Ghent Prest Mobile Manual de usuario
1/4"-20 X 2" SCREWS WITH WASHERS
(PAGE 1 OF 2)
(2)
Leg
(4)
Caster
(4)
Brace
(1)
Accessory Holder
(6)
1/4-20 x 7/8"
(6)
1/4-20 x 2"
(12)
WASHER
(1)
ALLEN WRENCH
Step 2:
Install the casters on the legs.
Prest Mobile Whiteboard
Instruction Sheet
Step 1:
Remove and unpack the legs, casters, braces, and hardware kit from the packaging, leaving the
whiteboard intact inside the box.
www.ghent.com/install - Lebanon, OH 800-543-0550 IS-PREST (12/19)
(1)
Whiteboard
Step 3:
Install the leg on one side of the whiteboard.
3a. Use the cardboard as a protective work area as you place the whiteboard on its side
3b. Align the legs with the pre-drilled holes on the frame.
3c. Use the screws with washers to attach the legs to the frame, hand tighten with provided allen
wrench.
A
BRACES OVERLAP
1/4"-20 X 7/8" SCREWS WITH WASHERS
Step 5:
Repeat steps 3 and 4 for the opposite side.
Step 6:
Stand the unit upright and attach the accessory holder using the provided magnets.
Step 7:
Recycle all packaging materials in accordance to local regulations.
Step 4:
Install the braces.
4a. Use the screws with washers to attach braces.
4b. Re-tighten all screws with provided wrench.
www.ghent.com/install - Lebanon, OH 800-543-0550 IS-PREST(12/19)
(PAGE 2 OF 2)
