George Foreman GRP5842 Instrucciones de instalación

USA/Canada 1-800-231-9786

www.prodprotect.com/applica

Accessories/Parts (USA/Canada)

Accesorios/Partes (EE.UU/Canadá)

1-800-738-0245

Please Read and Save this Use and Care Book

Por favor lea este instructivo antes de usar el producto

Model

Modelo

GRP5842

IMPORTANT SAFEGUARDS

When using electrical appliances, basic safety precautions should always be

followed, including the following:

❑Read all instructions.

❑Do not touch hot surfaces. Use handles or knobs.

❑To protect against electrical shock do not immerse cord, plugs or appliance in

water or other liquid.

❑Close supervision is necessary when any appliance is used by or near

children.

❑Unplug from outlet when not in use and before cleaning. Allow to cool before

putting on or taking off parts.

❑Do not operate any appliance with a damaged cord or plug, or after the

appliance malfunctions or has been damaged in any manner. Return

appliance to the nearest authorized service facility for examination, repair

or adjustment. Or, call the appropriate toll-free number on the cover of this

manual.

❑The use of accessory attachments not recommended by the appliance

manufacturer may cause injuries.

❑Do not use outdoors.

❑Do not let cord hang over edge of table or counter, or touch hot surfaces.

❑Do not place on or near a hot gas or electric burner, or in a heated oven.

❑Extreme caution must be used when moving an appliance containing hot oil or

other hot liquids.

❑To disconnect, turn any control to OFF, then remove plug from wall outlet.

❑Do not use this appliance for other than intended use.

SAVE THESE INSTRUCTIONS.

This product is for household use only.

POLARIZED PLUG (USA/Mexico)

This appliance has a polarized plug (one blade is wider than the other). To reduce

the risk of electric shock, this plug is intended to fit into a polarized outlet only

one way. If the plug does not fit fully into the outlet, reverse the plug. If it still

does not fit, contact a qualified electrician. Do not attempt to modify the plug in

any way.

GROUNDED PLUG (Canada models only)

As a safety feature, this product is equipped with a grounded plug, which will

only fit into a three-prong outlet. Do not attempt to defeat this safety feature.

Improper connection of the grounding conductor may result in the risk of electric

shock. Consult a qualified electrician if you are in doubt as to whether the outlet

is properly grounded.

TAMPER-RESISTANT SCREW

Warning: This appliance is equipped with a tamper-resistant screw to prevent

removal of the outer cover. To reduce the risk of fire or electric shock, do not

attempt to remove the outer cover. There are no user-serviceable parts inside.

Repair should be done only by authorized service personnel.

ELECTRICAL CORD

a) A short power-supply cord (or detachable power-supply cord) is to be

provided to reduce the risk resulting from becoming entangled in or tripping

over a longer cord.

b) Longer detachable power-supply cords or extension cords are available and

may be used if care is exercised in their use.

c) If a long detachable power-supply cord or extension cord is used,

1) The marked electrical rating of the detachable power-supply cord

or extension cord should be at least as great as the electrical

rating of the appliance,

2) If the appliance is of the grounded type, the extension cord should

be a grounding-type 3-wire cord, and

3) The longer cord should be arranged so that it will not drape over

the countertop or tabletop where it can be pulled on by children

or tripped over.

Note: If the power supply cord is damaged, it should be replaced by qualified

personnel. In Latin America, by an authorized service center.

Product may vary slightly from what is illustrated.

Integrated handle

†

2. Grill plate (upper) (Part # GRP5842-03)

3. Grill plate release handles (both sides)

†

4. Grill plate (lower) (Part # GRP5842-04)

5. Adjustable grill angle switch

6. Power cord (not shown)

†

7. Drip tray (Part # GRP5842-01)

†

8. Spatula (Part # GRP5842-02)

† Consumer replaceable/removable parts

Up/down selection

2. Sear button

3. Temp/Timer selector

4. Power button

5. Time display

6. Temp display

(

Plate Included Part #

1. Traditional grill plate 1 GRP5842-03

2. Cross-hatch grill plate 1 GRP5842-04

3. Waffle plate (upper) 1 GRP5842-05

4. Waffle plate (lower) 1 GRP5842-06

5. Deep dish bake plate 1 GRP5842-07

#/$

How to use:

This product is for household use only.

