Standard Features

• Aluminized-steel, dual-diameter tubular heat exchanger

• Stainless-steel secondary heat exchanger

• ComfortNetTM Communicating Systems compatible

• Self-calibrating, modulating gas valve operates

with two-stage or single-stage thermostats

• Efcient and quiet variable-speed circulator motor

• Furnace control board with self-diagnostics and

provisions for electronic air cleaners and humidiers

• Multiple continuous fan speed

options for quiet air circulation

• Dual-certied for sealed combustion direct vent

(2-pipe) or non-direct vent (1-pipe) applications

• Auto-Comfort and enhanced dehumidication

modes provide energy savings and additional

comfort during the cooling months

• Quiet variable-speed induced draft blower

• All models comply with California NOx emissions standards

* Complete warranty details available from your local dealer or at www.goodmanmfg.com. To receive the Lifetime Heat

Exchanger Limited Warranty (good for as long as you own your home), 10-Year Unit Replacement Limited Warranty and 10-

Year Parts Limited Warranty, online registration must be completed within 60 days of installation. Online registration is not

required in California or Québec.

Cabinet Features

• Cabinet air leakage (QLeak) ≤ 2%

• Fully insulated heavy-gauge steel cabinet

with durable baked-enamel nish

• Foil-faced insulation lines the heat exchanger section

• Designed for multi-position installation

• Airtight solid bottom for side-return applications and easy-cut

tabs for effortless removal in bottom air-inlet applications

• Convenient left or right connection for gas and electric service

• Coil and furnace t ush for most installations

SS-GMVM96 www.goodmanmfg.com 1/13

Supersedes 3/12

GMVM96 / GCVM96

CoMfortNet™-CoMpatible,

Multi-positioN, ModulatiNG

Variable-speed Gas furNaCe

upto 96% afue

2 www.goodmanmfg.com SS-GMVM96 SS-GMVM96 www.goodmanmfg.com 3

Product SPecificationS Product SPecificationS

NoMeNClature

     

 

 

Goodman

Brandor A Ini.alReleases(Major&Minor)

Dis.nc.ons™ B 1stRevisions(Major&Minor)

C 2ndRevisions



Downﬂow/Horizontal



D DedicatedDownﬂow N NaturalGas

H HighAirﬂow X LowNOx

K DedicatedUpﬂow

M Upﬂow/Horizontal 

A14”

 B17½”

V TwoStage/Variablespeed C21”

H TwoStage/Mul.speed D24½”

S SingleStage/Mul.speed

E TwoStage/HighEﬃciency 

31200

 41600

C ComfortNet™Communica.ngSystem 52000

M Modula.ngFurnace 

045:45,000

 060:60,000

96 96% 9

90%+

080:80,000

95 95% 8 80% 100:100,000

115:115,000































2 www.goodmanmfg.com SS-GMVM96 SS-GMVM96 www.goodmanmfg.com 3

Product SPecificationS Product SPecificationS

speCifiCatioNs

GMVM96

0603BX

GMVM96

0805CX

GMVM96

1005DX

GMVM96

1155DX

GCVM96

0604CX

GCVM96

0805DX

GCVM96

1005DX



High Fire Input¹ 60,000 80,000 100,000 115,000 60,000 80,000 100,000

High Fire Output¹ 57,600 76,800 96,000 109,250 57,600 76,800 95,000

Low-Fire Steady-State Input¹ 30,000 40,000 50,000 57,500 30,000 40,000 50,000

Low-Fire Steady-State Output¹ 28,800 38,400 48,000 54,625 28,800 38,400 47,500

AFUE² 96 96 96 95 96 96 95

Tons AC @ 0.5” ESP 1.5-3.0 2.0-5.0 2.0-5.0 2.0-5.0 1.5-4.0 2.0-5.0 2.0-5.0

Temperature Rise Range (°F) 20-50 35-65 35-65 35-65 20-50 20-50 25-55



Size (D x W) 10" X 8" 11" X 10" 11" X 10" 11" X 10" 10"X 10" 11" X 10" 11" X 10"

Horespower @ 1050 RPM 3/4 1 1 1 3/4 1 1

Speed Variable Variable Variable Variable Variable Variable Variable

Vent Diameter³ 2" 3" 3" 3" 2" 3" 3"

No. of Burners 3 4 5 5 3 4 5

Disposable Filter (in²) 731 683 853 981 731 975 1,056



Min. Circuit Ampacity (amps)6.0 14.2 14.2 14.2 6.0 14.2 14.2

 15.0 15.0 15.0 15.0 15.0 15.0 15.0

 135 145 170 170 139 165 170

¹Natural Gas BTU/h

² 

³ 





 



 

the same size as noted.



 All furnaces are manufactured for use on 115 VAC, 60 Hz, single-phase electrical supply.

