Graco TURBOBOOSTER PD349130E Manual de usuario

Do not install or use this child

restraint until you read, understand

and follow the instructions in this

manual and the warnings on

the car seat.

FAILURE TO PROPERLY USE THIS

CHILD RESTRAINT INCREASES THE

RISK OF SERIOUS INJURY OR DEATH

IN A SUDDEN STOP OR CRASH.

TURBOBOOSTER

www.gracobaby.ca

PD349130E 11/18

1-A Quick Guide to Your Manual

1-B Welcome to the Graco Family

1-C Before You Begin

If You Need Help

Certification

Car Seat’s Useful Life

Vehicle Seat Protection

Warm Weather Use

1-D Safety Warnings

1 Important Pages 5-19

2 Features Pages 20-23

2-A Car Seat Features

3 Booster Pages 24-27

4-A Securing Child Backed Booster

4-B Securing Child Backless Booster

4 Securing Child Pages 28-37

3-A Booster Use

3-B Install Booster

3-C Install Backless Booster

5 Accessories Page 38

6-A Choosing Vehicle Seat Location

6-B Unsafe Vehicle Seat Location

6-C Vehicle Seat Belts

7-A Cleaning Seat Pad

6 Vehicle Information Pages 39-42

7 Care & Cleaning Pages 43

Adult Assembly Required

1. Armrests

Insert armrest into base as shown until buttons snap into

slots on side of base.

Select the desired armrest height for your child, then insert

the height adjustment screw and tighten. Repeat for other

armrest.

To adjust armrests, remove screw and press in button on

side of base as shown to raise or lower. Reinsert screw and

tighten.CHECK to make sure armrests are securely attached

by pulling up on them.

1-A Quick Guide to Your Manual

This car seat is for children: Booster: 18-45 kg (40-100 lb) 110-145 cm (43-57 in)

Car Seat Assembly (On Select Models)

Adult Assembly Required

1. Armrests

Insert armrest into base as shown until buttons snap into

slots on side of base.

Select the desired armrest height for your child, then insert

the height adjustment screw and tighten. Repeat for other

armrest.

To adjust armrests, remove screw and press in button on

side of base as shown to raise or lower. Reinsert screw and

tighten.CHECK to make sure armrests are securely attached

by pulling up on them.

2. Armrest Covers

Slip armrest covers onto armrests as shown.

(on certain models)

3. Back support pad (on select models)

On certain models, your

lower back support pad

may not be attached to

the back support. Place

lower back support pad

around edges of support

as shown. Then fasten

lower elastic strap to the

metal hook on the other side of the seat pad.

4. Head support (on select models)

Flip head support and lower back support over

as shown.

Squeeze red adjustment button and slide two pieces

together until they snap into place.

CHECK to make sure two pieces are securely

snapped together by pulling on them.

Attach elastic strap to metal hook on other side of

seat pad as shown.

5. Head support pad (on select models)

Flip seat over and insert the fabric from the head

support underneath the fabric on the lower back support

as shown.

To make insertion of fabric easier, slide the upper and

lower back pieces apart by squeezing the red adjustment

button.

6. Backrest (on select models)

Attach backrest to base. “U”-shaped hooks on bottom

of backrest will interlock with bars on base.

Make sure that no part of the seat covering interferes

when attaching backrest to the base.

Once backrest is securely attached to the base, push

backrest up as shown.

Your Graco booster seat is now ready to use.

Once backrest is securely attached to the base, push

backrest up as shown.

Your Graco booster seat is now ready to use.

Get to Know Your Car Seat

What Seating Location Should I Use?

Review section 2-A to see all of the features of this booster seat.

The best seating location for this booster seat is one that:

• Is recommended by your vehicle owner’s manual, and

• Results in a secure installation of this booster seat.

Some vehicles have specific requirements for where the booster seat can be installed,

so be sure to check your vehicle owner’s manual for available seating positions, if any.

For example, sometimes the center rear seat has a lap belt only vehicle seat belt, which

cannot be used with this booster seat.

Review section 6-B and 6-C of this manual AND your vehicle owner’s manual.

According to collision statistics, the safest place for

your child in any vehicle is the back seat. The center

of the back seat can be the safest during a possible

side impact.
