GRE DECK1 Manual de usuario
HIMDECK1.22EN
DECK1
Before starting assembly, read carefully the instruction
manuals of every components of the kit.
Keep this instructions for future reference.
Non-contractual photos and pictures.
ASSEMBLY INSTRUCTIONS EN
MADE IN FRANCE
Manufacturas Gre, S.A. Aritz bidea nº 57
Belako industrialdea, apartado 69
48100 Munguia (Vizcaya) España
nº reg. Ind. 48-06762
Safety
precautions.
Preparation
of the site.
Components. Installation.
Guarantee.
Save this page for future claims
and / or returns.
#1 03 - 07 #2 08 - 09
#3 10 #4 11 - 20
21 - 23
#1
Safety
precautions.
OK
0º
EN
safety precautions
Safety
precautions.
Carefully read, understand, and follow all
information in this user manual before installing
and using the swimming pool.
These warnings, instructions, and safety
guidelines address some common risks of water
recreation, but they cannot cover all risks and
dangers in all cases.
Always use caution, common sense, and good
judgment when enjoying any water activity.
Retain this information for future use.
Non Swimmers safety:
Continuous, active, and vigilant supervision
of weak swimmers and non-swimmers by
a competent adult is required at all times
(remembering that children under five are at
the highest risk of drowning).
→ Designate a competent adult to supervise the
pool each time it is being used.
→ Weak swimmers or non-swimmers should
wear personal protection equipment when
using the pool.
→ When the pool is not in use, or unsupervised,
remove all toys from the swimming pool and
its surrounding to avoid attracting children to
the pool.
Safety devices
→ It is recommended to install a barrier
(and secure all doors and windows, where
applicable) to prevent unauthorized access to
the swimming pool.
→ Barriers, pool covers, pool alarms, or similar
safety devices are helpful aids, but they are
not substitutes for continuous and competent
adult supervision.
Safety equipment
→ It is recommended to keep rescue equipment
(e.g. a ring buoy) by the pool.
→ Keep a working phone and a list of emergency
phone numbers near the pool
Safe use of the pool
→ Encourage all users especially children to learn
how to swim.
→ Learn Basic Life Support (Cardiopulmonary
Resuscitation - CPR) and refresh this
knowledge regularly.
3
assembly instructions
This can make a life-saving difference in the
event of an emergency.
→ Instruct all pool users, including children, what
to do in case of an emergency.
→ Never dive into any shallow body of water. This
can lead to serious injury or death.
→ Do not use the swimming pool when using
alcohol or medication that may impair your
ability to safely use the pool.
→ When pool covers are used, remove them
completely from the water surface before
entering the pool.
→ Protect pool occupants from water related
illnesses by keeping the pool water treated
and practicing good hygiene. Consult the
water treatment guidelines in the user’s
manual.
WARNING
Every electrical appliance fed in
220V, has to be located at least at
3,50 m from the edge of the pool.
The equipment should be
connected to a voltage, with
earth connection, protected by
a residual current device (RCD)
having a rated residual operating
current not exceeding 30mA.
Read the instructions carefully
and keep for future reference.
IF YOU HAVE ANY PROBLEM,
CONTACT US!
www.grepool.com/en/after-sales
→ Store chemicals (e.g. water treatment,
cleaning or disinfection products) out of the
reach of children.
→ Signage is to be displayed in a prominent
position within 2 m of the pool.
→ Removable ladders shall be placed on a
horizontal surface.
4
EN
safety precautions
STORAGE
INSTRUCTIONS.
This pallet should be stored on a level floor,
preferably concrete.
If the pool is going to be immediately assembled:
• Revise the content.
• Assemble it as soon as possible to avoid
deformation of the parts after having released the
pallet straps.
If the pool is not going to be immediately
assembled:
• Do not remove the straps form the wooden pallet.
• In the case of having to undo the pallet and the
pool is not going to be immediately assembled,
the pallet should be rebuilt assuring good fixing to
avoid deformation of the parts (using ropes, straps,
etc).
NOTE:
In both cases, put weight on top to
assure the parts remain flat. Store
the pallet in an adequately ventilated
place.
5
IMPORTANT
In the case of breakages and/or deformations
of the wood, make a complete inventory of the
state of the pieces before requesting them from
after-sales. This way, the pieces will all arrive in
the same delivery.
After a few months since assembling the pool
we recommend using a water-based dye to
hydrate the wood. Remember wood is a live
being. This reduce the appearance of fissures.
This dye is advisable on copping because
being most exposed to sunlight and chemical
1.1
Autoclave 4
2 días
products. If you decide to paint your pool, make
sure the product you use is adequate for wood
treated with Autoclave 4.