GETTING STARTED

s 2EMOVEALLPACKINGMATERIALANDANYSTICKERS

s 2EMOVEANDSAVELITERATURE

s 7ASHDRIPTRAYASINSTRUCTEDIN#!2%!.$#,%!.).'SECTIONOFTHISMANUAL

s 7IPEGRILLPLATESWITHADAMPCLOTHORSPONGETOREMOVEANYDUST7IPEDRY

with a soft cloth or paper towels.

s 3ELECTLOCATIONWHEREUNITISTOBEUSEDLEAVINGENOUGHSPACEBETWEENBACK

of unit and wall to allow heat to ﬂow without damage to cabinets and walls.

ATTACH GRILL PLATES

Important: This appliance should always be used with 2 grill plates securely

attached.

Ceramic Grill Plates (See illustration A3)

1. Securely attach top and bottom grill plates using

release handles on sides of plates (B and C).

Important: When using these grill plates, use grill

slope adjustment knob at bottom right rear of grill to

lift back of bottom grill plate and have drippings run

into drip tray. (D)

Caution: This position should only be used when grilling.

2. Place drip tray under front sloped section of bottom

plate on grill.

Wafﬂe plates

(See illustration A3)

Important: When using these plates, make sure bottom grill plate is in a

completely horizontal position (see illustation D, pg 5).

1. When baking wafﬂes, securely attach top and bottom wafﬂe plates using

release handles on sides of plates.

2. Set temperature at 425º F and allow grill to preheat for at least 5 minutes.

3. Wafﬂes take about 8 minutes to cook to golden brown.

Deep baking pan

(See illustration A3)

Important: When using this plate, make sure the grill is in a completely horizontal

position (see illustation D, pg 5).

1. If using deep baking pan, securely attach top grill plate to top of grill and

securely attach ﬁlled deep baking pan to bottom of grill using release handles

on sides of plates.

2. When ﬁnished baking in deep baking pan use pot holders to remove pan to wire

rack.

Important: When attaching the plates, be sure they are securely attached using

release handles on sides of plates.

Suggestions for using deep baking pan:

s Brownies: set temperature at 350º F and bake for 25 minutes or until tests done

s Cornbread: set temperature at 350º F and bake 20 minutes.

s Focaccia: see recipe on page 15.

s Lasagna: see recipe on page 16.

s Chicken or ﬁsh in cream sauce: set temperature at 350º F and bake for 25

minutes or until tests done.

s Beef with vegetables in gravy: brown beef in deep dish pan at 400º F; add

remaining ingredients and reduce temperature to 300º F; cook until meat and

vegetables are tender.

PREHEATING THE GRILL:

1. Close lid on grill.

2. Unwind cord and plug it into standard electrical outlet. LCD display will show

dashes where time and temperature will be displayed.

3. Press POWER to turn grill on; 5 minutes will appear on timer display and

300º F will appear ﬂashing on temperature display.

4. To adjust the desired cooking time, press the "TEMP/TIMER" function button.

The "TEMP/TIMER" allows you to toggle between the two functions to adjust

desired grill settings.

5. Time can be changed at any time in one-minute increments by tapping or

repeatedly. Minimum cooking time is 1 minute; maximum is 20 minutes.

6. Set desired temperature by tapping repeatedly to select desired

temperature. Temperature changes in 25° increments. Temperature settings

RANGEFROM&TO&3%!2MAYALSOBESELECTEDSEE3%!2).'

7. Carefully place foods to be cooked on bottom grill plate. This grill usually

accommodates 2 to 4 servings.

Note: Do not overload the grill.

