The Grasshopper
Owners Manual
Classic - Cobra - Junior
(Twin Motor Models)
Golf Buggy
Page 2
TECHNICAL SPECIFICATION
Model: CLASSIC , COBRA & JUNIOR
Power: Twin 24 Volt Permanent Magnet 300 Watt
D.C. Motors
Transmission: Direct Drive Through 30:1 Reduction Gearboxes
Speed Control: Twist grip step-less control for smooth operation
up to max. 8mph.
Direction Control: Forward/Reverse switch conveniently located on
the main control panel.
Safety Features: Piezo reverse warning horn .
Climbing Ability: 1:3 Gradient.
Brakes: Non-fading regenerative braking
plus electromagnetic parking brake.
Battery Charging: Charging unit plugs directly into rear of buggy.
Batteries: Two sealed lead acid 12 V x 80/85amp coupled in
series
Battery Charger: 8 Amp, 24 Volt with automatic cut-out when
charging complete.
Body: Hand Made in Non-Rusting Glass Reinforced
Plastic
Chassis: MIG Welded High Tensile Steel, With Corrosion
Protection
Tyres: 13” x 6.5” x 6” Tubeless.
Turning Radius: 102” (140” Junior & Cobra)
Overall Height: 34”
Overall Width: 36” (27” or 30” Junior - 30” Cobra)
Overall Length: 48” (50” Junior & Cobra)
All Specifications subject to change without notice
Page 3
INTRODUCTION
Thank you for choosing a Grasshopper Golf Buggy, a product designed
and engineered by Grasshopper Golf Buggies Ltd.
This manual provides all the information you will require to drive your
buggy safely and to see that it continues to perform perfectly.
Ensure that you read and understand this manual thoroughly.
It is recommended that insurance cover to include third party liability,
theft and accidental damage should be taken. Some household insurance
companies will give extended cover.
We can supply details of ‘Fish Insurance’ an independent insurance
company recommended by Grasshopper Golf Buggies Ltd.
The Grasshopper Junior, Cobra & Classic
Page 4
CONTROL PANEL
1. Ignition Switch
2. Power LED (Green)
3. Battery Charge Indicator (Design may vary see insert)
4. Forward / Reverse LED (Red)
5. Forward / Reverse Switch
6. Speed Control Adjustment
Ignition Switch
Main On/Off Power Switch. Ensure that this is switched off before dismounting
to prevent accidental use of the accelerator.
Power LED (Green)
When lit this indicates that the ignition is switched on and power is connected
1 2 3 4 5 6
Page 5
Battery Charge/Power Indicator
There are two different types, both consist of a series of LED lights., when fully
charged the top or right hand light (dependant on type), will be illuminated As
battery charge is used, the light will move either down or to the left. It is advis-
able to leave the course when the final light is illuminated.
Forward / Reverse LED (Red)
Indicates when the reverse mode switch has been selected, it operates in
conjunction with a warning horn.
Forward/Reverse Switch:
This is a rocker switch, when pressed at the top forward mode is selected, when
pressed at the bottom reverse mode will be selected.
Speed Control Adjustment:
When turned fully, counter-clockwise, the buggy will move forward at 2 m.p.h.
By rotating the control clockwise the speed can be increased to a maximum of
8 m.p.h.
DRIVING THE VEHICLE
Sit comfortably on the vehicle and ensure feet are located on the foot tray. Place
both hands upon the handlebars. The steering column can be moved towards or
away from the driver to suit individual comfort.
The place the key in ignition switch on the control panel. Turn it 90 degrees
clockwise to connect the power. The charge/power indicator will light up to
indicate power on and will show the battery charge status.
Select forward or reverse mode and turn the
accelerator grip gently towards you.
The further the grip is turned the faster the
vehicle will travel. To slow down, gently
return the grip to its resting position.
The grip is spring loaded and if released will
immediately cause the vehicle to slow down
and stop.
Accelerator Twist Grip
Page 6
BRAKING SYSTEM
Regenerative Braking System: When you release the accelerator grip, for
example when travelling down slopes or up hills, the motor provides a reverse
pull effect, rapidly bringing your vehicle to a stop.
