Gigaware 2603142 Manual de usuario
TM
2603142
User’s Guide
Please read this user’s guide before using your new touchpad mouse.
Wireless Touchpad Mouse
with Ultra-Compact USB Receiver
TM
2
Package Contents
• Touchpad Mouse
• USB Receiver
• Touchpad Driver CD (Windows® 8 only)
• User’s Guide
Features
• Serves as a standard mouse and lets you use touch gestures to
navigate through Windows 8 and other applications
• Gravity-Sensor design so the mouse can be in a vertical or
horizontal direction when in touchpad mode
• Ultra-compact USB receiver
• 1600 DPI precision
System Compatibility
• Windows 8/7
• Windows Vista®
• Windows XP
• Mac® OS 10.5 and above*
* Not all functions will work with all Mac operating systems.
TM
3
Install Batteries
1. Open the stand then remove the battery compartment cover.
2. Insert two AAA batteries according to the polarity symbols
(+ and –) marked inside.
3. Replace the cover.
Battery Notes:
• Dispose of batteries promptly and properly. Do not burn or bury
them.
•
Use only fresh batteries of the required size and type.
• Do not mix old and new batteries, different types of batteries
(alkaline, or rechargeable), or rechargeable batteries of different
capacities.
• If you do not plan to use the mouse for some time, remove the
batteries. Batteries can leak chemicals that can damage electronic
parts.
2
13
TM
4
Plug in the Receiver
1. Turn on your computer.
2. Plug the USB receiver dongle into your computer’s USB port.
3. Slide the ON/OFF switch to ON. Your mouse and receiver are
automatically paired.
nNotes:
• If you do not plan to use your mouse for a long time, slide ON/
OFF to OFF to save battery power.
• See your operating system’s online help for additional mouse
configuration information.
Sleep Mode
Your mouse enters sleep mode if left idle for 10 minutes or if you
unplug the receiver from your USB port. To reactivate your mouse,
move the mouse or reconnect the receiver (if unplugged).
TM
5
Standard Mouse Operations
Stand
• Open for standard mouse operations
• Close for touchpad operations
Left Button Right Button
Touch Scroll Touchpad
Battery Indicator
Light flashes blue when battery
power is low
TM
6
Touchpad
1. Close the stand for touchpad
operations.
2. Set the gravity sensor to its
correct direction by standing the
mouse upright for approximately 3
seconds.
3. Place the mouse horizontally on a
flat surface and test touchpad.
nNote: You can use the touchpad in any one of the
three directions illustrated below. It will not work with
the logo facing away from you.
Left Right
Up
Down
TM
7
Basic Touchpad Functions
Function Gesture
Move Cursor Slide one finger on the touchpad.
Click /
Select /
Left button
function
Tap touchpad with one finger for
less than 0.2 seconds.
Open file /
Execute
Program
Tap touchpad twice with one
finger.
Right-click
function
Tap touchpad with two fingers
for less than 0.2 seconds.
8
Function Gesture
Scrolling 1. Slide two fingers on the
touchpad vertically or
horizontally in the desired
direction.
2. Remove fingers from the
touchpad to stop scrolling
Drag and Drop Select and move one object:
1. Move cursor to the selected
object.
2. Tap once and remove finger
from the touchpad.
3. Tap again and hold finger on
the touchpad.
4. Move finger to drag the
object.
Select and move multiple objects
:
1. Move cursor to an open space
in the window you want to
select from.
2. Tap once and remove finger
from the touchpad.
3. Tap again and hold finger on
the touchpad.
4. Move finger to select a group
of objects.
5. Tap to release.
6. Tap and hold finger on the
selected objects then drag the
objects to their new location.
9
Windows 8 Functions
Install the touchpad driver for additional functions in Windows 8.
1. Insert driver
CD into your
computer’s CD
drive. The CD will
run the installation
program
automatically.
2. Follow the
onscreen
instructions
to complete
installation.
A Touchpad
shortcut icon will
appear on your desktop for easy access to touchpad settings and
demonstration.
nNote: To access the Touchpad settings and demo go to the
Control Panel, click Mouse, click the Touchpad tab, and then click
select Options.
Function Gesture
Swipe page • Move three fingers to the
left to launch the assigned
function (Page Up).
• Move three fingers to the right
to launch assigned function
(Page Down).
10
Function Gesture
Toggle to
previous app
Place and hold one finger on the
left edge of the touchpad and
then swipe to the right.
Toggle Charm
Bar
Place and hold one finger on the
right edge of the touchpad and
then swipe to the left.
Toggle
Application Bar
(application
dependent)
Place and hold one finger on the
top edge of the touchpad and
then swipe down.
Windows Photo Viewer and Windows Paint
Rotating Move two fingers clockwise or
counterclockwise.
Zoom in and
out
• Zoom In: Place two fingers on
the touchpad and then move
them closer together.
• Zoom Out: Place two fingers
on the touchpad and move
them apart.
