GIGAIPC QBiX2-Pro-KBLB7100H-A1 Manual de usuario

System - QBiX-Pro Series QBiX2-Pro-KBLB7100H-A1 (QD-7100A-SI)

1www.gigaipc.com

QBiX2-Pro-KBLB7100H-A1

(QD-7100A-SI)

QBiX2-Pro Industrial Embedded System

Quick Start Guide

www.gigaipc.com

This document is copyrighted, 2019. All rights are reserved. The

original manufacturer reserves the right to make improvements to the

products described in this manual at any time without notice.

No part of this manual may be reproduced, copied, translated, or

transmitted in any form or by any means without the prior written

permission of the original manufacturer. Information provided in

this manual is intended to be accurate and reliable. However, the

original manufacturer assumes no respon¬sibility for its use, or for any

in¬fringements upon the rights of third parties that may result from its

use.

The material in this document is for product information only and

is subject to change without notice. While reasonable efforts have

been made in the preparation of this document to assure its accuracy,

GIGAIPC assumes no liabilities resulting from errors or omissions in this

document, or from the use of the information contained herein.

GIGAIPC reserves the right to make changes in the product design

without notice to its users.

System - QBiX-Pro Series QBiX2-Pro-KBLB7100H-A1 (QD-7100A-SI)

3www.gigaipc.com

Acknowledgement

All other products’ name or trademarks are properties of their

respective owners.

• AMD is trademark of Advanced Micro Devices.

• Microsoft Windows is a registered trademark of Microsoft Corp.

• Intel, Pentium, Celeron, and Xeon are registered trademarks of Intel

Corporation

• Core, Atom are trademarks of Intel Corporation

• ITE is a trademark of Integrated Technology Express, Inc.

• IBM, PC/AT, PS/2, and VGA are trademarks of International Business

Machines Corporation.

All other product names or trademarks are properties of their

respective owners.

www.gigaipc.com

Packing List

Before setting up your product, please make sure the following items

have been shipped:

Item Quantity

Screw I Head For 25HDD M3x8L (25KSG-130081-K1R) 4

Cable Sata (25CF4-170020-S9R) 1

Thermal pad for HDD (25ST3-200052-T5R) 2

Thermal Pad (25ST3-200053-T5R) 1

Thermal Pad (25ST3-200051-T5R) 1

Terminal Blocks Male Plug (25IO0-5ESDV0-D2R) 1

Exsiccator (10g) 1

If any of these items are missing or damaged, please contact your

distributor or sales representative immediately.

System - QBiX-Pro Series QBiX2-Pro-KBLB7100H-A1 (QD-7100A-SI)

5www.gigaipc.com

About this Document

This User’s Manual contains all the essential information, such as

detailed descriptions and explanations on the product’s hardware

and software features (if any), its specifications, dimensions, jumper/

connector settings/definitions, and driver installation instructions (if

any), to facilitate users in setting up their product.

Users may refer to the GIGAIPC.com for the latest version of this

document.

www.gigaipc.com

Safety Precautions

Please read the following safety instructions carefully. It is advised that

you keep this manual for future references

1. All cautions and warnings on the device should be noted.

2. Make sure the power source matches the power rating of the

device.

3. Position the power cord so that people cannot step on it. Do

not place anything over the power cord.

4. Always completely disconnect the power before working on the

system’s hardware.

5. No connections should be made when the system is powered

as a sudden rush of power may damage sensitive electronic

components.

6. If the device is not to be used for a long time, disconnect it from

the power supply to avoid damage by transient over-voltage.

7. Always disconnect this device from any AC supply before

cleaning.

8. While cleaning, use a damp cloth instead of liquid or spray

detergents.

9. Make sure the device is installed near a power outlet and is

easily accessible.

10. Keep this device away from humidity.

11. Place the device on a solid surface during installation to prevent

falls

12. Do not cover the openings on the device to ensure optimal heat

dissipation.

System - QBiX-Pro Series QBiX2-Pro-KBLB7100H-A1 (QD-7100A-SI)

7www.gigaipc.com

13. Watch out for high temperatures when the system is running.

14. Do not touch the heat sink or heat spreader when the system is

running

15. Never pour any liquid into the openings. This could cause fire or

electric shock.

