Instructions - Parts List

APEX

Oil Transfer Pump

For pumping non-flammable fluids including motor oils, hydraulic

fluid, and antifreeze. Do not use to pump water.

Model 260105, 3.0 gpm (11 lpm), 115 VAC (wall mount)

Model 260106, 3.0 gpm (11 lpm), 115 VAC

Model 260108, 4.2 gpm (16 lpm), 115 VAC

Model 260109, 7.9 gpm (30 lpm), 115 VAC

Model 260240, 6.3 gpm (24 lpm), 12 VDC (reversible)

150 psi (1.03 MPa, 10.3 bar) Maximum Working Pressure

Contents

Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Mounting Pump on Barrel or Tank . . . . . . . . . . . . . . . . 4

Mounting Pump In-line . . . . . . . . . . . . . . . . . . . . . . . . . 4

Electrical Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Electrical Installation

12 VDC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Technical Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Performance Chart . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Graco Standard Warranty . . . . . . . . . . . . . . . . . . . . . . . . 14

Graco Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Important Safety Instructions

Read all warnings and instructions in this

manual. Save these instructions.

Warnings

2311306E

Warnings

The following general warnings are for the setup, use, grounding, maintenance, and repair of this

equipment. Additional, more specific warnings may be found throughout the body of this manual

where applicable. Symbols appearing in the body of the manual refer to these general warnings.

When these symbols appear throughout the manual, refer back to these pages for a description

of the specific hazard.

WARNING

FIRE AND EXPLOSION HAZARD

When flammable fluids are present in the work area, such as gasoline and windshield

wiper fluid, be aware that flammable fumes can ignite or explode. To help prevent fire

and explosion:

• Use equipment only in well ventilated area.

• Eliminate all ignition sources, such as cigarettes and portable electric lamps.

• Keep work area free of debris, including rags and spilled or open containers of sol-

vent and gasoline.

• Do not plug or unplug power cords or turn lights on or off when flammable fumes

are present.

• Ground all equipment in the work area.

• Use only grounded hoses.

• If there is static sparking or you feel a shock, stop operation immediately. Do not

use equipment until you identify and correct the problem.

• Keep a fire extinguisher in the work area.

ELECTRIC SHOCK HAZARD

Improper grounding, setup, or usage of the system can cause electric shock.

• Turn off and disconnect power at main switch before disconnecting any cables and

before servicing equipment.

• Connect only to grounded power source.

• All electrical wiring must be done by a qualified electrician and comply with all local

codes and regulations.

PERSONAL PROTECTIVE EQUIPMENT

You must wear appropriate protective equipment when operating, servicing, or when in

the operating area of the equipment to help protect you from serious injury, including

eye injury, inhalation of toxic fumes, burns, and hearing loss. This equipment includes

but is not limited to:

• Protective eyewear

• Clothing and respirator as recommended by the fluid and solvent manufacturer

• Gloves

• Hearing protection

Warnings

311306E 3

PRESSURIZED EQUIPMENT HAZARD

Fluid from the gun/dispense valve, leaks, or ruptured components can splash in the

eyes or on skin and cause serious injury.

• Follow Pressure Relief Procedure in this manual, when you stop dispensing and

before cleaning, checking, or servicing equipment.

• Tighten all fluid connections before operating the equipment.

• Check hoses, tubes, and couplings daily. Replace worn or damaged parts immedi-

ately.

EQUIPMENT MISUSE HAZARD

Misuse can cause death or serious injury.

• Do not operate the unit when fatigued or under the influence of drugs or alcohol.

• Do not exceed the maximum working pressure or temperature rating of the lowest

rated system component. See Technical Data in all equipment manuals.

• Use fluids and solvents that are compatible with equipment wetted parts. See Tech-

nical Data in all equipment manuals. Read fluid and solvent manufacturer’s warn-

ings. For complete information about your material, request MSDS forms from

distributor or retailer.

• Check equipment daily. Repair or replace worn or damaged parts immediately with

genuine Graco replacement parts only.

• Do not alter or modify equipment.

• Use equipment only for its intended purpose. Call your Graco distributor for informa-

tion.

• Route hoses and cables away from traffic areas, sharp edges, moving parts, and

hot surfaces.

• Do not kink or over bend hoses or use hoses to pull equipment.

• Keep children and animals away from work area.

• Comply with all applicable safety regulations.

