GIGA-BYTE TECHNOLOGY MX32-BS0 Manual de usuario

MX32-BS0

Intel®Socket LGA1151 processor motherboard

User's Manual

Rev. 1001

The trademarks mentioned in this manual are legally registered to their respective owners.

Disclaimer

Information in this manual is protected by copyright laws and is the property of GIGABYTE.

Changes to the specifications and features in this manual may be made by GIGABYTE

without prior notice. No part of this manual may be reproduced, copied, translated, transmitted, or

published in any form or by any means without GIGABYTE's prior written permission.

Documentation Classications

In order to assist in the use of this product, GIGABYTE provides the following types of documentation:

For detailed product information, carefully read the User's Manual.

For product-related information, check on our website at:

http://www.gigabyte.com

- 3 -

Table of Contents

MX32-BS0 Motherboard Layout......................................................................................5

Block Diagram .................................................................................................................7

Chapter 1 Hardware Installation .....................................................................................8

1-1 Installation Precautions.................................................................................... 8

1-2 ProductSpecications...................................................................................... 9

1-3 Installing the CPU and CPU Cooler ............................................................... 11

1-3-1 Installing the CPU...................................................................................................11

1-3-2 Installing the CPU Cooler .......................................................................................13

1-4 Installing the Memory..................................................................................... 14

1-4-1 Installing a Memory ...............................................................................................14

1-5 Installing the M.2 SSD Module....................................................................... 15

1-6 Back Panel Connectors.................................................................................. 16

1-7 Internal Connectors........................................................................................ 17

1-8 Jumper Settings ............................................................................................. 26

Chapter 2 BIOS Setup ..................................................................................................27

2-1 The Main Menu .............................................................................................. 29

2-2 Advanced Menu ............................................................................................. 32

2-2-1 CPUConguration..................................................................................................33

2-2-2 PCI Subsystem Settings.........................................................................................34

2-2-3 Power & Performance Settings ..............................................................................35

2-2-4 ServerMEConguration ........................................................................................38

2-2-5 Trusted Computing .................................................................................................39

2-2-6 Serial Port Console Redirection .............................................................................40

2-2-7 AST2500SuperIOConguration...........................................................................43

2-2-8 NetworkStackConguration..................................................................................45

2-2-9 USBConguration..................................................................................................46

2-2-10 Runtime Error Logging Settings .............................................................................47

2-2-11 S5 RTC Wake Settings...........................................................................................48

2-2-12 NVMeConguration ...............................................................................................49

2-2-13 OffBoardSATAControllerConguration.................................................................50

2-2-14 ChipsetConguration.............................................................................................51

2-2-15 iSCSIConguration................................................................................................52

2-2-16 Intel(R) I210 Gigabit Network Connection..............................................................53

2-2-17 VLANConguration................................................................................................55

2-2-18 Driver Health...........................................................................................................57

2-3 Chipset Setup Menu....................................................................................... 58

- 4 -

2-3-1 SyetemAgent(SA)Conguration...........................................................................59

2-3-2 PCH-IOConguration............................................................................................60

2-4 Server Management Menu............................................................................. 61

2-4-1 System Event Log ..................................................................................................63

2-4-2 View FRU Information ............................................................................................64

2-4-3 BMCNetworkConguration...................................................................................65

2-4-4 IPv6BMCNetworkConguration...........................................................................66

2-5 Security Menu ................................................................................................ 67

2-5-1 Secure Boot ...........................................................................................................68

2-6 Boot Menu...................................................................................................... 70

2-6-1 UEFI NETWORK Drive BBS Priorities ..................................................................72

2-6-2 UEFI Application Boot Priorities ................................................................... 73

2-7 Save & Exit Menu........................................................................................... 74

2-8 BIOS POST Codes ........................................................................................ 76

2-8-1 AMI Standard - PEI.................................................................................................76

2-8-2 AMI Standard - DXE...............................................................................................76

2-8-3 AMI Standard - ERROR .........................................................................................78

2-8-4 Intel UPI POST Codes............................................................................................79

2-8-5 Intel UPI Error Codes .............................................................................................79

2-8-6 Intel MRC POST Codes .........................................................................................80

2-8-7 Intel MRC Error Codes ...........................................................................................80

2-8-8 Intel PM POST Codes ............................................................................................81

2-8-9 Intel PM POST Codes ............................................................................................81

2-9 BIOS POST Beep code (AMI standard)......................................................... 82

2-9-1 PEI Beep Codes.....................................................................................................82

2-9-2 DXE Beep Codes ...................................................................................................82

