Gigabyte GZ-XX1CA-SNS Manual de usuario

Triton Series

English User’s Manual

Triton + Triton 180

Triton GZ-XX1CA-SNS/SNB

Triton 180 GZ-AX1CA-SDS/SDB GZ-AX1CA-SD1/SD2

English

Thank you for purchasing GIGABYTE thermal product. GIGABY TE

is dedicated to the integration of casing liquid/air-cooling solution

technology, to provide users with the most optimal solution for heat

dissipation. For further information and specifications of the “Triton”

series, please visit GIGABYTE website. (http://www.gigabyte.com.tw)

The Following are not covered by the warranty:

1. Using the product incorrectly or in a manner other than the designed purpose.

2. Nonobservance of the proper operations provided.

3. Malfunction due to interference from other devices.

4. Unapproved modification of the product.

5. Consequential damage to other objects due to the product’s fault.

6. Malfunction arising from natural hazards E.g. earthquake, lighting, fire and floods.

7. The product’s warranty label has been removed or damaged.

8. The devices inside, including power supply, hard disk, CD-ROM drive, motherboard,

ventilator, etc, are not detached from the casing prior to transportation of the computer

system, resulting in damage to the casing or other computer-related devices.

9. Any loss/damage caused by failure to follow the installation process with in the user

manual.

Triton 180

Triton

Failure to wear gloves during installation of computer products

may cause bodily harm or damage to your devices. Incorrect

connector installation may possibly burn out the motherboard

and other components. Be sure to observe the instructions in

the user manual.

English

Table of Contents

1. Components Introduction　　　　　　　　　　　　　　 4

1-1 Casing’s Internal Structure 4

1-2 Front and Rear Panel Structure　　　　　　　　　　　5

1-3 Removal of Side and Front Panels 　 6

2. Features　　　　　　　　　　　　　　　　　　　　　　　　6

3. Specifications　　　　　　　　　　　　　　　　　　　　　 7

4. Installation Instructions　　　　　　　　　　　 8

4-1 Installation of Power Supply　　　　　　　　　　　　　8

4-2 Installation of Motherboard　　　　　　　　　　　　　8

4-3 Installation of Add-on Card　　　　　　　　　　　 9

4-4 Installation of Front Multi-Media I/O Port　　　　　　 10

4-5 Installation of Fan Power Cable　　　　　　　　　　 11

4-6 Installation of 5.25” Front Device Bay　　　　　　　　 12

4-7 Installation of 3.5” Front Device Bay 　　　 12

4-8 Installation of 3.5” Internal Device Bay　　　　　 13

4-9 Foot Supports　　　　 13

4-10 Liquid Cooling System Support　　　 13

4-11 Recommended Cooling Products 14

English

1.Components Introduction

1-1 Casing’s Internal Structure

Power Supply

Motherboard

Tray

PCI Tool-Free

Fastener

5.25” Front

Device Bay

3.5” Front

Device Bay

3.5” Internal

Device Bay

English

1-2 Front and Rear Panel Structure

a) Front Panel b) Rear Panel

Accessory Box

Securing Runner

x 6

Copper Stand Off

x 9

Motherboard

Securing Screw x 9

Power Supply

Securing Screw x 4

Wire Clamp x 1 Magnet Ring x 1

Front Cable Kit

USB 2.0 Audio Set

(HD & AC’97)

IEEE1394

(Multi-connectors)

3-Pin Fan

Connector

Basic chassis power

switch control cable kit

Triton 180 Triton

a-1) Reset SW / HDD LED / Power SW / Power LED

a-2)Front multi-media I/O ports

(USB x2, IEEE 1394 x1, Audio Set x1 (HD &AC’97))

b-1) Rear Fan

b-2) LCS Tube Inlet/Outlet

b-1

b-2

a-1

a-2

English

1-3 Removal of Side and Front Panels

1-3.1 To remove side panels:

Remove the 4 thumb screws at the rear of the

　　　 side panels, and detach the side panels.

1-3.2 To remove front panel:

Remove the left and right side panels (see step 1-3.1), release

　　　 the 4 clamps the hold the front panel onto the chassis.