16. As most electronic components are sensitive to static electrical

charge, be sure to ground yourself to prevent static charge

when installing the internal components. Use a grounding

wrist strap and contain all electronic components in any static-

shielded containers.

17. If any of the following situations arises, please the contact our

service personnel:

i. Damaged power cord or plug

ii. Liquid intrusion to the device

iii. Exposure to moisture

iv. Device is not working as expected or in a manner as described

in this manual

v. The device is dropped or damaged

vi. Any obvious signs of damage displayed on the device

18. DO NOT LEAVE THIS DEVICE IN AN UNCONTROLLED

ENVIRONMENT WITH TEMPERATURES BEYOND THE DEVICE’S

PERMITTED STORAGE TEMPERATURES (SEE CHAPTER 1) TO

PREVENT DAMAGE.

www.gigaipc.com

FCC Statement

This device complies with Part 15 FCC Rules. Operation

is subject to the following two conditions: (1) this device

may not cause harmful interference, and (2) this device

must accept any interference received including

interference that may cause undesired operation.

Caution:

There is a danger of explosion if the battery is incorrectly replaced. Replace only with

the same or equivalent type recommended by the manufacturer. Dispose of used

batteries according to the manufacturer’s instructions and your local government’s

recycling or disposal directives.

Attention:

Il y a un risque d’explosion si la batterie est remplacée de façon incorrecte.

Ne la remplacer qu’avec le même modèle ou équivalent recommandé par le

constructeur. Recycler les batteries usées en accord avec les instructions du fabricant

et les directives gouvernementales de recyclage.

System - QBiX-Pro Series QBiX2-Pro-KBLB7100H-A1 (QD-7100A-SI)

9www.gigaipc.com

Table Contents

QBiX2-Pro Industrial Embedded System 1

Quick Start Guide 1

Acknowledgement ....................................................................... 3

Packing List................................................................................... 4

About this Document ................................................................... 5

Safety Precautions ....................................................................... 6

FCC Statement.............................................................................. 8

Chapter 1 - Product Specifications 11

1.1 Specifications ............................................................... 13

Chapter 2 – QBiX2-Pro-KBLB7100H-A1 (QD-7100A-SI)

Industrial Embedded System Kit 15

2.1 Dimension .................................................................... 16

2.2 Getting Familiar with Your Unit..................................... 17

2.3 A) Wireless Module: How to safely install the Module

(Wireless Module inclusion may vary based on local

distribution) .................................................................. 19

2.4 B) Memory Installation: DDR4 SO-DIMM .................... 20

2.5 Antenna Installation (Antenna inclusion may vary based

on local distribution) .................................................... 21

2.6 GPIO Pin Define ........................................................... 22

2.7 Support ........................................................................ 23

2.8 Safety and Regulatory Information............................... 24

www.gigaipc.com

Chapter 3 – Board Hardware Information 25

3.1 Jumpers and Connectors ............................................. 26

3.2.1 CPU FAN (CPU FAN connector) .................................... 29

3.2.2 System FAN (System FAN connector) .......................... 30

3.2.3 COM2, COM3, COM4 (Serial port header) ................... 31

3.2.4 FUSB (USB 2.0 header) .................................................. 32

3.2.5 SATAIII_0, SATAIII_1 (SATA 6GB/S Connector) .............. 33

3.2.6 GPIO_CNT (General Purpose input/output header ).... 34

3.2.7 SATAPW1, SATAPW2 (SATA 6Gb/s power connector) ... 35

3.2.8 AT_CN (AT/ATX power mode select jumper) ................ 36

3.2.9 DC_IN (DC IN 1x4-pin power connector )..................... 37

3.2.10 SPK_OUT (Speaker out connector) ............................... 38

3.2.11 FP_Audio (Front Audio connector) ............................... 39

3.2.12 BKL_CN (Back light brightness control connector)....... 40

3.2.13 SYS_PANEL (Front panel header) ...................................41

3.2.14 LVDS (LVDS connector).................................................. 42

3.2.15 LSW (LVDS resolution jumper) ...................................... 43

3.2.16 BATTERY (Battery cable connector).............................. 44

3.2.17 JCOM1 (COM1 RI# pin RI#/5V/12V Select).................... 45
