GoPro HERO Camera Manual de usuario

USER MANUAL

To download this user manual in a diﬀerent language, visit

gopro.com/getstarted.

Pour télécharger ce manuel de l’utilisateur dans une autre langue,

rendez-vous sur gopro.com/getstarted.

Wenn Sie dieses Benutzerhandbuch in einer anderen Sprache

herunterladen möchten, besuchen Sie gopro.com/getstarted.

Per scaricare questo manuale utente in un’altra lingua, visita

gopro.com/getstarted.

Para descargar este manual de usuario en otro idioma, visite

gopro.com/getstarted.

Para baixar este manual do usuário em outro idioma, acesse

gopro.com/getstarted.

このユーザーマニュアルの他言語版をダウンロードするに

は、 gopro.com/getstartedにアクセスしてください。

若要下載其他語言版本的使用說明書，請前往：

gopro.com/getstarted。

如需下载本用户手册的其他语言版本，请访问

gopro.com/getstarted。

Чтобы загрузить это руководство пользователя на другом языке,

посетите страницу gopro.com/getstarted.

/ Join the GoPro Movement

twitter.com/GoPro

facebook.com/GoPro youtube.com/GoPro

instagram.com/GoPro

4 5

/ Table of Contents

Battery

Troubleshooting

Customer Support

Regulatory Information

The Basics

Getting Started

Camera Displays

Camera Modes

Navigating Settings Menus

Camera Icons

Camera Menus

Capturing Video

Capturing Photos

Capturing Burst Photos

Capturing Time Lapse Photos

Connecting to the GoPro App

Transferring Files to a Computer

Playing Back Video and Photos

Settings

Setup Mode

Important Messages

Using the Mounts

/ Table of Contents

6 7

7. Micro-USB Port

8. microSD Card Slot

(microSD card not included)

/ The Basics

1. Shutter/Select Button

2. Camera Status Screen

3. Settings/Tag Button

4. Power/Mode Button

5. Wireless Status Light (blue)

6. Camera Status Light (red)

/ The Basics

9. Touch Display

8 9

/ Getting Started/ Getting Started

CHARGING THE BATTERY

The integrated battery comes partially charged. No damage occurs to

the HERO+ LCD camera or battery if used before being fully charged.

1. Unlatch and open the backdoor.

Note: The camera cannot be removed from the housing.

2. Charge the battery using the included USB cable.

Note: The battery cannot be removed from the camera. When charging the camera with a

computer, be sure that the computer is connected to a power source. If the camera status

lights do not turn on to indicate that the battery is charging, use a diﬀerent USB port.

WARNING: Using a wall charger other than a GoPro Wall Charger

can damage the GoPro camera battery and could result in ﬁre or

leakage. Only use chargers marked: Output 5V 1A. If you do not

know the voltage and current of your charger, use the included

USB cable to charge the camera from your computer.

Slim housing surfboard mount installation

Slim housing remove camera Slim housing insert camera

Slim housing closed Swapping housing doors

Quick Release Buckle + Thumb Screw + Slim housing = Complete Unit

For fastest charging, make sure the camera is powered oﬀ aer

connecting it to a computer or USB charging adapter. When the

camera is powered oﬀ, the camera status light turns on during

charging and turns oﬀ when charging is complete.

For more battery information, see Battery (page 55).

WARNING: Use caution when using your GoPro as part of your

active lifestyle. Always be aware of your surroundings to avoid

injury to yourself and others.

Abide by all local laws when using your GoPro and related

mounts and accessories, including all privacy laws, which may

restrict recording in certain areas.

10 11

INSERTING + REMOVING MICROSD CARDS

Use brand name memory cards that meet these requirements:

• microSD, microSDHC, or microSDXC (sold separately)

• Capacity up to 64GB

• Minimum of Class 10 or UHS-I rating

For a list of the recommended microSD cards, visit gopro.com/support.

NOTICE: Use care when handling memory cards. Avoid liquids, dust,

and debris. As a precaution, power oﬀ the camera before inserting

or removing the card. Check manufacturer guidelines regarding use in

acceptable temperature ranges.

/ Getting Started

POWERING ON + OFF

To Power On:

Press the Power/Mode button once. The camera status lights

ﬂash three times and the sound indicator emits three beeps. When

the camera status screen displays information, your camera is on.

To Power Oﬀ:

Press and hold the Power/Mode button for two seconds.The

camera status lights ﬂash several times and the sound indicator

emits seven beeps.

/ Getting Started

12 13

PRO TIP: If QuikCapture is enabled, you can quickly turn your camera

on and immediately begin capturing video or Time Lapse photos just

by pressing the Shutter/Select button. Short press for video, press and

hold for Time Lapse photos. For details, see QuikCapture (page 45).

