GORMAN-RUPP PAH SERIES Guía de aplicación

OM-06662-02

July 6, 2016

GORMAN‐RUPP PUMPS

www.grpumps.com

2016 Gorman‐Rupp Pumps Printed in U.S.A.

INSTALLATION, OPERATION,

AND MAINTENANCE MANUAL

WITH PARTS LIST

PAH SERIESPUMP

MODEL

PAH10A60C-C18

Gorman‐Rupp pump online at

www.grpumps.com/register.

Valid serial number and e‐mail address required.

RECORD YOUR PUMP MODEL AND SERIAL NUMBER

Please record your pump model and serial number in the

spaces provided below. Your Gorman‐Rupp distributor

needs this information when you require parts or service.

Pump Model:

Serial Number:

The engine exhaust from this

product contains chemicals

known to the State of California to

cause cancer, birth defects or

other reproductive harm.

TABLE OF CONTENTS

INTRODUCTION PAGE I - 1.................................................

SAFETY ‐ SECTION A PAGE A - 1............................................

INSTALLATION - SECTION B PAGE B - 1....................................

Pump Dimensions PAGE B - 1.....................................................

PREINSTALLATION INSPECTION PAGE B - 1............................................

Battery Installation PAGE B - 2.....................................................

POSITIONING PUMP PAGE B - 2.......................................................

Lifting PAGE B - 2.................................................................

Mounting PAGE B - 2.............................................................

SUCTION AND DISCHARGE PIPING PAGE B - 3.........................................

Materials PAGE B - 3..............................................................

Line Configuration PAGE B - 3......................................................

Connections to Pump PAGE B - 3..................................................

Gauges PAGE B - 3...............................................................

SUCTION LINES PAGE B - 3...........................................................

Fittings PAGE B - 3...............................................................

Strainers PAGE B - 3..............................................................

Sealing PAGE B - 4...............................................................

Suction Lines in Sumps PAGE B - 4.................................................

Suction Line Positioning PAGE B - 4................................................

DISCHARGE LINES PAGE B - 5........................................................

Siphoning PAGE B - 5.............................................................

Valves PAGE B - 5................................................................

ALIGNMENT PAGE B - 5..............................................................

AUTO‐START PAGE B - 5.............................................................

Float Switch Installation PAGE B - 6.................................................

COLD WEATHER INSTALLATION PAGE B - 6............................................

OPERATION - SECTION C PAGE C - 1......................................

OPERATION PAGE C - 1..............................................................

STARTING PAGE C - 1................................................................

PRIMING PAGE C - 1.................................................................

ROUTINE OPERATION PAGE C - 1.....................................................

OPERATION IN EXTREME HEAT PAGE C - 2............................................

OPERATIONAL CHECKS PAGE C - 2...................................................

Leakage PAGE C - 2..............................................................

Pump Vacuum Check PAGE C - 2..................................................

Liquid Temperature And Overheating PAGE C - 2.....................................

Strainer Check PAGE C - 2.........................................................

STOPPING PAGE C - 3................................................................

Manual Stopping PAGE C - 3.......................................................

Automatic Stopping PAGE C - 3....................................................

TABLE OF CONTENTS

(continued)

Safety Shutdown System PAGE C - 3...............................................

PERIODIC CHECKS PAGE C - 3.......................................................

Seal Cavity And Bearing Lubrication PAGE C - 3......................................

Bearing Temperature Check PAGE C - 3.............................................

Engine Fuel Filter PAGE C - 3......................................................

Engine Oil PAGE C - 3.............................................................

COLD WEATHER PRESERVATION PAGE C - 4...........................................

TROUBLESHOOTING - SECTION D PAGE D - 1..............................

PREVENTIVE MAINTENANCE PAGE D - 3...............................................

PUMP MAINTENANCE AND REPAIR ‐ SECTION E PAGE E - 1.................

STANDARD PERFORMANCE CURVE PAGE E - 1........................................

PARTS LISTS:

Pump Model PAGE E - 3..........................................................

Power Unit Kit PAGE E - 5.........................................................

Pump End Assembly PAGE E - 9...................................................

Repair Rotating Assembly PAGE E - 11...............................................

Air Compressor Assembly PAGE E - 13...............................................

Priming Chamber Kit PAGE E - 14...................................................

Priming Chamber Assembly PAGE E - 15.............................................

Drive Assembly PAGE E - 16........................................................