BURN HAZARD

Equipment surfaces and fluid that’s heated can become very hot during operation. To

avoid severe burns, do not touch hot fluid or equipment. Wait until equipment/fluid has

cooled completely.

WARNING

Installation

4311306E

Installation

These pumps are positive displacement gear

pumps. The models with AC motors are 115

VAC, and use UL and CSA listed TENV

motors. The motors use sealed bearings and

require minimal maintenance. These pumps

are for use with motor oil, hydraulic fluid, anti-

freeze, gear lubes and other oil-based prod-

ucts. Models 260106, 260108, and 260109

include a bung adapter for mounting on any

standard 2 inch barrel or tank bung.

When unpacking check for shipping damage.

Report any shipping damage to delivering car-

rier immediately. See Parts, page 6.

Mounting Pump on Barrel or

Tank

1. Install bung adapter in 2 in. bung and

tighten.

2. Use a 1 in. (25 mm) steel or PVC pipe with

1 in. npt pipe threads on one end as a suc-

tion tube.

3. Cut tube to a length 1/2 in. (13 mm) less

than the distance from the top of the bung

to the bottom of the tank.

4. Apply pipe sealant to threads and install

pipe into pump inlet.

5. Insert the suction tube through the bung

adapter into the tank, and lower the pump

onto the bung adapter.

6. Tighten swivel nut on pump to the thread

on the bung adapter.

7. The pump outlet port is a 3/4 in. npt pipe

port. Make sure hose or pipe used on the

pump discharge is rated greater than the

maximum working pressure rating of the

pump

8. Fill pump outlet with fluid to aid initial prim-

ing.

Mounting Pump In-line

Model 260105 comes with a mounting bracket

and can be wall mounted.

The pump has a 1 in. npt inlet and a 3/4 in. npt

outlet.

If you are pumping used oil, install suction

tube assembly with inlet suction screen

(260306), to filter large contaminants.

If tank depth is greater than 60 in. (1524

mm), an intake check valve (260217) may

be required to retain pump prime.

If you are pumping used oil, install suction

screen (260238) to filter large contami-

nates.

Operation

311306E 5

Electrical Installation

115VAC

The pump comes pre-wired with a 30 in. (762

mm) power cord with a 3 prong grounded plug.

Power to the pump must be 115VAC, 60Hz,

single phase. If an extension cord is used it

should be a 3-wire cord with a ground.

To permanently hardwire the pump, remove

the conduit box cover and remove the power

cord strain relief. The conduit box wiring open-

ing is for a 1/2 in. conduit pipe. The motors are

all 115 VAC single phase, requiring a 3-wire

grounded electrical service.

Electrical Installation

12 VDC

The 12 VDC model (260100) is not shipped

with a power cord since the installation will

determine the length of the power cord.

1. Verify the on/off switch is in the off position.

2. Remove the wiring junction box cover by

removing the four screws.

3. Use 10 AWG wire to connect the red (+)

and black (-) wires to the 12 VDC supply.

4. Reattach the wiring junction box cover with

the four screws.

Operation

Follow these instructions for operation of the

260105, 260106, 260108, 260109, and

260240 oil transfer pumps. See Parts, page 8

for reference.

1. To start the pump, turn power switch ON.

Power switch is located on the back side of

the motor. For model 260240 (reversible),

ensure the switch is moved to the desired

flow direction.

2. The pump has an internal bypass valve that

will open when the pump discharge pres-

sure exceeds 150 psi (1.03 MPa, 10.3 bar).

If flow is blocked the fluid will bypass within

the pump.

3. Transfer or dispense fluids by opening the

required valves in your system.

4. Immediately after dispensing, turn power

switch to off position.

Before servicing, turn pump off and open

the nozzle to relieve pressure.

CAUTION

Do not operate pump dry. Make sure pump

has fluid in it when pump is initially installed.

Do not run the pump for more than 2 minutes

with the pump discharge blocked. Do not

operate pump for more than 30 minutes con-

tinuously in 1 hour.

Troubleshooting

6311306E

Troubleshooting

Problem Cause Solution

Motor runs but pump will not

prime.

Dirt under pressure relief valve

or seal.

Remove pressure relief valve

and inspect, clean, or replace if

damaged.

Worn or damaged gears. Remove cover and inspect

gears. Replace if worn or

damaged.

Fluid level low. Refill tank.

Cover seal damaged. Replace if worn or damaged.

Inlet strainer clogged. Remove and clean or replace.

Air leak in suction tube. Inspect all joints in suction

tube, make sure all joints have

sealant applied.

