MODEL T32730
OUTBOARD TURNING
ATTACHMENT FOR G0733/G0766
INSTRUCTIONS
Introduction
The Model T32730 Outboard Turning Attachment
is designed to fit on the Model G0733/G0766
lathes. The 223⁄4" bed extension can be installed
to support a tool rest and replace a floor-mounted
tool post for outboard turning operations.
Description (Figure 1) Qty
A. Bed Extension ............................................ 1
B. Tool Rest Base 1" ....................................... 1
C. Tool Rest Arm 1" ........................................ 1
D. Outboard Extension Shaft .......................... 1
E. Hex Wrench 8mm ....................................... 1
F. Adjustable Handles M10-1.5 x 18, 70L ....... 3
G. Cap Screws M10-1.5 x 25 .......................... 3
Inventory
Figure 1. Inventory.
COPYRIGHT © MAY, 2022 BY GRIZZLY INDUSTRIAL, INC.
NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE
OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC.
(FOR MODELS MFD. SINCE 01/22) #CS22255 PRINTED IN CHINA V1.05.22
Installation
Wear safety glasses during
the entire setup process!
Refer to Outboard Turning in the Model G0733/
G0766 Owner's Manual to remove the tailstock
and position the headstock for outboard turning
operations.
To install outboard turning attachment:
1. Attach bed extension to lathe with (3) M10-
1.5 x 25 cap screws (see Figure 2).
AB
C
DE
FG
Figure 2. Bed extension attached to lathe.
Bed Extension
x 3
***Keep for Future Reference***
-2- Model T32730 (Mfd. Since 01/22)
Figure 6. Tool rest arm installed in base.
Tool Rest
Arm
Adjustable
Handle
Figure 3. Location of hex nut and clamp plate.
2. Remove hex nut and clamp plate from tool
rest base (see Figure 3).
3. Place tool rest base on bed extension
with clamp bolt inserted through bed (see
Figure 4).
Figure 4. Clamp bolt inserted through bed and
location of eccentric rod handle.
4. Install clamp plate and hex nut removed in
Step 2 on clamp bolt and hand-tighten (see
Figure 5). Clamp plate must be aligned with
extension bed to sit flush.
Figure 5. Clamp plate and hex nut installed on
clamp bolt.
5. Rotate eccentric rod handle to secure tool
rest base on bed extension (see Figure 4).
Note: If eccentric rod handle does not secure
tool rest base, tighten hex nut from Step 4
until it does.
6. Install either tool rest arm or outboard exten-
sion shaft in tool rest base hole, then secure
with adjustable handle (see Figures 6–7).
— Tool rest arm provides extra adjustment
and reach for larger workpieces.
Tool Rest
Base
Clamp
Bolt
Clamp
Plate
Clamp
Plate
Eccentric Rod
Handle
Model T32730 (Mfd. Since 01/22)-3-
8. Loosen tool rest lock handle, then remove
tool rest.
9. Install tool rest in outboard extension shaft,
then secure with adjustable handle (see
Figures 9–10).
Figure 7. Outboard extension shaft installed in
base.
Outboard
Extension
Shaft
Adjustable
Handle
Figure 8. Outboard extension shaft installed in
tool rest arm.
Outboard
Extension
Shaft
Adjustable
Handle
Figure 9. Tool rest installed in outboard
extension shaft.
Tool Rest
Adjustable
Handle
Figure 10. Tool rest installed in outboard
extension shaft with arm.
Adjustable
Handle
Tool Rest
Refer to Model G0733/G0766 Owner's Manual
for instructions on operating lathe.
If you need help with your new outboard turning
attachment, call Tech Support at: (570) 546-9663.
— If installing tool rest arm, proceed to
Step 7.
— If installing outboard extension shaft, pro-
ceed to Step 8.
7. Install outboard extension shaft in tool rest
arm, then secure with adjustable handle (see
Figure 8).
-4- Model T32730 (Mfd. Since 01/22)
BUY PARTS ONLINE AT GRIZZLY.COM!
Scan QR code to visit our Parts Store.
1
2
3
4
5
6
7
8
9
10
11
12
8
8
11
T32730 Parts Breakdown & List
REF PART # DESCRIPTION REF PART # DESCRIPTION
1 PT32730001 HEX NUT M18-2. 5 7 PT32730007 TOOL REST BASE 1"
2 PT32730002 CLAMP PLATE 8 PT32730008 ADJUSTABLE HANDLE M10-1.5 X 18, 70L
3 PT32730003 TOOL REST CLAMP BOLT M18-2.5 X 44 9 PT32730009 OUTBOARD EXTENSION SHAFT
4 PT32730004 CAP SCREW M10-1.5 X 25 10 PT32730010 TOOL REST ARM 1"
5 PT32730005 BED EXTENSION 11 PT32730011 EXT RETAI NI NG RI NG 19MM
6 PT32730006 ECCENTRI C HA NDLE 12 PT32730012 HEX WRENCH 8MM
Please Note: We do our best to stock replacement parts whenever possible, but we cannot guarantee that all parts shown here
are available for purchase. Call (800) 523-4777 or visit our online parts store at www.grizzly.com to check for availability.
