The Best Got Better.

EclipseTM

Ergonomic

Braising Pan

ECLIPSETM ERGONOMIC

TILTING BRAISING PAN

Energy efficient, easy to use,

with the highest performance

Performance plus

Our performance is better than ever. Get the fastest

preheat and cook times in the business. Heats to 350ºF

in just 4 minutes

–

much faster than a conventional

oven. With fast, even cooking, you can cut preparation

times and increase batch consistency, while saving on

energy costs. No hot or cold spots either. Heat transfers

evenly over the entire cooking surface.

Ergonomic by design

The Eclipse ergonomic tilting braising pan has a

narrow-width footprint that saves on expensive

hood space. With only one control box, all controls

are centrally located and at an angle that ensures

easy viewing and access. Our streamlined, rounded

leg stands look great and are easy to clean, meeting

all NSF requirements. We’ve even made faucets

easier to reach by moving them closer to the front

–

and you still have the option of a right-, left-handed,

or rear-mounted faucet. Plus, we’ve kept our famous

easy-to-clean, rounded interiors

–

no corners to clean.

We’ve eclipsed

even ourselves

Yes, we’ve taken a great braising pan and

made it even better. The new Eclipse™ ergonomic

tilting braising pan surpasses the competition

(and even our own pan) for performance,

water resistance, and ergonomics

–

all with a

streamlined new design.

The Eclipse is a multi-tasking, hard-working,

high-performance braising pan

–

so versatile it

can braise, grill, hold, steam, or cook just about

anything you can dish up.

Whether you choose the 30- or 40-gallon model

–

in gas or electric, with manual tilt or power

tilt

–

you’ll get a fast, high-capacity braising pan

that will get the job done.

Easy-to-reach faucet for conveniently

adding water to the pan

Even more water resistance

The Eclipse is completely water-resistant, making it

less susceptible to water splashback or spray. The

control box is also water-resistant, protecting the

electric controls

–

and your investment. We’ve protect-

ed the ignition system and pilot light on gas mod-

els with a shield or baffle. Our thermostat is more

water-resistant. And we’ve even covered the worm

and gear mechanism to protect against water. It all

adds up to the quality you

need to run a clean,

busy kitchen.

Pouring made easier

The Eclipse center tilt design maximizes floor and aisle

space, and optimizes the pour path for customer use,

even with large-capacity batches of food product. It

uses less aisle and floor space, making it easy to navi-

gate the terrain of your kitchen. Pour out pan contents

easily with no mess or waste

–

every time. The pouring

lip is designed to deliver maximum effectiveness when

pouring food product, especially liquids.

3” radius seamless interiors

for durability and cleanability

Water-resistant controls

BPM-40G, 40 gallon, manual tilt,

standard with bullet feet

THE DIFFERENCE

IS IN THE DETAILS

Both 30- and 40-gallon models

Eclipse braising pans are offered in 30- and 40-gallon models that

are perfect for new installations or replacement business. The

30-gallon model has approximately the same width dimensions

as our previous 23-gallon model, and the 40-gallon model has

approximately the same width dimensions as our previous 30-

gallon model. Depth for both 30- and 40-gallon models has

increased slightly, but has proved ergonomically sound.

30-gallon model

40-gallon model

Precision controls

Precision thermostat regulates temperature for accurate

cooking every time. Dependable electronic ignition. Patented

burner system with high efficiency means lower energy costs. No

warping maintains an even pan surface, with no burning or

sticking for shallow cooking applications.

Smooth tilting action

Our smooth-action, quick-tilting body will never jerk or halt

when tilting the pan. Available in both manual tilt and electric

tilt — electric tilt has an easy-to-access manual override.

Manual tilt has a smooth-action, self-locking hand crank that

provides precise control when pouring. Ten-inch-high pan sides

and cover minimize grease and splatter — especially important

when pouring product during tilting.