Venturi Assembly PAGE E - 17......................................................

PUMP AND SEAL DISASSEMBLY AND REASSEMBLY PAGE E - 18.........................

Priming Chamber Removal And Disassembly PAGE E - 19..............................

Discharge Check Valve Removal and Disassembly PAGE E - 19.........................

Pump Casing and Wear Ring Removal PAGE E - 19....................................

Impeller and Wear Ring Removal PAGE E - 20.........................................

Seal Removal PAGE E - 20..........................................................

Separating Pump And Drive Assembly From Engine PAGE E - 20........................

Shaft and Bearing Removal and Disassembly PAGE E - 21.............................

Shaft and Bearing Reassembly and Installation PAGE E - 22............................

Securing Pedestal And Drive Assembly To Engine PAGE E - 23..........................

Seal Reassembly and Installation PAGE E - 24........................................

Impeller Installation PAGE E - 26.....................................................

Pump Casing And Wear Ring Installation PAGE E - 26..................................

Discharge Check Valve Reassembly And Installation PAGE E - 26.......................

Priming Chamber Assembly And Installation PAGE E - 26...............................

LUBRICATION PAGE E - 27.............................................................

Seal Assembly PAGE E - 27.........................................................

Bearings PAGE E - 27..............................................................

Engine PAGE E - 27................................................................

PAH SERIES OM-06662

PAGE I - 1INTRODUCTION

INTRODUCTION

Thank You for purchasing a Gorman‐Rupp pump.

Read this manual carefully to learn how to safely

install and operate your pump. Failure to do so

could result in personal injury or damage to the

pump.

Because pump installations are seldom identical,

this manual cannot possibly provide detailed in

structions and precautions for every aspect of

each specific application. Therefore, it is the re

sponsibility of the owner/installer of the pump to

ensure that applications not addressed in this

manual are performed only after establishing that

neither operator safety nor pump integrity are com

promised by the installation. Pumps and related

equipment must be installed and operated ac

cording to all national, local and industry stan

dards.

If there are any questions regarding the pump or

its application which are not covered in this man

ual or in other literature accompanying this unit,

please contact your Gorman‐Rupp distributor, or

The Gorman‐Rupp Company:

The Gorman‐Rupp Company

P.O. Box 1217

Mansfield, Ohio 44901-1217

Phone: (419) 755-1011

or:

Gorman‐Rupp of Canada Limited

70 Burwell Road

St. Thomas, Ontario N5P 3R7

Phone: (519) 631-2870

For information or technical assistance on the

power source, contact the power source manufac

turer's local dealer or representative.

HAZARD AND INSTRUCTION

DEFINITIONS

The following are used to alert maintenance per

sonnel to procedures which require special atten

tion, to those which could damage equipment, and

to those which could be dangerous to personnel:

Immediate hazards which WILL result in

severe personal injury or death. These

instructions describe the procedure re

quired and the injury which will result

from failure to follow the procedure.

Hazards or unsafe practices which

COULD result in severe personal injury

or death. These instructions describe

the procedure required and the injury

which could result from failure to follow

the procedure.

Hazards or unsafe practices which COULD

result in minor personal injury or product

or property damage. These instructions

describe the requirements and the possi

ble damage which could result from failure

to follow the procedure.

NOTE

Instructions to aid in installation, operation, and

maintenance or which clarify a procedure.

PAH SERIES OM-06662

PAGE A - 1SAFETY

SAFETY ‐ SECTION A

This information applies to Prime Airer

Series pumps. Refer to the manual ac

companying the engine or power

source before attempting to begin oper

ation.

Because pump installations are seldom

identical, this manual cannot possibly

provide detailed instructions and pre

cautions for each specific application.

Therefore, it is the owner/installer's re

sponsibility to ensure that applications

not addressed in this manual are per

formed only after establishing that nei

ther operator safety nor pump integrity

are compromised by the installation.

Before attempting to open or service the

pump:

1. Familiarize yourself with this man

ual.

2. Shut down the engine and discon

nect the positive battery cable to

ensure that the pump will remain

inoperative.

3. Allow the pump to completely cool

if overheated.

4. Check the temperature and make

sure the pump is cool before open

ing any covers, plates, or plugs.

5. Close the suction and discharge

valves.

6. Vent the pump slowly and cau

tiously.

7. Drain the pump.

This pump is designed to handle most

non‐volatile, non‐flammable liquids

containing specified entrained solids.