 

 

4 www.goodmanmfg.com SS-GMVM96 SS-GMVM96 www.goodmanmfg.com 5

Product SPecificationS Product SPecificationS

GMVM96 diMeNsioNs

MiNiMuM ClearaNCes to CoMbustible Materials

      

 0” 0” 3” C 0” 1”

Horizontal 6” 0” 3” C 0” 6”





 

 

 

  D H A B C D E

GMVM960603BX  28¾" 40¾"  16"   

GMVM960805CX 21" 28¾" 40¾" 21"   16" 

GMVM961005DX  28¾" 40¾"  23"   

GMVM961155DX  28¾" 40¾"  23"   



 





 

 

 





 

28¾



RIGHT SIDE VIEW

LEFT SIDE VIEW

22 ¹/₁₁

FOLDED FLANGES



UNFOLDED FLANGES

FRONT VIEW

FOLDED FLANGES

UNFOLDED FLANGES

1¾

11¾

30¼

1¾

11¾

1¾ 32¹³/₁₁

19³/₁₁

24₁/₁₁

2¹¹/₁₁

2¹/₁₁

19³/₁₁



21¼



















4 www.goodmanmfg.com SS-GMVM96 SS-GMVM96 www.goodmanmfg.com 5

Product SPecificationS Product SPecificationS

GCVM96 diMeNsioNs

FOLDED FLANGES

UNFOLDED FLANGES

FOLDED FLANGES

UNFOLDED FLANGES

MiNiMuM ClearaNCes to CoMbustible Materials

      

 0” 0” 3” NC 0” 1”

Horizontal 6” 0” 3” C 0” 6”







 

  D H A B C D E

GCVM960604CX 21" 28¾" 40¾" 21"   18" 

GCVM960805DX  28¾" 40¾"  23"   23"

GCVM961005DX  28¾" 40¾"  23"   23"



 









6 www.goodmanmfg.com SS-GMVM96 SS-GMVM96 www.goodmanmfg.com 7

Product SPecificationS Product SPecificationS

GMVM96 airflow data — CooliNG speeds

GMVM960603BX GVMV960805CX

   

  CFM*   CFM*   CFM*   CFM*

Minus(-) 567

Minus(-) 351

Minus(-) 747

Minus(-) 486

Normal 630 Normal 390 Normal 830 Normal 540

Plus (+) 693 Plus (+) 429 Plus (+) 913 Plus (+) 594

Minus(-) 720

Minus(-) 495

Minus(-) 981

Minus(-) 675

Normal 800 Normal 550 Normal 1090 Normal 750

Plus (+) 880 Plus (+) 605 Plus (+) 1199 Plus (+) 825

Minus(-) 900

Minus(-) 612

Minus(-) 1314

Minus(-) 882

Normal 1000 Normal 680 Normal 1460 Normal 980

Plus (+) 1100 Plus (+) 748 Plus (+) 1606 Plus (+) 1078

Minus(-) 1089

Minus(-) 720

Minus(-) 1620

Minus(-) 1089

Normal 1210 Normal 800 Normal 1800 Normal 1210

Plus (+) 1331 Plus (+) 880 Plus (+) 1980 Plus (+) 1331

* @ .1" - .8" w.c. ESP * @ .1" - .8" w.c. ESP

GMVM961005DX GMVM961155DX

   

  CFM*   CFM*   CFM*   CFM*

Minus(-) 711

Minus(-) 459

Minus(-) 711

Minus(-) 459

Normal 790 Normal 510 Normal 790 Normal 510

Plus (+) 869 Plus (+) 561 Plus (+) 869 Plus (+) 561

Minus(-) 990

Minus(-) 639

Minus(-) 990

Minus(-) 639

Normal 1100 Normal 710 Normal 1100 Normal 710

Plus (+) 1210 Plus (+) 781 Plus (+) 1210 Plus (+) 781

Minus(-) 1269

Minus(-) 819

Minus(-) 1269

Minus(-) 819

Normal 1410 Normal 910 Normal 1410 Normal 910

Plus (+) 1551 Plus (+) 1001 Plus (+) 1551 Plus (+) 1001

Minus(-) 1647

Minus(-) 1044

Minus(-) 1647

Minus(-) 1044

Normal 1830 Normal 1160 Normal 1830 Normal 1160

Plus (+) 2013 Plus (+) 1276 Plus (+) 2013 Plus (+) 1276

* @ .1" - .8" w.c. ESP



 All furnaces ship as high speed for cooling. Installer must adjust blower speed as needed.

 For most jobs, about 400 CFM per ton when cooling is desirable.

