INSTRUCTION MANUAL
Gas Range
Models:
CF-FS60/CF-FS60B
GREYSTONE®
3
Safety Precautions
WARNING
Never Operate The Top Surface Cooking Section of this
Appliance Unattended
Failure to follow this warning statement could result in
fire,explosion,or burn hazard that could cause property
damage,personal injury,or death.
If a fire should occur,keep away from the appliance and
immediately call your fire department.
DO NOT ATTEMPT TO EXTINGUISH AN OIL/GREASE FIRE WITH
WATER.
WARNING
A child or adult can tip the range and be killed.
Install the anti-tip device to the structure and the range. Verify the anti-
tip device has been properly installed and engaged.
Engage the range to the anti-tip device by wall and cabinet. Ensure the
anti-tip device is re-engaged when the range is moved.Re-engage the
anti-tip device if the range is moved. Do not operate the range without
the anti-tip device in place and engaged.
See installation instructions for details.
Failure to do so can result in death or serious burns to children or
adults.
WARNING
Warning: If the instructions in this manual are not
followed exactly, a fire or explosion may result causing
property damage, personal injury or death.
- Do not store or use gasoline or other flammable vapors
or liquids near this or any appliance.
-WHAT TO DO IF YOU SMELL GAS:
Do not try to light any appliance
4
Do not touch any electrical switch
Turn off the gas supply tank valve(s) or main gas
supply
From a location away from the gas smell, Immediately
call your gas supplier for instructions
If you cannot reach your gas supplier, call the fire
department
-Installation and service must be performed by a qualified
installer,service agency or the gas supplier.
is the safety alert symbol. This symbol alerts you to
potential hazards that can result in property damage
and/or serious bodily harm or death. All safety messages
will follow the safety alert symbol and either the word
WARNING or CAUTION. These words mean:
WARNING
Warning: Hazards or unsafe practices COULD result in severe
personal injury or death.
Caution
Caution: Hazards or unsafe practices COULD result in minor
personal injury
Read the follow all instructions before using this application to prevent the
potential risk of fire, electric shock, personal injury or damage to the
appliance as a result of improper usage of the appliance. Use appliance
only for its intended purpose as described in this guide.
Warning and important safety instructions appearing in this guide are not
meant to cover all possible conditions and situations that may occur.
Common sense, caution, and care must be exercised when installing,
maintaining, or operating the appliance. Always contact the manufacturer
about problems or conditions you do not understand.
5
Table of Contents
Safety Precautions......................................................................... 3
Getting Started................................................................................6
Safety Instructions..........................................................................7
Installation..................................................................................... 10
Gas range Features......................................................................13
Operation.......................................................................................14
Troubleshooting............................................................................21
Cleaning and Maintenance.........................................................22
Exploded-View Drawing..............................................................26
Warranty........................................................................................ 28
Contact Information..................................................................... 32
6
Getting Started
We appreciate your purchase of the GREYSTONE gas range.
Prior to operating your new appliance, please read this
manual carefully. This instruction manual contains information
for safe use, installation and maintenance of the appliance.
You will want to keep this manual handy for future reference.
Using the gas range by following the directions in this manual
will help ensure safe use and reduce the risk of injury. Please
pass on this manual to future owners of your gas range.
The manufacturer accepts no responsibility for any damage
caused by not observing these instructions.
7
Safety Instructions
To reduce risk of tipping of the appliance from abnormal
usage, the appliance must be secured by a properly
installed anti-tip device.
Remove all tape and packaging before using the gas
range. Destroy the carton and plastic bag after
unpacking the gas range. Never allow children to play
with packaging material.
Your appliance should be installed by a qualified
technician in accordance with state and locals laws.
Never modify or alter the construction of a gas range by
removing leveling legs, panels, anti-tip brackets/screws,
or any other pant of product.
Children climbing on the gas range to reach items could be
seriously injured.
WARNING
NEVER use this appliance as a space heater to warm a room.
Doing so may result in carbon monoxide poisoning and
overheating the appliance.
