Gigabyte M27F A Manual de usuario

The trademarks mentioned in this manual are legally registered to their

respective owners.

Disclaimer

Information in this manual is protected by copyright laws and is the

property of GIGABYTE.

Changes to the specifications and features in this manual may be made

by GIGABYTE without prior notice.

No part of this manual may be reproduced, copied, translated, transmitted,

or published in any form or by any means without GIGABYTE’s prior

written permission.

• In order to assist in the use of this monitor, carefully read the User

Guide

• For more information, check on our website at:

https://www.gigabyte.com

2021 – 10

Rev. A00

The terms HDMI and HDMI High-Definition

Multimedia Interface, and the HDMI logo are

trademarks or registered trademarks of HDMI

Licensing Administrator, Inc. in the United States

and other countries.

SAFETY INFORMATION

Safety Precautions

Read through the following Safety Precautions before using the monitor.

• Only use the accessories that are provided with the monitor or that

which are recommended by the manufacturer.

• Keep the plastic packaging bag for the product in a place that cannot

be reached by children.

• Before connecting the monitor to the power outlet, make sure that

the voltage rating of the power cable is compatible with the power

specification in the country where you are located.

• The power cord plug must be connected to a properly wired and

grounded power outlet.

• Do not touch the plug with wet hands, otherwise easily cause electric

shock.

• Place the monitor in a stable and well-ventilated place.

• Do not place the monitor near any heat sources such as electric

radiators or direct sunlight.

• The holes or openings on the monitor are for ventilation. Do not

cover or block the ventilation holes with any objects.

• Do not use the monitor near water, drinks, or all types of liquids.

Failure to do so may result in electric shock or damage to the

monitor.

• Make sure to unplug the monitor from the power outlet before

cleaning.

• As the screen surface is easy to be scratched, avoid touching the

surface with any hard or sharp object.

• Use a soft lint-free cloth instead of a tissue to wipe the screen. You

may use a glass cleaner to clean the monitor if required.

However, never spray the cleaner directly onto the screen.

• Disconnect the power cable if the monitor is not being used for a

long period of time.

• Do not attempt to disassemble or repair the monitor yourself.

Stability Hazard Precautions

The product may fall, causing serious personal injury or death. To

prevent injury, this product must be securely attached to the ﬂoor/wall in

accordance with the installation instructions.

Many injuries, particularly to children, can be avoided by taking simple

precautions such as:

• ALWAYS use stands or installation methods recommended by the

manufacturer of the product set.

• ALWAYS use furniture that can safely support the product.

• ALWAYS ensure the product is not overhanging the edge of the

supporting furniture.

• ALWAYS educate children about the dangers of climbing on furniture

to reach the product or its controls.

• ALWAYS route cords and cables connected to your product so they

cannot be tripped over, pulled or grabbed.

• NEVER place a product in an unstable location.

• NEVER place the product on tall furniture (for example, cupboards or

bookcases) without anchoring both the furniture and the product to

a suitable support.

• NEVER place the product on cloth or other materials that may be

located between the product and supporting furniture.

• NEVER place items that might tempt children to climb, such as toys

and remote controls, on the top of the product or furniture on which

the product is placed.

• If the existing product is going to be retained and relocated, the

same considerations as above should be applied.

• To prevent personal injury or damage to the product caused by

tipping over due to earthquakes or other shocks, make sure to install

the product in a stable location and take measures to prevent falling.

- 5 -

CONTENTS

SAFETY INFORMATION ...........................................3

Safety Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Stability Hazard Precautions. . . . . . . . . . . . . . . . . . . . . . . . 4

INTRODUCTION..................................................6

Unpacking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Package Contents. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Product Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

GETTING STARTED ............................................. 11

Installing the Monitor Base . . . . . . . . . . . . . . . . . . . . . . . 11

Adjusting the Viewing Angle . . . . . . . . . . . . . . . . . . . . . . 13

Installing a Wall-Mount Bracket (Optional) . . . . . . . . . . . . . 14

Making Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

USING THE DEVICE ............................................. 16

Turning the Power On/Off . . . . . . . . . . . . . . . . . . . . . . . . 16

User Comfort Recommendations . . . . . . . . . . . . . . . . . . . . 17

Selecting the Input Source . . . . . . . . . . . . . . . . . . . . . . . . 17

OPERATIONS .................................................. 18

Quick Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Configure the Device Settings. . . . . . . . . . . . . . . . . . . . . . 27

APPENDICES................................................... 37

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Supported Timing List . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

Basic Care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

Notes on USB Charging . . . . . . . . . . . . . . . . . . . . . . . . . . 40

GIGABYTE Service Information . . . . . . . . . . . . . . . . . . . . . 40

Regulatory Notices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

- 6 -

INTRODUCTION

Unpacking

1. Open the upper cover of the packaging box. Then observe the

unpacking label attached on the inner cover.

2. Making sure the box is in the correct orientation, carefully lay the box

on the stable surface.

3. Open the inner cover.

Openings

4. Grab the EPS foam assembly (through the openings) to pull it out of the box.

- 7 -

5. Remove the transparent wrapper securing the EPS foams. Then remove

the items from the upper EPS foam.

6. Remove the upper EPS foam. Then you can remove the monitor from

the lower EPS foam.

- 8 -

Package Contents

The following items come with your packaging box. If any of them is

missing, please contact your local dealer.

Monitor Monitor Base Power Cable

HDMI Cable USB Cable DP Cable

Multilingual

Installation

Guide

M27Q P

Warranty Card

Quick Start Guide Warranty Card

Note: Please keep the packaging box and packing materials for future

transportation of the monitor.

- 9 -

Product Overview

Front view

1Power LED

- 10 -

Rear view

5 6 8 94

1 2 3

1 Control button 6USB Type-C port

2 KVM button 7Headphone jack

3 AC Power in 8USB upstream port

4 HDMI ports (x2) 9USB 3.2 ports (x2)

5 DisplayPort

Note:

HDMI, the HDMI logo and High-Definition Multimedia

Interface are trademarks or registered trademarks of

HDMI Licensing LLC.
