Graco Bravo harness Manual de usuario

Rear-facing: Birth to 30 lbs. (13.6 kg)

• Infants from birth to 20 lbs. (9.1 kg) MUST

be rear-facing.

• Infants or toddlers 20 to 30 lbs.

(9.1 to 13.6 kg) may be rear-facing.

HEIGHT & WEIGHT LIMITS

A preterm infant or low birth weight infant may

be at special risk in a vehicle or aircraft.

According to the American Academy of

Pediatrics, these infants may suffer breathing

difficulties if improperly reclined in a car seat.

Century advises that you have your physician or

hospital staff evaluate your infant and

recommend the proper car seat or car bed

before you and your infant leave the hospital.

Preterm or Low Birth Weight

Infants

Forward-facing

Forward-facing: 20 to 40 lbs. (9.1 to 18.1 kg)

• Toddlers 20 to 30 lbs. (9.1 to 13.6 kg) who

are capable of sitting upright unassisted

may be forward-facing *. If unable to sit

unassisted, use rear-facing.

• Toddlers 30 to 40 lbs. (13.6 to 18.1 kg)

and up to 40 inches (101.6 cm) tall MUST

be forward-facing.

Outgrowing Car Seat

Rear-facing

40 lbs.

(18.1 kg)

Birth 30 lbs.

(13.6 kg)

20 lbs.

(9.1 kg)

To avoid injuries from whiplash, top of

child’s ears must be below top edge of

car seat.

WARNING

IMPORTANT: This car seat is certified for use

rear-facing with children up to 30 lbs. (13.6 kg).

However, some children approaching 30 lbs.

(13.6 kg) may be too tall to fit comfortably

rear-facing. When child can no longer

comfortably fit and knees remain bent, child

should use car seat forward-facing only if child

is over 20 lbs. (9.1 kg) and can sit upright

unassisted *.

*The American Academy of Pediatrics recommends

that children should be at least one year of age

before being positioned forward facing.

OPERATIONS and ADJUSTMENTS

Buckle:

5-Point Models

• To buckle: Insert both tongues into

buckle. Pull up on tongues to be sure

they are locked.

• To unbuckle: Press red button and pull

tongues out of buckle.

Recline:

Recline - Rear-facing only

Semi-upright - Forward-facing only

Upright - Forward-facing only

To adjust: Pull recline handle out and rotate

car seat to desired position, then release

handle (fig. b).

Level Adjuster (Rear-facing only):

4 Positions to adjust to vehicle seat angle:

To adjust: Squeeze handle and rotate car seat

to position ball in green zone, then release

handle (fig. c).

IMPORTANT: Level adjuster must be in

position 1 when used forward-facing with

car seat in semi-upright or upright positions.

Harness Straps (fig. a):

• To tighten: Pull lower belt tab.

• To loosen: Pull and hold upper belt tab

while pulling harness straps.

Harness Tie:

• To open: Press tab and pull apart.

• To close: Snap halves together. Make

sure harness tie is locked by pulling out

on each half.

(fig. a) (fig. b) (fig. c)

Upper

Lower

OPERATIONS and ADJUSTMENTS (continued)

Changing Harness Strap Slots:

Rear-facing - MUST use bottom or middle

harness slots which are at or below shoulders.

Forward-facing - MUST use top slots.

A Loosen harness straps:

Pull and hold upper belt tab.

Pull harness straps out.

B Remove both harness strap loops from

Splitter Plate on back of car seat.

C Change harness strap slots.

Make sure harness straps are threaded

through matching slot of seat pad and

car seat.

It may be necessary to remove seat pad

from top of car seat.

D Re-attach harness strap loops to Splitter

Plate:

5-Point Models (fig. d):

• For Infants or Small Toddlers:

Put Top right strap loop on Splitter

Plate first, then attach Top left strap

loop.

NOTE: Make sure ends of straps are

behind Splitter Plate.

• For Toddlers:

Put Bottom right strap loop on Splitter

Plate first, then attach Bottom left strap

loop.

OPERATIONS and ADJUSTMENTS (continued)

(fig. d)

Bottom

Loop

Splitter Plate

Top

Loop

OPERATIONS and ADJUSTMENTS (continued)
