INDEX

1. Safety cautions and warnings...................................................................................................................................... 3

2. Characteristics .............................................................................................................................................................. 3

3. Device description........................................................................................................................................................ 3

3.1. Jumper description.............................................................................................................................................. 4

4. Device installation........................................................................................................................................................ 4

5. Monitor conguration ................................................................................................................................................. 5

6.Web client....................................................................................................................................................................... 5

6.1. Settings.................................................................................................................................................................. 6

6.2. SIP Servers............................................................................................................................................................ 6

6.3. About..................................................................................................................................................................... 7

7. Settings........................................................................................................................................................................... 7

7.1. Address.................................................................................................................................................................. 8

7.2. Privacy................................................................................................................................................................... 8

7.3. Guard..................................................................................................................................................................... 8

7.4. Devices.................................................................................................................................................................. 9

7.5. SIP.......................................................................................................................................................................... 9

7.6. Password ............................................................................................................................................................... 9

ART 7AW/G+ IP G+

www.golmar.es

20-09-2017 Wed

Intercom Events App Settings

09:27

View

Status leds

Speaker

- TCP/IP video intercom system.

- Installation in an existing network structure (requires the addition of D4L-G+/PoE switches) or in its own structure using bre or

UTP cable of category 5 or higher.

- Up to 98 blocks for each installation.

- Up to 19 door panels for each block.

- Up to 799 apartments for each block.

- Up to 19 general gurad units for installation and 9 gurad units for each blockl.

- Up to 32 IP cameras with ONVIF protocol,

2. CHARACTERISTICS

- e installation and handling of this equipment must be carried out by authorised personnel only..

- e current regulations require the feeder to be protected with a circuit breaker.

- e entire installation must travel at least 40 cm from any other installation.

- In the power supply (FA-G+):

- Do not over-tighten the screws of the terminal strip.

- Install the power supply in a dry and protected place, without risk of dripping or splashing water.

- Avoid locations near heat sources, damp or dusty.

- Do not block the ventilation slots so that air can circulate freely.

- To avoid damage, the power supply must be rmly anchored. Usea a DIN 46277 guide for xing (8 DIN).

- To avoid electric shock, do not remove the cover or handle the wires connected to the terminals.

1. SAFETY CAUTIONS AND WARNINGS

3. DEVICE DESCRIPTION

- Front side

DUAL

POE

MONITOR IP 7”

ART 7AW/G+

12310720

GOLMAR S.A.

C/ Silici, 13

08940 - SPAIN

DUAL

POE

48V

18V

12V

GND

PCM IN

HZ+

HZ-

RJ45

PCM OUT

FPOE

SPOE

AL5

AL6

AL7

AL8

GND

COM1

NO1

COM2

NO2

AL1

AL2

AL3

AL4

GND

12V OUT

GND

485+

485-

- Back side

Microphone

RJ45 connector.

Alarm input connectors.

HZ(**)

(*) Makes reference to the doorbell of the house.

12V local power connector..

PCM/G+ connector

Power mode selector

jumper.

ART 7AW/G+IP G+

www.golmar.es

4. DEVICE INSTALLATION

1- Avoid exposing the monitor to backlighting from light

sources for optimal picture quality.

1,65m máx

1,45m máx

1,85m máx

16-03-2020 Mon

View Intercom Events Settings

11:24

2- Place the top of the monitor at a height of 1,65 m

for a correct viewing of the screen.

1,65m máx

16-03-2020 Mon

View Intercom Events Settings

11:24

Monitor location.

Necessary elements to complete an installation:

• FA-G+ power supply for each 8 devices (door panels, monitors...).

• Make the distribution of the dierent devices through 4 distributed outputs D4L-G+/PoE distributors or via standard PoE

switches.

• Choose 6502/G+ door panels, or a modular composition for the Nexa panel to be able to register all the units in it and set a

video intercom system as such.

In case of daisy-chain distribution of the devices (IN/OUT), use DCP/G+ injectors, accompanied by a FA-DC48/G+ power supply

and DCS/G+ ethernet switches in the monitors.

Use the monitor stand so that the monitor is at the above

mentioned height.

Place it in a at surface which allows a good t of the stand to

the wall.

3.1. Jumper description

FPOE

SPOE

FPOE

SPOE

We will be able to choose what supply voltage will be necessary for the correct operation of the device through the jumper located in the back side

of the monitor as follows:

48 V standard PoE (default position).

e device is ready to receive 48V from a PoE standard switch.

18 V.

e device is ready to receive 18V from a D4L-G+/PoE or from a

DCS/G+ ethernet switch.

ART 7AW/G+ IP G+

www.golmar.es

IP address of the monitor.

Subnet mask odf the monitor.

System gateway address. IP address of the system

router through which go out to internet.

If you want to assign a dierent network parameters as the ones that the system automatically assigns, we must to press on the icon located

in the bottom of the screen. is will bring us to a screen where we will be requested to enter the desired network parameters.

