URN 2
Installation Instructions 810401-01
Power Supply Unit URN 2
2
Contents
Usage for the intended purpose ................................................................................... 5
Safety note.....................................................................................................................5
Danger........................................................................................................................... 5
Important Notes
Warning.........................................................................................................................11
Fault finding list .............................................................................................................11
Declaration of conformity..............................................................................................11
Annex
Page
Explanatory Notes
Scope of supply ..............................................................................................................6
System description .........................................................................................................6
Function ..........................................................................................................................6
Design.............................................................................................................................6
Technical data .................................................................................................................7
Design “c”/“d” .................................................................................................................8
Attention..........................................................................................................................8
Tools................................................................................................................................8
Installation
Wiring
Wiring diagram................................................................................................................9
Key to wiring diagram .....................................................................................................9
Attention..........................................................................................................................9
Warning.........................................................................................................................10
Check wiring .................................................................................................................10
Apply mains voltage......................................................................................................10
Check output voltage ....................................................................................................10
Commissioning
3
Dimensions/Parts Drawings
Fig. 1
Fig. 2
169
128.5
30.01(6TE)
C
B
A
4
32pole screw-type connector
LEDOPERATION
Fixing screws
Key
B
C
A
5
Important Notes
Usage for the intended purpose
Use power supply unit URN 2 only for the voltage supply of a maximum of four
switching controllers type NRS 2-4 or NRS 2-5 and the cycling timer PRS 9.
Danger
The terminal strip of the URN 2 is live during operation.This presents the
danger of electric shock. Cut off power supply before opening the
equipment and before inserting or removing the 19" slide-in unit.
Safety note
The equipment may only be installed by qualified staff.
Qualified staff are those persons who – through adequate training in electrical
engineering, the use and application of safety equipment in accordance
with regulations concerning electrical safety systems, and first aid & accident
prevention – have achieved a recognised level of competence appropriate to
the installation and commissioning of this critical safety device.
6
Explanatory Notes
Scope of supply
URN 2, design “c”
1 Power supply unit type URN 2
2 Guide rails
1 32pole screw-type connector
1 Installation manual
URN 2, design “d”
1 Power supply unit type URN 2
1 Installation manual
Function
The mains voltage is stepped down, rectified and provided as 24 V DC supply
voltage to the level switches NRS 2-4 and the cycling timer PRS 9.
System description
The power supply unit type URN 2 in combination with up to four level switches
types NRS 2-4 or NRS 2-5 and the cycling timer type PRS 9 can be used as part of
a controlled drainage system in power stations.
Design
Design “c”
19" slide-in unit with guide rails and 32pole screw-type connector for installation in
19" magazine acc. to DIN 41494, part 5.
Design “d”
19" spare slide-in unit
7
Technical data
Mains voltage
1115/230 V±10%, 50/60 Hz
1115/224 V±10%, 50/60 Hz (optional)
Power consumption
10 VA
Output
5x24 V DC
Indicator and adjustor
1 green LED OPERATION
Protection
IP 10 to DIN EN 60529
Admissible ambient temperature
0°C to +70°C
Case
19" slide-in unit with front panel to DIN 41494 part 5 and rear 32 way Euro card
connector to DIN 41612 for installation onto 19" magazine.
Front panel: Aluminium
Wiring
via 32 pole screw-type connector at the back of the 19" magazine, max. conductor
size 1.5 mm2.
Internal fuse
Glass cartridge fine-wire slow-blow fuse 500 mA, replaceable
Weight
approx. 0.6 kg
8
Attention
To provide sufficient ventilation, ensure a minimum spacing of 20 mm
between adjacent units.
Installation
Design “c”/“d”
1. Install the guide rails and the screw-type connector in the 19" magazine.
2. Insert the 19" slide-in unit onto the guide rails until it hits the stop.
3.Tighten the fixing screws .
C
Tools
■Screwdriver for slotted screws, size 5, completely insulated according to VDE 0680.
9
Key to wiring diagram
Test loop
Wiring
Wiring diagram
Design “c”/“d”
Wiring is effected via the 32 pole screw-type connector.
1
1
Fig. 3
Attention
■Fuse supply cable with T 250 mA.
■When switching off inductive loads, voltage spikes are produced that
may impair the operation of control systems.
Inductive loads should be provided with commercial arc suppressor
RC combinations, e.g. 0.1 µF/100.
10
Commissioning
Warning
The terminal strip of the URN 2 is live during operation.This presents the
danger of electric shock. Cut off power supply before opening the
equipment and before inserting or removing the 19" slide-in unit.
Check wiring
1. Check whether the 19" slide-in unit has been properly inserted into the magazine.
2. Check whether the equipment has been wired in conformity with the mains voltage.
Apply mains voltage
1. Switch on the mains voltage and check the equipment for power supply.The
LED functions as visual check.
B
Check output voltage
Check whether all five outputs feature an output voltage of 24 V DC.