Air lock in system. This may occur if filter or meter

or automatic shut-off nozzle is

used. If this occurs, fill pump

and meter with fuel through top

of pump.

Motor does not run at proper

speed.

Check electric connections.

Check supply voltage for

proper voltage level.

Oil leaking in motor mount. Faulty or damaged motor shaft

seal.

Replace shaft seal

Operating pump extended time

with nozzle closed.

Do not exceed 5 minutes of

operation with nozzle closed.

Motor shaft worn. Replace motor if shaft has

groove worn in seal area.

Troubleshooting

311306E 7

Unit pumps but output flow is

low.

Clogged inlet strainer (12). Clean or replace.

Air leak in suction tube. Check to make sure all joints in

suction tube are sealed.

Suction tube too close to tank

bottom.

Suction tube must have a 2 in.

(51 mm) minimum clearance.

Tank empty. Refill tank.

Tank not vented. Tank must be vented to atmo-

sphere.

Worn or damaged gears. Remove cover and inspect

gears. Replace if worn or

damaged.

Damaged motor. Replace motor.

Clogged suction tube, hose, or

nozzle.

Inspect and clean.

Motor stalls when nozzle is

closed.

Bypass relief valve is stuck. Inspect relief valve, making

sure ball is free. Replace if

damaged.

Low supply voltage. Check supply voltage.

Gears damaged and binding. Inspect gears. Gears should

turn freely. Replace if dam-

aged.

Faulty motor. Replace motor.

Motor overheating. Gears binding. Check to make sure gears turn

freely on shaft.

Operating pump extended time

with nozzle closed.

Do not exceed 5 minutes of

operation with nozzle closed.

Clogged strainer. Clean or replace.

Clogged suction tube, hose, or

nozzle.

Inspect and clean if required.

Operating pump more than 30

minutes continuous duty.

Limit operation to 30 minutes

per hour.

Switch will not turn pump on. Blown fuse or circuit breaker. Replace fuse or reset breaker.

Electrical problem. Check that supply voltage is

proper to the pump motor.

Defective switch (model

260240).

Check and replace if defective.

Damaged or defective motor. Check motor, replace if dam-

aged or defective.

Problem Cause Solution

Parts

8311306E

Parts

Models 260105, 260106, 260108, 260109

Replacement Danger and Warning labels,

tags, and cards are available at no cost.

Accessories

415

Ref. No. Description Qty.

1a PUMP BODY, with swivel 1

1b PUMP BODY, without swivel 1

1c PUMP BODY,

high flow with swivel 1

2 ADAPTER, pump motor 1

3a GEAR, pump 2

3b GEAR, pump, high flow 2

4 SEAL, shaft 1

5a MOTOR, 115 VAC, 3/4 HP 1

5b MOTOR, 115 VAC, 1 HP 1

5c MOTOR, 12 VDC,

3/4 HP, reversible 1

6 POWER CORD 1

7 O-RING, -144 nitrile (Buna N) 1

8 BALL, relief valve 1

9 SPRING, relief valve 1

10 PLUG, 1/2 npt 1

11 ADAPTER, bung

(260106, 260108, 260109 only)

12 STRAIN RELIEF 1

13 NUT, wire 2

14a SCREW, cap, 5/16-18 x 1 in. 4

14b SCREW, cap, 5/16-18 x 1.5 in.

(260105 only)

15 SCREW, 3/8-16 x 1 in. 4

16 BRACKET, mounting (model

260105 only) (not shown)

17LABEL, warning (not shown)

Part no. 15G901

Part

Number Description

260124 Suction pipe, 55 in. PVC with check

valve

260217 Inlet check valve

260238 Y strainer

260300 Suction pipe, 34 in. PVC

260306 Inlet suction screen

Ref. No. Description Qty.