- 5 -

MX32-BS0 Motherboard Layout

DIMM_P0_A1

DIMM_P0_A0

DIMM_P0_B1

DIMM_P0_B0

CPU

1 2 3 4 5

1011

1213141516

202122

32 33 34 35 36

- 6 -

Item Code Description

1 VGA VGA Port

2 USB3_MLAN Server management LAN port (top)/ USB3.0 ports (bottom)

3 LAN1 GbE Ethernet LAN port #1

4 LAN2 GbE Ethernet LAN port #2 (top) / #4 (bottom)

5 COM1 Serial Port

6 SYS_FAN1 System fan connector #1

7 PMBUS PMBus connector

8 P2 8 pin power connector (for CPU, DDR)

9 CASE_OPEN Case Open Intrusion Alert Header

10 SYS_FAN3 System fan connector #3

11 SYS_FAN2 System fan connector #2

12 P1 24 pin main power connector

13 SYS_FAN4 System fan connector #4

14 CPU_FAN CPU fan connector

15 F_USB2 USB 2.0 connector

16 BAT Battery socket

17 SATA_0_1 SATA III 6Gb/s connector

18 SATA_2_3 SATA III 6Gb/s connector

19 SATA4 SATA III 6Gb/s connector (Support SATA DOM power)

20 SATA_DOM1 SATA port 4 DOM power connector

21 SATA_DOM2 SATA port 5 DOM power connector

22 SATA5 SATA III 6Gb/s connector (Support SATA DOM power)

23 F_USB3 USB 3.0 connector

24 SATA_SGP1 SATA SGPIO connector

25 USB_A Type A USB 2.0 connector

26 IPMB IPMB connector

27 FP_1 Front panel header

28 M2_MKEY M.2 slot (PCIe Gen3 x4, Support NGFF-2280, M-Key)

29 TPM TPM module connector

30 BP_1 HDD back plane board header

31 COM2 Serial port cable connector

32 PCIE_4 PCI Express x8 slot (Gen3 x4 Signal)

33 PCIE_6 PCI Express x16 slot

34 LED_BMC BMCrmwarereadinessLED

35 ID_LED ID Button LED

36 SW_ID ID Button

- 7 -

Block Diagram

Hardware Installation - 8 -

1-1 Installation Precautions

The motherboard contains numerous delicate electronic circuits and components which can

become damaged as a result of electrostatic discharge (ESD). Prior to installation, carefully read

the user's manual and follow these procedures:

• Prior to installation, do not remove or break motherboard S/N (Serial Number) sticker or

warranty sticker provided by your dealer. These stickers are required for warranty validation.

• Always remove the AC power by unplugging the power cord from the power outlet before

installing or removing the motherboard or other hardware components.

• When connecting hardware components to the internal connectors on the motherboard,

make sure they are connected tightly and securely.

• When handling the motherboard, avoid touching any metal leads or connectors.

• It is best to wear an electrostatic discharge (ESD) wrist strap when handling electronic

components such as a motherboard, CPU or memory. If you do not have an ESD wrist

strap,keepyourhandsdryandrsttouchametalobjecttoeliminatestaticelectricity.

•

Prior to installing the motherboard, please have it on top of an antistatic pad or within an

electrostatic shielding container.

• Before unplugging the power supply cable from the motherboard, make sure the power

supply has been turned off.

• Before turning on the power, make sure the power supply voltage has been set according to

the local voltage standard.

• Before using the product, please verify that all cables and power connectors of your

hardware components are connected.

• To prevent damage to the motherboard, do not allow screws to come in contact with the

motherboard circuit or its components.

• Make sure there are no leftover screws or metal components placed on the motherboard or

within the computer casing.

• Do not place the computer system on an uneven surface

• Do not place the computer system in a high-temperature environment.

• Turning on the computer power during the installation process can lead to damage to

system components as well as physical harm to the user.

• If you are uncertain about any installation steps or have a problem related to the use of the

product,pleaseconsultacertiedcomputertechnician.

Chapter 1 Hardware Installation

- 9 - Hardware Installation

1-2 ProductSpecications

CPU Supports Intel® Xeon® E-2100 Processors

8th Gen. Intel Core™ i3/ Pentium®/ Celeron® Processors

Chipset Intel® C242 Express Chipset

Memory 4 x DIMM slots

Dual channel memory architecture

Supports 1.2V DDR4 memory

ECC UDIMM modules supported; Up to 64GB

Supported speeds: 2666/2400 MHz

Onboard

Graphics

Integrated in Aspeed® AST2500

2D Video Graphic Adapter with PCIe bus interface

1920x1200@60Hz 32bpp, DDR4 SDRAM

LAN 2 x GbE LAN ports (Intel® I210)

1 x 10/100/1000 management LAN

Expansion Slots 1 x PCI Express x16 slot; running at Gen3 x16

1 x PCI Express x8 slot; running at Gen3 x4

1 x M.2 slot:

- M-key

- PCIe Gen3 x2 per slot

- Supports NGFF-2280/2260/2242 cards

Storage Interface 6 x SATA III 6Gb/s connectors

SATA4/ SATA5 support SATA DOM

RAID Intel® SATA RAID 0/1/10/5

Internal I/O

Connectors

1 x 24-pin ATX main power connector

1 x 8-pin ATX 12V power connector

6 x SATA III 6Gb/s ports

1 x M.2 slot

1 x USB 2.0 vertical port

1 x CPU fan header

4 x System fan headers

1 x USB 3.0 header

1 x USB 2.0 header

1 x COM port header

1 x Back panel header

1 x TPM header

1 x SATA SGPIO header

2 x SATA DOM headers

1 x Front panel header

1 x JTAG BMC header

1 x Chassis intrusion header

1 x IPMB connector

1 x PMBus connector

Hardware Installation - 10 -

Rear I/O

Connectors

1 x Serial port

1 x VGA port

2 x RJ45 ports

1 x MLAN port

2 x USB 3.0 ports

1 x ID switch

TPM 1 x TPM header

Board

Management

Aspeed® AST2500 management controller

AMI MegaRAC SP-X Solution Web interface

Form Factor microATX

244mm W x 244mm D

GIGABYTE reserves theright to make any changes to the product specications and product-related

information without prior notice.

