Gestetner AO70 Manual de usuario

Operating Instructions

Copy Reference

Read this manual carefully before you use this product and keep it handy for future

reference.

For safety, please follow the instructions in this manual.

DolphinGB-Copy-F_V4_FM.book Page 1 Monday, June 11, 2001 5:02 PM

Declaration of Conformity

“The Product complies with the requirements of the EMC Directive 89/336/EEC and the Low Voltage

Directive 73/23/EEC.”

In accordance with IEC 60417, this machine uses the following symbols for the main power switch:

ameans POWER ON.

cmeans STAND BY.

DolphinGB-Copy-F_V4_FM.book Page 1 Monday, June 11, 2001 5:02 PM

Introduction

This manual contains detailed instructions on the operation and maintenance of this machine. To get

maximum versatility from this machine all operators should carefully read and follow the instructions in

this manual. Please keep this manual in a handy place near the machine.

Please read the Safety Information before using this machine. It contains important information related

to USER SAFETY and PREVENTING EQUIPMENT PROBLEMS.

Notes

Some illustrations may be slightly different from your machine.

Certain options may not be available in some countries. For details, please contact your local dealer.

Operator Safety

This machine contains LED Arrey in scanner and writing units.

The machine is considered a class 1 LED device, safe for both office and EDP use.

Notes:

Two kinds of size notation are employed in this manual. With this machine refer to the metric version.

For good copy quality, Gestetner recommends that you use genuine Gestetner toner.

Gestetner shall not be responsible for any damage or expense that might result from the use of parts

other than genuine Gestetner parts in your Gestetner office product.

Power Source

220 - 240V, 50Hz/60Hz, 10A or more

Please be sure to connect the power cord to a power source as above. For details about power source,

see p.146 “Power Connection”.

Read this manual carefully before you use this product and keep it handy for future reference.

For safety, please follow the instructions in this manual.

DolphinGB-Copy-F_V4_FM.book Page 1 Monday, June 11, 2001 5:02 PM

Safety Information

When using your equipment, the following safety precautions should always be

followed.

Safety During Operation

In this manual, the following important symbols are used:

RWARNING:

WARNING:

Indicates a potentially hazardous situation which, if instructions

are not followed, could result in death or serious injury.

CAUTION:

Indicates a potentially hazardous situation which, if instructions are not

followed, may result in minor or moderate injury or damage to property.

•Connect the power cord directly into a wall outlet and never use an ex-

tension cord.

•Disconnect the power plug (by pulling the plug, not the cable) if the

power cable or plug becomes frayed or otherwise damaged.

•To avoid hazardous electric shock or laser radiation exposure, do not

remove any covers or screws other than those specified in this manu-

al.

•Turn off the power and disconnect the power plug (by pulling the plug,

not the cable) if any of the following conditions exists:

•You spill something into the equipment.

•You suspect that your equipment needs service or repair.

•Your equipment's cover has been damaged.

•Do not incinerate spilled toner or used toner. Toner dust might ignite

when exposed to an open flame.

•Disposal can take place at our authorized dealer or at appropriate col-

lection sites.

•Dispose of the used toner cartridge in accordance with the local regu-

lation.

DolphinGB-Copy-F_V4_FM.book Page i Monday, June 11, 2001 5:02 PM

RCAUTION:

•Protect the equipment from dampness or wet weather, such as rain, snow,

and so on.

•Unplug the power cord from the wall outlet before you move the equipment.

While moving the equipment, you should take care that the power cord will

not be damaged under the equipment.

•When you disconnect the power plug from the wall outlet, always pull the

plug (not the cable).

•Do not allow paper clips, staples, or other small metallic objects to fall inside

the equipment.

•Keep toner (used or unused) and toner bottle out of the reach of children.

•For environmental reasons, do not dispose of the equipment or expended

supply waste at household waste collection points. Disposal can take place

at an authorized dealer or at appropriate collection sites.

•The inside of the machine could be very hot. Do not touch the parts with a

label indicating the “hot surface”. Otherwise it could cause a personal burn.

•Our products are engineered to meet high standards of quality and function-

ality, and we recommend that you only use the expendable supplies availa-

ble at an authorized dealer.

DolphinGB-Copy-F_V4_FM.book Page ii Monday, June 11, 2001 5:02 PM

iii

Warnings and Precautions

This manual uses the following warning and precaution symbols to indicate im-

portant safety information.

When adding paper or clearing paper jams, be careful not to burn or injure your-

self.

1 Hot Surface Warning

ZEDH280E

ZEDH290E

DolphinGB-Copy-F_V4_FM.book Page iii Monday, June 11, 2001 5:02 PM

This symbol indicates that you should take care not to touch a hot surface. The

fusing unit becomes hot. Be careful not to touch this area when clearing paper

jams.

2 Cutter Blade Warning

This label indicates that there is a cutter blade inside, and you should be careful

not to touch this area with your fingers or hands. Be careful not to touch this area

when adding paper.

3 Feed Roller Warning Label

This label indicates that you should be careful not get your fingers or cloths

caught in the feed roller. When replacing the paper roll, or clearing paper jams

in the paper feed area, be careful so that your hand or clothing does not get

caught in the feed roller.

ZEDH300E

ZEDH310E

DolphinGB-Copy-F_V4_FM.book Page iv Monday, June 11, 2001 5:02 PM

How to Read this Manual

Symbols

In this manual, the following symbols are used:

WARNING:

This symbol indicates a potentially hazardous situation that might result in

death or serious injury when you misuse the machine without following the in-

structions under this symbol. Be sure to read the instructions, all of which are de-

scribed in the Safety Information section.

CAUTION:

This symbol indicates a potentially hazardous situation that might result in mi-

nor or moderate injury or property damage that does not involve personal injury

when you misuse the machine without following the instructions under this

symbol. Be sure to read the instructions, all of which are described in the Safety

Information section.

* The statements above are notes for your safety.

Important

If this instruction is not followed, paper might be misfed, originals might be

damaged, or data might be lost. Be sure to read this.

Preparation

This symbol indicates the prior knowledge or preparations required before op-

erating.

Note

This symbol indicates precautions for operation, or actions to take after misop-

eration.

Limitation

This symbol indicates numerical limits, functions that cannot be used together,

or conditions in which a particular function cannot be used.

Reference

This symbol indicates a reference.

[]

Keys that appear on the machine's panel display.

{}

Keys built into the machine's operation panel.

DolphinGB-Copy-F_V4_FM.book Page v Monday, June 11, 2001 5:02 PM

Terms in this Manual

Guide To Option Components

In this manual, the following abbreviations are used.

• Roll Holder Unit Type A →Roll holder

• 2nd Roll Tray Type A →Lower tray

•StampBoardTypeA→Stamp board

• Original Tray Type G →Original Tray

• Hard Disk Drive Option Type 470 →HDD

Terms

• Long length original/paper

Original/paper length longer than 1,189mm, 44".

Key Names

In the screen and panel display, the following abbreviation are used.

• Direct Size Magnification →D. Size Mag.

•HardTone→H.T.

• Horizontal →Horiz.

•Magnification→Mag.

• Original →Orig.

•Preview→Prev.

• Reduce/Enlarge →R/E

•Vertical→Vert.

DolphinGB-Copy-F_V4_FM.book Page vi Monday, June 11, 2001 5:02 PM