Do not attempt to pump volatile, corro

sive, or flammable liquids which may

damage the pump or endanger person

nel as a result of pump failure.

Death or serious personal injury and

damage to the pump or components

can occur if proper lifting procedures

are not observed. Make certain that

hoists, chains, slings or cables are in

good working condition and of suffi

cient capacity and that they are posi

tioned so that loads will be balanced

and the pump or components will not be

damaged when lifting. Suction and dis

charge hoses and piping must be re

moved from the pump before lifting. Lift

the pump or component only as high as

necessary and keep personnel away

from suspended objects.

After the pump has been installed, make

certain that the pump and all piping or

hose connections are tight, properly

supported and secure before operation.

Do not operate the pump against a

closed discharge valve. If operated

against a closed discharge valve, pump

components will deteriorate, and the

liquid could come to a boil, build pres

sure, and cause the pump casing to rup

ture or explode. Momentary closure of a

discharge valve is acceptable only

when required for startup or shutdown

procedures.

Do not remove plates, covers, gauges,

PAH SERIESOM-06662

PAGE A - 2 SAFETY

pipe plugs, or fittings from an over

heated pump. Vapor pressure within the

pump can cause parts being disen

gaged to be ejected with great force. Al

low the pump to cool completely before

servicing.

This pump may be used to handle mate

rials which could cause illness through

direct exposure or emitted fumes. Wear

adequate protective clothing when

working on the pump or piping.

Do not operate the pump without guards

in place over the rotating parts. Ex

posed rotating parts can catch clothing,

fingers or tools, causing severe injury to

personnel.

Make sure the pump is level. Lower jack

stands and chock the wheels, if so

equipped. Use caution when positioning

the skid‐mounted unit to prevent damage

to the fuel tank.

Do not operate an internal combustion

engine in an explosive atmosphere.

When operating an internal combustion

engine in an enclosed area, make sure

exhaust fumes are piped to the outside.

These fumes contain carbon monoxide,

a deadly gas that is colorless, tasteless

and odorless.

Fuel used by internal combustion en

gines presents an extreme explosion

and fire hazard. Make certain that all

fuel lines are securely connected and

free of leaks. Never refuel a hot or run

ning engine. Avoid overfilling the fuel

tank. Always use the correct type of fuel.

Never tamper with the governor to gain

more power. The governor establishes

safe operating limits that should not be

exceeded. Refer to the performance

curve in Section E for the maximum con

tinuous operating speed for this pump.

PAH SERIES OM-06662

PAGE B - 1INSTALLATION

INSTALLATION - SECTION B

Review all SAFETY information in Section A.

Since pump installations are seldom identical, this

section offers only general recommendations and

practices required to inspect, position, and ar

range the pump and piping.

Most of the information pertains to a standard

static lift application where the pump is positioned

above the free level of liquid to be pumped.

If installed in a flooded suction application where

the liquid is supplied to the pump under pressure,

some of the information such as mounting, line

configuration, and priming must be tailored to the

specific application. Since the pressure supplied

to the pump is critical to performance and safety,

be sure to limit the incoming pressure to 50% of the

maximum permissible operating pressure as

shown on the pump performance curve.

For further assistance, contact your Gorman‐Rupp

distributor or the Gorman‐Rupp Company.

Pump Dimensions

See Figure 1 for the approximate physical dimen

sions of this pump.

OUTLINE DRAWING

Figure 1. Pump Model PAH10A60C-C18

PREINSTALLATION INSPECTION

The pump assembly was inspected and tested be

fore shipment from the factory. Before installation,

inspect the pump for damage which may have oc

curred during shipment. Check as follows:

a. Inspect the pump for cracks, dents, damaged

threads, and other obvious damage.

b. Check for and tighten loose attaching hard

ware. Since gaskets tend to shrink after dry

ing, check for loose hardware at mating sur

faces.

OM-06662 PA SERIES

PAGE B - 2 INSTALLATION

c. Carefully read all tags, decals, and markings

on the pump assembly, and perform all duties

indicated. Note that the pump shaft rotates in

the required direction.

Only operate this pump in the direction in

dicated by the arrow on the pump body

and on the accompanying decal. Other

wise, the impeller could become loosened

from the shaft and seriously damage the

pump.

d. Check levels and lubricate as necessary. Re

fer to LUBRICATION in the Maintenance and

Repair Manual and perform duties as in

structed.

e. If the pump has been stored for more than 12

months, some of the components or lubri

cants may have exceeded their maximum

shelf life. These must be inspected or re

placed to ensure maximum pump service.

