Gigabyte GS-SR102 Guía del usuario
System Installation Guide
1-i
GS-SR102/SR202
System Installation Guide
System Installation Guide
1-ii
Table of Contents
1. INTRODUCTION 1-3
1.1. PREFACE 1-3
1.2. FEATURES 1-3
2. PACKAGE CONTENTS 2-1
3. SYSTEM INSTALLATION PROCEDURES 3-1
3.1. CHASSIS COVER REMOVAL 3-1
3.2. CPU INSTALLATION 3-2
3.3. HEAT SINK INSTALLATION 3-3
3.4. MEMORY INSTALLATION 3-5
3.5. PCI EXPANSION CARD INSTALLATION 3-5
3.6. AIR FLOW DUCT INSTALLATION GUIDE 3-7
3.7. REINSTALL TOP COVER 3-9
3.8. SCSI ID SETTINGS 3-10
3.9. JUMPER SETTING FOR HD1 ‘HD2 AND HD3 3-11
3.10. DOCK HANDLES INSTALLATION 3-12
3.11. HARD DISK DRIVE INSTALLATION 3-12
3.12. FRONT PANEL 3-14
3.13. LED PANEL 3-14
3.14. REAR PANEL 3-15
3.15. DUAL LAN CARD INSTALLATION ( OPTIONAL ) 3-15
3.16. CONNECTOR ICONS 3-18
System Installation Guide
1-3
1. Introduction
1.1. Preface
This manual will assist you in installing all of the essential
components for rack mount system. We recommend you keep
this manual for future reference.
In order to maintain the rack mount server in its original
condition, please pay attention to the following tips.
1. Thoroughly read the manual before installing any
component.
2. Keep the system away from static and magnetic field.
3. Do not apply cleaning solutions directly to the system.
1.2. Features
The 1U Rackmount server contains the several features. These
features provide respective advantages to your system. The key
features of the adapter are:
Processor Support
Dual Socket 370 for Intel FC-PGA Pentium III or other
compatible processor up to 1 GHz and above
100/133MHz FSB
AUTO detect CPU voltage
BIOS
Support Dual BIOS technology ; 2M bit flash ROM
IDE#0~#3 ,LS120 ,ZIP & CD-ROOM bootable
AC recovery ON/OFF control
AMI BIOS with enhanced ACPI feature for
PC99/Win98/Win2000 compliance
Green ,PnP ,DMI ,INT 13(>8.4GB) & Anti-Virus functions
Auto-detect & report system health status
System Installation Guide
1-4
Chipset
VIA Apollo Pro Family AGPset
( VT82C694X ,VT82C686A ) Chipset
ATI Rage XL VGA Chip
PROMISE PDC20265R
Intel 82559 Dual LAN chip
Memory Support
4 168-pin 25 degree slant DIMM sockets
Supports PC-100/PC-133 SDRAM and VCM SDRAM
Supports up to 4.0GB SDRAM
Supports only 3.3V SDRAM DIMM
Storage Controller
Max 4 IDE ATA channels ( 2 x ATA-66 and 2 x ATA-100
for IDE RAID 0 or 1 )
System Installation Guide
2-1
2. Package Contents
When opening the package, please insure the system has not
been damaged during shipping. Using the following list as a
check off, verify the contents. If there is missing component or
damage to the system, please inform your vendor immediately.
Contents：
System Chassis
Power Supply (installed)
GA-6ETXDR Motherboard (installed)
Slim type CD-ROM drive (installed)
Slim type Floppy drive (installed)
Three/Six Hard Disk Drive Trays for SR102/SR202
Two CPU heat sinks
Two Dock Handles, with tow screws
Driver & Application CD
Installation Manual
System Installation Guide
3. System Installation Procedures
Warning: Please remove the protective thin films (Top and
Bottom) from the system when installing.
3.1. Chassis Cover Removal
a. Unscrew the two thumb screws from the back of the system
(Fig-1).
b. Standing at the front of the system. Gently apply force to
the indentures with your thumbs and push toward the rear
of the chassis for about 3/4 of an inch. Top cover may be
lifted straight up (Fig-2).
Fig-1
c. With the top cover removed, you will see a plastic air duct
over the CPU and Memory. Remove the air duct to install
the CPU and Memory (Fig-3).
Fig-2
System Installation Guide
3-2
3.2. CPU Installation
To install Socket 370 CPU, lift up bar located next to the
Socket. Then, insert Socket370 CPU inside Socket, and
push the lever bar back into original position. (Fig-4 &
Fig-5 )
CPU-1
CPU-2
Fig-4
Fig-3
System Installation Guide
3.3. Heat Sink Installation
Click Fan+Heatsink to CPU socket 370 and plug the Fan power
cable to the each single CPU cooling Fan connector on the
motherboard. (Fig-6 and Fig-7)
Fig-5
Fig-6
System Installation Guide
3-4
For CPU1, Fan power cable connect to J13 (CPU1 FAN)
connector and for CPU2, Fan power cable connect to J15 (CPU2
Fan) Connector. Note to make sure the connector is plugged into
the header in the correct and firmly seated. (Fig-8)
J13-CPU1 Fan Connector J15-CPU2 Fan Connector
Fig-7
Fig-8