Tabla de contenidos

Otros manuales de Placa madre de GIGA-BYTE TECHNOLOGY

GIGA-BYTE TECHNOLOGY

GIGA-BYTE TECHNOLOGY H310N 2.0 Manual de usuario

GIGA-BYTE TECHNOLOGY

GIGA-BYTE TECHNOLOGY Z370XP SLI Manual de usuario

GIGA-BYTE TECHNOLOGY

GIGA-BYTE TECHNOLOGY GA-A320-DS3 Manual de usuario

GIGA-BYTE TECHNOLOGY

GIGA-BYTE TECHNOLOGY GA-Z97X-Gaming GT Manual de usuario

GIGA-BYTE TECHNOLOGY

GIGA-BYTE TECHNOLOGY H310M D3H 2.0 Manual de usuario

GIGA-BYTE TECHNOLOGY

GIGA-BYTE TECHNOLOGY GA-Z270X-Gaming K5 Manual de usuario

GIGA-BYTE TECHNOLOGY

GIGA-BYTE TECHNOLOGY GA-H110-D3 Manual de usuario

GIGA-BYTE TECHNOLOGY

GIGA-BYTE TECHNOLOGY GA-H110TN-M Manual de usuario

GIGA-BYTE TECHNOLOGY

GIGA-BYTE TECHNOLOGY GA-6LXSL Manual de usuario

GIGA-BYTE TECHNOLOGY

GIGA-BYTE TECHNOLOGY X570S AORUS MASTER Manual de usuario

GIGA-BYTE TECHNOLOGY

GIGA-BYTE TECHNOLOGY MZ01-CE0 Manual de usuario

GIGA-BYTE TECHNOLOGY

GIGA-BYTE TECHNOLOGY GA-B150M-D3V Manual de usuario

GIGA-BYTE TECHNOLOGY

GIGA-BYTE TECHNOLOGY GA-Z270X-Gaming 5 Manual de usuario

GIGA-BYTE TECHNOLOGY

GIGA-BYTE TECHNOLOGY H270-F4G Manual de usuario

GIGA-BYTE TECHNOLOGY

GIGA-BYTE TECHNOLOGY R160-S34 Manual de usuario

GIGA-BYTE TECHNOLOGY

GIGA-BYTE TECHNOLOGY B650M C V2 Manual de usuario

GIGA-BYTE TECHNOLOGY

GIGA-BYTE TECHNOLOGY B660M DS3H AX DDR4 Manual de usuario

GIGA-BYTE TECHNOLOGY

GIGA-BYTE TECHNOLOGY GA-E3800N Manual de usuario

GIGA-BYTE TECHNOLOGY

GIGA-BYTE TECHNOLOGY GA-A320M-H Manual de usuario

GIGA-BYTE TECHNOLOGY

GIGA-BYTE TECHNOLOGY GA-H110M-WW Manual de usuario

GIGA-BYTE TECHNOLOGY

GIGA-BYTE TECHNOLOGY GIGABYTE GS-W42G-P08R Manual de usuario

GIGA-BYTE TECHNOLOGY

GIGA-BYTE TECHNOLOGY B550M AORUS PRO Manual de usuario

GIGA-BYTE TECHNOLOGY

GIGA-BYTE TECHNOLOGY GA-H110M-S2PV DDR3 Manual de usuario

GIGA-BYTE TECHNOLOGY

GIGA-BYTE TECHNOLOGY B550 GAMING X V2 Manual de usuario

Manuales populares de Placa madre de otras marcas

DFI

DFI SD170 Manual de usuario

ASROCK

ASROCK ROMED8-2T Manual de usuario

Asus

Asus P2L97A Manual de usuario

Winmate

Winmate IC70 Manual de usuario

Asus

Asus MES-B Manual de usuario

Grantech

Grantech SYS8F377VGGA-3OMN Manual de usuario

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Manual de usuario

Gigabyte

Gigabyte GA-9IVDT Manual de usuario

Texas Instruments

Texas Instruments ADS8372EVM Manual de usuario

Commell

Commell MS-C73 Manual de usuario

IBT Technologies

IBT Technologies MB860 Manual de usuario

Nvidia

Nvidia TEGRA DG-04927-001_V01 Manual de usuario

Biostar

Biostar M7VIT Bravo Instrucciones de funcionamiento e instalación

Intel

Intel D33217CK Manual de usuario

Asus

Asus F1A55-M LX PLUS R2.0 Manual de usuario

EPC

EPC EPC9147C Manual de usuario

Asus

Asus EX-B760M-V5 D4 Manual de usuario

EPOX

EPOX MU-8KHA0010 Manual de usuario