 

6 www.goodmanmfg.com SS-GMVM96 SS-GMVM96 www.goodmanmfg.com 7

Product SPecificationS Product SPecificationS

GMVM96 airflow data — HeatiNG speeds

GMVM960603BX



GMVM960805CX





   

  

Minus(-) 855 62 Minus(-) 1,440 49

Normal 950 56 Normal 1,600 44

Plus (+) 1,045 51 Plus (+) 1,760 40

Minus(-) 945 56 Minus(-) 1,521 47

Normal 1,050 51 Normal 1,690 42

Plus (+) 1,155 46 Plus (+) 1,859 38

Minus(-) 1,053 50 Minus(-) 1,620 44

Normal 1,170 45 Normal 1,800 39

Plus (+) 1,287 41 Plus (+) 1,980 36

Minus(-) 1,143 46 Minus(-) 1,701 42

Normal 1,270 42 Normal 1,890 37

Plus (+) 1,397 38 Plus (+) 2,079 34

* @ .1" - .5" w.c. ESP * @ .1" - .5" w.c. ESP

GMVM961005DX



GMVM961155DX





   

  

Minus(-) 1,629 54 Minus(-) 1,629 62

Normal 1,810 49 Normal 1,810 56

Plus (+) 1,991 44 Plus (+) 1,991 51

Minus(-) 1,665 53 Minus(-) 1,665 60

Normal 1,850 48 Normal 1,850 54

Plus (+) 2,035 43 Plus (+) 2,035 49

Minus(-) 1,701 52 Minus(-) 1,701 59

Normal 1,890 47 Normal 1,890 53

Plus (+) 2,079 43 Plus (+) 2,079 48

Minus(-) 1,746 51 Minus(-) 1,746 58

Normal 1,940 46 Normal 1,940 52

Plus (+) 2,134 41 Plus (+) 2,134 47

* @ .1" - .5" w.c. ESP * @ .1" - .5" w.c. ESP



 All furnaces ship as high speed for cooling. Installer must adjust blower speed as needed.

 For most jobs, about 400 CFM per ton when cooling is desirable.

 

cooling purposes only.

 

8 www.goodmanmfg.com SS-GMVM96 SS-GMVM96 www.goodmanmfg.com 9

Product SPecificationS Product SPecificationS

GCVM96 airflow data — CooliNG speeds

GCVM960604CX GCVM960805DX

   







  





  





  





 

Minus(-) 594

Minus(-) 333

Minus(-) 810

Minus(-) 477

Normal 660 Normal 370 Normal 900 Normal 530

Plus (+) 726 Plus (+) 407 Plus (+) 990 Plus (+) 583

Minus(-) 774

Minus(-) 486

Minus(-) 990

Minus(-) 657

Normal 860 Normal 540 Normal 1100 Normal 730

Plus (+) 946 Plus (+) 594 Plus (+) 1210 Plus (+) 803

Minus(-) 1035

Minus(-) 711

Minus(-) 1287

Minus(-) 837

Normal 1150 Normal 790 Normal 1430 Normal 930

Plus (+) 1265 Plus (+) 869 Plus (+) 1573 Plus (+) 1023

Minus(-) 1323

Minus(-) 882

Minus(-) 1692

Minus(-) 1098

Normal 1470 Normal 980 Normal 1880 Normal 1220

Plus (+) 1617 Plus (+) 1078 Plus (+) 2068 Plus (+) 1342

* @ .1” - .8” w.c. ESP



 All furnaces ship as high speed for cooling. Installer must adjust blower speed as needed.

 For most jobs, about 400 CFM per ton when cooling is desirable.

GCVM961005DX

 







  





 

Minus(-) 702

Minus(-) 450

Normal 780 Normal 500

Plus (+) 858 Plus (+) 550

Minus(-) 963

Minus(-) 666

Normal 1070 Normal 740

Plus (+) 1177 Plus (+) 814

Minus(-) 1242

Minus(-) 828

Normal 1380 Normal 920

Plus (+) 1518 Plus (+) 1012

Minus(-) 1602

Minus(-) 1044

Normal 1780 Normal 1160

Plus (+) 1958 Plus (+) 1276

* @ .1” - .8” w.c. ESP



 All furnaces ship as high speed for cooling. Installer must adjust blower speed as needed.

 For most jobs, about 400 CFM per ton when cooling is desirable.

