GeoVision GV-BX320D-0 Manual de usuario

GV-BX320D-0/320D-1 January 28, 2013

- 1 -

GV-BX320D-0 / 320D-1 3MP H.264 D/N Box IP Camera



•3megapixelprogressivescanCMOS

•DualstreamsfromH.264andMJPEG

•Upto20fpsat2048x1536,30fpsat1920x1080

•Built‐in/externalmicrophone

•2‐wayaudio

•Onesensorinputandalarmoutput

•TV‐outsupport

•Memorycardslot

•WideDynamicRange(WDR)

•Motiondetection

•Tamperingalarm

•Privacymask

•IPaddressfiltering

•DC12V/PoE

•RemovableIR‐cutfilterforDay/Nightfunction

•Varifocalmegapixellens

•SupportsiPhone,iPad,Android&3GPP

•31languagesonWebinterface

•ONVIFconformant

*NoMemorycardslot&localstoragefunctionforArgentina.

Models

ModelsIris FocalLength(mm) MaximumAperture ImageFormat

GV‐BX320D‐03.1~8mmF/1.2

GV‐BX320D‐1DCDrive2.8~6mmF/1.31/3”

ActiveTamperingAlarm

TamperedFocusChangeCameraShift



Dimensions

GV-BX320D-0/320D-1 January 28, 2013

- 2 -

Specifications

GV‐BX320D‐0GV‐BX230D‐1

Camera

ImageSensor1/2.5"progressivescanCMOS

PictureElements2048(H)x1536(V)

Color 1Lux(1/30sec),0.5Lux(1/5sec)

B/W0.2Lux(1/30sec),0.1Lux(1/5sec)

Minimum

Illumination

IRON 0Lux

ShutterSpeedAutomatic,Manual(1/5~1/8000sec)

WhiteBalanceAutomatic,Manual(2800K~8500K)

GainControlAutomatic

S/NRatio45dB

BLCYes

Lens

MegapixelYes

Day/NightYes(withremovableIR‐cutfilter)

LensTypeVarifocal

FocalLength3.1~8mm2.8~6mm

MaximumApertureF/1.2F/1.3

MountCSMount

ImageFormat1/3"

FocusManual(w/lock)

ZoomManual(w/lock)

Operation

IrisDCdrive

Max.Torque(Focus/ZoomScrews)0.049N.m

Operation

VideoCompressionH.264,MJPEG

VideoStreamDualstreamsfromH.264andMJPEG

FrameRate

20fpsat2048x1536,30fpsat1920x1080

*Theframerateandtheperformancemayvarydependingonthenumberofconnectionsanddata

bitrates(differentscenes).

ImageSettingBrightness,Contrast,Sharpness,Gamma,WhiteBalance,Flicker‐less,ImageOrientation,ShutterSpeed,

D/NSensitivity,BacklightCompensation,WDR,Defog

AudioCompressionG.711,AAC(16kHz/16bit)

*AACisonlysupportedbyGV‐SystemV8.5orlater

Two‐wayAudioYes

SensorInput1Input(DryContact)

AlarmOutput1DigitalOutput(200mA5VDC)

VideoResolution

4:32048x1536,1600x1200,1280x960,640x480,320x240

16:91920x1080,1280x720,640x360,448x252

MainStream

5:41280x1024,640x512,320x256

4:3640x480,320x240

16:9640x360,448x252

SubStream

5:4640x512,320x256

Network

Interface10/100Ethernet

EthernetProtocolHTTP,HTTPS,TCP,UDP,SMTP,FTP,DHCP,NTP,UPnP,DynDNS,3GPP/ISMA,RTSP,PSIA,SNMP,QoS

(DSCP),ONVIF

Mechanical

Power2‐pinterminalblock,PoE

Ethernet RJ‐45

Audio 1In(Usingthebuilt‐inmicrophoneorexternallyconnectingamicrophone)

1Out(Stereophonejack,3.5mm/0.14in)

DigitalI/O 3‐pinterminalblock,pitch2.5mm/0.1in

AutoIris DCdrive

LocalStorageMicroSD/SDHC/SDXCmemorycardslot(forClass6cardorabove)

Connectors

TV‐Out BNCconnector(640x480resolution)

LEDIndicator2LEDs:Power,Status



GV-BX320D-0/320D-1 January 28, 2013

- 3 -



General

EnvironmentTemperature 0°C~50°C/32°F~122°F

Humidity 10%to90%(nocondensation)

PowerSource 12VDC/PoE

Max.PowerConsumption 7W

Regulatory CE,FCC,C‐Tick,RoHScompliant

Dimension(LXWXH) 76x74.9x54.3mm/2.99x2.95x2.14in(withoutlens)

Weight 321g/0.71lb

PoweroverEthernet

PoEStandard IEEE802.3afPoweroverEthernet/PSE

PoEPowerSupplyType End‐Span

PoEPowerOutput PerPort48VDC,350mA.Max.15.4watts

WebInterface

InstallationManagement Web‐basedconfiguration

MaintenanceFirmwareupgradethroughWebBrowser

AccessfromWebBrowser

Cameraliveview,videorecording,changevideoquality,bandwidthcontrol,imagesnapshot,digitalI/O

control,audio,PictureinPicture,PictureandPicture,PrivacyMask,VisualAutomation,TamperingAlarm,

TextOverlay

Language

Arabic/Bulgarian/Czech/Danish/Dutch/English/Finnish/French/German/Greek/Hebrew/

Hungarian/Indonesian/Italian/Japanese/Lithuanian/Norwegian/Persian/Polish/Portuguese/

Romanian/Russian/Serbian/SimplifiedChinese/Slovakian/Slovenian/Spanish/Swedish/Thai/

TraditionalChinese/Turkish

Applications

NetworkStorageGV‐NVR,GV‐System,GV‐BackupCenter,GV‐RecordingServer

SmartDeviceAccessGV‐EyeforAndroidsmartphone,tablet,iPhone,andiPodTouch

GV‐EyeHDforiPad

LiveViewingIE,mobilephone

CMSServersupport GV‐ControlCenter,GV‐CenterV2,GV‐VSM

Note:Specificationsaresubjecttochangewithoutnotice.



Accessories

Name  Details

GV‐IRLEDT2



Weight:140g/0.31lbs

Dimensions(HxWxD):49x47x67mm/1.93x1.85x2.64in

GV‐PA191PoEAdapter



Weight:130g/0.29lb

Dimensions(HxWxD):43x69x40mm/1.69x2.72x1.57in

GV‐RelayV2



TheGV‐RelayV2isdesignedtoexpandthevoltageloadofGVIP

devices.Itprovides4relayoutputs,andeachcanbesetas

normallyopen(NO)ornormallyclosed(NC)independentlyas

peryourrequirement.

PowerAdapterPoweradaptersareavailablein4regions:U.S.A.,Australia,U.K

andEurope.