Once you open the pallet of the wood, the pool
must be assembled within a maximum period
of two days. In addition, we suggest doing this
on days without any rain to avoid that the wood
is humidified, complicating the final assembly.
assembly instructions
IMPORTANT:
Without these numbers you can
not claim the warranty.
Compulsory
FICHE DE GARANTIE FABRICANT
PISCINE CANELLE
Piscine Bois RL 551 x 351 H119 All - 8 pans
Référence Designation QTE Unité
BOV551119 LOT Bois Pin V4 1 UN
KITBCANELLE Bois Pin V4
786266 Sabot renfort 2 UN
622564 Sac de Sable 1 UN
→ It is mandatory to keep it in order to use the
warranty
6
Cracks Resin
Diferencias de
tonalidad
Nerves and long
knots
Retention of sterilization
products
Surface mould Round knots
WOOD: A LIVING MATERIAL
Wood is a natural product, the fissures visible on
the edges of the wood are completely normal and
do not modify the resistance characteristics of
the same.
Wood is always a malleable material (from 3% to
4% of dimensional variations) with humidity and
temperature oscillations. Therefore, small cracks
can appear and in order to limit later deformations,
the technical criteria have been respected regarding
the design, the choice of sections, and of packaging
and the fixing methods.
Knots are natural elements of wood: their aspect
and their size vary from one product to another.
Mould can appear on the surface of wood, although
not penetrating into it and not degrading it. After
being treated with UV radiation, wood turns greyish
with time without this affecting its durability.
Varnish can be applied to wood treated in autoclave.
In addition to protection, varnish contributes to the
beauty and long-life of wood. In this case¡, wait for
the wood to completely dry before applying the
varnish.
The secretion of resin is a natural phenomenon of
resinous wood. Just as no tree is like another tree,
the following photographed elements cannot be
considered as defects:
1.2
EN
guarantee
IMPORTANT:
SYLVESTER PINE TREATED IN AUTOCLAVE
The wood we use is select pine and dried to 2.5% before treatment in class
IV utoclave. It has a 10-year guarantee against insect attack and against
rot for the parts in the ground.
7
1667
1358
924
1056
1000
600391
900
1795
#2
assembly instructions
Preparation
of the site.
8
EN
preparation of the site
1
2
3568mm
6318mm
50cm
90º
25
cm
50
cm
6520+1887=8407mm
4568mm
1887mm
3854mm
3568mm
25cm
25
cm
50
cm
4068+1887=5955mm
4354mm
1887mm
Ref. 790302 VASTO + DECK
L: 5,95 x A: 4,35 x AL: 0.10 m = 2.58 m3of concrete.
AREA REQUIRED
Ref. 7900892 SAFRAN 2 + DECK
L: 8,47 x A: 4,57 x AL: 0.17 m = 6.58 m3of concrete.
9
#3
Components.
ref no. description qty
32 CACHE L 22X56X1400 3
33 CORBELET 46X145X225 2
1 LAME 22X133X379 7
2 LAME 22X133X1095 1
34 LAME 22x133x1095 1
3 LAME 22x133x1655 7
4 LAME 22X133X2135 9
35 LAME 22X133X2135 1
5 LAME 22X133X2634 2
36 LAME 22X1332634 1
19 LIM F ECH 28/145/1.612 1
20 LIM G ECH 28/145/1.612 1
13 MARCHE ECH 28X145X586 4
9 MARG STD 28X145X115 1
10 MARG STD 28X145X260 1
11 MARG STD 28X145X405 1
12 MARG STD 28X145X550 1
14 MARG STD 28X145X695 1
15 MARG STD 28X145X840 1
16 MARG STD 28X145X985 1
17 MARG STD 28X145X1000 1
18 MARG STD 28X145X1200 2
21 MARG STD 28X145X1795 2
22 MARG STD 28X145X1800 1
23 MARG STD 28X145X2634 9
6 PORTE 44X594X924 1
30 POTEAU 68/68/1330 1
31 POTEAU 68/68/2358 5
38 SOLIVE 36/120/369 1
25 SOLIVE 36/120/795 2
37 SOLIVE 36/120/841 1
26 SOLIVE 36/120/955 1
27 SOLIVE 36/120/1055 4
28 SOLIVE 36/120/1190 4
29 SOLIVE 36/120/1800 1
24 SUPPORT 36/120/250 4
8 TASSEAU 22/68/1124 2
assembly instructions
23
17
22
18 32 16336
35
5
4
13
19
20
23
32
32
21
21
23
16
15 14
12
11
10 9
24 24
24
24
37 27 27
31
31
31
31
30
26
31
29
28
25
25
28
27 27
28 28
10