If the maximum shelf life has been exceeded, or if

anything appears to be abnormal, contact your

Gorman‐Rupp distributor or the factory to deter

mine the repair or updating policy. Do not put the

pump into service until appropriate action has

been taken.

Battery Installation

Unless otherwise specified on the pump order, the

engine battery is not included with engine driven

units.

Refer to the information accompanying the battery

and/or electrolyte solution for activation and charg

ing instructions.

Before installing the battery, clean the positive and

negative cable connectors, and the battery termi

nals. Secure the battery by tightening the

holddown brackets. The terminals and clamps

may be coated with petroleum jelly to retard corro

sion. Connect and tighten the positive cable first,

then the negative cable.

POSITIONING PUMP

Death or serious personal injury and

damage to the pump or components

can occur if proper lifting procedures

are not observed. Make certain that

hoists, chains, slings or cables are in

good working condition and of suffi

cient capacity and that they are posi

tioned so that loads will be balanced

and the pump or components will not be

damaged when lifting. Suction and dis

charge hoses and piping must be re

moved from the pump before lifting. Lift

the pump or component only as high as

necessary and keep personnel away

from suspended objects.

Lifting

Pump unit weights will vary depending on the

mounting and drive provided. Check the shipping

tag on the unit packaging for the actual weight, and

use lifting equipment with appropriate capacity.

Drain the pump and remove all customer‐installed

equipment such as suction and discharge hoses

or piping before attempting to lift existing, installed

units.

Mounting

Locate the pump in an accessible place as close as

practical to the liquid being pumped. Level mount

ing is essential for proper operation. The pump

may have to be supported or shimmed to provide

for level operation and eliminate vibration.

For engine driven units, the pump must be posi

tioned as level as possible to ensure sufficient lubri

cation and fuel supply to the engine.

If your pump is equipped with optional oil

lubricated bearings, level mounting is es

sential to ensure sufficient lubrication to

the pump bearings. Damage to the pump,

PAH SERIES OM-06662

PAGE B - 3INSTALLATION

including the bearings, shaft and/or bear

ing housing may occur if the pump is oper

ated for an extended period of time on an

unlevel surface. To ensure sufficient lubri

cation, never operate a unit equipped with

oil lubricated bearings at an angle greater

than 2off level.

If the pump has been mounted on a moveable

base, make certain the base is stationary by setting

the brake and blocking the wheels before attempt

ing to operate the pump.

If the pump has been mounted on a mov

able base, do not attempt to operate the

pump unless the unit is level. Be sure

the leveling stands are positioned on a

solid surface, and the wheels are

chocked.

SUCTION AND DISCHARGE PIPING

Pump performance is adversely effected by in

creased suction lift, discharge elevation, and fric

tion losses. See the performance curve and oper

ating range shown on Page E‐1 to be sure your

overall application allows pump to operate within

the safe operation range.

Materials

Either pipe or hose maybe used for suction and

discharge lines; however, the materials must be

compatible with the liquid being pumped. If hose is

used in suction lines, it must be the rigid‐wall, rein

forced type to prevent collapse under suction. Us

ing piping couplings in suction lines is not recom

mended.

Line Configuration

Keep suction and discharge lines as straight as

possible to minimize friction losses. Make mini

mum use of elbows and fittings, which substan

tially increase friction loss. If elbows are necessary,

use the long‐radius type to minimize friction loss.

Connections to Pump

Before tightening a connecting flange, align it ex

actly with the pump port. Never pull a pipe line into

place by tightening the flange bolts and/or cou

plings.

Lines near the pump must be independently sup

ported to avoid strain on the pump which could

cause excessive vibration, decreased bearing life,

and increased shaft and seal wear. If hose‐type

lines are used, they should have adequate support

to secure them when filled with liquid and under

pressure.

Gauges

The pump is drilled and tapped for installing dis

charge pressure and vacuum suction gauges. It is

recommended that gauges be installed to monitor

pump performance. Seal the gauge threads with

pipe dope to ensure an airtight seal. Follow the

sealant manufacturer's recommendations when

selecting and applying the pipe dope. The pipe

dope should be compatible with the liquid being

pumped.