8 www.goodmanmfg.com SS-GMVM96 SS-GMVM96 www.goodmanmfg.com 9

Product SPecificationS Product SPecificationS

GCVM96 airflow data — HeatiNG speeds

GCVM960604CX

ACVM960604CX



GCVM960805DX

ACVM960805DX





   

  

Minus(-) 1,098 48 Minus(-) 1,440 49

Normal 1,220 44 Normal 1,600 44

Plus (+) 1,342 40 Plus (+) 1,760 40

Minus(-) 1,206 44 Minus(-) 1,539 46

Normal 1,340 40 Normal 1,710 41

Plus (+) 1,474 36 Plus (+) 1,881 38

Minus(-) 1,314 40 Minus(-) 1,620 44

Normal 1,460 36 Normal 1,800 39

Plus (+) 1,606 33 Plus (+) 1,980 36

Minus(-) 1,431 37 Minus(-) 1,719 41

Normal 1,590 33 Normal 1,910 37

Plus (+) 1,749 30 Plus (+) 2,101 34

* @ .1" - .5" w.c. ESP * @ .1" - .5" w.c. ESP

GCVM961005DX





  

Minus(-) 1,557 56

Normal 1,730 51

Plus (+) 1,903 46

Minus(-) 1,593 55

Normal 1,770 49

Plus (+) 1,947 45

Minus(-) 1,656 53

Normal 1,840 48

Plus (+) 2,024 43

Minus(-) 1,683 52

Normal 1,870 47

Plus (+) 2,057 43

* @ .1" - .5" w.c. ESP



 All furnaces ship as high speed for cooling. Installer must adjust blower speed as needed.

 For most jobs, about 400 CFM per ton when cooling is desirable.

cooling purposes only.

10 www.goodmanmfg.com SS-GMVM96 SS-GMVM96 www.goodmanmfg.com 11

Product SPecificationS Product SPecificationS

teMperature rise raNGe CHart

30 40 50 60 70 80 90 110 120

100 130 140 150

100

OUTPUT BTU/HR x 1000

BTU OUTPUT vs TEMPERATURE RISE CHART

TEMPERATURE RISE

600 CFM

700

900

1000

1100

1200

1400

1600

1800

2000

2200

2400 CFM

FORMULAS

BTU OUTPUT = CFM x 1.08 x RISE

RISE =

BTU OUTPUT

1.08

÷ CFM

800







BTU/h Output = CFM x 1.08 x Rise

Rise = BTU/H Output

CFM x 1.08



Otros manuales para GMVM96

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Horno de Goodman

Goodman

Goodman GDS80453AXCA Manual de uso y cuidado

Goodman

Goodman GMES8 U Series Guía

Goodman

Goodman CVC97 Series Manual de usuario

Goodman

Goodman GMEC80 Instrucciones de funcionamiento

Goodman

Goodman GMVM96 Manual de usuario

Goodman

Goodman HAMFK Manual de usuario

Goodman

Goodman [A/G]PG Instrucciones de funcionamiento

Goodman

Goodman GMH95 Instrucciones de instalación

Goodman

Goodman GMH95 Manual de usuario

Goodman

Goodman *CVC96 Manual de usuario

Goodman

Goodman GMV95 Series Documento técnico

Goodman

Goodman Amana GMH8 Manual de usuario

Goodman

Goodman AKSS9/GKS9 Manual de usuario

Goodman

Goodman GMS95 Manual de usuario

Goodman

Goodman MEC80 Series Manual de usuario

Goodman

Goodman GMEC80 Manual de usuario

Goodman

Goodman GKS9 Manual de usuario

Goodman

Goodman ComfortNet GCVC95 Series Manual de usuario

Goodman

Goodman GMH95 Manual de usuario

Goodman

Goodman VC8 Manual de usuario

Goodman

Goodman ComfortNet GMVC95 Manual de usuario

Goodman

Goodman GMEC96 Instrucciones de funcionamiento

Goodman

Goodman GDS8 Documento técnico

Goodman

Goodman GMP Series Manual

Manuales populares de Horno de otras marcas

Armstrong

Armstrong EG7H SERIES Manual de usuario

Payne

Payne PG92ESA Guía

SUPREME

SUPREME FEM10-M2301CM-A Instrucciones de montaje

Ingersoll-Rand

Ingersoll-Rand S9V2B080D4VSAC/D Instrucciones de montaje

Johnson Controls

Johnson Controls TM9T Guía

Fluke

Fluke 9118A Manual de usuario

Lennox

Lennox EL195UHE Elite Series Manual de instalación y operación

Intertherm

Intertherm M7RL Series Manual de usuario

HDG

HDG Pelletmaster 15 Manual de usuario

Pinnacle

Pinnacle Aero Bella AB-716C-QH Manual

Nortek

Nortek MG2S Series Manual de usuario

VERDER

VERDER CARBOLITE GERO ABF 8/28 Manual

SUPREME

SUPREME SUP10-M2301C Instrucciones de montaje

Dettson

Dettson AMT400B34-SM1PMA Instrucciones de montaje

Evcon

Evcon DGD 60 MBH Manual de usuario

Trane

Trane S8B1A026M2PSAB Instrucciones de montaje

Hart Sceintific

Hart Sceintific 9113 Manual de usuario

Whirlpool

Whirlpool Gold WGGE45 Manual de usuario