8. Close lid and allow food to cook for desired time.

Note:5SESUGGESTEDCOOKINGTIMESFOUNDIN'2),,).'#(!24ONPAGE

!FTERSELECTEDCOOKINGTIMEFOODSHOULDBEDONE

10. Using pot holder or oven mitts carefully open lid.

11. Remove cooked food using plastic spatula provided.

12. When ﬁnished cooking, press POWER and unplug grill.

Important: Heat continues to be ON until the power button is turned off or the grill

is unplugged.

Note: Always use heatproof plastic, nylon or wood utensils to avoid scratching

NONSTICKSURFACEOFGRILLPLATES.EVERUSEMETALSKEWERSTONGSFORKSORKNIVES

SEARING:

Pressing "SEAR" will enable the red LED button to become visible and

automatically set the highest temperature (500º F) for a duration of time.

In order to properly sear, make sure the surface of your meal is free of water. If

you choose to sear before grilling, place your food on the grill, then press the sear

button. The grill will heat up to 500º F. Do not touch the grill during searing. The

SEARINGWILLLASTFORSECONDS7HENSEARINGISOVERTEMPERATUREWILLDEFAULTTO

previously selected temperature. Continue with normal grilling instructions.

GRILLING MEAT, POULTRY, FISH AND SANDWICHES:

In this position, grill plate rests on top of food.

When grilling meats, poultry and ﬁsh, use switch at bottom right rear of the grill

to lift back of bottom grill plate and have drippings run into drip tray.

(See illustration D.)

When grilling sandwiches, tilt bottom grill plate to horizontal position.

3ELECTTIMEANDTEMPERATUREDESIREDFOLLOWINGDIRECTIONSIN02%(%!4).'

GRILL. Allow time for preheating grill.

2. Before ﬁrst use, if desired, lightly oil grill plates.

Note: Aerosol cooking spray should not be used on ceramic or nonstick surface.

Chemicals that allow spray to come out of can build up on surface of grill plates

and reduce their efﬁciency.

3. Carefully place foods to be cooked on bottom grill plate of preheated grill.

This grill usually accommodates 2 to 4 servings.

Note: Do not overload grill plate.

4. Close lid, closing it directly onto food.

Note:5SESUGGESTEDCOOKINGTIMESFOUNDIN'2),,).'#(!24ONPAGE

5. Allow food to cook for selected time.

Important: Do not leave the appliance unattended during use.

6. During cooking, timer display will count down. When selected time has

elapsed, grill will give audible signal. Grill will remain on until it is unplugged.

7. After selected time, food should be done. If you would prefer longer cooking,

simply follow steps beginning at step 4.

8. Using pot holder, carefully open lid.

2EMOVECOOKEDFOODUSINGPLASTICSPATULAPROVIDED

Note: Always use heatproof plastic, nylon or wood utensils to avoid scratching

NONSTICKSURFACEOFGRILLPLATES.EVERUSEMETALSKEWERSTONGSFORKSORKNIVES

10. Press POWER to turn off and unplug grill.

Caution: To avoid sparks at outlet while disconnecting plug, make sure power is

off before disconnecting plug from outlet.

11. Allow drip tray to cool before removing from under grill. Wash and dry the

drip tray after each use.

Note: Be sure liquid in drip tray has cooled.

Caution: Do not remove grill plates while grill is hot. Always allow them to cool

to room temperature before removing or cleaning.



SUGGESTED GRILLING CHART FOR MEATS,

POULTRY, FISH AND SANDWICHES

The following are meant to be used as a guideline only. Times reﬂect full grill of

food. Cooking time will depend upon thickness and cut being used. Use cooking

thermometer as test for doneness. If food needs longer cooking, check periodically

to avoid overcooking food.

