Gigabyte GA-A75-DS3P Manual de usuario
GA-A75-DS3P
User's Manual
Rev. 1001
12ME-A75DS3P-1001R
Motherboard
GA-A75-DS3P
Feb. 24, 2012
Feb. 24, 2012
Motherboard
GA-A75-DS3P
Copyright
©2012 GIGA-BYTE TECHNOLOGY CO., LTD. All rights reserved.
The trademarks mentioned in this manual are legally registered to their respective owners.
Disclaimer
Information in this manual is protected by copyright laws and is the property of GIGABYTE.
Changes to the specications and features in this manual may be made by GIGABYTE without
prior notice. No part of this manual may be reproduced, copied, translated, transmitted, or
published in any form or by any means without GIGABYTE's prior written permission.
Documentation Classications
In order to assist in the use of this product, GIGABYTE provides the following types of
documentations:
For quick set-up of the product, read the Quick Installation Guide included with the product.
For detailed product information, carefully read the User's Manual.
For product-related information, check on our website at:
http://www.gigabyte.com
Identifying Your Motherboard Revision
The revision number on your motherboard looks like this: "REV: X.X." For example, "REV: 1.0"
means the revision of the motherboard is 1.0. Check your motherboard revision before updating
motherboard BIOS, drivers, or when looking for technical information.
Example:
- 4 -
Table of Contents
Box Contents...................................................................................................................6
Optional Items .................................................................................................................6
GA-A75-DS3P Motherboard Layout ................................................................................7
GA-A75-DS3P Motherboard Block Diagram ...................................................................8
Chapter 1 Hardware Installation .....................................................................................9
1-1 Installation Precautions.................................................................................... 9
1-2 Product Specications.................................................................................... 10
1-3 Installing the APU and APU Cooler................................................................ 13
1-3-1 Installing the APU ...................................................................................................13
1-3-2 Installing the APU Cooler........................................................................................15
1-4 Installing the Memory..................................................................................... 16
1-4-1 Dual Channel Memory Conguration .....................................................................16
1-4-2 Installing a Memory ...............................................................................................17
1-5 Installing an Expansion Card ......................................................................... 18
1-6 Setup of the AMD Dual Graphics Conguration............................................. 19
1-7 Back Panel Connectors.................................................................................. 20
1-8 Internal Connectors........................................................................................ 22
Chapter 2 BIOS Setup ..................................................................................................31
2-1 Startup Screen ............................................................................................... 32
2-2 The Main Menu .............................................................................................. 33
2-3 MB Intelligent Tweaker(M.I.T.)........................................................................ 35
2-4 Standard CMOS Features.............................................................................. 40
2-5 Advanced BIOS Features .............................................................................. 42
2-6 Integrated Peripherals.................................................................................... 44
2-7 Power Management Setup............................................................................. 47
2-8 PC Health Status............................................................................................ 49
2-9 Load Fail-Safe Defaults.................................................................................. 51
2-10 Load Optimized Defaults................................................................................ 51
2-11 Set Supervisor/User Password ...................................................................... 52
2-12 Save & Exit Setup .......................................................................................... 53
2-13 Exit Without Saving........................................................................................ 53
- 5 -
Chapter 3 Drivers Installation........................................................................................55
3-1 Installing Chipset Drivers ............................................................................... 55
3-2 Application Software ...................................................................................... 56
3-3 Technical Manuals.......................................................................................... 56
3-4 Contact........................................................................................................... 57
3-5 System ........................................................................................................... 57
3-6 Download Center ........................................................................................... 58
3-7 New Utilities ................................................................................................... 58
Chapter 4 Unique Features...........................................................................................59
4-1 Xpress Recovery2.......................................................................................... 59
4-2 BIOS Update Utilities ..................................................................................... 62
4-2-1 Updating the BIOS with the Q-Flash Utility.............................................................62
4-2-2 Updating the BIOS with the @BIOS Utility .............................................................65
4-3 EasyTune 6 .................................................................................................... 66
4-4 Q-Share.......................................................................................................... 67
4-5 SMART Recovery........................................................................................... 68
4-6 Auto Green..................................................................................................... 69
Chapter 5 Appendix ......................................................................................................71
5-1 Conguring SATA Hard Drive(s) .................................................................... 71
5-1-1 Conguring SATA Controllers ................................................................................71
5-1-2 Installing the SATA RAID/AHCI Driver and Operating System ...............................77
5-2 Conguring Audio Input and Output............................................................... 81
5-2-1 Conguring 2/4/5.1/7.1-Channel Audio...................................................................81
5-2-2 Conguring S/PDIF Out..........................................................................................83
5-2-3 Conguring Microphone Recording........................................................................84
5-2-4 Using the Sound Recorder .....................................................................................86
5-3 Troubleshooting.............................................................................................. 87
5-3-1 Frequently Asked Questions ..................................................................................87
5-3-2 Troubleshooting Procedure ....................................................................................88
5-3-3 Regulatory Statements...........................................................................................90
- 6 -
Box Contents
GA-A75-DS3P motherboard
5
Motherboard driver disk
5
User's Manual
5
Quick Installation Guide
5
Two SATA cables
5
I/O Shield
5
Optional Items
2-port USB 2.0 bracket (Part No. 12CR1-1UB030-5*R)
2-port SATA power cable (Part No. 12CF1-2SERPW-0*R)
COM port cable (Part No. 12CF1-1CM001-3*R)
3.5" Front Panel with 2 USB 3.0/2.0 ports (Part No. 12CR1-FPX582-0*R)
The box contents above are for reference only and the actual items shall depend on the product package you obtain.
