USER MANUAL

MODEL: MICRODAB10

DAB CD MICRO SYSTEM

AUDIO IN

SOURCE

PLAY/PAUSE

PREV NEXT EJECT

Welcome1

Troubleshooting

Technical Specifications

Your Micro system

2.1 In The Box

2.2 Front View

2.3 Rear View

Quick Setup

Features4

CD Mode

MODEL: MICRODAB10

3.1 Install the Left/Right speakers

3.2 Power on the unit

3.3 Listen to the Radio

3.4 Place CD disc and play

3.5 Play audio device

Customer Support

4.1 Switch to CD mode

4.2 Eject the disc

4.3 Play the disc

4.4 Stop the disc

4.5 Skip the song

4.6 Accelerate the song

4.7 Select the song

4.8 Repeat the song

4.9 Random the songs

4.10 Set the programmed order

AUDIO Mode

4.11 Connect audio device

4.12 Power on the unit

4.13 Switch to AUDIO mode

4.14 Play audio device

4.15 Adjust the volume

FM Mode

DAB Mode

4.16 Switch to FM mode

4.17 Tune the frequency

4.18 Skip stations

4.19 Store the stations

4.20 Check the FM information

4.21 Scan setting

4.22 Switch to DAB mode

4.23 Select DAB stations

4.24 Store the stations

4.25 Check the DAB information

4.26 Manual tune

4.27 Auto scan

DAB menu settings

4.28 DRC setting

4.29 Prune the stations

4.30 System reset

Welcome

Thank you for choosing this Goodmans product. We’ve been

making electronics for the British people for 70 years. Each of

our projects has been carefully designed to be great at what

it does and this one is no exception. We hope you enjoy your

new DAB CD Micro system.

Your Micro system2

In The Box

Carefully remove your product from the box.

Inside the box you will find:

• Micro System

• Quick Start Guide

• Guarantee Booklet

2.1

Mains Power

Please ensure that your mains supply is compatible before use.

Disconnect the Power Cord from the mains when not in use.

Position of Micro System

Place on a fat, stable surface that is not subject to vibrations.

Avoid the following locations:

• Where it is exposed to direct sunlight

• Where it is close to heat radiating sources

• Where the humidity is high and ventilation is poor

• Where it is dusty

Adjusting the Aerial

Fully extend the aerial to ensure good reception in F

It may be necessary to alter the position of the product to achieve the best signal.

MODEL: MICRODAB10

• Remote Control

Your DAB CD Micro System requires a mains supply of 220V 240V AC, 50 Hz. ~

M/DAB mode.

Front View

Rear View

Remote sensor

Point the remote control to the sensor

within 7 metres range.

PLAY/PAUSE button

Press to pause or play the music.

STANDBY button

Press to set to standby mode or turn on.

PREVIOUS/NEXT buttons

Press to skip to the previous or next song

or station.

VOLUME+/- button

Press to adjust the volume level.

3.5mm Audio in socket

Used to connect external audio sources.

MODEL: MICRODAB10

2.2

2.3

AC 220V-240V 50Hz

ANTENNA

SOURCE button

Press to select the modes.

AUDIO IN

SOURCE

PLAY/PAUSE

PREV NEXT EJECT

EJECT button

Press to pop out the disc drawer.

Aerial

Indicate the status.

Display the station information.

Disc drawer

Power Indicator

LCD Display

Power cord lead

Connect to the power supply.

Speaker connections

Remote control

STANDBY button

Press to enter the standby mode or turn on.

MODEL: MICRODAB10

2.4

SOURCE buttons

Press to select modes: CD, DAB, FM, AUX IN.

PLAY/PAUSE button

Press to pause or play the music.

STOP/MENU button

Press to stop the music or enter the menu.

PROGRAM

SHUFFLE

LOUD

DSP

MUTE

TONE

VOLUME

DAB/FM

MENU REPEAT

INFO

CD AUX IN

STANDBY EJECT

ENTER

PREVIOUS/NEXT buttons

Press to skip to the previous or next song.

NUMBER (0-9) buttons

Use these buttons to select song.

VOLUME+/- buttons

Press to adjust the volume level.

REPEAT button

Press to repeat the song.

MUTE button

Press to mute the sound, press again or

press VOLUME+/- button to resume.

TONE button

Use the TONE and VOLUME+/- buttons

to adjust the tone.

EJECT button

Press to pop out the disc drawer.

INFORMATION button

Press to view the station information.

ENTER button

PROGRAM button

Use to program the playback order.