Dial thermostat control for electric units

Previous 30-gallon

Eclipse 30-gallon

Width Height Depth

49" 38" 36.5"

39" 38" 40"

Previous 40-gallon

Eclipse 40-gallon

Width Height Depth

59" 38" 36.5"

48" 38" 40"

30-gallon model

40-gallon model

Previous 30-gallon

Eclipse 30-gallon

Width Height Depth

49" 38" 36.5"

39" 38" 40"

Previous 40-gallon

Eclipse 40-gallon

Width Height Depth

59" 38" 36.5"

48" 38" 40"

30-gallon model

40-gallon model

Dial thermostat control for gas units

Hand crank wheel for

manual tilt units

BPP-30E, 30 gallon, electric tilt,

standard with bullet feet

BPM-40G, 40 gallon, manual tilt,

shown with optional casters

Counterbalance cover design

The Eclipse tilting braising pan’s improved,

counterbalanced cover design ensures ease of assembly

and easier cleaning that meets all NSF standards. The

fully adjustable cover will stay put wherever you set it

for ease of operation. The new counterbalanced cover

allows you to control steam venting more easily during

cooking. The adjustable steam vent controls condensate

during cooking. The heavy-duty cover lets you oven cook

all meats, poultry, and seafood. And the counterbalanced

cover has fewer working parts, so you’re assured of

increased durability and higher performance.

Eclipse one-year warranty

A risk-free purchase is ensured by the Groen one-year

warranty on every Eclipse model.

Pan cooking volume to nominal

Eclipse has increased pan cooking volume to nominal

for increased holding capability, while preserving safety

standards. Cook more food product faster in fewer

batches with preserved food quality, texture, and flavor.

Increased flexibility

New bullet feet are field-retrofittable and interchangeable

with our new flanged feet or casters. Four bullet feet

are standard, while our casters and flanged feet are

offered as accessories.

Groen durability

No one beats our build quality. We’ve strengthened

our hinges on the cover for increased durability

and longer life. Easy-to-clean, three-inch rounded

interiors are just part of our streamlined pan design.

Our stainless steel interiors with easy-to-clean sanitary

finishes make cleanup easy and fast.

SPECIFICATIONS

Model Power Input Dimensions Approximate

(per cavity) Width x Depth x Height* Weight

30 Gallon Electric 11.5 KW 39” x 40” x 38” 425 LBS

BPM-30E Manual Tilt or BPP-30E Power Tilt 991mm x 1016mm x 965mm (193 Kg)

30 Gallon Gas 104,000 BTU 39” x 40” x 38” 440 LBS

BPM-30G Manual Tilt or BPP-30G Power Tilt 991mm x 1016mm x 965mm (200 Kg)

40 Gallon Electric 15 KW 48” x 40” x 38” 510 LBS

BPM-40E Manual Tilt or BPP-40E Power Tilt 1219mm x 1016mm x 965mm (232 Kg)

40 Gallon Gas 144,000 BTU 48” x 40” x 38” 540 LBS

BPM-40G Manual Tilt or BPP-40G Power Tilt 1219mm x 1016mm x 965mm (246 Kg)

*Add 3-1/2” in height for stands with casters

MENU APPLICATIONS

& COOK TIMES

*Cook times are only approximate and don’t include preparation or warm-up time.

Actual cook times will depend on the condition and size of ingredients, kitchen temperature and other variables.

MENU ITEMS TOTAL QUANTITY COOK TIME* (MINUTES)

SCRAMBLED EGGS 100 Servings 5

BACON 90 Servings 10 - 12

HAMBURGER 60 Servings (4 Ounce) 5

STEAK SANDWICH 26 Servings (7 Ounce) 5

MEAT LOAF 16 Loaves 90

CHICKEN 150 Pounds 40

FISH FILLETS 50 - 100 Fillets 10 - 14

CHILI 400 Servings 20

CUT & PEELED POTATOES 10 Pounds 25

GRAVY 23 Gallons 15

CHOCOLATE MOUSSE 200 - 300 Portions 15

07/04-2 (5m)

1055 Mendell Davis Drive • Jackson MS 39272 • 888-994-7636 • 601-372-3903 • Fax 888-864-7636 • difoodservice.com

Eclipse™ is a trademark of Groen