The box contents are subject to change without notice.
- 7 -
GA-A75-DS3P Motherboard Layout
KB_MS CPU_FAN
Socket FM1
ATX
GA-A75-DS3P
F_AUDIO
AUDIO
PCIEX4
DDR3_4
DDR3_3
DDR3_2
DDR3_1
BAT
F_USB2F_USB3
SYS_FAN2
TPMSPDIF_O
COM
ATX_12V
AMD A75
SATA3
PCI2
PCI3
HDMI
R_USB
R_USB30
CODEC
PWR_FAN
SYS_FAN1
PCIEX1_2
PCIEX1_1
OPTICAL
USB_LAN
PCIEX16
PCI1
F_USB1 F_USB30 F_PANEL
M_BIOSB_BIOS
CLR_CMOS
Realtek
GbE LAN
iTE
Super I/O
1 3 5
0 2 4
- 8 -
GA-A75-DS3P Motherboard Block Diagram
UMI
AMD A75
PCI Bus
AMD APU
3 PCI
PCI CLK
(33 MHz)
COM Port
iTE
Super
I/O
LPC
Bus
PS/2 KB/Mouse
Dual BIOS
10 USB 2.0/1.1
6 SATA 6Gb/s
PCI Express Bus
PCI Express Bus
PCIe CLK
(100 MHz)
PCIe CLK
(100 MHz)
1 PCI Express x16
2 PCI Express x1
x16
x1 x1
x4
1 PCI Express x4
x1
LAN
RJ45
Realtek
GbE LAN
APU CLK+/- (100 MHz)
DISP CLK+/- (100 MHz)
Dual Channel Memory
HDMI
Center/Subwoofer Speaker Out
Line Out
MIC
Line In
S/PDIF Out
Side Speaker Out
Surround Speaker Out
CODEC
4 USB 3.0/2.0
DDR3 2400 (O.C.)/1866/
1600/1333/1066 MHz
For detailed product information/limitation(s), refer to "1-2 Product Specications."
- 9 - Hardware Installation
1-1 Installation Precautions
The motherboard contains numerous delicate electronic circuits and components which can become
damaged as a result of electrostatic discharge (ESD). Prior to installation, carefully read the user's
manual and follow these procedures:
Prior to installation, make sure the chassis is suitable for the motherboard.•
Prior to installation, do not remove or break motherboard S/N (Serial Number) sticker or warranty•
sticker provided by your dealer. These stickers are required for warranty validation.
Always remove the AC power by unplugging the power cord from the power outlet before•
installing or removing the motherboard or other hardware components.
When connecting hardware components to the internal connectors on the motherboard, make•
sure they are connected tightly and securely.
When handling the motherboard, avoid touching any metal leads or connectors.•
It is best to wear an electrostatic discharge (ESD) wrist strap when handling electronic com-•
ponents such as a motherboard, APU or memory. If you do not have an ESD wrist strap, keep
your hands dry and rst touch a metal object to eliminate static electricity.
Prior to installing the motherboard, please have it on top of an antistatic pad or within an•
electrostatic shielding container.
Before unplugging the power supply cable from the motherboard, make sure the power supply•
has been turned off.
Before turning on the power, make sure the power supply voltage has been set according to•
the local voltage standard.
Before using the product, please verify that all cables and power connectors of your hardware•
components are connected.
To prevent damage to the motherboard, do not allow screws to come in contact with the•
motherboard circuit or its components.
Make sure there are no leftover screws or metal components placed on the motherboard or•
within the computer casing.
Do not place the computer system on an uneven surface•
.
Do not place the computer system in a high-temperature environment.•
Turning on the computer power during the installation process can lead to damage to system•
components as well as physical harm to the user.
If you are uncertain about any installation steps or have a problem related to the use of the•
product, please consult a certied computer technician.