Ajustes de red ~ Network settings

Local IP

Subnet Mask

Gateway

Server IP

Automatic

10.0.0.107

255.0.0.0

10.0.0.1

10.0.14.9 Server system IP address. It is the management panel

IP address.

6. WEB CLIENT

We can access the Web Client of the monitor to make changes in the conguration or to congure its network parameters

manually, entering the device IP address in our web browser. If the device still being with its default factory settings, we have to enter

the 10.0.0254 IP address in our web browser. If the device is already congurated, we have to enter the IP address that the system

automatically assigned or we manually assigned.

Type the IP in the web browser:

10.0.14.9

e password to access is 888999.

5. MONITOR CONFIGURATION

Once the monitor is connected to the network, it will automaticalle start and it will show an initial conguration screen in which we must set the

following parameters related with the physical location of the monitor in the installation:

Ediﬁcio ~ Block

Dígitos llamada ~ Call digits

Idioma ~ Language

Vivienda ~ Apartment

Monitor

Conﬁguración inicial ~ Initial conﬁg

1 / 6

English

Always has to be 5.

Up to a maximum of 6 apartment

unit for each apartment..

Block in which the apartment is

located.

Apartment number in the block..

Save the conguration set.

Manual assignment of network parameters.

ART 7AW/G+IP G+

www.golmar.es

Below, it is described the initial screen of the Web Client for the ART 7AW/G+ monitor:

If we do not remember the IP address that we assigned the monitor, we can make a search of IP addresses in the network via searching

programmes as “IP search Tool”.

SIP server

About

Settings

APARTMENT UNIT

Monitor unit

Apartment address

Block number

Apply

Network

Automatic settings

Local IP

Gateway

Server IP

Subnet Mask

10.0.0.107

10.0.0.1

10.0.14.9

255.0.0.0

Dialing code length 5

Language * 1

* Languages

1 Spanish

2 English

3 Portuguese

About the device.

SIP settings.

Settings.

Monitor language.

Dialling code

length.

Block number.

Apartment number.

Unit number of the

apartment.

Available languages.

Manual assignment of

network parameters.

6.1. Settings

Go to the next screen.

SIP server

About

Settings

APARTMENT UNIT

Background picture

Load Restore

Go to the next screen.

Go to the previous

screeen.

ART 7AW/G+ IP G+

www.golmar.es

6.2. SIP Servers

In the SIP Servers section, we will be able to add the device in the PABX switchboard registered in the master panel to make and re-

ceive calls from SIP devices included in the system via extensions assigned to the monitor.

SIP server

About

Settings

SERVER REGISTRATION

User

Password

SERVER LIST

Qualvision

Golmar

Oﬃce 1

Update

Admin

Registered on Oﬃce 1

User and password

created in the PABX

switchboard.

We can change the background picture of the monitor for the picture that we consider through the “Load” option that allows us to

upload an image from our laptop. We also can re-set the default background pressing over the “Restore” option.

SIP server

About

Settings

APARTMENT UNIT

Applications

Add Delete

YnO

G2Call+

Go to the previous

screen..

We can see which applications are installed in the monitor and install new desired applications. For this, we have to previously obtain

the apk le of the application to be installed and upload it to the list of applications throgh the “Add” option. A progress bar will appear

indicating that the application is installing and when it ends, the application will appear in the list. Otherwise, if we want to delete an

application of the monitor we must select it and then press over the “delete” option. We must press accept in a conrmation screen that

will appear and the application will disappear of the list.

ART 7AW/G+IP G+

www.golmar.es

7. SETTINGS

In this section of the manual, we will see in detail the system settings. If you want to see other type of settings to which we can access with

the monitor, see the ART 7AW/G+ user manual that you will nd in the “Downloads” tab in the product website.

When pressing over the system settings, in the monitor will appear a screen in which you must type the installer password to be able to

access the setting system menu. e default installer password is: 2718.

Once you have access the system settings, the following screen will appear:

System

PrivacyAddress

Password

****

SIP

Devices

Guard

To re-set the monitor settings to a factory values, we must press over the icon located in the bottom right on the screen. e

following screen will appear and we must conrm the factory reset of the monitor settings.

Reset all settings ?

Reset

6.3. About

SIP server

About

LOCAL INFORMATION UNIT VERSION

PASSWORD

Local IP

Hardware

Administrator

Gateway

Firmware

Unit

MCU

Subnet Mask

Server IP

MAC address

10.0.0.107

10.0.0.1

1.00

255.0.0.0

10.0.14.9

e6:ﬀ:6f:78:6a:27

Dialing code length

Block number

Apartment address

Monitor unit

Reboot Update

888999

0000

Apply

Settings

Restore

Return to factory values.Reboot device. Update FW version..

