Graco 244113 Manual de usuario

309317

Rev. A

Cup Feed

Includes 1-quart (1 liter) cup

Model 244113, without fluid set

Model 244117, with # 3 fluid set

T10746

Remote Pressure Feed

Model 244115, without fluid set

Model 244118, with # 3 fluid set

INSTRUCTIONS

This manual contains important

warnings and information.

READ AND KEEP FOR REFERENCE.

US Patent Pending

HVLP–Turbine Guns

10 psi (0.07 MPa, .7 bar) Maximum Inlet Air Pressure

50 psi (0.35 MPa, 3.5 bar) Maximum Inlet Fluid Pressure

Related Manuals

309205 – HVLP–Turbine Gun for maintenance and service instructions

309243 – HVLP Turbine

309244 – HVLP Compressor/Cart

GRACO INC. P.O. BOX 1441 MINNEAPOLIS, MN 55440–1441

Graco Inc. is registered to I.S. EN ISO 9001

2309317

Table of Contents

Symbols 2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Warnings 3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Component Identification 4. . . . . . . . . . . . . . . . . . . . . . . .

Setup 7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Spray 7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Shutdown 8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Parts List 15. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Parts Drawing 14. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Technical Data 16. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Graco Phone Number 18. . . . . . . . . . . . . . . . . . . . . . . . . .

Warning Symbol

WARNING

This symbol alerts you to the possibility of serious

injury or death if you do not follow instructions.

Caution Symbol

CAUTION

This symbol alerts you to the possibility of damage to

or destruction of equipment if you do not follow instruc-

tions.

You will need:

Cleaning fluids: a compatible solvent; water–based paint also requires soap and water.

Suggested proper clothing:

•Safety glasses •Sturdy boots or shoes

•Respirator •Gloves

TOXIC FLUID HAZARD: Hazardous fluid or toxic

fumes can cause serious injury or death if

splashed in eyes or on skin, inhaled, or swallowed.

DKnow specific hazards of fluid you are

using and take protective measures as

recommended by the fluid and solvent manufacturer.

Equipment Misuse Hazard: Equipment misuse

can cause the equipment to rupture or malfunction

and result in serious injury.

DBefore operating equipment, read all instruction

manuals, tags, and labels.

DCheck equipment daily. Repair or replace worn

or damaged parts immediately.

DDo not exceed maximum working pressure (MWPR) of the lowest–rated

system component

DUse fluids and solvents that are compatible with the equipment

wetted parts. See Specifications on page for this information.

DWear hearing protection when operating this equipment.

DDo not “blow back”fluid; this is not an air spray system

DFollow Pressure Relief before cleaning, checking or servicing the

equipment.

Fire and explosion hazard: Solvent and paint

fumes can ignite or explode.

DSprayers generate sparks. Keep sprayer at least

20 feet (6 m) from explosive vapors.

DUse in an extremely well ventilated area.

DEliminate all ignition sources; such as pilot lights,

cigarettes and static arcs from plastic drop cloths.

Do not plug or unplug power cords or turn lights

on or off in spray area.

DGround Sprayer, object being sprayed, paint and

solvent pails.

DDo not use 1,1,1-trichloroethane, methylene chlo-

ride, other halogenated hydrocarbon solvents or

fluids containing such solvents in pressurized alu-

minum equipment. Such use could result in a

chemical reaction, with the possibility of explosion.

3309317

4309317

Component Identification

Air inlet

Air cap/retaining ring –Adjusts

fan direction

Air flow control –Adjusts TOTAL

air flow to spray gun Pattern Adjustment Knob –

Adjusts pattern from fan to

round

Fluid flow/Pattern size control –

Adjusts fluid volume

Cup

Swivel tube and strainer

EasyGlidetTrigger

Duckbill check valve

5309317

PRESSURE RELIEF –Follow this procedure when cleaning, repairing or shuting down

sprayer

1. Turn off turbine. 2. Unlatch cup

TIP SELECTION

A Tip consists of a fluid

nozzle, and fluid needle.

Use the following chart

for recommendations.