FOOD COOKING TIME COMMENTS

MEAT

(AMBURGEROZ nMINUTES ÐINCHTHICK

Cooked to medium (160ºF)

&ROZENHAMBURGERSOZ nMINUTES #OOKEDTOMEDIUM&

&LANKSTEAKÐLB nMINUTES ÐINCHTHICK

Cooked to medium rare (145ºF)

3KIRTSTEAKLB nMINUTES #OOKEDTOMEDIUM&

.9STRIPSTEAK nMINUTES ÐINCHTHICK

(shell steak) (6 oz.) Cooked to medium rare (145ºF)

"EEFTENDERLOINOZ nMINUTES ÐINCHTHICK

Cooked to medium rare (145ºF)

"EEFKABOBS nMINUTES #OOKEDTOMEDIUM&

0ORKLOINCHOPSBONELESS nMINUTES ÐINCHTHICK

Cooked to 160ºF

0ORKLOINCHOPSBONEIN nMINUTES INCHTHICK

Cooked to 160ºF

3AUSAGELINKORPATTY nMINUTES #OOKEDTO&

(OTDOGS nMINUTES #OOKEDTO&

"ACON nMINUTES

3MOKEDPORKLOINCHOPSnMINUTES #OOKEDTO&

boneless

,AMBCHOPSLOIN nMINUTES ÐINCHTHICK

Cooked to medium (160ºF)

Tabla de contenidos

Idiomas:

Otros manuales de Parrilla de George Foreman

George Foreman

George Foreman GFF2021 Guía de instalación

George Foreman

George Foreman GRP4 Manual de usuario

George Foreman

George Foreman GLP80VB Manual de usuario

George Foreman

George Foreman GBZ6BW127V Manual de usuario

George Foreman

George Foreman Big George GGR50 Manual de usuario

George Foreman

George Foreman The Next Grilleration Super Champ GRP3 Instrucciones de instalación

George Foreman

George Foreman GFPTBBQ1005B Manual de usuario

George Foreman

George Foreman GR18870AU Guía de instalación

George Foreman

George Foreman GR0080 Manual de usuario

George Foreman

George Foreman Evolve grill GFP84SP Manual de usuario

George Foreman

George Foreman GR35SBTMR Manual de usuario

George Foreman

George Foreman GR10 Manual de usuario

George Foreman

George Foreman GFSBBQ1 Guía de mantenimiento y servicio

George Foreman

George Foreman GR1036BTR Manual de usuario

George Foreman

George Foreman GR44VTCAN Manual de usuario

George Foreman

George Foreman GR2060 Manual de usuario

George Foreman

George Foreman GBZ201RCDS Manual de usuario

George Foreman

George Foreman Evolve grill GFP84MP Manual de usuario

George Foreman

George Foreman GBZ236CTP Manual de usuario

George Foreman

George Foreman GRP4842 Manual de usuario

George Foreman

George Foreman GFD3021 Manual de usuario

George Foreman

George Foreman GR144 Grand Champ Manual de usuario

George Foreman

George Foreman Power Grill GRP101CTG Instrucciones de instalación

George Foreman

George Foreman GR0060W Super Champ Power Press Manual de usuario

Manuales populares de Parrilla de otras marcas

Orbegozo

Orbegozo GR 2300 Manual de usuario

bora

bora PT11 Manual de usuario

Klarstein

Klarstein 10031664 Manual de usuario

Garland

Garland MWE3W Manual de usuario

Char-Broil

Char-Broil 463722714 Manual de usuario

Nexgrill

Nexgrill 720-0830HK Manual de usuario

Kenmore

Kenmore 415.16123800 Manual de usuario

Camp Chef

Camp Chef PG24CLAU Manual de usuario

Tucker Barbecues

Tucker Barbecues GTR Series Instrucciones de montaje

Monogram

Monogram ZGG540NCP1SS Manual de usuario

Equipex

Equipex Sodir Savoy Manual de usuario

Gaggenau

Gaggenau VR 414 610 Manual de usuario

Miele

Miele KM 408-1 Manual de usuario

AOG

AOG T series Manual de usuario

Gorenje

Gorenje TG2000CB Manual de instrucciones

Weber

Weber Genesis Silver-B Permamount NG 051701 Manual de usuario

Glen

Glen SA 3037 Manual de usuario

Stalgast

Stalgast 9730100 Manual de usuario