ART 7AW/G+ IP G+

www.golmar.es

7.1. Address

Address

Block number

Dialing code length

Apartment address 1

Monitor unit 1 / 6

In this section we can modify the system address. If we modify the physical address of the monitor, the network parameters of the moni-

tor will also change. ese can be assigned automatically by the system or manually accessing to the screen explained before pressing

over the icon.

We would ll in the elds in the same way as in the beginning of the conguration but updating the data which have changed.

7.2. Privacy

Automatic erasing

Automatic snapshot

Preview video sources

Privacy

In the privacy section, we will be able to enable or disable the monitor’s view of the door panels and the CCTV IP cameras added in the

system, the automatic snapshot when there is a call from the door panel and the automatic erasing of them aer the set period of 30 days.

7.3. Guard

Guard

Block number

Direct call button

Notify alarm alerts

Unit address 919

With regard to the guard unit settings, we will be able to set to which address we will call when we press the direct call to the guard

button from the main screen of the monitor. We will also be able to enable the general guard’s reception of the alarms when them occurs.

CATEGORY 1_HEADERCATEGORY 2_HEADER

10Footer Infos

7.5. SIP

SIP

Server

User

Password

SIP protocol

In the “SIP” section we will be able to add the monitor in a PABX switchboard in order to receive and make calls through the PABX via

a previously created extension for our device in the switchboard. For this, we will must ll in the elds requested by the monitor in the

following way:

Server name which we are going to

use..

Extension created for our device.

Password set in the web client of

the PABX when we created the

extension..

7.6. Password

To conclude with the system settings menu, we will emphasise in the “Password” section which will allow us to change the password to

be entered to access the system setings menu.

Password

****

Enter new password

****

789

7.4. Devices

Devices

Floor number

Lift control

Private call module

Staircase light control

Link to access control

In the “Devices” section, we will be able to enable, if we have it, the PCM/G+ private call module panel. We will also be able to enable

the li control from the main screen of the monitor and link it with the access control so that, when you open the door presenting the

keys to the RFID reader of the door panel, the li is activated in the respective oors of the panel and the apartment.

www.golmar.es

IP G+ ART 7AW/G+

Otros manuales para ART 7AW/G+

Tabla de contenidos

Otros manuales de Monitor de golmar

golmar

golmar PENTHA GB2 Manual de usuario

golmar

golmar VESTA2 GB2 Manual de usuario

golmar

golmar thera gb2 Manual de usuario

golmar

golmar ART 7/G+ Manual de usuario

golmar

golmar VESTA7 GB2 Manual de usuario

golmar

golmar ART 5W/GTWIN MONITOR Manual de usuario

golmar

golmar BEOVIEW 7 Manual de usuario

golmar

golmar Art 4WH /G2+ Manual de usuario

golmar

golmar Art 7/G2+ Manual de usuario

golmar

golmar ART W LITE/G2+ Manual de usuario

golmar

golmar TEKNA-S GTWIN Manual de usuario

golmar

golmar ART 7 LITE/G2+ Manual de usuario

golmar

golmar ART 7AW/G+ Manual de usuario

golmar

golmar ART W LITE/G2+ Manual de usuario

golmar

golmar TEKNA-S TWIN Manual de usuario

golmar

golmar Art 7/G2+ Manual de usuario

golmar

golmar ART 5W/GTWIN MONITOR Manual de usuario

golmar

golmar VESTA SE GB2/H Manual de usuario

golmar

golmar VESTA SE GB2 Manual de usuario

golmar

golmar Art 7/G2+ Manual de usuario

golmar

golmar 4/G2+ Manual de usuario

golmar

golmar VESTA GB2 Manual de usuario

golmar

golmar 4WH/G2+ Manual de usuario

golmar

golmar ART 7W/G2+ Manual de usuario

Manuales populares de Monitor de otras marcas

Linear Acoustic

Linear Acoustic LQ-1000 Manual de usuario

AOC

AOC I2579V Manual de usuario

Gateway

Gateway FPD1520 Manual de usuario

Furuno

Furuno Mu 120c Manual de usuario

Asus

Asus VB171D - 17" LCD Monitor Manual de usuario

Dell

Dell S2230MX Instrucciones de uso

Philips

Philips 107C64 Manual de usuario

Dell

Dell S2409WFP Manual de usuario

EverFocus

EverFocus EN-7517E Manual de usuario

Panasonic

Panasonic TH152UX1 - 152" PLASMA TV Manual de usuario

Dell

Dell Precision 7680 Manual de instrucciones

LG 50PM1M - - 50" Plasma Panel Manual de usuario

Bosch

Bosch DDU 9 Manual de usuario

Acer

Acer A231HL Manual de usuario

Philips

Philips 86BDL4152T Manual de usuario

NEC

NEC AccuSync LCD5V Manual de usuario

Emay

Emay SleepO2 Manual de usuario

IBM

IBM 6360 Instrucciones de instalación

golmar ART 7AW/G+ Guía del usuario

Manuales populares de Monitor de otras marcas
