gap of 3 mm in

all poles.

SB, SBA: make sure that

there is at least 3 m free

cable above liquid level.

This limits the

installation depth to 7 m

for pumps with ten-meter

cable and to 2 m for

pumps with five-meter

cable.

English (GB)

Starting up the product

Servicing the product

Maximum total head

WARNING

Flammable material

Death or serious

personal injury

- Do not use the pump

for flammable liquids,

such as diesel oil,

petrol or similar liquids.

DANGER

Electric shock

Death or serious

personal injury

- Do not use the pump in

swimming pools,

garden ponds or

similar places if there

are people in the water.

DANGER

Electric shock

Death or serious

personal injury

- If the power supply

cable is damaged, it

must be replaced by

the manufacturer, his

service agent or

similarly qualified

persons in order to

avoid hazard.

Pump Total head

[m]

MQ3-25 25

MQ3-35 35

MQ3-45 45

JP 5 / JP 5 PM / JP 5 43

JP 6 / JP 6 PM / JP 6 57

JPA 3-42 / JPA 3-42 PT-H 42

JPA 4-47 / JPA 4-47 PT-H /

JPA 4-47 PT-V 47

JPA 4-54 / JPA 4-54 PT-H /

JPA 4-54 PT-V 54

JPA 5-61 / JPA 5-61 PT-V 61

JPA 8-62 / JPA 8-62 PT-V 62

JPA 12-41 41

JPA 12-51 51

JPC 3-42 / JPC 3-42 PT 42

JPC 4-47 / JPC 4-47 PT 47

JPC 4-54 / JPC 4-54 PT 54

JPC 5-48 48

JPD 4-47 PT 47

JPD 4-54 PT 54

JPD 5-61 PT 61

JPD 8-62 PT 62

NS 3-40 40

NS 4-23 23

NS 5-33 33

NS 5-50 50

NS 5-60 60

NS 6-30 30

NS 6-40 40

NS 13-18 18

NS 30-18 18

NS 30-30 30

NS 30-36 36

PF 1-30 30

PF 2-50 50

English (GB)

Maximum inlet pressure Further product

documentation

For further product documentation, see

product-selection.grundfos.com

Disposing of the product

Dispose of this product or parts of it in an

environmentally sound way:

1. Use the public or private waste collection service.

2. If this is not possible, contact the nearest

Grundfos company or service workshop.

Dispose of the waste battery through the national

collective schemes. If in doubt, contact your local

Grundfos company.

Subject to alterations.

Pump Inlet pressure

[bar]

