USER MANUAL
Genmitsu
Benutzerhandbuch
Contents / Inhalt
English
Deutsch
01 - 09
10 - 18
3040 Aluminium Spoilboard
für Y-Achsen Erweitungskit der 3018er Serie
3040 Aluminium-Arbeitsplatte
for 3018 Y-axis Extension Kit
Contents
Package List
Installation
Step 1
Step 2
Step 3
Step 4
Step 5
Step 6
Step 7
Assembly Overview
01
02
02
03
04
05
06
07
08
09
01
Package List
MDF Connecting Plate,
300*360*9mm
Aluminum Profile,
300*180mm
1 2
23×T-nuts, M6
511×Hexagon Socket
Screw, M6*22mm
613×Hexagon Socket Screw
with Flat Head, M6*18mm
7
Limt Switch Cable
Y LIM-, 3pin 1m
10
Install Positioning Tool
8Plastic Spacer
9
Allen Wrench, 4mm
3
Allen Wrench, 5mm
4
Preparation before assemble:
1. Turn off the power supply.Disconnect and remove the Y-axis stepper motor cable and Y-axis limit switch cable.
2. Please wear gloves before operation.
02
Installation
Step 1: Disassemble the Acrylic Baffles and X aixs / Z axis Gantry
03
Installation
Step 2: Y axis Base Disassembly
①Remove the Stock Side Profiles, Guide Rails and Lead Screw on both sides of the machine.
②Remove the Aluminum Profile, Sliders and Nut Seat, putting them aside for later use.
Left Profile
Right Profile
Y axis Lead Screw
04
Installation
Step 3: Assemble the 3040 Upgraded Accessories
①Assemble two 3040 Guide Rails and 4 Sliders.
②Assemble 3040 Lead Screw and Nut Seat.
③ Assemble the Left and Right Side Profiles.
Right Profile
Nut Seat
3040 Guide Rail
Slider
Left Profile
3040 Lead Screw
M6 T-Nuts
Positioning Tool
Aluminum Profile
05
Installation
Step 4: T-Nuts Positioning
①Place the original and new aluminum beds on a flat table as shown in the image below.
②Use the positioning tool to place the T-nuts to the desired position.
06
Installation
Step 5: Connecting two Aluminum Profiles
①Place the MDF Board on Top of the Two Aluminum Beds so that the Holes Overlap with the T-Nuts from Step 4.
②Use M6*18 Hexagon Socket Screw with Flat Head to fix the Aluminum Beds and MDF Board.
M6 *18 Hexagon Socket
Screw with Flat Head
M6 *22 Hexagon Socket
Screw with Flat Head
Plastic Spacer
MDF Connecting Plate
Aluminum Profile
Slider
07
Installation
Step 6: Assemble the 3040 Platform
①Align the through holes on the Sliders and Nut Seat on the 3040 platform with the corresponding holes on the MDF Spoilboard
and Plastic Spacer to make them concentric. Please note that Plastic Spacer should be placed between the Nut Seat, Sliders
and the MDF Spoilboard.
②Use M6*25 Hexagon Socket Screw with Flat Head and M6 locknuts to fix it.
120mm
08
Installation
Step 7: Assemble the original X aixs / Z axis Gantry
①Rotate the Lead Screw to check whether the Bed assembly moves smoothly along the Y Axis. If there is any abnormality, you need
to adjust till it can move smoothly.
②Install the original X aixs / Z axis Gantry. The distance between the gantry and the end of the Y axis should be 120mm, as shown in
the image below.
