Growonix GX400 Manual de usuario
1
www.growonix.com toll free 888.406.8521, oce 818.510.0264, sales@growonix.com
GX300/GX400
Owners Manual
www.growonix.com
5
www.growonix.com toll free 888.406.8521, oce 818.510.0264, [email protected]
OUR MISSION
Durability, Reliability, Eciency, Purity, and Conservation form the foundation on which we design
and build all of our products. Consistent and superior quality sets us apart from other manufacturers
and increases our value to you - our customer. Whether you are a hydroponics hobbyist, serious
enthusiast, or large-scale gardener, GrowoniX is committed to bringing you the best solution for
water purication systems.
WHAT IS REVERSE OSMOSIS?
Reverse osmosis (RO) is a ltration method that removes many types of large molecules and ions
from solutions by applying pressure to the solution when it is on one side of a selective membrane.
This ltering process ensures that the solute (waste water) is contained within the pressurized
chamber while the pure solvent (RO water) is allowed to pass freely through the membrane.
TUNED FOR GROWING - IN TUNE WITH OUR CUSTOMERS
Traditional RO systems have waste ratios of approximately 4:1, which means there are 4 gallons
of waste water produced for every 1 gallon of puried water. GrowoniX line of water lters achieve
waste ratios of 2:1 with the EX100 through GX400 and an astounding 1:1 ratio with the GX600 and
GX1000.
GrowoniX has created a complete product line that will address the needs of hydroponic operations
of all sizes. Our lters will signicantly reduce your water use while dramatically increasing your yields.
INTRODUCTION
THE TRADITIONAL WAY
takes 4 gallons of waste water to produce 1 gallon of pure water
THE GrowoniX WAY
8
FLOW RATES
600GPD—1000GPD FILTER FLOW RATES
WATER PRESSURE (PSI) WITH OR WITHOUT PUMP
2400
2600
2800
EX/GX1000-HF, 77ºF
EX/GX1000-HF, 60ºF
EX/GX1000-HF, 50ºF
EX/GX600-HF, 77ºF
EX/GX600-HF, 60ºF
EX/GX600-HF, 50ºF
2200
2000
1800
1600
1400
1200
1000
800
600
400
200
0
GALLONS PER DAY
40 50 60 70 80 90 100 110 120 130 140 150 160 170 180
100GPD—400GPD FILTER FLOW RATES
WATER PRESSURE (PSI) WITH OR WITHOUT PUMP
600
550
500
450
400
350
300
250
200
150
100
50
0
EX/GX200-HF, 50ºF
EX/GX200-HF, 60ºF
EX/GX200-HF, 77ºF
EX/GX400-HF, 60ºF
EX/GX400-HF, 77ºF
EX/GX400-HF, 50ºF
EX100-HF, 50ºF
EX100-HF, 60ºF
EX100-HF, 77ºF
40 45 50 55 65 7560 70 80
GALLONS PER DAY
7
www.growonix.com toll free 888.406.8521, oce 818.510.0264, [email protected]
INFORMATION ON QUICK CONNECT FITTINGS
INSERT TUBE INTO FITTING
Push the tubing through the collet and dual o-rings until it bottoms out against the tube stop.
The collet holds the tube in place and the dual o-rings provide a leak resistant seal.
MAKE A CLEAN TUBE CUT
Cut the tube squarely and if using plastic tubing, ensure that the cut has not made the tube out of round.
Also ensure that the tube has a smooth outside diameter without any burrs or score marks
prior to inserting it into the tting.
TEST AND INSPECT
Push and pull the tubing toward and away from the tting to ensure that it has been installed properly.
Test and inspect the installation for any leaks.
TUBE REMOVAL
Relieve pressure from the tubing and tting. Push uniformly around the collet ange against the
tting body while pulling the tubing away from the tting to release it.
O-RING
COLLET
TUBING
PUSH COLLET IN
PULL TUBE OUT
GROWONIX WATER FILTERS USE QUICK CONNECT FITTINGS
THAT ALLOW FOR EASY MAINTENANCE.
2
w/HIGH FLOW
MEMBRANE
tuned for growing
tm
GX300/GX400
2:1 WASTE RATIO
FEATURES:
150 GALLONS PER DAY / 200 GALLONS PER DAY
6.25 GALLONS PER HOUR
2:1 WASTE RATIO
GX150HR - DOW CHEMICAL MEMBRANE
GX200HF -HIGH FLOW COLD WATER
MEMBRANE
HIGH FLOW WASHABLE SEDIMENT FILTER
CLEAR FILTER HOUSINGS
STAINLESS STEEL LIQUID FILLED
PRESSURE GAUGES
PATENTED METAL HOUSING
AUTO SHUTOFF VALVE
EZ HOOKUP KIT
WALL MOUNTABLE
USES 50% LESS WATER THAN TRADITIONAL
RO SYSTEMS
THE GX300
When we developed the GX300, we decided to pack all the high end features into a tight ecient RO
unit. We engineered a 50% increase in water production over traditional ROs, lowered the waste ratio to
2:1, and still oered it to you for the same price point of an entry level RO lter. But we didn’t stop there.
We topped it all o with a 2” stainless steel liquid-lled pressure gauge, never before seen in a lter this
size, and integrated it into our patented GX Series bracketing system. A manual ush valve allows you
to clean the membrane, purging out pollutants that could otherwise add buildup to the system. Flushing
adds considerable life to the membrane. With ow rates at 6.25 GPH (Gallons Per Hour), the GX200HF
delivers the same excellent ltration as our larger models.