Parts

311306E 9

Kits

Kit

Number Description Includes Items

260061 ADAPTER, bung 11

260245 KIT, fluid, 3 gpm with swivel

(model 260106)

1a, 2, 3a, 4, 7, 8, 9, 10, 14, 15

260246 KIT, fluid, 3 gpm without swivel

(model 260105)

1b, 2, 3a, 4, 7, 8, 9, 10, 14, 15

260247 KIT, fluid with swivel

(models 260108, 260109, 260240)

1c, 2, 3b, 4, 7, 8, 9, 10, 14, 15

260248 KIT, motor, 115 VAC 3/4 HP

(models 260105, 260106, 260108)

5a, 6, 12

260249 KIT, motor, 115 VAC 1 HP

(model 260109)

5b, 6, 12

260292 KIT, packing 4, 7

260293 KIT, gear, high flow

(models 260108, 260109, 260240)

3b, 4, 7

260294 KIT, gear

(models 260105, 260106)

3a, 4, 7

260295 KIT, pressure relief 8, 9, 10

260541 KIT, MOTOR, 12 VDC 3/4 HP

(model 260240)

5c, 12

Technical Data

10 311306E

Technical Data

Maximum working pressure 150 psi (1.05 MPa, 10.5 bar)

Output flow Model 260105: 3.0 gpm (11 lpm)

Model 260106: 3.0 gpm (11 lpm)

Model 260108: 4.2 gpm (16 lpm)

Model 260109: 7.9 gpm (30 lpm)

Model 260240: 6.3 gpm (24 Ipm)

Inlet size 1 in. npt

Outlet size 3/4 in. npt

Weight Model 260105, 260106, 260108:

25 lb (11.25 kg)

Model 260109: 30 lb (13.5 kg)

Model 260240: 28 lb (12.7 kg)

Dimensions See page 11

Power cord 30 in. (762 mm), 3 prong grounded (AC models only)

Horsepower Model 260105, 260106, 260108, 260240: 3/4 hp

Model 260109: 1 hp

Max current Model 260105, 7.5 amps

Model 260106, 7.5 amps

Model 260108: 9.0 amps

Model 260109: 11.0 amps

Model 260240: 60 amps

Wetted parts carbon steel with zinc plating, stainless steel,

galvanized steel, aluminum, nitrile, rubber

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Bomba de agua de Graco

Graco

Graco Husky 715 Manual de usuario

Graco

Graco Husky 1050 Series Manual de instrucciones

Graco

Graco Husky 715 Manual de operación

Graco

Graco Husky 205 Manual de operación

Graco

Graco 127643 Manual de usuario

Graco

Graco SaniForce STU.A09GAB2AB1C21 Manual de uso y cuidado

Graco

Graco saniforce 2150 Manual de usuario

Graco

Graco SaniForce 2150e Manual de instrucciones

Graco

Graco Power-Star B Series Manual de usuario

Graco

Graco 248652 Manual de usuario

Graco

Graco Husky 515 series Manual de operación

Graco

Graco 3A2977K Manual de lista de piezas

Graco

Graco Ratio King A Series Hoja de datos

Graco

Graco Husky 1050A Manual de instrucciones

Graco

Graco 253377 Manual de operación

Graco

Graco Power-Star 236754 Manual de usuario

Graco

Graco Hydra-Cat H.P. Series Manual de usuario

Graco

Graco 8900 Manual de usuario

Graco

Graco Series B Manual de operación

Graco

Graco 237-004 Manual de operación

Graco

Graco Hydra-Spray 224-623 Manual de operación

Graco

Graco 29:1 Lube Pro Manual de usuario

Graco

Graco ToughTek F340e Manual de uso y cuidado

Graco

Graco SaniForce BES Series Manual de operación

Manuales populares de Bomba de agua de otras marcas

Neptun

Neptun NPHW 5500 Manual de usuario

Sensidyne

Sensidyne Gilian BDX-II Instrucciones de instalación y funcionamiento

Draper

Draper 47808 Manual de usuario

Trolla

Trolla 12820 Manual de usuario

Sunfab

Sunfab SVH Series Manual de usuario

WilTec

WilTec 50740 Manual de usuario

Fieldmann

Fieldmann FVC 5015 EK Manual de usuario

Everbilt

Everbilt EFSUB5-122HD Manual de usuario

esotec

esotec 101018 Manual de usuario

moyno

moyno 2000 CC Manual de usuario

Becker

Becker BASIC VASF 2.80/1-0.AC230 Manual de usuario

Sykes AmeriPumps

Sykes AmeriPumps GP100M Guía de solución de problemas

DUROMAX

DUROMAX XP WX Series Manual de usuario

BRINKMANN PUMPS

BRINKMANN PUMPS SBF550 Manual de usuario

Franklin Electric

Franklin Electric IPS Manual de usuario

Xylem

Xylem e-1532 Series Manual de usuario

Milton Roy

Milton Roy PRIMEROYAL Manual de usuario

STA-RITE

STA-RITE ST33APP Manual de usuario
