Grand Cinema SIM2 HT3000 Manual de usuario
Headquarters:
SIM2 MULTIMEDIA S.p.A.
Viale Lino Zanussi, 11
33170 Pordenone - Italy
Tel. +39.0434.383256
Telefax +39.0434.383260
Web site: www.sim2.com
Germany:
SIM2 DEUTSCHLAND GmbH
ArndStr. 34-36
D-60325 Frankfurt Am Main
Tel. +49.0800-800 7462
Fax. +49.0800-900 7462
e-mail: [email protected]
web site: www.sim2de.com
UK:
SIM2 UK LTD
Steinway House, Worth Farm
Little Horsted, Nr. Uckfield
East Sussex TN22 5TT
Tel. +44.01825.750850
Telefax +44.01825.750851
e-mail: [email protected]
USA:
SIM2 USA INC.
10108 USA Today Way
Miramar, FL 33025
Tel. +1.954.442.2999
Telefax +1.954.442.2998
E-mail: [email protected]
Web site: www.sim2usa.com
SIM2 Multimedia is certified
UNI EN ISO 9001
Due to constant product development, specifications and design might be subject to change without notice. GRAND CINEMA HT3000 leaflet - World - June 2006
Key points
•New 0,95" 1080p DLP® chipset
by Texas Instruments
•1920 x 1080 pixel HDTV resolution
•Proprietary SIM2 ALPHA PATH™
light engine
•New 7-segment color wheel
(RGBRGB + NDF Neutral Density
Filter)
•2 HDMI™ HDCP inputs
•Contrast ratio >5000:1
•Lamp: 200W (dimmed)
•SIM2 Live Colors Management and
Gamma Functions
•Intelligent memory functions
•New Dynamic Noise Reduction and
Spatial Noise Reduction
SIM2 Multimedia presents the latest
addition to: their award-winning
Grand Cinema™ HT range:
the all-new Grand Cinema HT3000.
This premier single chip projector
offers true, uncompressed
1920x1080 HDTV
Resolution, thanks to a new 0,95"
1080p DLP® chipset from Texas
Instruments.
Combining this new chipset with
full 10 bit video processing, SIM2’s
ALPHA PATH™ light engine and
Live Colors Management system,
HT3000 is able to reach a new level
of cinematic realism in single chip
projection.
This is achieved in typical SIM2 style
through a balanced design ethos:
a fined tuned system will always
deliver the best results.
HT3000 has a wide range of both
analogue and digital video inputs,
including two HDCP enabled HDMI™
sockets, ensuring compatibility with
the vast array of today’s video
sources (including HD).
Taking styling cues from the C3X
series, HT3000 sports an elegant
Giorgio Revoldini designed cabinet
in SiM2’s signature Gunmetal finish.
SIM2 Grand Cinema™HT3000
The new benchmark for future standards
in single-chip front projection Grand Cinema™ HT3000:
Technical Specifications
LIGHT ENGINE
Technology: 1 chip DMD 0,95” 1080p DarkChip3™
Resolution: 1920 x 1080 pixels
Color Wheel: 7 segment (RGBRGB+NDF Neutral
Density Filter)
Lamp power & life time*: 200W dimmed, 4000 hours*
INSTALLATION
Throw ratio: 1,5-2,0:1
Lens shift: V+/-6°
Digital keystone adjustment: V+/-18°
Picture size (inches diagonal): 50-300
Aspect ratio: 4:3, 16:9 Anamorphic, LetterBox,
panoramic, pixel to pixel + 3 custom-user adjustments
ELECTRONICS
Horizontal & vertical scan freq.: 15-80kHz/48-100Hz
Video and Graphic standards: PAL (B,G,H,I,M,N,60);
SECAM; NTSC 3,58; NTSC 4,43 automatically
selected; HDTV: ATSC (480p, 720p, 1080i, 1080p); EU
576p + 1080i 50Hz; PC graphic: VGA, SVGA, XGA,
SXGA, UXGA
Contrast ratio (Full ON/ Full OFF): >5000:1
Format Board: 10 Bit
Video processor: built in
Special video adjustments: Dynamic Noise Reduction,
Spatial Noise Reduction, Fleshtone Regulation
Other special adjustments: Memories/Overscan, Live
Colors Management (LCM) and Gamma Functions
INPUTS/OUTPUTS
1 x Composite Video (RCA)
1x S-Video (mini Din 4 pin)
1 x RGBS/YCrCb (4x RCA)
1 x RGBHV/YCrCb (1x VGA)
2 x HDMI – HDCP compliant
1 x OUT Digital Audio (Toslink)
1 x RS232 (D-Sub 9 pin)
1 x Input External IR sensor
2 x OUT 12V 100mA (via Jack)
GENERAL SPECIFICATIONS
Software control: upgradable via RS232 serial
interface
Mains voltage range: 100-240Vac ±10% (48/62Hz)
Weight: 11 Kg (24,2 lbs)
Dimensions (WxHxD): 435x195x431mm
(17.1”x7.7”x17”)
SUPPLIED ACCESSORIES
Installation and User Manual; AC power cords (EU,
UK and USA) 2m (6.6 ft); Backlit remote control and
batteries
The DLP® logo and DLP® medallion are trademarks of Texas Instruments.
(*) Lamp life: the hours quoted have been measured in a lab under strict test conditions. Lamp life varies depending on usage conditions and the surrounding
environment. The measured lamp life cannot be guaranteed and is not protected by warranty