Built in the U.S.A.
No Assembly Required
MEMBRANE FLUSH KIT INCLUDED
NO ADDITIONAL PRE-FILTERS NEEDED
6
PRECAUTIONS
• Do not use unit with inlet water pressure exceeding 80 psi. If inlet water pressure is too high,
install water pressure regulator before the unit. Regulators and pressure limiters are available at
www.Growonix.com or your local plumbing supply.
• Keep unit away from direct light.
Direct light can cause algae and other biologicals to grow inside of the lter housings.
• Do not install unit near electrical outlets or electrical devices.
• Do not install in places where a leak can cause damage.
• GrowoniX EX Series RO water lters are rated using supply water that is 77°F, 475ppm, at 70psi.
Slower performance may be noted in areas with colder temperatures, higher water salinity, or
lower inlet water pressure.
• A minimum of 40psi is recommended to operate GrowoniX water lters. If your inlet water
pressure is too low, booster pumps can be used to increase pressure.
Pumps are available at www.Growonix.com.
• Do not use a ow restrictor other than the one included with your unit.
• Flow restrictors help tune the unit for proper waste ratio.
• Using bigger ow restrictors, or using the unit in areas with exceptionally dirty water,
will decrease membrane performance and longevity.
10
3 2
GX300 COMPONENT DIAGRAM
12
13 14
15
16
1. Patented GX mounting bracket
2. Sediment lter
3. Carbon lter
4. RO membrane
5. Pressure gauge
6. Supply water in
7. RO water out
8. Waste/drain tubing
9. Flow restrictor
10. Membrane Flush Valve
11. Auto shuto valve
12. Drain saddle clamp
13. In line shuto valve
14. Filter wrench
15. Supply, RO, and drain tubing
16. Garden hose adapter
1
5
4
4
6
7
11
10 9
8
11
www.growonix.com toll free 888.406.8521, oce 818.510.0264, [email protected]
Connect the 1/4” blue drain tubing to the
tee tting just after the ow restrictor.
IMPORTANT TIPS:
• The GX300HR and GX400HF water lters are designed to be used with between 40-80 psi of incoming
water pressure.
• Units upgraded with High Flow Membranes can work with as low as 20 psi of incoming water pressure.
• Do not exceed 80 psi of incoming water pressure.If incoming water pressure is too high,
install pressure regulator before unit.
• Pressure regulators are available at www.GrowoniX.com
• Always turn incoming water pressure on slowly,
allowing all air to be discharged before full water pressure is restored.
Connect 3/8” white supply tubing to
the inlet tting, making sure inlet seats
all the way in quick-connect tting. This
is the supply water line.
Connect 1/4” white RO tubing to the auto
shut-o valve, making sure RO tubing
seats all the way in quick-connect tting.
This is the ltered RO water out line.
Mount drain clamp to available drain
pipe. Connect other end of drain tubing
to included drain clamp.
1
3
2
4
SETUP INSTRUCTIONS
12
FLUSHING THE KDF85 CARBON FILTER
Make sure incoming feed water is
shut o, ensuring the RO lter is
depressurized.
Disconnect the 1/4” white tubing that
feeds the membrane input from the
carbon lter.
Position tting over drain or bucket and
slowly turn on incoming water pressure.
Allow ten gallons of water to ush through
carbon before reconnecting to membrane
input.
1 2
Growonix GX600 and GX1000 water lters come with a manual ush valve. Flushing the membrane
element after each use for approximately 3-5 minutes will remove standing salts from the membrane,
signicantly extending membrane life. Even weekly ushes will improve membrane life and system
performance.
The ush valve is located on the waste line of the RO membrane. To ush the membrane simply
turn the ush valve to the FLUSH position as seen in picture 1. High-pressure water will bypass the
ow restrictor and shuto valve and be sent down the drain, carrying membrane pollutants with it. If
using a oat valve and the system happens to be OFF due to valve engagement, opening the ush
valve will start the system again in ush mode, and the membrane will be cleaned.
DISCONNECT TUBING
FROM PUMP INPUT
OR MEMBRANE INPUT
AND FLUSH 10 GALLONS
THROUGH
KDF CARBON FILTER
WARNING
MAKE SURE WATER IS FREE
FROM CARBON FINES & DEBRIS
BEFORE RECONNECTION
TO MEMBRANE INPUT
13
www.growonix.com toll free 888.406.8521, oce 818.510.0264, [email protected]
1
3
2
4
REPLACING SEDIMENT AND CARBON PRE-FILTERS
Unscrew sediment and carbon lter
housings using supplied lter wrench.
Wash inside of lter housings to
remove debris.
When replacing lter housings, make
sure housing O-rings are seated
properly. O-rings function best when
lubricated with food grade silicone
lubricant.
Install new sediment and carbon lter,
making sure they go into the correct
lter housings.
IMPORTANT TIPS:
• Pre-lters should be changed when either brown discoloration occurs,
or system ow rates have signicantly declined.
• Always turn incoming water pressure o before servicing the unit.
• Always turn incoming water pressure on slowly,
allowing all air to be discharged before full water pressure is restored.
Sediment Carbon
Tighten lter housings by hand,
do not use lter wrench. Do not over
tighten.
