Giant TCR COMPOSITE 1 Manual de usuario

TCR composite 1

Speciﬁcations and availability subject to change without notice.

Specifications

frame

SIZES XS,S,M,M/L,L,XL

COLOUR White / Black / Red

FRAME Composite

FORK Composite w/ OverDrive steerer

SHOCK N/A

componentS

HANDLEBAR Giant Connect SL 31.8mm

STEM Giant Connect SL

SEATPOST Giant Vector Advanced composite

SADDLE Giant Racing

PEDALS Not included

DriVetrain

SHIFTERS Shimano Ultegra

FRONT DERAILLEUR Shimano Ultegra

REAR DERAILLEUR Shimano Ultegra

BRAKES Shimano 105

BRAKE LEVERS Shimano Ultegra

CASSETTE Shimano 105 12-25T 10SPD

CHAIN Shimano 105

CRANKSET Shimano Ultegra 39/52T

BOTTOM BRACKET Shimano internal press ﬁt

WHeeLS

RIMS DT Swiss R 1900

HUBS DT Swiss

SPOKES DT Swiss

TIRES Michelin Dynamic 700x23c

EXTRAS

*Seat angle is actual

**Toptube is measured from the center of the headtube horizontally back to the top of the effective extension of the seattube

***Standover height is based on the largest size tire that will ﬁt the bike, not necessarily the included size tire

Actual

Frame Size Part

Number Head

Angle Seat

Angle* Toptube** Headtube Chainstay Wheelbase Standover

Height***

centimeters degrees degrees centimeters centimeters centimeters centimeters inches

XS 43.0 2115800 71.0 74.5 52.0 12.0 40.5 97.7 28.5

S 46.5 2115801 72.0 73.5 53.5 13.5 40.5 97.4 29.2

M 50.0 2115802 73.0 73.0 55.5 15.0 40.5 98.0 30.1

M/L 53.5 2115803 73.0 72.0 57.0 17.0 40.5 98.6 31.0

L 55.5 2115804 73.0 72.0 58.5 18.5 40.5 100.1 31.7

XL 58.5 2115805 73.0 72.0 60.5 20.0 40.5 102.1 32.4

frame geometry

Spec Features

— Complete Shimano Ultegra & 105 series component group

— Giant Connect SL handlebar & stem, Vector Advanced composite seatpost

— Wheelset: DT Swiss R 1900

A B C D E F G H

on-road | performance | Competition

CMYK / GREYSCALE APPLICATION

1 COLOR / SPOT APPLICATION

KNOCKOUT APPLICATION