MQ3-25 5 bar ~ 0.5 MPa

MQ3-35 4 bar ~ 0.4 MPa

MQ3-45 3 bar ~ 0.3 MPa

JP 5 / JP 5 PM / JP 5 1.7 bar ~ 0.17 Mpa

JP 6 / JP 6 PM / JP 6 0.3 bar ~ 0.03 Mpa

JPA 3-42 / JPA 3-42 PT-H 3.8 bar ~ 0.38 MPa

JPA 4-47 / JPA 4-47 PT-H /

JPA 4-47 PT-V 3.3 bar ~ 0.33 MPa

JPA 4-54 / JPA 4-54 PT-H /

JPA 4-54 PT-V 2.6 bar ~ 0.26 MPa

JPA 5-61 / JPA 5-61 PT-V 1.9 bar ~ 0.19 MPa

JPA 8-62 / JPA 8-62 PT-V 1.8 bar ~ 0.18 MPa

JPA 12-41 3.9 bar ~ 0.39 MPa

JPA 12-51 2.9 bar ~ 0.29 MPa

JPC 3-42 / JPC 3-42 PT 1.8 bar ~ 0.18 MPa

JPC 4-47 / JPC 4-47 PT 1.3 bar ~ 0.13 MPa

JPC 4-54 / JPC 4-54 PT 0.6 bar ~ 0.06 MPa

JPC 5-48 1.2 bar ~ 0.12 MPa

JPD 4-47 PT 1.3 bar ~ 0.13 MPa

JPD 4-54 PT 0.6 bar ~ 0.06 MPa

JPD 5-61 PT 1.9 bar ~ 0.19 MPa

JPD 8-62 PT 1.8 bar ~ 0.18 MPa

NS 3-40 2 bar ~ 0.2 MPa

NS 4-23 3.7 bar ~ 0.37 MPa

NS 5-33 2.7 bar ~ 0.27 MPa

NS 5-50 3 bar ~ 0.3 MPa

NS 5-60 2 bar ~ 0.2 MPa

NS 6-30 3 bar ~ 0.3 MPa

NS 6-40 2 bar ~ 0.2 MPa

NS 13-18 4.2 bar ~ 0.42 MPa

NS 30-18 4.2 bar ~ 0.42 MPa

NS 30-30 3 bar ~ 0.3 MPa

NS 30-36 2.4 bar ~ 0.24 MPa

PF 1-30 3 bar ~ 0.3 MPa

PF 2-50 5 bar ~ 0.5 MPa

 (BG)

 (BG)      

    

    

     , 

      

    .

     

, , , ,

    .

    

 ,   

      

     

.

     

     .

 

  

  

 

  

 

.

 

 

  

 

 

  

.

    

    8 

   

, 

 

  

  , 

     

 

 

 

 

  

 .

    

  .

 

 

 

  

    

 .

 , 

,  

 , 

 

  

.

  

 

  

.

Otros manuales para JPA Series

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Bomba de agua de Grundfos

Grundfos

Grundfos CMBE TWIN Manual de usuario

Grundfos

Grundfos DMH 28X Manual de usuario

Grundfos

Grundfos RF2 Manual de usuario

Grundfos

Grundfos NK B Instrucciones de funcionamiento

Grundfos

Grundfos Sololift2 WC-1 Manual de usuario

Grundfos

Grundfos DMX 226 Manual de funcionamiento

Grundfos

Grundfos PS.R Series Manual de usuario

Grundfos

Grundfos S 50 Series Manual de usuario

Grundfos

Grundfos SCALA2 Manual de usuario

Grundfos

Grundfos APG Series Manual de usuario

Grundfos

Grundfos GT-C Manual de usuario

Grundfos

Grundfos BME Manual de usuario

Grundfos

Grundfos CMV Series Manual de usuario

Grundfos

Grundfos CHV 2-50 Manual de usuario

Grundfos

Grundfos UPE Series Manual de usuario

Grundfos

Grundfos PS.G Series Manual de usuario

Grundfos

Grundfos JP Manual de usuario

Grundfos

Grundfos CU 3x2 Manual de usuario

Grundfos

Grundfos MAGNA1 C Manual

Grundfos

Grundfos CR Manual de usuario

Grundfos

Grundfos TPE 2 Series Manual de usuario

Grundfos

Grundfos Unilift AP12 Manual de usuario

Grundfos

Grundfos UPS3 15-50/65 Manual de usuario

Grundfos

Grundfos UPM3 FLE Manual de usuario

Manuales populares de Bomba de agua de otras marcas

Neptun

Neptun NPHW 5500 Manual de usuario

Sensidyne

Sensidyne Gilian BDX-II Instrucciones de instalación y funcionamiento

Draper

Draper 47808 Manual de usuario

Trolla

Trolla 12820 Manual de usuario

Sunfab

Sunfab SVH Series Manual de usuario

WilTec

WilTec 50740 Manual de usuario

Fieldmann

Fieldmann FVC 5015 EK Manual de usuario

Everbilt

Everbilt EFSUB5-122HD Manual de usuario

Graco

Graco Husky 3300e Manual de usuario

esotec

esotec 101018 Manual de usuario

moyno

moyno 2000 CC Manual de usuario

Becker

Becker BASIC VASF 2.80/1-0.AC230 Manual de usuario

Sykes AmeriPumps

Sykes AmeriPumps GP100M Guía de solución de problemas

DUROMAX

DUROMAX XP WX Series Manual de usuario

BRINKMANN PUMPS

BRINKMANN PUMPS SBF550 Manual de usuario

Franklin Electric

Franklin Electric IPS Manual de usuario

Xylem

Xylem e-1532 Series Manual de usuario

Milton Roy

Milton Roy PRIMEROYAL Manual de usuario