2.Features

-High Quality Design

• High-end aluminum bezel design

• Skid-proof & shock-proof foot stands

-Complete Support

• Front panel multi-media I/O ports

(USB x2, IEEE 1394 x1, Audio Set x1 (HD &AC’97))

• Dual 12cm silent & shock proof fan (Front x 1 and Rear x 1)

• Supports liquid cooling systems

-Integration of Cooling Technology

• Intel CAG 1.1 Air Duct

-Convenience of Assembly

• Internal Cable Management

• Tool-free installation design

1-3.1a

1-3.2a

English

3.Specifications

Triton Triton 180

Model GZ-XX1CA-SNS/SNB GZ-AX1CA-SDS/SDB

GZ-AX1CA-SD1/SD2

Case Type Middle Tower

Size (W x H x D) 200 x 440x 480 mm

Front Bezel Material Aluminum

Color Silver / Black

Side Panel Intel CAG1.1

Body Material 0.7 mm SECC

Net Weight 8.4kg

5.25” Device Bay (external) 5

3.5” Device Bay (external) 2

3.5” Device Bay (internal) 3

PCI Slot 7

Motherboard Size ATX / Micro ATX / Flex ATX

System Fan (front) 12cm silent fan x 1

System Fan (rear) 12cm silent fan x 1

Multi-Media I/O Port USB2.0 x 2 , IEEE 1394 x 1 ,

Audio Set x 1 (HD & AC'97)

English

4.Installation Instructions

Please follow the reference sections in order for installation.

4-1 Installation of Power Supply

To facilitate the installation, it is recommended to set the chassis

upright on the table.

Required Tools: Power supply securing screw x 4.

Remove side panel (see step 1-3.1 on page 6).

Place the power supply unit into the case.

Secure the power supply with the 4 securing

screws.

4-2 Installation of Motherboard

This chassis is compatible with ATX / Micro ATX / Flex ATX

motherboards.

Please confirm the dimensions and fixing points of the

motherboard prior to installation.

Required Tools: Copper stand offs, Motherboard screws.

According to motherboard specifications,

select proper screw points, screw in the

copper stand offs into the corresponding

points on the motherboard.

Change the motherboard I/O bracket on the

rear panel (supplied by the motherboard

manufacturer).

4-1.1

4-1.2

4-2.1

4-2.2

English

Secure the motherboard with the motherboard

screws (refer to your motherboard manual to

check what type of motherboard you have).

4-3 Installation of Add-on Card

This chassis supports tool-free installation of add-on cards, e.g.

graphics cards, sound cards, and etc.

Required Tools: None

Unlock the corresponding PCI tool-free

fastener by pushing it downwards.

Lift the fastener upwards and remove the

internally attached dust-proof PCI cover.

Insert the add-on card into the expansion slot

and then lock the PCI tool-free fastener.

4-2.3

Motherboard Code name Motherboard

screws

Case copper

post

ATX A1-A9 9 9

Micro ATX U1-U9 9 9

Flex ATX F1-F6 6 6

4-3.1

4-3.2

4-3.3

English

4-4 Installation of Front Multi-Media I/O Ports

The front panel consists of:

(1) 2 x USB, 1 x IEEE 1394 and 1 x Audio Set (HD & AC’97)

(2) Basic casing power switch control cable kit.

Required Tools: None

(1) 2 x USB, 1 x IEEE 1394 and 1 x Audio Set (HD & AC’97)

Insert the USB 2.0 connectors into the

corresponding socket on the motherboard.

Insert the IEEE 1394 connector into the

corresponding socket on the motherboard.

Please refer to the instructions supplied by the motherboard

manufacturer and make sure the correct type of connector is used

prior to installation.

Incorrect connection of the slots can possibly cause the

motherboard to malfunction or completely destroy the

motherboard. Please read the installation procedure within the

user manual as incorrect installations or connections causing

faults will void your warranty.

4-4.1

4-4.2

Pin Definition Pin Definition

1 Power 6 USB Dy+

2 Power 7 GND

3 USB Dx- 8 GND

4 USB Dy- 9

5 USB Dx+ 10 USB Over current

USB 2.0 connector

Pin Definition Pin Definition

1 TPA+ 6 TPB-

2 TPA- 7

3 GND 8 +12V

4 GND 9 +12V

5 TPB+ 10 GND

IEEE 1394 connector A

Pin Definition Pin Definition

1 TPA+ 6 TPB-

2 TPA- 7 +12V

3 GND 8 +12V

4 GND 9

5 TPB+ 10 GND

IEEE 1394 connector B

Pin Definition Pin Definition

1 +12V 9 +12V

2 +12V 10 +12V

3 TPA+ 11 TPA1+

4 TPA- 12 TPA1-

5 GND 13 GND

6 GND 14

7 TPB+ 15 TPB1+

8 TPB- 16 TPB1-

IEEE 1394 connector C

B C