SUCTION LINES

To avoid air pockets which could affect pump prim

ing, the suction line must be as short and direct as

possible. When operation involves a suction lift, the

line must always slope upward to the pump from

the source of the liquid being pumped; if the line

slopes down to the pump at any point along the

suction run, air pockets will be created.

Fittings

Suction lines should be the same size as the pump

inlet. If reducers are used in suction lines, they

should be the eccentric type, and should be in

stalled with the flat part of the reducers uppermost

to avoid creating air pockets. Valves are not nor

mally used in suction lines, but if a valve is used,

install it with the stem horizontal to avoid air pock

ets.

Strainers

Be certain to use the strainer furnished with the

pump; any spherical solids which pass through the

strainer will also pass through the pump itself.

Otros manuales para PAH SERIES

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Bomba de agua de GORMAN-RUPP

GORMAN-RUPP

GORMAN-RUPP T8A60-B/F Instrucciones de instalación y funcionamiento

GORMAN-RUPP

GORMAN-RUPP V3A60-B Manual de usuario

GORMAN-RUPP

GORMAN-RUPP PA4A60-4024T-ESP Manual de usuario

GORMAN-RUPP

GORMAN-RUPP SF6D Guía de aplicación

GORMAN-RUPP

GORMAN-RUPP Patterson/AMT 573 Series Instrucciones de montaje

GORMAN-RUPP

GORMAN-RUPP 10 SERIES Guía de aplicación

GORMAN-RUPP

GORMAN-RUPP 82D1-1B20 FT4-X Guía de aplicación

GORMAN-RUPP

GORMAN-RUPP AMT 316T-95 Instrucciones de montaje

GORMAN-RUPP

GORMAN-RUPP SUPER T8A71S-B/FM Manual de usuario

GORMAN-RUPP

GORMAN-RUPP AMT 368C-98 Instrucciones de montaje

GORMAN-RUPP

GORMAN-RUPP AMT 316A-95 Manual de usuario

GORMAN-RUPP

GORMAN-RUPP PRIME-AIRE PA4B Series Instrucciones de funcionamiento

GORMAN-RUPP

GORMAN-RUPP PAH SERIES Manual de usuario

GORMAN-RUPP

GORMAN-RUPP AMT 5586-H6 Manual de usuario

GORMAN-RUPP

GORMAN-RUPP PA6F60 ---4045D Manual de usuario

GORMAN-RUPP

GORMAN-RUPP PAH SERIES Guía de aplicación

GORMAN-RUPP

GORMAN-RUPP AMT 489 Series Instrucciones de montaje

GORMAN-RUPP

GORMAN-RUPP AMT 576B-95 Manual de usuario

GORMAN-RUPP

GORMAN-RUPP 80 SERIES Manual de usuario

GORMAN-RUPP

GORMAN-RUPP 83B31-B Guía de aplicación

GORMAN-RUPP

GORMAN-RUPP PA6C60-4045T-ESP Manual de usuario

GORMAN-RUPP

GORMAN-RUPP 10 SERIES Instrucciones de funcionamiento

GORMAN-RUPP

GORMAN-RUPP 02F1?GR Manual de usuario

GORMAN-RUPP

GORMAN-RUPP AMT 576D-95 Manual de usuario

Manuales populares de Bomba de agua de otras marcas

Neptun

Neptun NPHW 5500 Manual de usuario

Sensidyne

Sensidyne Gilian BDX-II Instrucciones de instalación y funcionamiento

Draper

Draper 47808 Manual de usuario

Trolla

Trolla 12820 Manual de usuario

Sunfab

Sunfab SVH Series Manual de usuario

WilTec

WilTec 50740 Manual de usuario

Fieldmann

Fieldmann FVC 5015 EK Manual de usuario

Everbilt

Everbilt EFSUB5-122HD Manual de usuario

Graco

Graco Husky 3300e Manual de usuario

esotec

esotec 101018 Manual de usuario

moyno

moyno 2000 CC Manual de usuario

Becker

Becker BASIC VASF 2.80/1-0.AC230 Manual de usuario

Sykes AmeriPumps

Sykes AmeriPumps GP100M Guía de solución de problemas

DUROMAX

DUROMAX XP WX Series Manual de usuario

BRINKMANN PUMPS

BRINKMANN PUMPS SBF550 Manual de usuario

Franklin Electric

Franklin Electric IPS Manual de usuario

Xylem

Xylem e-1532 Series Manual de usuario

Milton Roy

Milton Roy PRIMEROYAL Manual de usuario
