Manual Instruction

for Table-Top Screen

Model: PT-Uxx

U-WORK

Description

Accessories

Bag (1pcs) Manual Instruction (1psc)

Illustration

Part name

Opener

Foot

Casing

Left End Cap

Black Border

Fabric

End Cap

Cover

End Cap

Right End Cap

Conjugation

Support Lever

Joint

Support Lever

Locker

Front RearSide

W (mm) L (mm) H (mm) A (mm)

PT-U-32

488 742 566

650

4:3

PT-U-40

813 610 905 688

4:3

Specifications

Format Model Specification

(In)

Viewing area Screen dimension

Net weight

(kg)

Note: Sizes and specifications are subject to change at any time. Refer to real product for exact data.

The tolerance for L is ± 5mm.

The surface of screen is processed to achieve good performance of the reflector. Any

damage of surface will influence projection effects so please use this product in right way.

Caution

Please do not shake the screen by hand.

Please do not make any marks on screen

surface.

Prohibited

Prohibited Prohibited

Prohibited

Please do not use any cloth with water, volatile oil and

corrosive cleaning agents to clean the screen, because

they will make the surface metamorphism and paint off.

Please do not pull the screen strongly that it will cause

the risk of damage.

Any stains on the casing, please use dry-cloth to

clean softly. If too serious, please use soft-cloth

with water-diluted neutral detergent to clean.

Neutral

Detergent

Please use a brush to clean the dust of screen surface

softly.

Please keep the screen far away from sunshine,dust and wet. Avoid using the screen in strong wind.

Tips The surface of screen is dried

before shipment; if have any

strong smell, please open the

windows.

Note

Maintenance

Location Caution

Please contact your local dealer for repairing and

replacing. Please contact us if you have any questions.

Avoid taking apart the fixture yourself.

Proh ibited

Taking Ap art

Caution

1.13

1.46

1. According to figure 3-1 and 3-2, following the steps to close the screen.

2. According to figure 4-1, using fingers to hold the opener and push the screen down (figure 4-2). Please

ensure that the cover is locked to the casing that the retracting is completed (figure 4-4).

Figure4-1 Figure4-2

Figure4-3

Figure 3-1 Figure 3-2 Figure 3-3

收合银幕

Retracting

1. Stay the screen on suitable position and the screen faces to projector, and the set up the

foot of screen (figure 1, 2 and 3)

2. According to figure 2-1, use fingers to hold the opener, and then pull the screen up to your desired

position slowly (figure 2-2)

Figure1

Figure 2

Figure 3

Figure 2-1 Figure 2-2

Expanding

Figure4-3

Note: Avoid hurting fingers while running those operations(figure 4-3).

Be careful