NEVER cover rear vent on counter top. Never cover an entire
rack with materials such as aluminum foil or any other
flammable items. Doing so blocks air flow through the grill and
may cause carbon monoxide poisoning, explode, or start a
fire.
The appliance and its individual shutoff valve must be
disconnected from the gas supply piping system during any
pressure testing of that system at test pressures in excess
of 1/2 psi(3.5 kPa).
8
The appliance must be isolated from the gas supply piping
system by closing its individual manual shutoff valve during
any pressure testing of the gas supply piping system at test
pressures equal to or less than 1/2 psi(3.5 kPa).
The maximum gas supply pressure 1/2 PSI,the gas supply
pressure for checking of the regulator setting: 10in.wc.The
gas supply pressure for checking of the regulator setting
shall be at least 11 in wc (2740Pa).
DO NOT TOUCH SURFACE BURNERS, AREAS NEAR
THESE BURNERS.
During and after use, do not touch or let clothing or other
flammable items touch these areas until they have sufficient
time to cool down. Both surface burners may be hot even
though flames are not visible and may be hot enough to cause
burns.
Wear proper apparel: Loose fitting or hanging clothing
should never be worn while using this appliance.
When heating fat or grease, watch it closely. Fat and grease
may catch fire if allowed to become too hot. If there is a
grease fire, smother the fire with a pan lid, use baking soda,
or a dry chemical or foam-type extinguisher. DO NOT USE
WATER OR FLOUR.
WARNING
Gas leaks may occur in your system and result in a dangerous
situation. Gas leaks may not be detected by smell alone. Gas
suppliers recommend you purchase and install an UL
approved gas detectors. Install and use in accordance with
the manufacturer’s instructions.
9
Use only dry potholders and do not let potholders touch hot
heating burners. Do not use a towel or other bulky doth or
towels in place of potholders.
Never heat unopened food containers as the buildup of heat
and pressure may cause container to explode and result in
injury.
Instructions for using your gas range
Using proper flame size: adjust flame so it does not extend
beyond the edge of utensils. Undersized utensils will expose
a portion of the burner flam to direct contact and may result
in ignition of clothes. Proper utensil and flame size will
improve efficiency. Burners are different sizes for different
utensil sizes.The furniture above hobs has the potential risk
during gas range working.
If you use stove top grill on a sealed gas burner, it will cause
incomplete combustion and can result in carbon monoxide
poisoning.
Know which knob controls each surface burner. Place a pan
of food on the burner before turning it on, and turn the
burner off before removing pan.
Always turn the knob to the full HI position when igniting top
burners and visually check that burner is lit.
Then adjust the flame so it does not extend beyond the
edge of the utensil.
Utensil handles should be turned outward and not extend
over adjacent surface burners. This will help reduce the risk
of burns, ignition of flammable materials, and spillage due to
unintentional contact with the utensil.
Never leave surface burners unattended at high heat
settings: Boil overs cause smoking and greasy spillovers
that may ignite.
10
Protective liners: Do not use aluminum foil to line surface
burner pans, except as suggested in this manual. Improper
installation of these liners may result in risk of electric shock
or fire.
Cleaning Instructions
Clean your gas range regularly to keep all parts free of
grease that could catch fire. Exhaust fan ventilation hoods
and grease filters should be kept clean. Do not allow grease to
accumulate on hood or filter as greasy deposits in the fan
could ignite. When you are cooking food under the hood, turn
the fan on.
Installation
The installation must conform with local codes or, in the
absence of local codes, with the National Fuel Gas Code,
ANSI Z223.1/NFPA 54 or, in Canada, the Natural Gas and
Propane Installation Code, CSA B149.1. The appliance, when
installed, must be electrically grounded in accordance with
local codes or, in the absence of local codes, with the
National Electrical Code, NFPA 70 or the Canadian Electric
Code, CSA C22.1-02.
WARNING
Installation of this appliance must adhere to the written
instructions in this manual. No agent, representative or
employee of the manufacturer of GREYSTONE appliances
or other person has the authority to change, modify or
waive any provision of the instructions this manual.
The minimum clearance of 0” between the adjacent
combustible construction and the back of the
