INSTALLATION INSTRUCTIONS
FOR PORTABLE XENON FLOODLIGHT
TXP400 -230V/400W
TXP400Y - 110V/400W
IMPORTANT SAFETY INFORMATION
ELECTRICAL SAFETY
This worklight must e earthed. If it ecomes necessary to
rewire the plug please follow these guidelines. Always secure
wires in plug terminals carefully. Make sure the ca le is firmly
located in the cord grip. NEVER connect the green & yellow wire
to any terminal other than one marked with the earth sym ol ‘E’
or ‘ ’.
Regularly inspect all electrical connections and wiring for
damage. Any faults should e immediately rectified efore
further use of the worklight. Always have the wiring and
connections checked y a qualified electrician. In use, ensure all
wiring and extension ca les are kept clear of any cutting tools,
sharp o jects and any other potential hazards such as wet
floors, chemicals & solvents etc.
Note:
If your mains wiring differs in any way from Diagram A. Consult
a qualified electrician. Always replace the fuse with one of an
identical rating.
1. Slide the stand into the worklight racket (G).
2. Align the holes in the racket and the stand.
3. Insert and tighten angle adjustment control (D).
4. To alter the angle of the worklight, simply loosen the angle
adjustment control (D), pivot the worklight until the
desired angle is achieved and re-tighten control (D).
5. Check the worklight is secure and that the stand is sta le and
has a firm footing.
6. Ensure ca le is not catching on any sharp o ject and that the
mains plug connection is adequately protected against rain or
moisture.
7. Your worklight is now ready for use.
Blue: Neutral to ‘N’ Terminal
Brown: Live to ‘L’ Terminal
Green & Yellow: Earth Terminal
Diagram A
ASSEMBLY AND USE
WEST ROAD . HARLOW
ESSEX . CM20 2BG . UK
sales@green rook.co.uk
WWW.GREENBROOK.CO.UK
Issue No: 702190
PART IDENTIFICATION
A. Padded Carry Handle
B. Cover Retaining Screw
C. Protective Grill
D. Angle Adjustment Control
E. Stand
F. Mains Ca le
G. Worklight Bracket
A
F
G
B
C
D
E
INSTALLER - Please pass instruction manual
onto the owner of the unit
Please keep these instru tions
for future referen e.
FITTING THE LAMP
CAUTION:
This unit an be ome extremely hot whilst in operation, do not
tou h the unit until it has had time to ool down. Make sure the
worklight is far enough away from any ombustible materials
and/or surfa es. Make sure there is adequate ventilation to aid
heat dissipation.
TECHNICAL DATA
Power Source:-
TXP400: 230V-50Hz
TXP400Y: 110V-50Hz
Lamp Wattage:-
TXP400:400W class C Xenon Tu e
TXP400Y:400W class C Xenon Tu e
IP Rating: IP54
Power Cord: H05VV-F 3x1.0mm2
1. To fit the supplied Xenon lamp you need to loosen the screw
(B) securing the hinged front cover and swing the cover down.
The lamp is attached y spring loaded holders at each end.
2. Gently locate the lamp into position ensuring good contact at
oth ends. Take care not to touch the glass of the lamp, if this
does occur clean the lamp with methylated spirit.
3.Close the hinged front cover and re-tighten the top retaining
screw(B).
DO NOT OVERTIGHTEN,
THIS MAY DAMAGE THE GLASS.
Note:
The lighting direction cannot e adjusted downwards.