Chapter 1 Hardware Installation
Hardware Installation - 10 -
1-2 Product Specications
APU FM1 Socket:
- AMD A series processors/AMD E2 series processors
- AMD Athlon™ II series processors/AMD Sempron™series processors
(Go to GIGABYTE's website for the latest APU support list.)
Chipset AMD A75
Memory 4 x 1.5V DDR3 DIMM sockets supporting up to 64 GB of system memory
* Due to Windows 32-bit operating system limitation, when more than 4 GB of physical
memory is installed, the actual memory size displayed will be less than 4 GB.
Dual channel memory architecture
Support for DDR3 2400 (O.C.)/1866/1600/1333/1066 MHz memory modules
* The 2133 MHz (or above) memory speed is supported only when one or
two DIMMs are installed. It is not supported when four DIMMs are installed.
(Dual channel memory mode must be enabled when installing two DIMMs.)
(Go to GIGABYTE's website for the latest supported memory speeds and
memory modules.)
Onboard
Graphics
APU:
* To use the onboard graphics, you must install an AMD APU with integrated
graphics.
- 1 x HDMI port, supporting a maximum resolution of 1920x1200
Audio Realtek ALC887 codec
High Denition Audio
2/4/5.1/7.1-channel
Support for S/PDIF Out
LAN Realtek GbE LAN chip (10/100/1000 Mbit)
Expansion Slots 1 x PCI Express x16 slot, running at x16 (PCIEX16)
* For optimum performance, if only one PCI Express graphics card is to be installed,
be sure to install it in the PCIEX16 slot.
1 x PCI Express x16 slot, running at x4 (PCIEX4)
2 x PCI Express x1 slots
(All PCI Express slots conform to the PCI Express 2.0 standard.)
3 x PCI slots
Multi-Graphics
Technology
Support for AMD CrossFireXTM technology
* The PCIEX16 slot operates at up to x4 mode when AMD CrossFireXTM is enabled.
Support for AMD Dual Graphics technology
* Only A series APUs support AMD Dual Graphics.
Storage Interface Chipset:
- 6 x SATA 6Gb/s connectors supporting up to 6 SATA 6Gb/s devices
- Support for RAID 0, RAID 1, RAID 10, and JBOD
USB Chipset:
- Up to 4 USB 3.0/2.0 ports (2 ports on the back panel, 2 ports available
through the internal USB header)
- Up to 10 USB 2.0/1.1 ports (4 ports on the back panel, 6 ports available
through the internal USB headers)
Tabla de contenidos
Otros manuales de Placa madre de Gigabyte
Gigabyte
Gigabyte GA-8VT800 Manual de usuario
Gigabyte
Gigabyte GA-8SDX Manual de usuario
Gigabyte
Gigabyte GA-Z170-HD3P Manual de usuario
Gigabyte
Gigabyte B560M DS3H V2 Manual de usuario
Gigabyte
Gigabyte GA-B150M-VP Manual de usuario
Gigabyte
Gigabyte GA-P41T-D3P (rev. 1.3) Manual de usuario
Gigabyte
Gigabyte GA-B75M-S Manual de usuario
Gigabyte
Gigabyte B760M D2H Manual de usuario
Gigabyte
Gigabyte GA-B250M-DS3H Manual de usuario
Gigabyte
Gigabyte Z790 AORUS ELITE AX ICE Manual de usuario
Gigabyte
Gigabyte GA-H110N Manual de usuario
Gigabyte
Gigabyte B550 AORUS ELITE AX V2 Manual de usuario
Gigabyte
Gigabyte GA-MA69G-S3H Manual de usuario
Gigabyte
Gigabyte GA-73PVM-S2H Manual de usuario
Gigabyte
Gigabyte GA-790FXTA-UD5 Manual de usuario
Gigabyte
Gigabyte GA-P35-DS3R Manual de usuario
Gigabyte
Gigabyte GA-H81.AMP-UP Manual de usuario
Gigabyte
Gigabyte Q570M D3H Manual de usuario
Gigabyte
Gigabyte MZ72-HB0 Manual de usuario
Gigabyte
Gigabyte GA-P61A-D3 Manual de usuario
Manuales populares de Placa madre de otras marcas
Telit Wireless Solutions
Telit Wireless Solutions SL869-3DR Manual de usuario
Texas Instruments
Texas Instruments ADS8372EVM Manual de usuario
Commell
Commell MS-C73 Manual de usuario
IBT Technologies
IBT Technologies MB860 Manual de usuario
Nvidia
Nvidia TEGRA DG-04927-001_V01 Manual de usuario
Biostar
Biostar M7VIT Bravo Instrucciones de funcionamiento e instalación
