Gigabyte M6980 Manual de usuario
- 1 -
ENGLISH
Introduction
GIGABYTE M6980 laser gaming mouse is one of most popular choice of GIGABYTE gaming series. The combination of
2000dpi, 1000rps report rate and 20G acceleration provide a very accurate basis for gaming.
GHOST™ Macro Engine of 8KB on-board memory supports 3 gaming proles stored on the mouse. Having personal
macro settings portable with the mouse allow users to load their proles on any computers.
Equipped for gamer, GIGABYTE M6980 upgrades your level in game play!
Feature
2000DPI Laser Gaming Sensor
y
GHOST™ Macro Engine
y
Gaming-grade Tracking Capability up to 7080FPS
y
On-the-y DPI Switching
y
Streamlined ergonomic design
y
7 (+2) customizable buttons, 3proles
y
Mouse Instruction
Left Click
Right Click
Forward
Back
On-the-y DPI
adjustment
Prole change
Middle Click and
4 ways scrolling
Pro-laser gaming sensor
Ultra-Durable™ Teon feet
- 2 -
ENGLISH
Please DO NOT directly look into the laser beam.
LED display
- DPI indicator
800dpi / 1600dpi / 2000dpi (customizable 400~2000dpi adjustment via GHOST™ Engine)
- Prole indicator
Red: Prole1 / Green: Prole2 / Blue: Prole3 (customized color lighting via GHOST™ Engine)
Important information
Long period of repetitive motion using an improperly set-up workplace, or incorrect body posture may be associated with
physical discomfort and injury to nerves, tendons and muscles.
- 3 -
ENGLISH
GHOST™ Macro Engine
GHOST™ Macro Engine supports Windows 98, Windows 2000, Windows XP, and Windows 7. Install the software to
assign buttons and set up your personal prole.
BUTTON ASSIGN
User can assign various functions to buttons from both “BASIC FUNCTION” and “MACRO SCRIPTS”. All you have to do
is drag the function icon and simply drop to the button you would like to assign. Remember that you may edit each macro
script in the “MACRO EDITING” tab.
There are three default color LED lights (red/green/blue) on the panel which indicate three different proles set up by
users. Each individual prole can be assigned various settings to 9 customizable buttons. Moreover, you can also change
the color of LED light for each prole.
(There are 7 colors and a light-off mode to choose from).
- 4 -
ENGLISH
MACRO EDITING
The macro editing tab allows you easily to record all the commands, including key bindings and the press of mouse button.
Each single macro also can be imported and exported onto your hard disk for further usage.
Start with:
Step 1 Click “Record the duration or intervals” if you’d like to record intervals between two commands.
Step 2 Double-click “Cycle through selection of action mode” to change the execute mode.
Step 3 Click “Record” to start creating a macro and recording all the keystrokes or mouse commands.
Step 4 Click “Stop” to nish recording this macro when a macro is done.
Step 5 You can also insert additional commands on the “Quick-insert bar” left.
Step 6 After recording a macro, you may drag commands of the macro and drop into “On-board script” to store this
macro on the mouse.
Step 7 Double-click on the macro scrip to rename this macro. Moreover, you may also change icon of your personal
macro through clicking “change icon”.
Step 8
Come back to “Button Assign” tab, the macro you had built would become one application of “Macro scrip” in this tab.
- 5 -
ENGLISH
Learn more:
Record the duration or intervals (Time lag)
If this function is marked, it allows you to record the intervals between two commands.
Cycle through selection of action mode
Execute once:
y
To execute a macro once.
Loop mode:
y
Re-pressing to stop: Executing a macro continuously, and re-pressing the assigned button to stop the running macro.
Fire-button mode:
y
Executing a macro continuously until you release the assigned button.
Export
To export your macro to the PC.
Import
To import a macro to the macro editing in GHOST engine application program.
Re-edit the macro
Dragging the macro script back to macro editing allows you to re-edit this macro.
- 6 -
ENGLISH
SENSITIVITY/ SCROLLING Tab
Sensitivity
As default setting, there are three sensitivity stages: 800, 1600, and 2000DPI (dots per inch). You can set up preferred
sensitivity value of three sensitivity stages, then you can simply adjust through on-the-y switch. Check “set X and Y axis
separately” option to adjust X-Y sensitivity levels.
Report rate
The report rate determines the time intervals that your PC retrieves data from your mouse. You can set the report rate to
125Hz (8ms), 250Hz (4ms), 500Hz (2ms), or 1000Hz (1ms) by moving the knob on the slider.
Scrolling
You can adjust vertical & horizontal scroll wheel speed by moving the knob on the slider.
- 1 -
繁中
簡介
技嘉M6980雷射遊戲滑鼠是技嘉電競系列又一熱門首選。結合2000dpi，1000rps回報速度和20G移動加速度的高規格提供
玩家在遊戲中最精確的後盾。
搭載技嘉獨家GHOST™巨集引擎，內建8KB內嵌式記憶體可支援硬體滑鼠三組模式儲存，讓玩家可以帶著滑鼠在任何電腦
載入個人專屬巨集的模式設定。
玩家級裝備，GIGABYTE M6980讓您的遊戲戰力升級！
特點
2000DPI玩家級雷射感應器
y
先進的GHOST™巨集引擎軟體
y
7080FPS電競等級位移追蹤速度
y
快速DPI切換鍵
y
人體工學流線形設計
y
7 (+2)客製按鍵，三組模式
y
滑鼠操作指示
左鍵
右鍵
拇指前鍵
拇指後鍵
DPI切換鍵
模式切換鍵
中鍵和四向滾輪
專業電競雷射感應器
超耐磨鐵氟龍滑鼠腳墊
- 2 -
繁中
請勿直視雷射光源。
LED燈號顯示
- DPI指示燈
800dpi / 1600dpi / 2000dpi (透過GHOST™引擎軟體可依個人喜好調整400~2000dpi)
- 模式指示燈
紅：模式1 / 綠：模式2/ 藍：模式3 (透過GHOST™引擎軟體可依個人喜好變換多種燈光色彩)
重要資訊
長期重複的動作、未有適當的工作空間、錯誤的身體姿勢以及不佳的工作習慣，都可能導致身體不適並造成神經、肌腱或
肌肉的傷害。
- 3 -
繁中
GHOST™巨集編輯引擎
GHOST™巨集編輯引擎可支援Windows 98、Windows 2000、Windows XP和Windows 7等作業系統。安裝此軟體便可以
錄製各種按鍵功能以及設定您個人專屬的模式。
按鍵配置
使用者可以同時從GHOST軟體內建的「基本功能庫」和自行編集的「巨集腳本庫」裡的挑選功能選項來設定滑鼠按鍵，
操作上只要將功能方塊拖曳到欲設定的按鍵鈕上，即可輕鬆完成設定。請記得，你可以到「巨集編集器」分頁裡編集你專
屬的巨集設定。
右上方控制列顯示三個預設LED燈光(紅/綠/藍)分別代表三個不同的模式設定，而每一種模式又有九個按鍵鈕可以設定(共有
七種燈光顏色以及關閉燈光效果可供選擇)。