SHUFFLE button

Press to play music in the random order.

LOUD button

Press to add a rounder bass sound at low levels.

DSP button

Press to select the sound fields.

FAST REWIND/FAST FORWARD buttons

Press to rewind or forward the music.

Press to perform a scan and confirm selection.

Audio cable

MODEL: MICRODAB10

Quick Setup

AC 220V-240V 50Hz

ANTENNA

AUDIO IN

SOURCE

PLAY/PAUSE

PREV NEXT EJECT

AUDIO IN

Music device

3.2 Plug in the mains cable and turn the power on at the power supply. Press the STANDBY button

to turn on the unit.

3.3 Extend the ANTENNA to get the best reception. Press the SOURCE button to enter the DAB or

FM mode. Follow the detailed operations to control playback in DAB or in FM mode.

3.4 Press the SOURCE button to enter the CD mode. Press the EJECT button to open the disc

drawer and insert a disc. Press the EJECT button again to close. The CD will begin playing from

the first track.

3.5 Press the SOURCE button to enter the Aux in (Audio) mode. Connect your audio device to the

AUDIO IN socket via a 3.5mm aux in cable. Control playback via your connected audio device.

3.1

3.2

3.3

3.4

3.5

3.1 Insert the speaker cables (red+ and black-) into the back of the unit to connect the left and right

speakers.

MODEL: MICRODAB10

Features

AUDIO IN

SOURCE

PLAY/PAUSE

PREV NEXT EJECT

EJECT

CD mode

4.1 Press the SOURCE button on the panel or the CD button on

remote control to enter the CD mode.

4.2 Press the EJECT button to pop out the disc drawer, put a CD

on, then press the EJECT button again.

4.3 Press the PLAY/PAUSE button to pause or play the song.

4.4 Press the STOP button on remote control to stop playing,

press the PLAY/PAUSE button to re-start.

4.5 Press the PREV/NEXT buttons on the panel or / buttons

on remote control to skip to the previous or next song.

4.6 Press the / buttons on remote control to fast rewind or

forward the song , press repeatedly to resume normal speed.

4.7 Press the NUMBER buttons 0-9 on remote control to directly

select the wanted song.

4.8 Press the REPEAT button on remote control to set the repeat

mode.

4.9 Press the SHUFFLE button no remote control to play the disc

in random order, press again to resume.

4.10 You can set the disc played in a programmed order.

a) Press the STOP button on remote control to stop playing.

b) Press the PROGRAM button on remote control.

The screen displays: 01[00] 02[00].

c) Press the NUMBER buttons on remote control to select the

tracks to program.

d) Press the / buttons on remote control to skip between

the program tracks.

e) Press the / buttons on remote control to access the

further track orders.

f) When complete, use the / on remote control to scroll

across to the arrow , and then press the ENTER button on

remote control to begin playback.

g) To cancel the program sequence, press the button twice.

01 [00] 02 [00]

Track order

Track to program

ENTER

PROGRAM

MODEL: MICRODAB10

Features

Audio allows your unit quickly and easily to connect to an MP3

player or other external sources.

4.11 Use a 3.5mm audio cable to connect your external audio

device to the AUDIO IN socket on the front panel.

4.12 Connect the Micro system mains plug to the power supply.

4.13 Press the SOURCE button on the panel or the AUX IN button

on remote control to enter the AUDIO mode.

4.14 You may need to operate the external audio device directly

for playback features.

4.15 For optimum volume levels, adjust the volume on the external

audio device.

Audio Mode

Audio cable

Music devices

AUDIO IN

SOURCE

PLAY/PAUSE

PREV NEXT EJECT

FM mode

DAB/FM

4.16 Press the SOURCE button on the panel or the DAB/FM button

on remote control to switch to the FM mode.

4.17 Press the / buttons on remote control or the PREV/NEXT

buttons on the panel to decrease or increase the frequency in

0.05MHz increments.

4.18 Press and hold the PREV/NEXT buttons on the panel or the /

buttons on remote control to scan through the frequency

range quickly. The scan will stop once it has found a station.

4.19 Press and hold one of the NUMBER buttons 0-9 to store the

station under that number. Directly press the required number

button to select a preset and activate the stored station.

4.20 Press the INFO button on remote control to cycle through the

information provided by the broadcasting stations:

Radio text: broadcasting text about the program;

Program type: the style or genre of music;

Program name: the frequency or name of the station;

Audio mode: stereo or mono.