Fluid Set Tip Size Fluid Usage

244123 0.8 mm

(0.032 in) Ink, dye and non–wiping stain.

244124 1.3 mm

(0.051 in) Water base lacquer, urethane, varnish, stain, and automotive finish.

244125

1.8 mm

(0.071 in) Lacquer, urethane, varnish, stain, primer, enamel and epoxy.

244126 2.2 mm

(0.087 in) Lacquer, urethane, varnish, stain, primer, enamel, epoxy and

higher output industrial finishes.

244127 2.5 mm

(0.098 in) Latex, multi–spec, oil wall paint, industrial finishes, buty-

rate, and nitrate dope.

Installing the Fluid Set

Trigger the gun whenever you tighten or remove the nozzle. This keeps the needle seat away from

the nozzle seating surface and prevents the seat from being scratched.

CAUTION

For Cup Guns

Follow these

instructions whenever

you stop spraying.

1. Turn off air supply to the pot.

2 quart

8069A 0288

For Pressure Feed Guns

2. Open pressure relief (A) on

pot until pressure is completely

relieved. Close relief.

Follow these

instructions whenever

you stop spraying.

6309317

1. Use your hand to loosen and remove the air cap retaining ring

and air cap housing.

2. Test spray pattern and atomization while holding gun about 6

to inches (150 to 200 mm) from test piece.

3. While triggering the gun, use your hand to loosen and remove the nozzle.

4. Use your hand to loosen and remove the fluid knob assembly and

compression ring from the back of the gun and remove the old needle.

5. Insert the needle assembly in the back of the gun. Reassemble nozzle, air cap housing and air cap re-

taining ring. Hand tighten.

Note: Nozzle should always have an o–ring (A).

7309317

6. Connect air hose to gun and turbine.

7. For cup gun, turn fluid control out until trigger movement is not restricted.

Caution: Turning knob too far will remove it.

Setup

8. Reduce and test catalyze all paint to manufacturer’s specifications.

SIf no reduction instructions are given, mix the fluid thoroughly, then gradually mix in reducer. To check

the consistency of the fluid. Remove the stir stick from the thinned paint. When the paint streaming off

the stick breaks into droplets, the first few drops should be one second apart.

STo compensate for faster drying time of turbine systems, use a reducer one step slower than used for

conventional air spray systems.

9. Remove cup. Fill 3/4 full. DO NOT OVERFILL. Reattach and latch cup.

For remote pressure pot, hold gun parallel to floor and adjust fluid pressure

to an 8 to 10 inch (203 to 254 mm) fluid stream.

NOTE: Heavier fluids or longer fluid hoses require greater pressures.

8309317

10. Plug turbine power cord into a grounded outlet.

SPRAY

11. Open air control valve.

12. Turn turbine on. Wait several minutes prior

to spraying to allow warm–up time.

13. Turn air cap to obtain desired direction.

9309317

air control

14. Lock air cap with retaining ring.

15. Select spray pattern by adjusting the fluid knob

and pattern selection knob. The air control ad-

justs the TOTAL air to the pattern and gun.

Retainingring

Nozzle

Air cap

pattern selection

knob

fluid knob

16. Hold gun perpendicular, 6–8 inches from surface. Move

gun first, then pull gun trigger to spray.

RoundPattern

Set knob to RND

Vertical Pattern

Set knob to FAN

Horizontal Pattern

Set knob to FAN

Note: If fluid is not atomizing properly, fluid may need to be thinned further, or a different tip size may be used.

10 309317

17. To control over–spray, reduce air flow or reduce fluid volume.

Note: If fluid is not atomizing properly, fluid may need to be thinned further, or a different

tip size may be used.

Swivel Tube Adjustment

The adjustable swivel tube allows the HVLP–Turbine Gun to be held in any position why spraying. To adjust the

position of the tube in the cup:

1. Loosen the nut (A) with a wrench (42).

2. Rotate the cup to the desired spray position.

3. Retighten the nut (A) with a wrench (42).

Swivel tube positioned

for spraying UP

Swivel tube positioned

for spraying DOWN

cup

swivel tube