Electro Magnetic Brake: This is an automatic safety device, which locks the
motor once the vehicle has stopped moving, it prevents it from rolling even if
the power is switched off.
The brake lifts off as the accelerator is turned to move forward and re-applies
when the accelerator returns to its resting position.
To enable the vehicle to be pushed without battery power there is a free wheel
device fitted to your vehicle. By removing the battery cover you will see a lever
at the top of each of the two electric drive motors (see below), turn them
clockwise as far as they will go, you are now able to push your vehicle. There
will however still be some resistance against the motor.
Note: Ensure you return the brake release levers to there original
position, by turning the levers fully counter-clockwise, before
driving the vehicle.
Page 7
BATTERIES
Your new Grasshopper Golf Buggy is fitted with SEALED GEL batteries.
Please ensure that the correct maintenance is carried out as per the infor-
mation below to prolong their life. DO NOT fit other types of battery
without first checking compatibility with Leisure Karts.
Charging your Batteries
The first charge should be for 24 hours. Subsequent charges should be
five hours maximum. Unless you have a fully automatic charger which
automatically cuts out when charging is complete, you should connect
your charger using a timer to ensure the five hour charge is not exceeded.
We do not recommend that you leave the charger
on for long periods of time once the batteries are
fully charged as this will shorten the life of the
battery.
Step One – Connect the charger plug into the
charging socket on the rear of the Buggy, there is a
locating groove to ensure correct polarity.
Step Two – Plug the charger into the mains and switch the mains on, (an
in-built safety feature will disable the power system of the buggy).
When using the charger, keep it well ventilated and dry, it is suitable for
indoor use only. It is normal for the charger to become warm during use.
Always carry the charger never pick it up by the cables.
If you have difficulty finding a suitable place to charge your batteries you
may charge them independently with an off-buggy charging lead.
(Available as an optional extra).
Page 8
Battery Maintenance
Your batteries are the heart of your vehicle and the better you take care of
them the longer they will last.
Charge your Buggy nightly when in daily use.
Connect the charger to the Buggy before switching on the
mains.
Keep the battery terminals and connectors clean.
When using the charger allow plenty of airflow around it.
Charge your Buggy in a well ventilated area.
Do not leave your Buggy uncharged, this will shorten the life
of the batteries
Only use the recommended charger.
Charge for a maximum 5 hours—Use a timer if necessary.
Battery Life Expectancy
Many factors can significantly alter the performance of the batteries.
The weight of the occupant.
The type of terrain covered.
The style of driving.
Incorrect tyre pressure (we recommend 20 - 29 psi)
The age and condition of the battery.
The ambient temperature the vehicle is used in.
Page 9
TRANSPORTING YOUR BUGGY
One of the main design criteria for the Grasshopper Classic, was ease of
transportation.
There are two options dependant or the type of vehicle used to carry your
buggy.
Firstly, if you have a large family hatchback, MPV or estate car, then you
are able to load the buggy into the rear of the vehicle without dismantling,
other than removing the seat (even this may not be necessary with larger
vehicles).
This is achieved by placing ramps up to the rear of the vehicle and using
the buggies own power, driving the buggy up into the vehicle.
Visit www.grass-hopper.co.uk and view a short video demonstrating how.
Secondly, if your car is not able to accommodate the fully assembled
buggy, you can easily dismantle the buggy into manageable parts
allowing it to be placed into the boot of most cars - The only tool
required is a 13mm Spanner to undo the battery terminals.
Page 10
HOW TO DISMANTLE THE BUGGY
Remove the Seat - On the base of the seat stem you will find the seat
locking bolt. Turn this counter
clockwise to loosen the seat
from the frame. however the
lever can only rotate 180
degrees because of the body of
the buggy, to overcome this,
the lever has a ratchet system to allow further
movement. Pull the lever away from the post
turn it back to the original position and allow it
to spring back, once again turn the lever to
unscrew the bolt until the seat can be removed. To re-assemble reverse
the procedure.
Remove the Battery Cover and Batteries
Remove the battery cover by releasing
the three spring clips (four for the
Junior) and then pulling the cover up
and away from the frame.
Unscrew the battery terminal nuts and lift away the cables (only one nut
needs to be removed from the short link cable).
Lift batteries vertically from the frame and stand them in a secure
position.