4.21 Scan setting

a) Press the MENU button on remote control, when the SCAN

SETTING appears, then press the ENTER button on remote

control to view the sub menu.

b) Press the / buttons on remote control to select

<ALL STATIONS> (which will detect any station, even with

weak signal) or <STRONG STATION> (which will only detect

stations with good signal strength).

c) Press the ENTER button on remote control to confirm the

require option.

d) When you perform a scan, only stations fitting the applied

setting will be detected.

INFO

MODEL: MICRODAB10

Features

DAB mode

4.22 Press the SOURCE button or the DAB/FM button to switch

to the DAB mode.

4.23 Press the / button on remote control or the PREV/NEXT

button on the panel to find the previous or next station, then

press the ENTER on remote control or PLAY/PAUSE button on

the panel to activate the station.

4.24 Press and hold one of the NUMBER buttons 0-9 to store the

station under that number. Press the required number button

to select a preset and press the ENTER button to activate the

stored station.

4.25 Press the INFO button on remote control to cycle through the

station information: DLS text, signal strength, program type,

ensemble name, channel frequency, signal error, and bit rate.

4.26 Manual tune

a) Press the MENU button on remote control, then press the

PREV/NEXT button on the panel or / button on remote

control to find <MANUAL TUNE> and press the ENTER

button on remote control or PLAY/PAUSE button on the

panel to enter the manual tune options interface.

b) Press the PREV/NEXT button on the panel or / button

on remote control to cycle through the stations from 5A to

13F.

c) When you have selected one of the stations from 5A to 13F,

press the PLAY/PAUSE button on the panel or the ENTER

button on remote control to view the details, press again to

activate the station.

4.27 Auto scan

Press the MENU button on remote control, when AUTO SCAN

appears, press the PLAY/PAUSE or ENTER button, the unit will

search for all available DAB stations.

ENTER

PLAY/PAUSE

PREV NEXT

DAB/FM

ENTER

MODEL: MICRODAB10

Features

DAB menu settings

4.28 DRC (Dynamic range control)

To reduce and adapt the dynamic range of the audio signal

to listen in a noisy environment. This is not always available

for some DAB stations.

a) Press the MENU button, then press the PREV/NEXT button

or / button to find <DRC>, and press the PLAY/PAUSE

or ENTER button to enter the options interface.

b) Press the PREV/NEXT button or / button to select from

DRC OFF/ DRC LOW/ DRC HIGH.

c) At last press the ENTER button or PLAY/PAUSE button to

confirm the selection.

4.29 Prune the stations

When the radio has performed a scan in several locations,

there are some stored stations are no longer receive. Prune

function removes them from the stored list.

a) Press the MENU button, then press the PREV/NEXT button

or / button to find <PRUNE>, and press the PLAY/

PAUSE or ENTER button to enter the options interface.

b) Press the PREV/NEXT button or / button to select YES,

then press the ENTER button or PLAY/PAUSE button to

confirm the selection.

4.30 System reset

To set the system to the original settings.

a) Press the MENU button, then press the PREV/NEXT button

or / button to find <RESET>, and press the PLAY/

PAUSE or ENTER button to enter the options interface.

b) Press the PREV/NEXT button or / button to select YES,

then press the ENTER button or PLAY/PAUSE button to

reset the system.

ENTER

Otros manuales para MICRODAB10

Tabla de contenidos

Otros manuales de Micro sistema de música de Goodmans

Goodmans

Goodmans GMC01 Manual de usuario

Manuales populares de Micro sistema de música de otras marcas

Rautz

Rautz MC-5100DU Manual de usuario

Philips

Philips DCM1075/96 Manual de usuario

Philips

Philips BTB2570 Manual de usuario

Philips

Philips 8000 Series Manual de usuario

Sanyo

Sanyo DC-D9 Manual de usuario

Philips

Philips MCM906/12 Manual de usuario

Philips

Philips DTM3155 Manual de usuario

Curtis

Curtis RCD744 Manual de usuario

Samsung

Samsung MM-UC8 Manual de usuario

Philips

Philips MCM3150 Manual de usuario

Philips

Philips MCD268/93 Manual de usuario

Akai

Akai AMP300UCI Manual de usuario

Hyundai

Hyundai MS 132 DU3BL Manual de usuario

JVC

JVC UX-GP5 Manual de usuario

Philips

Philips DCM377/12 Manual de usuario

Philips

Philips DualDock DCB2270 Manual de usuario

Philips

Philips DCM2025 Manual de usuario

Tiger Electronics

Tiger Electronics Hitclips Beat Bot 6000 Manual de usuario