/ Getting Started / Getting Started

CAMERA BACKDOORS

Your HERO+ LCD camera comes with three types of backdoors.

The Standard Backdoor makes the housing

waterproof to 131’ (40m). Use this door to protect

the camera from water, dirt, sand and other

environmental hazards. This backdoor reduces

wind noise at speeds greater than 100mph.

The Touch Backdoor enables access to the touch

display and provides waterproof protection to

10’ (3m).

NOTICE: To prevent damage to the touch display,

do not exceed this depth when using this backdoor.

Touch functions do not work underwater.

In extreme altitude and temperatures, keep the

housing unlatched until you use the camera.

The Skeleton Backdoor is not waterproof. This

backdoor enables access to the touch display,

provides enhanced cooling, and allows more

direct access to the microphone. Use this

backdoor only when sand, excessive dirt/dust,

and water damage are not a risk. This backdoor

is also recommended for use inside vehicles.

14 15

/ Camera Displays

HERO+ LCD features a status screen on the front of the camera and a

larger touch display on the back

CAMERA STATUS SCREEN

The camera status screen on the front of the camera displays the

following information about modes and settings:

CAMERA SOFTWARE UPDATES

To get the latest features and best performance from your HERO+ LCD

camera, make sure you are using the most current camera soware.

You can update your camera soware via the GoPro App or GoPro

Studio soware. For more information, visit gopro.com/getstarted.

CAMERA DEFAULT SETTINGS

The HERO+ LCD camera powers up with the following default settings:

Video 1080p30, Auto Low Light

Photo 8MP, Wide Field of View (FOV)

Burst 10 photos in 2 seconds (5 fps)

Time Lapse 0.5 seconds

QuikCapture Oﬀ

Wireless Oﬀ

PRO TIP: To open the settings menu for the current mode, tap the

Settings icon [ ] or press the Settings/Tag button. To change general

camera settings that apply to all modes, navigate to Setup mode.

/ Getting Started

1. Camera Mode/FOV

(ﬁeld of view)

2. Resolution/fps

(frames per second)

3. Number of Files Captured

4. Remaining Time/Files on

microSD Card

Note: The icons that appear on the camera status screen vary by mode.

5. Spot Meter

(when feature is enabled)

6. Time Lapse Interval/Burst

Rate (not shown)

7. Wireless

8. Battery Life

16 17

TOUCH DISPLAY

The integrated touch display on the back of the camera lets you control

your camera and its settings, and preview and play back videos and

photos. You can also use it as a viewﬁnder so you can see what your

camera sees for easy shot-framing.

To use the touch display with the housing door closed, attach the

Touch Backdoor or the Skeleton Backdoor. For more information, see

Camera Backdoors (page 13).

PRO TIP: To conserve battery power, the touch display is set to

automatically sleep aer 1 minute of inactivity. For details on touch

display settings, see Touch Display (page 43).

/ Camera Displays / Camera Displays

Gestures

Use these gestures to navigate the touch display:

Tap Up/DownTap Tap Mode Tap Settings

Tap the Mode Icon

Display camera modes.

Tap Up/DownTap Tap Mode Tap Settings

Tap the Settings Icon

Open the settings menu for the current mode.

Tap Up/DownTap Tap Mode Tap Settings

Tap the Up/Down Arrows

Move through settings lists or gallery images.

Tap Up/DownTap Tap Mode Tap Settings

Tap

Select an item, turn a setting on/oﬀ.

18 19

HERO+ LCD features several camera modes. Tap the mode icon on

the touch display, or press the

Power/Mode button repeatedly to cycle

through the modes

These modes appear:

Video Record video

Photo Capture a single photo

Burst Capture 10 photos in 2 seconds (5 fps)

Time Lapse Capture a series of photos at speciﬁed

intervals

Playback Play back videos and view photos

Setup Adjust general camera settings

PRO TIP: To change settings for the current mode, press the

Settings/Tag button. To change general camera settings that apply

to all modes, navigate to Setup mode.

/ Camera Modes

With the HERO+ LCD camera, you can navigate the settings menus

using the touch display or the buttons on the camera. Each camera

mode has its own settings menu.

To Navigate with the Touch Display:

1. Verify that the camera is in the desired camera mode. To select a

diﬀerent mode, tap the mode icon, and then tap the desired mode.

2. Tap the Settings icon [ ] to open the settings menu for that mode.

Arrows indicate additional options, if available.

3. Tap the down arrow to scroll through the settings for that mode.

4. Tap a setting repeatedly to cycle through the options for that setting.

5. To exit the settings menu, tap Exit.

/ Navigating Settings Menus
